Protecting Confidential Client Data

1
Protecting Confidential Client Data!

• Presented by
• Insert Your Name Here

2
Agenda

• Background
• Sizing Up the Problem
• The Fix!
• Human Aspects
• Technology
• Local
• Remote
• Sharing
• Disposing of Old Data

3
Background
4
Sensational Headlinesdaily!

• Cyber-thieves shift nearly 450,000 from
  Carson,CA city coffers (May 2007) using keylogger
  software.
• T.J. Maxx data theft (some 45 million credit and
  debit card numbers) likely due to wireless
  wardriving, i.e. thief with a laptop, a
  telescope antenna, and a wireless LAN adapter
  (December 2006).

5
Sensational HeadlinesDaily!

• Veterans Administration announces confidential
  information of 26.5 million service personnel was
  stolen when employees home laptop was stolen
  (June 2006).
• Over 600,000 laptop thefts occurred in 2004,
  totaling an estimated 720 million in hardware
  losses and 5.4 billion in theft of proprietary
  information.

6
The Times are a Changing

• Over the next 3 years employees equipped with
  Notebooks or Tablet PCs will grow from 35 to 50
• 95 will be wirelessly enabled.
• Knowledge workers will be mobile 50 of the time
  working from home, office, hotels, airports,
  customer sites, etc.
• Iny 2008 75 of business cell phones will be
  smart phones (Blackberry, Treo, Communicator,
  etc.)
• Most have removable memory cards.
• In their present state they do not offer adequate
  security (file encryption, device kill,
  firewalling, authentication, tracking and
  logging).

7
The Times are a Changing

• Increase in mobility with devices roaming wild
  will cause a major upsurge in breaches
• Breaches may go undetected or undiscovered for
  long periods of time.
• Problem could easily become overwhelming
  (identity theft will look like childs play).

8
Information Security ManagementShort List

• Router/IP addressing
• Firewall
• Patches
• Anti-
• Virus
• Spam
• Spyware
• Passwords / Passphrases

• Unprotected Shares
• Personal Firewall
• Web-based e-mail/file sharing
• Wireless
• Physical Access
• Backups

9
Goals of IT Security

• Confidentiality
• Data is only available to authorized individuals
• Integrity
• Data can only be changed by authorized
  individuals
• Availability
• Data and systems are available when needed

10
OVERALL GOAL Reduce Risk to an Acceptable Level

• Just because it can happen doesnt mean it will.
• Put threats into perspective by assessing
• Probability of attack
• Value of business assets put at risk
• Business cost and consequence of attack
• REMEMBER no policy, procedure, or measure can
  provide 100 security

11
Sizing Up the Problem
12
Whats Confidential?

• Social Security
• Credit/debit card numbers
• Drivers license number
• Bank account numbers
• Birth dates
• PIN codes
• Medical records
• Mothers maiden name?

13
Where Is Confidential Data Stored?

• In-House Systems
• Physically secure?
• Network access restricted to only authorized
  individuals?
• Backup Media
• Physical location?
• Format?
• Remote Users
• Laptops, home computers memory sticks?

14
Who Has Access?

• Data access restricted to authorized individuals?
• Shared passwords shared data and no
  accountability
• Wide open network information free-for-all

15
The Fix
16
The Fix!

• In short
• Restrict access
• and/or
• Make it unreadable
• Data is made unreadable using encryption
  technology.

17
The Fix!

• Encryption
• Process of transforming information to make it
  unreadable to anyone except those possessing
  special key (to decrypt).
• Ciphers
• Algorithm or code used to encrypt/decrypt
  information.

18
The Fix!

• Encryption Ciphers

Ciphers
Classical
Rotor Machines
Modern
Substitution
Transposition
Private Key
Public Key
Stream
Block
19
The Fix!

• Things to remember about encryption
• Use modern, public standards!
• Longer key lengths are always better (increased
  computing power has made shorter keys vulnerable
  to cracking in shorter time)
• Private keys are optimal

20
Human Aspects

• Policy
• Who is allowed access?
• When is access allowed?
• What users are allowed to do?
• Where is data permitted to be
• Accessed from (devices locations?)
• Stored
• Network servers
• Desktops
• Laptops (data is now mobile)
• Thumb drives

21
Human Aspects Mitigating Risk

• Acceptable Use Policies
• Business data access rules who, where, when and
  what
• Supported mobile devices and operating systems
• Required security measures and configurations
• Process for usage monitoring, auditing and
  enforcement (check your state and local laws)
• Non-Disclosure Agreements (NDA)?
• Training Communication regular and often?
• Social Engineering
• Click here to download key logger!
• Phishing attacks are still highly effective for
  stealing
• Personal information
• Login information can then be used to access
  systems contain confidential data

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Technology Local

• Physical security
• Sensitive data located on secure systems
• Locked server room
• Locker server cage(s)

26
Storage Media

• Hard drive encryption Software-based
• Windows Encrypting File System (EFS)
• Supported on NTFS volumes (W2K, XP Vista)
• Encrypt/decrypt files and/or folders in real time
• Uses certificate issued by Windows

27
Storage Media

• Hard drive encryption Software-based
• Vista BitLocker
• Encrypts entire Windows Operating System volume
• Available with
• Vista Ultimate
• Vista Enterprise
• Third party, commercial encryption software
• TrueCrypt
• PGP Desktop Home

28
Storage Media

• Hard drive encryption Hardware-based
• Seagate Technology Momentus 5400 FDE.2 laptop
  drive features built-in (hardware) encryption
  (March 2007)
• Heart of the new hardware-based system is a
  special chip, built into the drive, that will
  serve to encode and decode all data traveling to
  or from the disk.
• Requires password to boot machine
• Disk is useless/inaccessible to others

29
Storage Media

• Phone home software
• Software that monitors machines and notifies
  system administrators regarding
• Who is using
• Where machine is located
• What hardware and/or software changes are made
• Example
• CompuTrace

30
Storage Media

• USB Thumb Drives
• Most older drives completely insecure
• If you want to store/transfer secure data on USB
  thumb drive, look for device that can
• Encrypt data
• Authenticate user

31

• USB anti-copy products
• Prevents data theft / data leakage and
  introduction of malware
• Manage removable media and I/O devices USB,
  Firewire, WiFi, Bluetooth, etc.
• Audits I/O Device usage
• Blocks Keyloggers (both PS2 and USB)
• Encrypts removable media
• Enables Regulatory Compliance
• Products
• Device Lock
• Sanctuary
• DeviceWall
• Safe End Port Protector

32
Authentication

• Authentication Factors
• What you know
• Passwords/passphrases
• What you have
• Tokens, digital certificates, PKI
• Who you are
• Biometrics (finger, hand, retina, etc.)
• Two factor authentication will become
  increasingly important.

33
Authentication

• APC BIOMETRIC PASSWORD MANAGER fingerprint reader
  - USB by APC (35 - 50)
• Hundreds of devices like this ranging from 25 -
  300.

34
Application Software

• In general, application passwords are poor
  protection (since most can be broken)
• e.g. Passware (www.lostpassword.com)
• Unlock 25 different applications including
  Windows, Office, Quick Books, Acrobat, Winzip,
  etc.

35
Mitigating Unsafe User Behavior

• Managed services key piece of security puzzle
• Spam, virus, content management and filtering,
  spyware, etc.
• Benefits
• Easier on the user
• Easier on IT
• Mobile devices should be periodically reviewed
• Currency of software and patches
• Health of machine
• User logs
• Recommendation Quarterly or Trimester

36
VPN (Virtual Private Network)

• A VPN is a private network that uses a public
  network (usually the Internet) to connect remote
  sites or users together. Instead of using a
  dedicated, real-world connection such as leased
  line, a VPN uses "virtual" connections routed
  through the Internet from the company's private
  network to the remote site or employee.

37

• Overview

38
VPN (Virtual Private Network)

• Benefits
• Extend geographic connectivity
• Reduce transit time and transportation costs for
  remote users
• Provide telecommuter support
• Improve security
• Reduce operational costs versus traditional WAN
• Improve productivity
• Direct printing to office
• Direct connect to network drives

39
VPN

• Use 3rd-party VPN service, e.g. HotSpotVPN,
  JiWire Spot Lock, Public VPN or WiTopia Personal
  VPN

40
Host-Based Computing

• Remote Control
• GoToMyPC - 14-34/month
• LogMeIn
• Symantec pcAnywhere
• VNC

41
Host-based Computing

• Windows Terminal Server

42
Digital Certificates

• Implement digital certificates for internally
  hosted corporate web resources or web-presence,
  e.g. E-mail, CRM, B2? site, etc. This allows all
  traffic to be encrypted via SSL (Secure Sockets
  Layer).
• Pad lock indicates traffic is being encrypted and
  the web site owners identity can be verified (by
  certificate authority).

43
Wireless Security Network Side

• DONT do a plug-n-play install!
• Password protect administrative setup
• Encryption
• WEP (good) remember to change keys regularly
• WPA (better)
• WPA2 (best)
• Enter authorized MAC addresses on WAP
• Use VPN or IPSec to encrypt all traffic
• Walk perimeter to determine whether rogue WAPs
  are active

44
Wireless Security - End Users

• No unprotected shares all shares turned off
• Ensure all mobile devices are updated with the
  latest security patches
• Only use SSL websites when sending/entering
  sensitive data (credit cards and personal
  identity information)
• Digitally sign data to make it difficult for
  hackers to change data during transport
• Encrypt documents that contain sensitive data
  that will be sent over the Internet

45
Wireless Security - End Users

• As a general rule (while not always possible) use
  WiFi for Internet surfing only
• Disable or remove wireless devices if they are
  not being used. This includes
• WiFi 802.11a/b/g/n
• Bluetooth
• Infrared
• Cellular
• Avoid hotspots where it is difficult to tell who
  is connected
• Ad-hoc/peer-to-peer setting should be disabled

46
WiFi Security - End Users

• WiFi Best Practices
• Use broadband wireless access (EvDO, 3G/GPRS,
  EDGE, UMTS) to make wireless connections
• Verizon and Sprint Broadband services are very
  fast - 59.99/month unlimited access
• Wireless carriers offer fairly good encryption
  and authentication

47
Wireless Recommendations

• Consider using specialized security software to
  help mobile users detect threats and enforce
  company policies
• Example - http//www.airdefense.net

48
Sharing Confidential Data

• Options
• E-mail
• FTP / Secure FTP
• Secure transmission programs
• Customer portal / extranet
• 3rd Party Hosted Data Exchange
• Digital Rights Management (DRM)

49
Sharing Confidential Data

• E-mail
• As a general rule, e-mail is insecure!
• In order to secure
• Digital Certificates / PKI
• PGP
• Verisign

50
Sharing Confidential Data

• Secure FTP
• Secure FTP utilizes encryption to transfer files
  in a secure manner.
• Can use a number of different strategies/approache
  s to accomplish.
• Due to complexity, not often utilized for sharing
  data with clients.

51
(No Transcript)
52
(No Transcript)
53
Sharing Confidential Data

• Client Extranets
• Internal
• Hosted
• e.g. ShareFile
• Branded!
• 100/mo.
• 30 employees
• Unlimited clients

54
(No Transcript)
55

• CipherSend - secure link embedded in E-mail
  message when clicked, brings up login screen
• 40/yr./user

56
Sharing Confidential Data
57
Digital Rights Management

• Evolving strategy utilizes a combination of
  technologies in order to control access to
  content.
• Incorporates
• Encrypted files file is locked until permission
  to access is granted by DRM Server.
• Digital Rights Management Server provides
  web-based permission to View/Edit/Copy/Print an
  encrypted document.
• Access granted based on date, version, user, etc.
• Content can be shared freely openly since
  access is separately governed by DRM Server.

58
Disposing of Confidential Data

• Remove media!
• Wipe media
• Software to overwrite drive multiple times
• Permanent magnet
• Destroy media
• Semshred www.semshred.com

59
Conclusion
60
Keys to Implementing a Successful Security
Strategy for Confidentiality

• Define the scope
• Users
• Devices (dont forget PDAs and smart phones)
• Locations
• Define your usage policies
• Communicate
• Get buy in (if they dont agree you wont be
  successful)
• Enforce with management tools
• Dont over engineer

61
Contact Information

• Insert Your Name
• Insert Firm Name Here
• Insert Address
• Insert Phone No.
• Insert email address
