Intrusion Styles

1
Intrusion Styles
2
Updates/questions?

• Things to turn in
• Questions?

3
Intrusions

• Todays Topic
• 1. Question of the Day
• 2. Intrusive styles
• Dikessupply line
• Othermostly storage

http//www.nobleworksinc.net/licensing/albums/ cal
endar-office-mccoy/devil_telemarketer.jpg
4
Question of the Day

5
Intrusions
Skinner Porter, 1995
6
http//www.geology.um.maine.edu/geodynamics/ Analo
gWebsite/Projects2005/Naus_Thijssen_2005/ html/bac
kground1.html
Dikes
Rubin, 1995
Skinner Porter
7
Dikes transport (Hawaii)
Horizontal
Feeders (vertical)
8
Dikes rift zones
Rubin, 1990
9
Dike propagation off-rift
Rubin, 1990
10
Dike propagation (Etna)
Aloisi et al., 2006
11
Dike propagation (Hawaii)
Rubin et al., 1998
12
http//www.es.ucsc.edu/afisher/ People/Images/EG-
Sheeted dikes
http//www-odp.tamu.edu/ publications/206_IR/chap_
01/ images/01_f05.jpg
13
More dikes
14
Cone sheets
Ancochea et al., 2003
15
Cone sheets 2
16
Ring dikes
Sparks, 1988
17
Ring dikes 2
Adapted from www.webdesign.org/img_articles/1074/c
18
Giant dike swarms
Baragar et al., 1996
Mantleplumes.org adapted from Baragar et al.,
1996
19
Giant dike swarms 2
Mantleplumes.org adapted from Ernst Buchan,
2001
20
Sills
www.rosssea.info/geology.html
http//community.iexplore.com/ advancedSearch/defa
ult.asp? searchTypephotoslocation Isle20Of20S
kye20 locationID1779
21
Ferrar
Elliottt Fleming, 2000
22
Batholiths
Wikipedia
23
Batholiths 2
bio-geo-terms.blogspot.com/ 2007/02/batholith.html
www.bates.edu/acad/depts/geology/jcreasy.WM.html
24
Laccoliths
Jackson Pollard, 1988
25
Stocks
Skinner Porter, 1995
Nabelek et al., 1984
