A hierarchical Bayesian model of causal learning in humans and rats

1
A hierarchical Bayesian model of causal learning
in humans and rats

• Tom Beckers1, Hongjing Lu2, Randall R. Rojas2,
  Alan Yuille2
• 1UvA / 2UCLA

2
overview

• the problem effects of pre-training on blocking
  in humans and animals
• a work-in-progress solution causal learning as
  hierarchical Bayesian inference
• problems with the solution

3
prelude blocking

• blocking a touchstone phenomenon of associative
  learning in animals (Kamin, 1969) and humans
  (Dickinson, Shanks Evenden, 1984)

4
prelude blocking

• blocking in animal Pavlovian conditioningexp
  buzz --gt shock / buzzlight --gt shock
• contr tone --gt shock / buzzlight --gt shock

5
prelude blocking

• blocking in human causal learningA --gt allergy,
  Z --gt no allergy / AX --gt allergy, KL --gt
  allergy, Z --gt no allergy

6
prelude blocking

• the observation of blocking provided the main
  inspiration for the development of the
  Rescorla-Wagner model of conditioning (Rescorla
  Wagner, 1972) and its application to human causal
  learning (Dickinson et al., 1984)

7
act 1 introducing the problem

• pre-training appears to significantly modulate
  blocking, both in human causal learning and in
  rat Pavlovian fear conditioning (e.g., Beckers et
  al., 2005, 2006 Vandorpe, De Houwer Beckers,
  2007 Wheeler, Beckers Miller, 2008)

8
pre-training in humans
pretraining elem.tr.
comp.tr. additive C D CD E M- A M-
AX KL M- subadditive C D CD E M- A
M- AX KL M-
Beckers et al., 2005, JEPLMC, Exp. 2
9
pre-training in rats
Beckers et al., 2006, JEPG, Exp. 1
10
pre-training in rats
Beckers et al., 2006, JEPG, Exp. 1
11
act 2 toward resolution

• to date, no convincing formal explanation
  available for pre-training effects on blocking
• blocking in itself is compatible with a number of
  formalisations, including associative models,
  probabilistic models, and Bayesian inference
  models

12
learning as Bayesian inference

• Bayes rule p(HD) p(DH)?p(H)/p(D)
• to evaluate the existence of a causal
  linkp(H1D) p(DH1)?p(H1)
  p(H0D) p(DH0)?p(H0)
• can be used for Bayesian parameter estimation of
  the weight of the causal link

13
learning as Bayesian inference

• in this framework, learning implies the
  application of Bayes theorem to find the most
  likely causal structure of the world given the
  available data
• the posterior probability of a causal model H
  given the data is a function of the probability
  of the data given the causal model (which can be
  derived analytically) and the prior probability
  of the causal model

14
learning as selection between causal graphs

• A X A
  X
• effect effect

15
a generative graphical model
hidden variables represent internal states that
reflect the magnitudes of the effect generated by
each individual cause
16
a generative graphical model
p(DH) obviously depends on how R1 and R2 combine
to produce R
17
a generative graphical model
simplest assumption linear-sum model R
expressed as the sum of R1 and R2 plus some
Gaussian noise.
18
applying the linear-sum model to a blocking
contingency

• priors on weights are set (close
  to) 0
• weights are then updated trial-by-trial by
  combining priors with likelihoods (likelihoods
  being derived using a linear-sum model)

p(HD) p(DH)?p(H)/p(D)
19
applying the linear-sum model to a blocking
contingency

• using some mathematical hocus-pocus, this yields

Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
20
other integration models

• as indicated, these results crucially depend on
  the choice of the integration rule, here a
  linear-sum model
• one could think of an alternative rule, such as a
  max or noisy-max rule
• the noisy-max rule is a generalisation of the
  noisy-OR rule to continuous outcomes, the
  noisy-OR rule itself being a mathematical
  implementation of the power PC model

21
the noisy-max model

• basically, the noisy-max rule implies that R is
  either the maximum of R1 and R2 (the max rule) or
  the average of R1 and R2, or something in between

22
applying the noisy-max model to a blocking
contingency

• using this rule instead of the linear-sum model,
  yields for the same blocking contingency

Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
23
Bayesian inference for model selection

• so far, we have used Bayesian inference to
  estimate parameter weights (causal strengths),
  based on a hypothetical integration model
• however, Bayesian inference can also be used to
  estimate which integration model best fits a set
  of data (this is called hierarchical Bayesian
  inference)
• i.e., what is the posterior likelihood that we
  would observe the sequence of data
  (presence/absence of cues and outcomes) given
  either a linear or noisy-max rule?

24
pre-training and model selection

• simplifying things slightly, the pretraining data
  are consistent with one causal graph only, so we
  do not need to select between a graph that
  contains one causal link and a graph that
  contains two causal links
• instead, for pretraining, we can focus on which
  integration rule best fits the data, given the
  causal graph with two links

25
learning as selection between causal graphs

• C D C
  D
• effect effect

26
pre-training and model selection

• the pretraining trials can thus serve to compute
  log-likelihood ratios for the noisy-max model
  relative to the linear-sum model

Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
27
pre-training and model selection

• additive pretraining induces a preference
  towards the linear-sum model, subadditive
  pretraining a preference towards the noisy-max
  model, relative to no CD compound trials (red
  line)

Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
28
combining model selection and parameter estimation

• the model selected on the basis of the
  pretraining trials can then be applied to do
  parameter estimation based on the elemental and
  compound trials

Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
29
hierarchical Bayesian inference in animal
conditioning

• slightly different pretraining subadditive
  versus irrelevant
• for model selection, log likelihood treshold set
  such that without pretraining, animals exhibit
  preference for linear-sum model

30
model selection by pre-training
Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
31
parameter estimation

• using the model that best fits the pre-training
  data, we do Bayesian parameter estimation from
  the elemental and compound trials
• these weight estimates are translated in
  estimated suppresion ratios using
• where N number of lever presses in pre-CS
  baseline period

32
simulation results
Lu, Rojas, Beckers Yuille, Proc Cog Sci, 2008
33
so ...

• hierarchical, sequential Bayesian inference can
  account for influences of pretraining on
  subsequent learning with completely different
  stimuli
• key assumption learners have available multiple
  integration models for combining the influence of
  multiple causes i.e., both humans and rats have
  tacit knowledge that multiple cues may have
  summative impact on the outcome (linear-sum
  model), or that the outcome may be effectively
  saturated at a level approximated by the weight
  of the strongest individual cause (noisy-max
  model)

34
so ...

• using standard Bayesian model selection, the
  learner selects the model that best explains the
  pretraining data, and then continues to favor the
  most successful model during subsequent learning
  with different cues

35
act 3 conflict / complication

• there are a number of problems and complications
  to be spelled out so far
• in its present form, the simulations capture some
  of the data very well however, the model would
  probably fail with other data, e.g., on effects
  of outcome maximality

36
act 3 conflict / complication

• there are a number of problems and complications
  to be spelled out so far
• for the human data, the model does not assume any
  priors on the integration models this is
  psychologically implausible
• on the other hand, humans and other animals are
  probably capable of learning other integration
  rules as well (e.g., super-additive rules)

37
act 3 conflict / complication

• there are a number of problems and complications
  to be spelled out so far
• if so, the present model still represents a gross
  simplification we need a prior distribution on
  the whole range of possible integration models,
  and ways to compute posterior likelihoods for
  them
• the whole damn thing feels like shooting a cannon
  ball to kill a fly
