NWS Southern Region Marine Workshop 2004

1
NWS Southern Region Marine Workshop 2004

• Steve LyonsTropical Program ManagerThe Weather
  Channel

2
OCEAN WAVE FORECASTING

• Steve Lyons
• The Weather Channel
• March 2004
• NWS Southern Region
• Marine Workshop

3
What I will try to cover!

• 1) Briefly review fundamentals
• 2) Storm wave forecasting tips
• 3) Shallow water effects rip currents

4
REVIEW FUNDAMENTALS

• WIND IS EVERYTHING!

5
(No Transcript)
6
Fundamentals are the most
important!
7
Have an overall understanding of the wave
forecast challenge

• Wave growth
• Wave spectra
• Swell propagation
• Swell decay
• Deep water waves
• Shallow water waves
• Shallow water wave modification

8
Statistical Wave Spectrum
9
WAVE SPECTRUM

• Measured sea state is typically H1/3 termed
  significant wave height
• H1/10 1.27H1/3
• H1/100 1.67H1/3
• H max 2.0H1/3

10

• 'Rogue wave' theory for ship disaster
• The 44 crewmen perished when the bulk carrier
  sank
• Scientists have discovered that a rogue wave
  pattern helped cause one of the UK's biggest
  maritime disasters.

11
Transient Wave-Wave Superposition
12
Example of dispersive waves(just 2 components!)
13
COMBINED SEAS

• Combined seas represent the sum total height of
  wind-wave and any number of swell components
  mixed in with it.
• Cssqrt(wwww s1s1s2s2s3s3
• Max Cs2.0Cs

14
COMBINED SEAS CALCULATION

• 1) Combined seas square root of
  (WWS1S1S2S2)
• 2) Remember wave spectrum concept
• 3) This process explains wave sets observed by
  surfers and sailors
• 4) Oh, but what about SHALLOW WATER?

15
COMBINED SEAS

• Two gnarly surf dudes are ready to surf, but will
  not go out unless waves exceed 15 feet
• The wind wave is 2 feet, and two swells one of 8
  ft and one of 9 ft are occurring togetherwill
  the dudes go out surfing?

16
Wave Steepness

• H/L
• Affects boats ships differently
• Vessel size dependence
• Wave height dependent

17
Angular Spreading and Dispersion
18
WAVE GROUP VELOCITY

• OFTEN THE TERM USED TO INDICATE SPEED OF WAVE
  PACKET (Cg)
• FOR DEEP WATER Cg(1.56T)/2
• FOR SHALLOW WATER CgC

• CdSQRT(gL/2PIE)
• CsSQRT(gH)
• gGRAVITY
• LWAVE LENGTH
• HWATER DEPTH
• Pi3.14159

19
STEVES WAVE TOOLS

• VALIDATE MODELS
• IMPROVE WAVE SWELL FCSTS
• FCST HURRICANE WAVES
• FCST WAVE SETUP
• MODIFY FCST USING LATEST OBSERVATIONS

20
WAVE RELATIONSHIPS
21
WAVE RELATIONSHIPS
22
WAVE RELATIONSHIPS
23
Summary
Fundamentals Review

• Understand basic wave characteristics and their
  behavior
• Some very simple concepts go a long way toward
  understanding waves and making good wave forecasts

24
2) Storm wave forecasting
25
Deep water storm wave
forecasting
26
LIMITS TO WAVE GROWTH

• WIND SPEED
• WIND FETCH LENGTH
• WIND DURATION
• WIND FETCH WIDTH FOR SWELL
• These can be tricky!

27
Maximizing wave growth in a gale,
storm, hurricane

• Wind speed is NOT the answer! Why?
• Wind duration is extremely important! Why?
• Wind fetch length is relatively important! Why?
• Effective fetch, dynamic fetchfancy names for
  combinations of the 2 elements above!
• Why must you know wave period?

28
For Strong Winds

• Fetch length is usually limiting
• Fetch duration is nearly always limiting!
• If the wind field moves with the wave field it
  generates, then effective wind duration will
  increase.
• How doe we quantify this affect?
• How do we determine how fast a storm should
  move to maximize wave growth?

29
Moving wind fetches

• Fetch speed MUST be linked to the group velocity
  of waves generated by that fetch
• Group velocity is ½ the wave celerity
• Wave celerity, C1.56T
• You are focusing on H1/3 periods even though an
  entire spectrum is being generated
• The ideal wave generation scenario is an
  accelerating wind fetch area. That acceleration
  matching the changing group velocity of waves the
  fetch is generating. Concentrate on H1/3 or you
  will go crazy!

30
Calculating effective wind
duration

• Compute wave group velocity
• Compute fetch speed in the direction of wave
  propagation
• Compute the duration of superposition of waves
  and wind fetch for the sector of interest to your
  forecast area
• Decay waves to final their destination as swell
  if they are not collocated with area of interest

31
Hurricane Wave Generation
32
The Stationary Hurricane
33
Stationary Hurricane

• Only asymmetries in wind field
• Latitudinal change in Coriolis parameter
• Are responsible for wave asymmetries,
  otherwise waves of equal height period spread
  away equally from TC in all directions in deep
  water.
• What is deep water?

34
The Moving Hurricane
35
Moving Hurricane

• Wind field around hurricane modified by the
  forward motion of the hurricane
• Result is winds are strongest (weakest) on side
  with winds blowing in the same (opposite)
  direction from the TC motion
• But that wind asymmetry is NOT the primary reason
  for much higher waves in the TC righ-front
  quadrant in the Northern Hemisphere
• Increased wind duration over developing waves is
  the primary reason!!!!!!!!!!!

36
The old right-front quadrant

• 1400 mph
• R34275
• R50125
• R64100
• Rmax25
• Duration72 hours
• Speed0 Speed12kt

37
(No Transcript)
38
WAVE PROPAGATION

• MOST storms or strong wind areas are NOT
  collocated with your forecast area of interest,
  but can still cause swell there some time later!

39
Dispersion of deep water waves
40
Angular Spreading Dispersion modify wave
energy away from the generation
area
41
IS IT POINTING AT YOU?

• WAVES/SWELLS MOVE ON GREAT CIRCLE PATHS
• ONE MUST KNOW GREAT CIRCLE PATH IN ORDER TO
  FORECAST SWELL AT YOUR LOCATION
• GREAT CIRCLES FROM WHICH YOU CAN MAKE A CHART FOR
  YOUR AREA http//www.indo.com/distance/

42
GREAT CIRCLE EXAMPLE
43
DRAW GREAT CIRCLE INITIAL TRAJECTORIES TO YOUR
FINAL DESTINATION
http
//

• www.indo.com/distance

44
SWELL TRAVEL TIME TO FINAL DESTINATION

• A storm is 1000km from your coast
• H1/310 meters
• T1/310 seconds
• How many hours will it take for the H1/3 waves to
  reach your coast?

• 1) CgC/2
• 2) Cg(1.56T)/2
• 3) Calculate deep water swell group velocity
• 4) Divide travel distance by swell group velocity

45
Swell Travel Time
46
Summary

• Swell forecasts can be the best extended range
  forecast you can make
• NEVER forget the great-circle
• Make a great-circle chart for your office
• Try some unique graphs that help you and others
  in your office make wave forecasts easier!

47
3) Shallow Water Effects Rip Currents

• HUGE CUSTOMER GROUP IN THIS ZONE
• SHOALING
• REFRACTION
• PERCOLATION/DAMPING
• REFLECTION

48
Shallow water, where big transformations take
place!
49
Vertical Distribution Of Water
Motion in Swell
50
Shallow Water Affects

• The Coastal Impacts
• The Masses Affected
• Can be complex
• Can be extremely beach dependent
• You should know what happens
• Affects forecast timing

51
WAVE SHOALING (100 MI W OF SAN
DIEGO)
52
WAVE SHOALING

• Wave height change due to its interaction with
  the bottom
• Wave slows, but wave period is conserved
• Wave length shortens height increases, period is
  unchanged!
• Shoaling factor is between .5 and 2

53
Shoaling Coefficient

• Ks sq root (Cgo/Cga)
• Cgodeep water group velocity
• Cgagroup velocity at depth a
• For breaking a is the depth of breaking
• (NOTE IF WAVES REMAIN IN SHALLOW WATER FOR
  SIGNIFICANT LENGTHS OF TIME WAVE DAMPING CAN
  BECOME VERY IMPORTANT)

54
WAVE REFRACTION

• BENDING OF WAVE ENERGY DUE TO OCEAN CURRENTS, AND
  SHALLOW WATER
• BIGGEST EFFECT FOR LONGEST WAVE PERIODS. WHY?

55
FIGURE IT OUT!

• DIRECTIONAL WAVE INFORMATION FROM A BUOY 100nm
  OFFSHORE INDICATES A WNW SWELL
• HUNTINGTON BEACH REPORTS A SW SWELL. WHY?

56
REFRACTION

• WAVES ALWAYS BEND TOWARD SHALLOW WATER
• WAVES ALWAYS BEND AWAY FROM DEEP WATER
• WAVES ALWAYS BEND AWAY FROM MAX. CURRENT

• REFRACTION MAGNITDUES VARY GREATLY FROM ABOUT
  10 DEEP WATER WAVE HEIGHT TO 300 DEEP WATER
  WAVE HEIGHT

57
Wave bends toward shallow water, energy is
concentrated
58
WAVE REFRACTION
59
Calculating Wave Refraction

• From Snells Law
• sin Aa /Ca sin Ao/Co
• Aodeep water wave angle to coast
• Codeep water wave celerity
• Aawave angle to coast at desired depth
• Ccwave celerity at desired depth

60
Refraction Coefficient

• Depends on the magnitude of convergence or
  divergence of wave paths!
• Kr((1-sin2 Ao)/(1-sin2Aa))1/4

61
WAVE REFRACTION!
62
Shoaling, Refraction Breaking Waves
63
BREAKING WAVE TYPE

• SPILLING BREAKERS
• PLUNGING BREAKERS
• SURGING BREAKERS
• COLLAPSING BREAKERS

64
Modeled wave breaking by Liu
Pengzhi (Cornell U.)

65
Breaker Types
66
Shallow Water Wave Breaking
67
Spilling Breaker
68
Waves break in many shapes. Why?
69
BREAKER DEPTH

• Breaker depth for a spilling breaker is defined
  as 5/3H (Hheight at breaking)
• The end of the pier is at a depth of 30 feet
• Significant wave heights are 15 feet
• Will they break before the end of the pier?

• First calculate breaker depth of H1/3
• Then for H1/10
• Then for H1/100
• Then for H max
• What is your answer?

70
WAVE SETUP

• WATER RISE AT THE COAST DUE TO BREAKING WAVES ON
  THE BEACH
• PROPORTIONAL TO BREAKING WAVE DEPTH, THUS HEIGHT
  FOR GENTLE SLOPING BOTTOM

71
WAVE SETUP

• KINETIC ENERGY OF ONSHORE WAVE ENERGY TO
  POTENTIAL ENERGY OF WATER SURFACE
• WAVE HEIGHT AND BREAKER DEPTH DEPENDENT

72
WAVE SETUP

• RANGE IS FROM INCHES TO 10 FEET FOR SOME
  HURRICANES!
• COEFFICIENT IS APPROXIMATELY
• 0.12 BREAKER DEPTH

• A SPILLING BREAKER IS 30 FEET HIGH
• WHAT IS THE BREAKER DEPTH?
• WHAT IS THE MAX WAVE SETUP ELEVATION ON THE BEACH?

73
Wave Setup Approximation

• S (g1/2 Hs2 T) / (64piBD3/2)
• where g gravity 9.8 (units in meters)
• Hs deep water significant wave height
• T wave period
• BD depth of breaking
• pi3.14159

74
Wave Run-up

• R1/31.38HE (.77) Significant run up
• Rmax2.32HE (.77) Maximum run up
• Hbreaker height
• EB/sqrt(H/L)
• Bbeach slope (any units)
• Run up is less for fluffy, rapidly absorbing
  sande.g. rising tide

75
WAVE REFLECTION

• RARE EVENTS
• MUST HAVE A WALL TO REFLECT FROM
• TYPICALLY ENGINEERED STRUCTURES AND BREAK WATERS

76
Wave Reflection!

• Newport Beach
• Wedge gt35

77
What do you see in this photo?
78
RIP CURRENTS

• MUST HAVE
• BREAKING WAVES
• BEACH CURRENTS
• TIDE CHANGES
• TO GET RIP CURRENTS

79
RIP CURRENTS

• Characteristics
• Danger
• Cause
• Locations
• Forecasts

80
RIP CURRENT RESCUES
81
Rip Current Process
82
Rip Current Processes
83
(No Transcript)
84
(No Transcript)
85
Rip Current Examples
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
RIP CURRENTS
92
RIP CURRENTS
93
(No Transcript)
94
Rip Current Video
95
RIP CURRENTS

• More likely as breaking wave height increases
• More numerous with shorter period breakers
• Stronger with longer period breakers
• Anchored by natural and man-made barriers

96
Simplifying to extremes!
97
Longshore Current

• V(mid breaker zone)1.17sqrt(gHb)
• sin (breaker angle)cos(breaker angle)
• Hbbreaker height, ggravity
• Try Hb5 meters, breaker angle15 degrees
• V1.17sqrt(105)sin(15)cos(15)
• V 2 m/sec

98
Rip Current Index?

• Scale from 0-10 or 0-5
• Related to risk to swimmers/surfers/jet
  skiers/boaters/ fishermen

• Rip current frequency and strength depends on
• Wave height
• Wave period
• Wave angle to coast
• Coastal barriers
• Width of breaker zone

99
Rip Currents

• Rip current spacing 3 times the distance of the
  surf zone?
• Surf zone width is directly related to wave
  height for any given beach beach slope
• Coastal irregularities account for more than 60
  of rip current longshore variability in frequency
  and about 30 variability in intensity

100
Rip Currents

• Rip current strength is directly proportional to
  breaking wave height. Large waves cause strong
  rip currents.

101
RIP CURRENT FORECAST?

• RIP CURRENT STRENGTH BREAKER HEIGHT (SCALE 0 -
  30)
• RIP CURRENT SPACING 3.0 BREAKER ZONE DISTANCE
• RIP CURRENT LOCATION RANDOM FOR STRAIGHT BEACH
  ANCHORED BY COASTAL OBJECTS
• RIP CURRENT FREQUENCY PULSES WITH BREAKER BEAT.
  CONSIDER IT CONTINOUSLY OCCURING FROM A FORECAST
  VIEWPOINT

102
Long-term longshore (sand) transport rate

• Dependent upon mean breaker height squared!
• Q(cubic yards/year) 2 x 105 x Hb2
• Hb breaker height in feet

103
Summary

• WOW shallow water is important
• WOW 99 of my customers are in shallow water
• WOW I better understand these simple shallow
  water concepts
• WOW I can make some real value-add to the model
  forecast near shore
• WOW no one should ever die from a rip current on
  my forecast shift!

104
THE END

• Remember forecast for your customers, not for
  yourself
• Understand the basics and you will make superior
  forecasts

105
Coastal Beach Erosion
106
January 3, 2002 3.5 tide!
107
Coastal Erosion Rate

• Shoreline change (meters/year)
• -.27(sea level rise mm/yr) 0.41
• Global sea level rise estimated to be 2mm / year
  over the past 100 years

108
Coastal Subsidence Rates
109
Summary

• I now have some sound bites for the media when
  they come around after a big beach erosion event!
• Gee, I can actually make some generic forecasts
  of the magnitude of the erosion potential for
  each wave event!
• Wow, I should practice these applications in my
  spare time

110
Summary

• WOW I can think of 1,000s of wave/weather
  scenarios that this simple information can be
  applied to
• Gee, I better practice applying this and training
  the rest of the office or we are going to blow it
  during some big events!

111
EVERYONE LIKES WAVES!
112
What do you see in this photo?
113
What do you see in this photo?
114
What do you see in this photo?
115
What do you see in this photo?
116
What do you see in this photo?
117
What do you see in this photo?
118
Surfing a Tidal Bore
119
Summary

• Man I feel like a pro surfer, I can now see
  things in wave photos I never knew about.and I
  have never even gone swimming in the ocean!
• Gee, maybe I should head down to the beach this
  weekend and see how much of all this I can apply
  to what I see! Ill take (a copy of) Lyons wave
  cheat sheet with me!
• THE END!

120
3) How to analyze marine data
121
Marine Wind Analysis

• Use STREAMLINES AND ISOTACHS!
• Pressure is rather worthless!
• Get good at analysis
• Get fast at analysis
• Synthesize data
• Be better than the model initial condition!!!

122
Satellite Cloud Drift Winds

• Lo/mid/high levels
• Bias to cloud
• Uncertain height
• Must correct to
• surface wind speed
• From GOES, hence
• continuous coverage

123
Use ALL tools available to you!

• Observations
• Numerical models
• Analyses
• Satellite imagery
• Satellite remote sensing tools
• Wave relationships
• Simple models

124
Satellite Cloud Winds

• Correction to 10 meters seasonal!
• Correction dependent on air/sea temp difference
• Correction must include footprint size
• General correction factor 80
• Range or correction factors 65 - 100
  excluding strong sfc water current affects

125
Interpreting Buoy Observations

• Significant Wave Height (H0) 7.9 ft
• Swell Height 7.9 ft
• Swell Period 14.3 sec
• Wave Steepness SWELL
• Average Wave Period 8.3 sec

126
Interpreting Buoy Observations

• Wind NNW ( 330 deg ) 15.5 kts G19.4
• Wave Height 7.9 ft
• Dominant Wave Period 14 sec
• Air Temp 55.0 F SST 53.8

127
88D Winds?

• Must be very close to radar due to beam elevation
• Must include modification for wind direction
  angle to inbound/outbound
• Know beam elevation angle as a function of
  distance for 1.5 degree elevation angle

128
Wind Adjustment!

• Correction for height (10 meters)
• Correction for duration
• Correction for direction
• Gusts?
• Currents?
• Air-sea temperature contrasts?

129
(No Transcript)
130
Wind Height Adjustment

• Log-wind profile with height
• Uz U/k x ln (z/z0)
• Kvon Karmans constant .4

131
Interpreting Buoy Observations

• 2 am 1.9 kts
• 6 am 1.9 kts
• 10 am 3.9 kts
• 2 pm 5.8 kts
• 6 pm 11.7 kts
• 10pm 15.5 kts
• 2 am 15.5 kts

132
Interpreting Buoy Observations

• What does this tell us about local conditions?
• What does this tell us about swell?
• What would you expect to see at the beach?

133
Summary

• Define the wind and forecast it accurately, if
  not you cannot make good wave forecasts.
• Use ALL available data to define the wind field!
