An Introduction to the Material Handling Equipment

1
An Introduction to the Material Handling
Equipment Manufactured by Palamatic Handling USA,
Inc. Presented by Jack Mener
2
About Palamatic Handling Palamatic Handling
USA, Inc. was founded in August 1990. In only a
little more than a decade we have developed
representation for a broad product line for
special lifting and bulk and powder process
material handling.
3
Our innovative solutions

• Improve safety and ergonomics
• Increase efficiency and process throughput
• Speed assembly
• Improve quality
• Save time and money

4
Our Equipment Range

• Vacuum Lifting Equipment
• Manipulators
• PneuLifts
• Drum Tippers
• Powder Processing Equipment

5
Vacuum Lifting Equipment
Vacuum lifters are ideal cost effective solutions
for handling bags, boxes, cartons, sheet
materials, drums and other common payloads.  We
also design and build special tooling for every
imaginable payload  electronic and computer
system components, refractory, signature logs,
pallets, furniture, reels, rolls and multiple
payload handling for more productive palletizing
or depalletizing.
6
Vacuum Lifting Equipment
Palamatic lift tube systems use vacuum and flow
to both lift and hold payloads.  The use of a
hoist is not required. Using vacuum lift tube
technology to lift as well as hold requires
design within an optimum range of flow, contact
area, vacuum pressure and lift tube diameter.
7
Vacuum Bag Lifters
8
Vacuum Carton Lifters
9
Vacuum Pail Lifters
10
Vacuum Drum Lifters
11
Vacuum Drum Lifters
12
Manipulators
Manipulators and special PneuLift or PneuHoist
lifters are ideal cost effective solutions for
handling for assembly, machine loading or
unloading, handling for inspection, and handling
for packaging in a broad range of industries.
13
Manipulators
Manipulators allow a single operator to safely
and efficiently handle heavy and delicate
payloads with the greatest of precision.
Manipulators can provide reach in or under
ability for loading machines that cannot be
accessed by a hoist or vertically suspended
lifting device.
14
Manipulators
15
Manipulators
16
Manipulators
17
PneuLifts
Palamatic PneuLifts are a new idea in the
industrial handling world.  PneuLifts combine the
tooling, control and manipulation features of our
manipulators in a compact, light weight and easy
to maneuver device that is tailored to your
specific handling application.
18
PneuLifts
PneuLifts use a pneumatic cylinder with an
external bearing rod to handle payloads from 10
to 800 pounds in both light and heavy industrial
environments.
19
PneuLifts
PneuLifts can be floor mounted from a light
weight enclosed track jib crane or articulating
crane, overhead mounted from an enclosed track
crane, or mounted on a Palamatic PalTrac
stainless steel clean room crane.
20
PneuLifts
21
PneuLifts
22
PneuLifts
23
Drum Tippers
Palamatic's Drum Tippers offer an economical
solution to pouring heavy drums for reactor
charging or blender loading.  Fixed in place or
mobile units are available to meet a wide range
of requirements.
24
Drum Tippers
25
Drum Tippers
26
Drum Tippers
27
Powder Processing Equipment
Palamatic can meet your handling needs from
general bulk and powder processes, food and
sanitary processes, primary fine chemical
environments through secondary processing, final
product handling, packaging materials handling,
packaged product handling, storage and shipping.
28
Powder Processing Equipment
Palamatics solutions for powder processing range
from simple bag dump workstations to fully
automated bag opening systems. We also
manufacture bulk bag unloading stands.
29
Powder Processing Equipment
30
Powder Processing Equipment
31
Powder Processing Equipment
32
Contact Information Main Office Chicago
Branch Tennessee Branch Tim Carney Jack
Mener Ron Castle President Regional
Sales National Sales Manager (610)
701-6350 [phone] [phone] (610)
701-6354 [phone] [phone]
33
Please visit our Website at WWW.PALAMATICUSA.COM
