Industrial Energy Efficiency Programs National and International Trends

1
Industrial Energy Efficiency ProgramsNational
and International Trends

• California Public Utilities Commission
• Pre-hearing Conference
• Energy Efficiency Strategic Planning
• 2009-2020
• November 5, 2007
• Aimee McKane
• Lawrence Berkeley National Laboratory

2
Energy Efficiency and Climate Change
Gt of CO2
Increased nuclear (10) Increased renewables
(12) Power sector efficiency fuel
(13) Electricity end-use efficiency (29) Fossil
fuel end-use efficiency (36)
Alternative Policy Scenario
Energy efficiency is the major path to limiting
growth in global energy consumption and carbon
emissions
Improved end-useefficiency accounts for
two-thirdsof avoided emissions in 2030
2030
Source International Energy Agency, World Energy
Outlook. 2006
3
Focus on industrial energy efficiency is growing
around the globe

• UN Industrial Development Organization is
  promoting systems energy efficiency and energy
  management standards for both developed and
  developing nations.
• International Organization for Standardization(IS
  O) is initiating a broad portfolio ofinitiatives
  to promote energy efficiency.
• China initiated plan to reduce energy use 20per
  unit of GDP over 2005 levels by 2010.
• Through the Asia Pacific Partnership, the U.S.,
  Australia, Korea, Japan, China, and India
  arepromoting greater industrial energy
  efficiency.
• Energy efficiency is now a major focus of
  G-8meetings.

4
Industrial Energy Efficiency Global Context

• Goal
• integrate energy efficiency projects into
• existing management structures
• for continuous improvement
• Elements
• Energy management standard
• Training (energy management, system optimization)
• Capacity building- create cadre of system experts
  to develop projects
• Access to tools to identify opportunities and
  document compliance
• Recognition of companies that make outstanding
  efforts to improve their energy efficiency
• Agreements with industrial sectors that establish
  plant-specific energy efficiency targets

5
Industrial Energy Efficiency Policies that Work

• Energy Management Standards
• Purpose is to provide guidance for industrial
  facilities to integrate energy efficiency into
  their management practices. All existing and
  planned energy management standards are
  compatible with ISO 9000/14000
• Industrial System Optimization
• Purpose is to provide immediate opportunities
  (often 2 year payback or less) from projects to
  optimize industrial systems for energy
  efficiency. These systems are found in all
  industrial sectors. Training is essential.
• Target-setting Agreements
• Also known as voluntary or negotiated agreements
• Purpose is to establish targets for energy
  intensity reduction in industrial sectors.
  Agreements are typically between a government and
  industrial companies, based on sector-based
  negotiated agreements

6
Why an Energy Management Standard?

• Most energy efficiency in US industry is achieved
  through changes in how energy is managed in an
  industrial facility, rather than through
  installation of new technologies
• An energy management standard provides a
  framework for integrating energy efficiency into
  existing industrial management systems for
  continuous improvement. All existing and planned
  energy management standards are compatible with
  ISO 9000/14000, as well as other management
  systems (e.g- 6 Sigma)
• Companies who have voluntarily adopted an energy
  management plan (a central feature of an energy
  management standard) have achieved major energy
  intensity improvements1, for example
• Dow Chemical achieved 22 improvement (4B
  savings) between 1994 and 2005, now seeking
  another 25 from 2005 to 2015
• United Technologies Corp reduced global GHG
  emissions by 46 per dollar of revenue from 2001
  to 2006, now seeking an additional 12 reduction
  from 2006 to 2010

1 Btu/lb of product
7
Components of an EM Standard

• Typical features include
• a strategic plan that requires measurement,
  management, and documentation for continuous
  improvement for energy efficiency
• a cross-divisional management team led by an
  energy coordinator who reports directly to
  management and is responsible for overseeing the
  implementation of the strategic plan
• policies and procedures to address all aspects of
  energy purchase, use, and disposal
• projects to demonstrate continuous improvement in
  energy efficiency
• creation of an Energy Manual, a living document
  that evolves over time as additional energy
  saving projects and policies are undertaken and
  documented
• identification of key performance indicators,
  unique to the company, that are tracked to
  measure progress and
• periodic reporting of progress to management
  based on these measurements

8
Plan-do-check-act model
Source Danish DS 24032001, Energy
Management-Specifications
9
Energy Management Standards

• Current Status
• Several countries already have energy management
  standards (Denmark, Ireland, Sweden, US)
• Energy management standards are under development
  in China, Spain, Brazil, Korea and the European
  Union
• ISO will be initiating work on an international
  energy management standard, with preparatory
  assistance from the United Nations Industrial
  Development Organization (UNIDO)
• The US has proposed to lead the ISO effort

10
Supportive Policies for National Energy
Management Standards

• In all countries with existing standards
• Energy management standards are voluntary
• Programs target large industrial plants
• Technical assistance is available
• Case studies are used to publicize benefits
• Provide recognition for outstanding performers
• In addition, most countries
• Offer financial incentives for compliance,
  usually as part of a voluntary agreement1
• Provide training on standards compliance
• Provide opportunities for companies to network
  and learn from each other
• Several countries also offer system optimization
  training

1 typically energy or carbon dioxide tax relief
11
Business Benefits

• Assists the company to
• Develop a baseline of energy use
• Actively managing energy use and costs
• Reduce emissions without negative effect on
  operations
• Continue to improve energy use/product output
  over time
• Document savings for internal and external use
  (e.g. emission credits

12
Why make this public policy?

• Many companies, especially those with small and
  medium sized facilities, do not have the internal
  resources and expertise required to develop an
  energy management plan without assistance
• A turnkey program could be rapidly established by
  drawing on existing and available resources (EPA,
  DOE, LBNL, Georgia Tech)
• Could leverage national and international
  activities, placing California in a leadership
  position among states
• Applies to all industrial sectors

13
System Optimization

• Steam and motor-driven systems account for nearly
  50 of final manufacturing energy use worldwide
• These systems typically offer at least a 10-30
  improvement opportunity using readily available
  technology because they are engineered for
  reliability without regard to energy efficiency
• Both industrial markets and policy makers tend to
  focus on system components, which have a 2-5
  improvement potential
• Barriers to improvement are institutional, not
  technical
• Systems engineered for energy efficiency are
  actually more reliable, have lower operating
  costs, and can result in higher productivity

14
Industrial Systems Energy Efficiency
System efficiency 13
15 kW motor efficiency 91
Combined motor pump efficiency 59
Adapted from Don Casada (Diagnostic Solutions)
15
Why are these systems so inefficient?

• Most managers are unaware that these systems are
  energy inefficient
• System performance is not measured
• No data no way to assess performance or
  performance improvement
• Management focus on production, not energy
  efficiency
• Separate budgets for equipment
• purchases and operating budgets

16
Save Energy Now initiative

• The U.S. Department of Energy (DOE)
• Created initiative in 2006 based on more than a
  decade of experience in industrial system energy
  efficiency
• Trains DOE energy experts to work with plant
  energy teams to identify opportunities for
  improving steam, process heating, pump, or
  compressed air systems through Energy Savings
  Assessments (ESAs)
• Together with energy experts, trains plant
  personnel to apply DOE software analysis tools to
  identify additional opportunities
• Recognizes plants with high energy savings
  resulting from implementation
• http//www.eere.energy.gov/industry/saveenergynow/

17
USDOEs Save Energy Now Energy Savings
Assessment Status (March 15, 2007)

• 303 assessments completed
• Implemented energy savings 13.1 TBtu/ 69.6
  million
• Planned energy savings 27.4 TBtu/334
  million
• Identified total energy savings 55.5 TBtu
• Identified energy cost savings gt 548 million
• Total potential carbon dioxide (CO2) emissions
  reduction 3.6 million metric tons

18
Target-setting Programs

• Industrial sector target-setting programs are
  common
• Range from voluntary to mandatory
• Targets can be set for either industrial
  sub-sectors or industrial facilities
• Typically based on signed agreements committing
  upper management to reaching targets
• Some include energy or GHG taxes
• Some include emissions trading
• Supporting policies and programs are essential
  for assisting industry in reaching ambitious
  targets

19
Industrial Target-Setting Supporting Policies
and Programs

• Informational campaigns
• Energy management standards
• Energy audits, system assessments, benchmarking
• Assistance in preparing inventories, identifying
  opportunities, developing energy management plans
• Financial assistance and incentives

• Government and public recognition
• Relief from additional regulations or exemptions
  from regulations
• Reduced or avoided energy/GHG taxes
• Penalties for non-compliance stricter
  environmental permitting, penalty fees, energy or
  CO2 tax
• Emissions trading

20
Examples of Industrial Target-Setting Programs

• Netherlands
• 20 energy efficiency improvement by 2000 (1989
  baseline)
• Long-Term Agreements contracts between the Dutch
  Minister for Economic Affairs and associations
  representing 29 industrial sectors (1250 firms)
  representing 90 of industrial energy consumption
• U.K.
• 20 CO2 emissions reduction by 2010 (1990
  baseline)
• Climate Change Agreements Government signed
  agreements with either industrial sector
  associations or individual companies representing
  44 sectors (about 5,000 companies and 10,000
  facilities) responsible for 90 of
  energy-intensive industry
• China
• 20 reduction of energy use per unit of GDP by
  2010 (2005 baseline)
• Top-1000 Energy-Consuming Enterprises contracts
  between Provincial governments and 1000
  enterprises representing 48 of industrial energy
  consumption and 30 of total energy consumption
  in China

21
Netherlands Long-Term Agreements on Energy
Efficiency

• Results
• Overall energy efficiency savings of 22.3
  realized
• 157 PJ or 9 MtCO2/year saved
• 1/3 to 1/2 of the savings stimulated by the
  agreements (remainder was autonomous)
• Cost to government of program was 10-20/tCO2
  saved, depending upon whether full costs of all
  subsidies are included
• Industry realizing 650 M per year in reduced
  energy costs

improvement in energy efficiency, 1989-2000
22
UK Climate Change Agreements

• Goal Carbon savings of 9.2 MtCO2 between 2000
  and 2010 (2.5 MtC) which is ten times the
  estimated savings from the Levy without the
  agreements
• Climate Change Levy tax on energy (natural gas,
  coal, LPG, electricity)
• Companies that agree to and achieve GHG emissions
  reduction targets receive an 80 Climate Change
  Levy discount
• Company that does not enter into an agreement and
  does not reach its target must pay 100 of the
  energy tax
• Supporting Policies and Programs
• Carbon Trust an independent body to promote
  carbon reductions in industry and commerce
  provides site visits, advice, information and low
  costs loans for energy efficiency projects
• Enhanced Capital Allowance Scheme 100 tax
  allowances on capital spending on energy saving
  equipment (specified in a government list)
  against taxable profits for the year during which
  a business make the investment
• Domestic Emissions Trading Scheme
• Light Touch on energy efficiency regulation

23
UK Climate Change Agreements

• Results
• 2001-2002 reductions of 16.4 MtCO2
• 2003-2004 reductions of 14.4 MtCO2
• Sectors did better than expected because industry
  underestimated what they could achieve via energy
  efficiency
• Industry is saving over 832 M/year on the energy
  it has not purchased as a result of meeting the
  CCA targets, in addition to the savings on the
  Climate Change Levy itself

24
Superior Energy Performance Partnership

• A partnership between industry and government
  to accelerate US industrys energy efficiency by

• Delivering tools, training, technologies
  standards to all types of manufacturing plants
• Facilitating recognition and incentives for
  effective industrial energy management and energy
  efficient technology adoption

• Partners
• U.S. Industry
• U.S. Department of Energy Industrial Technologies
  Program
• U.S. Environmental Protection Agency ENERGY STAR
  Program
• U.S Department of Commerce Manufacturing
  Extension Partnership
• American National Standards Institute

25
Vision By 2017
US industry improves energy intensity by 25 from
2007

• US Industrial Sector
• A world leader in energy efficiency
• Known for best-in-class plants for
  energy-efficient technology
• A leading exporter of energy efficiency
  technologies and solutions
• Staffed by and working with engineers with
  extensive energy management expertise
• Driven by the performance of manufacturing plants
• using ANSI-certified energy management systems
• implementing system assessment protocols

• Leading US Corporations
• Over 100 major corporations
• Have integrated energy management into their
  business strategy
• Improved their energy intensity by more than 25
  from 2007 to 2017
• Assist their plants and supply chain in becoming
  ANSI certified for energy efficiency

• US Manufacturing Plants
• 25 of the 200,000 U.S. plants with 10 employees
  (50,000 plants) have adopted basic energy
  management principles
• 5,000 plants are certified by an ANSI accredited
  organization for energy management committed to
  continuous improvement in energy efficiency

26
Superior Energy PerformanceInterim Steering
Committee

• Interim Steering Committee Members
• Representative Organization
• Bill Allemon Ford
• Joe Almaguer Dow Chemical
• Bill Bailey DuPont
• Sean Diamond Texas Petrochemical
• Tom Dunn Weyerhaeuser
• Betsy Dutrow EPA
• Fred Fendt Rohm and Haas
• Martha Gibbons IPSCO Steel
• Jim Hoffman Huntsman Chemical
• Greg Jason Cargill
• Brad Reed Toyota
• Paul Scheihing DOE ITP
• Steve Schultz 3M
• Dan Pitkin NIST
• Don Verdiani Sunoco
• Glen Wieger Eastman Chemical
• Jeff Yigdall PPG

• Address need for a consistent, performance-based
  framework that fosters continuous progress in
  industrial energy efficiency
• The proposed framework provides a mechanism to
  help individual companies
• Assign greater value to energy efficiency
  improvements
• Verify the resulting energy savings
• Receive public recognition for achievements
• Lay the groundwork for carbon and energy
  efficiency credits

27
What is a Corporate Partner?

• Energy Policy Act (EPAct) of 2005, Section 106
• Voluntary Commitments to Reduce Industrial Energy
  Intensity
• Authorizes the Secretary of Energy to enter into
  voluntary agreements with industrial firms that
  consume significant amounts of energy to reduce
  the energy intensity of their production
  activities
• Participating companies agree to a 25 energy
  intensity reduction goal over 10 years
  (2007-2016) or an average of 2.5 per year from
  date the corporation joins the program
• Requires DOE to recognize and publicize the
  achievements of participants
• Partner may receive
• Early credit for energy intensity improvements
  and carbon reductions
• For high-performers, preference in RDD
  solicitations
• Enhanced technical assistance from DOE to
  achieve energy intensity goals and to assist
  corporations plants and supply chain to become
  ANSI certified.

28
What is a Partner Plant?

• Any size industrial facility, regardless of their
  level of experience in energy management, that
• Seeks to accelerate existing energy efficiency
  efforts
• Participates in self assessment of energy
  management practices
• Takes steps to save energy
• Benefits
• Develop baseline on energy use
• Begin actively managing energy use
• Identify energy cost savings opportunities
• Recognition for efforts

• Tools Resources
• Quick Start website
• Energy management guidelines
• Plant Energy Profiler
• System optimization training
• Assessments
• Software tools
• Access to qualified specialists
• Opportunity calculator

29
What is an ANSI-accedited Certified Plant?

• Meets ANSI Energy Management Standard (revision
  of existing ANSI standard)1
• Applies System Assessment Standards for
  industrial systems (initially pumping, compressed
  air, steam, process heating) to assess plant
  facilities
• May use Certified Practitioners, recognized by
  third party (details TBD), to assist in
• Complying with energy management standards
• Implementing system assessment standards
• Uses an ANSI-accredited process to independently
  verify energy savings and compliance with the
  ANSI Energy Management Standards

1 ANSI MSE 20002005. Note the International
Organization for Standardization (ISO) is
undertaking work on an international energy
management standard in 2008.
30
How Does a Plant Become Certified?

• Current Proposal
• The plant achieves validated initial energy
  intensity performance improvement via
• Compliance with ANSI Energy Management Standard
• AND
• implementation of gt30 of total Btu energy
  savings opportunities that meet the companys IRR
  and as identified by system assessment standards,
  OR
• demonstrates energy intensity improvement of gt5
  over past two years OR
• meets or exceeds the best practice threshold
  (TBD) from the application of each system
  standard.
• Note some fee structure will be associated
  w/certification

31
Superior Energy Performance Timeline

• Tax credits
• Potential carbon credits
• OTHER ?

INCENTIVES

• Recognition (ENERGY STAR, other)
• Access to low-interest capital
• Market value
• ITP resource commitment

2008
Save Energy Now Partner Plant
Save Energy Now Corporate Partner Agreement
Pilot Certification
Certified Plant (ANSI accredited
ENERGY STAR Plant
32
Resources

• LBNLs industrial energy use website
  http//industrial-energy.lbl.gov
• Energy management information http//industrial-e
  nergy.lbl.gov/node/398
• Voluntary agreement information
  http//industrial-energy.lbl.gov/node/93
• Energy Management --UNIDO Experts Group Meeting
• http//www.unido.org/doc/64561
• UK Climate Change Agreements http//www.defra.gov
  .uk/environment/ccl/index.htm
• US DOE BestPractices http//www1.eere.energy.gov
  /industry/bestpractices/
• US DOE Save Energy Now http//www1.eere.energy.g
  ov/industry/saveenergynow/
• US EPA Energy Star for Industry
  http//www.energystar.gov/index.cfm?cindustry.bus
  _industry
• US EPA Climate Leaders http//www.epa.gov/statepl
  y/
• US ClimateVISION www.climatevision.gov
• US Superior Energy Performance
  http//www.superiorenergyperformance.net/

33
Contact Information

• Aimee McKane
• Lawrence Berkeley National Laboratory
• P.O. Box 790
• Latham, NY 12110
• 518 -782-7002
• atmckane_at_lbl.gov
