Components of Image Quality

1
Components of Image Quality Radiographic
Artifacts

• Radiologic Technology A
• Spring 2009

2

• X-ray Exposure Factors
• Radiographic Density Contrast
• Components of Image Quality
• Radiographic Artifacts

3
Review Chapter 7

• Primary radiation exits the tube
• Interacts with various densities in the body
• Photons may be absorbed
• Scattered
• Passed through without any interference to the
  cassette or image receptor (IR)

4
(No Transcript)
5
How well we can see something on the image
6
Image detail is affected byPhotographic
propertiesand Geometric properties
7
Photographic Properties

• Contrast
• Density

8
X-ray Exposure Factors

• TECHNIQUE SELECTION
• Radiographer selects the
• Kilovoltage peak (kVp)
• Milliamperage (mA) time (s)
• Milliamperage x time mAs
• (milliamperage multiplied by a set time
  measured in seconds)

9
Kilovoltage Peak

• kVp
• One kilovolt 1000 volts
• The amount of voltage selected for the x-ray
  tube.
• Range 30 to 150 kVp
• kVp controls __________ ?

10
Milliamperage

• One milliampere (mA) one thousandth of an
  ampere.
• The amount of current supplied to the x-ray tube
• How many x-rays will be produced
• Range 10 to 1200 mA

11
Time

• In seconds
• How long x-rays will be produced
• 0.001 to 6 seconds

12
Milliampere Seconds

• Technologists think in terms of mAs
• Calculated by mA x seconds
• Ex 100mA X 0.2s 20 mAs
• How many x-rays will be produced and for how
  long.
• Modern x-ray machines only allow control of
• mAs controls _______________ ?

13
Factors Affecting Density

• Primary control factor
• mA
• Time (seconds)
• Influencing factors
• kVp
• Grids
• Beam restriction
• Body structures (size of pt, pathology
• Processing
• SID OID
• Film Screen combinations

14
Primary Controlling Factor of Density

• mAs
• mA AMOUNT of electrons sent across the tube
  combined with TIME (S) mAs
• mAs controls DENSITY on radiograph primary
  function of mAs is DENSITY

15
Imagine this

• If the mA station is changed from 200 to 400 mA,
  twice as many electrons will flow from the
  cathode to the anode.
• From 10 mA to 1000 mA 100 x more
• mA controls how many electrons are coming at the
  target
• mAs is a combination of how many and for how long
  (seconds)

16
10 mA
1000 mA
17
(No Transcript)
18
Changing Mas Changes Density
25
50 mas
19
Influencing Factor on DensitykVp
20
??? kVp more energy more photons passing though
tissue striking the image

• 15 kVp doubling of exposure to the film
• ? 15 kVp halving of exposure to the film
• 15 rule will also change the contrast of the
  image because kV is the primary method of
  changing image contrast.
• Remember
• 15 change ( ??) KVP has the same effect as
  doubling or ½ the MAS on density

21
Change in kVp

• kVp controls the energy level of the electrons
  and subsequently the energy of the x-ray photons.
• A change from 72 kVp will produce
• x-rays with a lower energy than at
• 82 kVp
• Difference between a ball traveling 72 mph and 82
  mph (how much energy did it take to throw the
  ball at the rates?)

22
15 kvp - 15 kvp
This will also influence the density on the image
Increasing kVp increase energy reaching the IR
23
Radiolucent vs. Radiopaque

• Radiolucent materials allow x-ray photons to pass
  through easily (soft tissue).
• Radiopaque materials are not easily penetrated by
  x-rays (bones)

24
Creating the Image

• Transmission (no interaction)
• Responsible for dark areas
• Scatter (grays) produces no diagnostic info
• Absorption (photoelectric effect)
• Responsible for light areas

25
Images

• DENSITY THE AMOUNT OF BLACKENING DARKNESS ON
  THE RADIOGRAPH (mAs)
• CONTRAST THE DIFFERENCES BETWEEN THE BLACKS TO
  THE WHITES (kVp)

26
Why you see what you see

• The films or images have different levels of
  density different shades of gray
• X-rays show different features of the body in
  various shades of gray.
• The gray is darkest in those areas that do not
  absorb X-rays well and allow it to pass through
• The images are lighter in dense areas (like
  bones) that absorb more of the X-rays.

27
Image Production

• Primary Radiation The beam of photons, B4 it
  interacts with the pts body.
• Remnant Radiation The resulting beam that is
  able to exit from the patient.
• Scatter Radiation Radiation that interacts with
  matter only continues in a different direction
  not useful for image production.
• Attenuation Primary radiation that is changed
  (partially absorbed) as it travels through the pt.

28
Patient Body Size and Pathology
29
3 Different Body HabitusHypersthenic Sthenic
Hyposthenic
Dr. Charman,
Eric Guzman, Adam
Guzman
Thank you to the 3 men in my life ! ? DCharman
30
PATHOLOGY Pleural Effusion Excessive fluid in
lung More dense than air
31
pneumonia
32
The right lung is almost completely
collapsed vascular shadows can not be seen in
this area (arrow).
Lung collapses No tissue in space Easy to
penetrate with x-ray photons
pneumothorax
33
LUNGCancer
34
LUNG CANCER
35
Density and Images
36
Goal Producing optimal radiographsDENSITY
Too dark Too light
37
(No Transcript)
38
Controlling Factor ofContrast
39
Controlling Factor of Contrast

• Kilovolts to anode side kVp
• Kilovolts controls how fast the electrons are
  sent across the tube
• kVp controls CONTRAST on images

40
Producing optimal radiographsContrast Scale
Long scale short scale
41
(No Transcript)
42
Scale of Contrast?
Which one is better
How does the kVp affect these images?
43
(No Transcript)
44
(No Transcript)
45
Short Scale vs. Long Scale
46
(No Transcript)
47
Beam Restriction and Grids
48
Scatter

• Creates fog
• Lowers contrast (more grays)
• Increases as
• kV increases
• Field size increases
• Thickness of part increases

49
Effects of collimation (beam restriction) on
scatter
50

• Collimate to area of interest -reduces scatter
  and radiation dose to the patient

51
Grids

• A device with lead strips that is placed between
  the patient and the cassette
• Used on larger body parts to reduce the number of
  scattering photons from reaching the image

52
GRID NO GRIDCONTROLS CONTRAST
53
Basic Grid Construction

• Radiopaque lead strips
• Separated by radiolucent interspace material -
  Typically aluminum
• Allow primary radiation to reach the image
  receptor (IR)
• Absorb most scattered radiation
• Primary disadvantage of grid use
• Grid lines on film

54
GRIDS
55
Grid is placedbetween patient (behind table or
upright bucky) cassette
56
Grids absorb scatter prevents it from reaching
the image
GRID STOPS SCATTER
57
(No Transcript)
58
Contrast changes with the use of a grid Less
scatter radiation shorter scale better
contrast
With Grid No Grid
59
GRIDS CAN LEAVE LINES ON THE IMAGE
60
GEOMETRIC Properties

• Recorded Detail
• DISTORTION
• Size distortion
• Magnification
• Shape distortion
• Elongation
• Foreshortening

61
RECORDED DETAIL
62
RECORDED DETAIL

• The degree of sharpness in an objects borders
  and structural details.
• How clear the object looks on the radiograph

63
Recorded Detail

• The degree of sharpness in an objects borders
  and structural details.
• Other names
• -sharpness of detail
• -definition
• -resolution
• -degree of noise

64
RESOLUTION TEST TOOLS
LINE PAIRS/ MM Depicts how well you can see the
differences in structures More linesmore detail
65
(No Transcript)
66
Factors that affectRecorded Detail

• Geometric unsharpness
• OID SID SIZE SHAPE
• Motion unsharpness (blurring)
• Intensifying Screens
• Film Speed / Composition
• Film Screen contact
• Kvp Mas (density / visibility)

67
(No Transcript)
68
MOTION AKABlurring
69
Motion

• Can be voluntary or involuntary
• Best controlled by short exposure times
• Use of careful instructions to the pt.
• Suspension of pt. respiration
• Immobilization devices

70
(No Transcript)
71
Decrease Motion Unsharpness

• Instruct patient not to move or breath
• Use Immobilization devices
• Use Short exposure times
• Lock equipment in place

72
Blurring of image due to patient movement during
exposure.
73
(No Transcript)
74
Object Unsharpness

• Main problem is trying to image a 3-D object on a
  2-D film.
• Human body is not straight edges and sharp
  angles.
• We must compensate for object unsharpness with
  factors we can control focal spot size, SID
  OID

75
SID Source to Image Distance

• The greater the source X-ray tube) to image
  (cassette) distance, the greater the image
  sharpness.
• Standard distance 40 in. most exams
• Exception Chest radiography 72 in.

76
The SID will influence magnification. The
farther away the less magnified ?SID ?
MAGNIFICATION
77
SID

• Shine a flashlight on a 3-D object, shadow
  borders will appear fuzzy
• -On a radiograph called Penumbra
• Penumbra (fuzziness) obscures true border umbra
• Farther the flashlight from object sharper
  borders. Same with radiography.

78
(No Transcript)
79
OIDObject to Image Distance

• The closer the object to the film, the sharper
  the detail.
• OID ?, penumbra ?, sharpness ?
• OID ?, penumbra ?, sharpness ?
• Structures located deep in the body, radiographer
  must know how to position to get the object
  closest to the film.

80
The position of the structure in the body will
influence how magnified it will be seen on the
image The farther away the more magnified
81
(No Transcript)
82
Distortion

• Misrepresentation of the true size or shape of an
  object
• MAGNIFICATION
• size distortion
• TRUE DISTORTION
• shape distortion

83
MAGNIFICATION

• TUBE CLOSE TO THE PART (SID)
• PART FAR FROM THE CASSETTE (OID)

84
(No Transcript)
85

• http//www.coursewareobjects.com/objects/mroimagin
  g_v1/mod04i/0416a.htm

86
Size Distortion OID

• If source is kept constant, OID will affect
  magnification
• As OID ?, magnification ?
• The farther the object is from the film, the more
  magnification

87
(No Transcript)
88

• In terms of recorded detail and magnification the
  best image is produced with a
• small OID large SID

89
Minimal magnification small OID
Magnification - large OID
90
Size Distortion SID

• Major influences SID OID
• As SID ?, magnification ?
• Standardized SIDs allow radiologist to assume
  certain amt. of magnification factors are present
• Must note deviations from standard SID

91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
40 SID VS 72 SID
95
(No Transcript)
96
SHAPE DISTORTIONElongationand Foreshortening
97
Shape Distortion

• Misrepresentation of the shape of an object
• Controlled by alignment of the beam, part
  (object), image receptor
• Influences Central ray angulation body part
  rotation

98
A goodB C shape distortion
(elongation of part)
99
D E shape distortion (foreshortening of
part)
100
Image Distortion

• When the part to be imaged does not lay
  parallel with the IR (cassette)
• If the Central Ray is not perpendicular to the
  part
• CR should be at right angle with the cassette

101
Central Ray Angulation

• Body parts are not always 90 degrees from one
  another
• Central ray angulation is used to demonstrate
  certain details that can be hidden by
  superimposed body parts.
• Body part rotation or obliquing the body can also
  help visualize superimposed anatomy.

102
Central Ray

• Radiation beam diverges from the tube in a
  pyramid shape.
• Photons in the center travel along a straight
  line central ray
• Photons along the beams periphery travel at an
  angle
• When central ray in angled, image shape is
  distorted.

103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
Elongation Foreshortened Normal
107
(No Transcript)
108
Distortion (x-ray beam not centered over object
film)
Distortion (object film not parallel)
109
Distortion of multiple objects in same image
(right) due to x-ray beam not being centered over
objects.
110
Focal Spot Size

• Smaller x-ray beam width will produce a sharper
  image.
• Fine detail small focal spot (i.e. small bones)
• General radiography uses large focal spot
• Beam from penlight size flashlight vs. flood
  light beam

111
ANODE
ANODE
112
THE SMALLER THE BEAM TOWARDS THE PATIENT - THE
BETTER THE DETAIL OF THE IMAGE PRODUCED
113
FOCAL SPOT ANGLE
SMALLER ANGLE SMALLER BEAM AT
PATIENT
114
ARTIFACTSAN UNWANTED DENSITYON THE FILM
http//www.xray2000.co.uk/
115
Artifacts - Types

• Processing Artifacts
• Exposure Artifacts
• Handling Storage Artifacts

116
Processing Artifacts

• Emulsion pickoff
• Chemical fog
• Guide-shoe marks
• Water marks
• Chemical spots
• Guide-shoe roller scratches

117
Developer Spots
118
Water spot
119
Discolored film due to hypo (fixer)
retention. Chemicals not washed off over time
will turn film brown
120
Scratch marks from rollers in automatic processor.
121
Exposure Artifacts

• Motion
• Improper patient position
• Wrong screen-film match
• Poor film/screen contact
• Double exposure
• Warped cassette
• Improper grid position

122
Artifact
123
(No Transcript)
124
Blurred image due to patient motion
125
PATIENT ARTIFACT - JEWERLY
126
Handling Storage Artifacts

• Light fog
• Radiation fog
• Static
• Kink marks
• Scratches
• Dirty cassettes

127
Crimping /cresent mark
128
Double Exposure 2 exposures made on top of each
other from poor handling of cassettes
129
(No Transcript)
130
Static electricity
131
Dirt on screen mimicking a foreign object.
132
Scratch marks from improper handling.
133
Light fog
134
Kink mark or nail pressure mark
135
cast
136
POOR SCREEN CONTACT
137
Patient motion
138
motion
139
Double exposureChild
140
Poorscreen contact
141
Double exposure
142
?
Hands over upper abdomen
143
Is itmotion or double exposure?
144
(No Transcript)
145
Pt clothing
146
Hip replacement
147
2 chest tubes in the patient
148
Patient swallowed batteries What size are they?
149
(No Transcript)
150
PATHOLOGY NOT ARTIFACT
151
Name causeof this?
152
scratches
153
Digital image Mis- Registration error
154
Roller marks from film stuck then pulled from
processor
155
Hardware In cervical spine
156

• Dust in imaging plate can cause white marks on
• Both in film/screen and computed radiography

157
E E G MONITOR
158
What do you See? 2 exposures
159
(No Transcript)
160
(No Transcript)
161
Evaluating Images

• What do you think?

162

• Does this show good detail?
• Is all of the anatomy present?
• How is the density / contrast?

163

• Does this show good detail?
• YES
• Is all of the anatomy present?
• No (part of the little finger is not seen)
• How is the density / contrast?
• Density a little light underexposed
• Contrast is good

164
See anythingwrong with this image?
165
Contrast? What influences this? (kVp in f/s)
166
Collimation reducing the size of beamhelps to
improve the image, and reduce the dose to the
patient
167
?
