Title: ECE 453 Embedded Microprocessor System Design


1
ECE 453Embedded MicroprocessorSystem Design
Week 5
  • Michael G. Morrow, P.E.

2
Whats Happening in ECE 453?
  • This Week
  • Lab Exercise
  • TLL6219 Software Applications
  • Detailed Proposal due Friday by 500pm
  • See me/Dan beforehand if you have questions
  • Next Week
  • Lab
  • Linux Apps for Hardware
  • Plexus Visit on Friday 2/27
  • Depart 945am from Union South

3
Week 5 Topics
  • Component Selection
  • Layout and Support Circuits
  • Power Supplies
  • Interfacing to Displays

4
Hofstadters Law
  • It always takes longer than you expect, even when
    you take Hofstadters Law into account.

5
Quotes
  • "An effective way to test code is to exercise it
    at its natural boundaries" Brian Kernighan
  • "Program testing can be used to show the presence
    of bugs, but never to show their absence!"
    Dijkstra
  • "Testing is the process of comparing the
    invisible to the ambiguous, so as to avoid the
    unthinkable happening to the anonymous." James
    Bach

6
Resistors
  • Characteristics and Specification
  • What characteristics do we need to specify when
    selecting a resistor?
  • Resistor Markings
  • Through-hole components
  • SMT components
  • Selection and Usage
  • Power Dissipation
  • SMT Chip Resistors

7
Capacitors
  • Characteristics and Specification
  • CeA/d
  • ESR/ESL
  • Capacitor Types
  • Film Capacitors
  • Ceramic Capacitors
  • Electrolytic
  • UltraCapacitors

8
Inductors
  • We spend most of our time getting rid of
    inductance in our digital circuits, but it does
    have its uses
  • Power supplies for mixed-signal circuits
  • Ground noise issues
  • Conducted radiation issues
  • Inductors are heavily used in switch-mode power
    supply (SMPS) designs more on that later

9
Power Supply Bypassing
  • The Issues
  • CMOS synchronous circuits draw current in large
    spikes near the clock edges, and very little in
    between
  • Capacitance charging/discharging
  • Switching (shoot-through) currents
  • The current drawn by a device is essentially
    proportional to the number of transistors
    changing state ? more activity more current
  • Solutions
  • Decoupling Capacitance
  • Bulk Capacitance

10
Layout and Support Circuits
  • Circuit Layout
  • Wire Selection
  • Power and Ground Distribution
  • Daisy-Chain
  • Star
  • Rails
  • Planes
  • Mixed-Signal Systems
  • Logic
  • Inputs
  • Outputs
  • Clock Circuits

11
Power Supplies
  • Functions and design considerations
  • Voltage references
  • Linear regulators
  • Inductor-based SMPS
  • Buck converters PWM operation PFM operation
  • Boost converters Operation
  • Flyback converters
  • Capacitor-based SMPS (charge pumps)
  • The size of reactive components in SPMS is a
    function of frequency

12
Power Supplies (continued)
  • Batteries
  • Terminology
  • Primary versus secondary cells
  • Chemistry
  • Alkaline and Carbon Zinc
  • Lead-acid
  • NiMH / NiCad
  • Lithium Primary Cells
  • Lithium Ion
  • Power Supply Sequencing
  • CMOS inputs
  • Protection diodes
  • Power flow

13
Display Technologies
  • Liquid-Crystal Displays (LCD)
  • Cholesteric LCDs
  • Light-Emitting Diodes (LED)
  • Vacuum Fluorescent (VFD)
  • Cathode-Ray Tube (CRT)
  • Incandescent Lamps
  • Plasma Displays
  • Cold-Cathode Fluorescent (CCF) / EL
  • Organic Electroluminescent (OEL)
  • Digital Micromirror Devices (TI DLP)
  • Etc...

14
Display Types
  • Annunciator
  • True/false, on/off indication
  • Numeric
  • i.e. 7-segment displays, numeric data
  • Textual (Character-Based)
  • i.e. dot-matrix, 14-segment displays, limited to
    fonts
  • Iconic
  • Fixed graphic elements
  • Graphic
  • Each pixel individually addressable, arbitrary
    display

15
LCD Displays
  • Numeric, text, iconic, and/or graphic
  • Extremely low power
  • Passive
  • Temperature sensitive
  • Complex drivers needed to create segment voltages
    on multiplexed displays
  • Require no net DC offset on segments on single
    polarity systems this adds to complexity
  • LCD modules versus LCD glass

16
LCD Technology
  • A combination of polarizing filters and twisted
    liquid crystal creates a liquid crystal display.
  • TN (twist nematic) display

17
LCD Architecture
  • Display drive organizations
  • Reflective, transmissive and transflective
  • Monochrome versus color
  • Selection parameters
  • Resolution
  • Viewing angle
  • Contrast
  • Brightness (transmission)
  • Response time / frame rate
  • Operating temperature range

18
Wrapping Up
  • Next week in ECE 453
  • Lab ????
  • Sensors, Audio and Speech
  • Plexus trip on Friday 2/27/2009
  • Depart from Union South at 945am
  • Return to UW around 600pm
  • Resume?

19
Alkaline Carbon Zinc
  • Low-cost primary cells
  • VCELL 1.55-1.6V
  • RINT 0.2O (D alkaline)
  • Capacity
  • IEC/ANSI tests

20
Alkaline Carbon Zinc (cont)
  • Capacity is a function of discharge rate,
    terminal voltage, and temperature

21
IEC/ANSI Battery Tests
22
Lead-Acid
  • Secondary cells
  • VCELL 2.3V
  • Low cost, high energy density, rugged
  • High current capacity
  • Off-gassing

23
NiMH / NiCad
  • Secondary cell
  • VCELL 1.25V
  • Low RINT (D-cell 0.01O)
  • Discharge characteristics

24
NiMH / NiCad (cont)
  • Self-discharge
  • Charging
  • Fuel gauges
  • NiCad vs. NiMH

25
Lithium Primary
  • Primary cell
  • VCELL 1.5V, 3.0V, 3.6V
  • Numerous chemistries
  • Storage
  • RINT

2L76
CR2032
26
Lithium-Ion
  • Secondary cell
  • VCELL 3.6V
  • Storage
  • Support circuits
  • Charging
  • Gauging
  • Protection

27
Lithium Battery Management
28
Boost Switcher Topology
  • VOUT gt V

29
Buck Switcher Topology
  • VOUT lt V

30
Buck Switcher (25V ? 5V, PWM)
iL
vL
iout
iin
31
Buck Switcher (25V ? 5V, PFM)
iL
vL
iin
iout
32
Boost Switcher (3.6V ? 27V)
iiniL
iout
vout
vL
vin
33
Flyback Switcher Topology
  • Transformer provides isolation and voltage
    increase/decrease.

34
Color TFT LCD
35
LCD Pixel Drive Organizations
Passive matrix
Static (waveforms)
Multiplexed (waveforms)
Active matrix
36
(No Transcript)
37
Resistor Power Dissipation
38
Chip Resistor Construction
Source Walsin Technology Corporation http//www.p
assivecomponent.com/product/document/Chip-R/wrxx2
0general.pdf
39
Power and Ground Distribution Daisy-Chain
vcc
vcc

-
gnd
gnd
vcc
gnd
40
Power and Ground Distribution Daisy-Chain with
Impedance
Z
Z
vcc
vcc

digital
analog
-
gnd
gnd
Z
Z
Z
Z
vcc
digital
gnd
41
Power and Ground Distribution Star
vcc
vcc

-
gnd
gnd
vcc
gnd
42
Power and Ground Distribution Railed
vcc
vcc

-
gnd
gnd
vcc
gnd
43
Power and Ground Distribution Planes
vcc
vcc

-
gnd
gnd
vcc
gnd
44
Static LCD Drive
http//ww1.microchip.com/downloads/en/devicedoc/41
265a.pdf
45
LCD ½ Mux½ BiasDrive
http//ww1.microchip.com/downloads/en/devicedoc/41
265a.pdf
46
Film Capacitors
47
Ceramic Capacitors
48
Ceramic Capacitor Dielectrics
Y5V
X7R
X5R
COG(NPO)
49
Electrolytic Capacitors
50
Ultracapacitors
