Intrusion Detection System Survey :: Collaborative Intrusion Detection System CIDS

1
Intrusion Detection System Survey
Collaborative Intrusion Detection System (CIDS)

• Yuhong Dong
• ydong_at_fau.edu

2
Collaborative Intrusion Detection
SystemPresentation Content

• CIDS Basic Concept
• CIDS Architecture
• Experiment
• Result
• Reference

3
Collaborative Intrusion Detection SystemConcept

• Multiple Intrusion Detectors
• -- Snort, Libsafe, Sysmon
• Multiple layers
• -- Network, Application, Kernel
• Manager
• --Graph-based and Bayesian-Based Inference
  Engine
• Mechanism
• -- Manager aggregates the alarms from different
  detectors and provides a alarm for an intrusion

4
Collaborative Intrusion Detection
SystemArchitecture (instance of CIDS)
5
Collaborative Intrusion Detection
SystemArchitecture (from system view)
6
Collaborative Intrusion Detection
SystemArchitecture (for Manager)
7
Collaborative Intrusion Detection
SystemArchitecture (for Event Dispatcher)
How does the Event Dispatcher works? -- Dispatch
event to local reference Engine according to
destination (DIP) --Group the event according to
the target process (PID)
8
Collaborative Intrusion Detection
SystemGraph-based Inference Engine
9
Collaborative Intrusion Detection
SystemBayesian Network-based Inference Engine
10
Collaborative Intrusion Detection
SystemExperiment

• Environment Red Hat Linux 8.0 with Apache web
  server version 1.3.24
• Simulation Electronic Store Front Workload with
  three Attack types Buffer Overflow Attack,
  flooding Attack, Script-Based Attack

11
Collaborative Intrusion Detection SystemResult
-- Performance Evaluation
12
Collaborative Intrusion Detection
SystemResult--Detection Effectiveness
Evaluation
13
Collaborative Intrusion Detection
SystemResultAttack Propagation Speed
14
Collaborative Intrusion Detection
SystemReference

• Collaborative Intrusion Detection System(CIDS) A
  Framework for Accurate and Efficient IDS
• Apache OpenSSL Attack at http//www.cert.org/adv
  isories/CA-2002-27.html
• Avaya Labs Research-ProjectLibsafe, At
  http//www.research.avayalabs.com/project/libsafe
• Kevin Murphy, Bayes Net Toolbox for Matlab,
  Athttp//www.ai.mit.edu/murphyk/Software/BNT/bnt
  .html
• Snort-Lightweight Intrusion Detection for
  Networks
• Apache Chunk Buffer Overflow Attack. At
  http//httpd.apache.org/info/security_bulletin_200
  20617.txt
