Horizontal Diaphragms

1
Horizontal Diaphragms

• by Bart Quimby, P.E., Ph.D
• UAA Civil Engineering
• CE 434 - Timber Design

2
Lateral Forces

• Lateral forces result from either wind loading or
  seismic motion.
• In either case, the diaphragms are generally
  loaded with distributed loads.
• The example here is more closely associated with
  wind loading.

3
The Building
4
Tributary Areas
5
Loadings for Roof Diaphragm

• The upper beam diagram is for loading in the
  2 direction.
• The lower beam diagram is for loading in the
  1 direction.
• The distributed loads equal the pressure times
  the tributary height of the exposed area.
• The unit shears equal the beam reaction divided
  by the length of the edge.

6
Loadings for Floor Diaphragm

• Note that the unit shears at the ends of the
  diaphragm are the result of the interaction with
  the shear walls that are providing lateral
  support for the diaphragm.
• These forces are transferred to the shear walls.

7
Elements for Direction 1
8
Idealized Diagram for Dir. 1

• Green arrows are unit shears at edge of roof
  diaphragm.
• Yellow arrows are unit shears at edge of floor
  diaphragm.
• Shear in upper part of shear wall is from roof
  diaphragm only.
• Shear (red arrows )in lower part of shear wall
  includes both horizontal diaphragms.

9
Shear Wall Free Body Diagram
10
Elements for Direction 2
11
Idealized Diagram for Dir. 2

• Green arrows are unit shears at edge of roof
  diaphragm.
• Yellow arrows are unit shears at edge of floor
  diaphragm.
• Shear in upper part of shear wall is from roof
  diaphragm only.
• Shear (red arrows )in lower part of shear wall
  includes both horizontal diaphragms.

12
Shear Wall Free Body Diagram
13
Another View
Amrhein, James E Reinforced Masonry Engineering
Handbook, 4th edition
14
Diaphragms are Beams

• Like beams, diaphragms carry loads in bending.
• Wood diaphragms are considered to be simply
  supported.
• This results in both internal bending moment and
  shear.
• The diaphragm can be considered to be similar to
  a wide flange beam where the flanges (diaphragm
  chords) take all the bending and the web (the
  plywood sheathing) takes all the shear.
• In diaphragms, the shear force is expressed in
  terms of unit shear.

15
Beam Behavior of Diaphragms
Amrhein, James E Reinforced Masonry Engineering
Handbook, 4th edition
16
Diaphragm Forces in Dir. 1
C M / L1
M w(L2)2/8
v w(L2)/(2L1)
T M / L1

• Unit shear, v, equals the shear force, V, at a
  location along the span divided by the depth of
  the diaphragm at that location.
• Moment is taken by chord forces whose magnitudes
  equal the Moment at a particular location
  divided by the diaphragm depth at the same
  location.

17
Diaphragm Forces in Dir. 2
v w(L2)/(2L1)

• The diaphragm must be analyzed and designed to
  handle the forces in both principle directions.

M
C M / L2
T M / L2
18
Maximum Diaphragm Ratios2003 IBC

• IBC Table 2305.2.3 (text pg C.42) - Rules of
  Thumb used to control diaphragm deflections.
• If the span to width ratios are too large, then
  the diaphragm is not stiff enough to transfer the
  forces without significant deflection.
• Deflection is a function of beam bending, shear
  deflection, nail slip in diaphragm and slip in
  chord connections.

19
Shear Capacity of Horizontal Wood Diaphragms2003
IBC

• UBC Table 2306.3.1 (pgs C.45-C.47)
• Also see Special Design Provisions for Wind
  Seismic Table A.4.2A
• Shear capacity depends on the following design
  variables
• supporting member species
• plywood grade
• nail size (and penetration)
• plywood thickness (normally selected for vert.
  loads)
• support widths
• nail spacing
• blocking
• layup

20
Footnote a

• Use of supporting lumber species other than
  Douglas Fir or Southern Pine
• (1) find specific gravity of supporting framing
  (see NDS Table 11.3.2A, NDS pg 74)
• For Staples Use Structural I values multiplied
  by either 0.82 or 0.65 depending on specific
  gravity of supporting members.
• For Nails Use values from table for actual
  grade of plywood used multiplied by
  min(.5S.G),1

21
Footnote b

• Field nailing requirement
• Spacing of fasteners along intermediate framing
  to be 12 O.C. unless supporting member spacing
  equals 48 or more, then use 6 O.C. nail spacing.

22
Use With Wind Loads

• IBC-03 2306.3.1 states
• The allowable shear capacities in Table 2306.3.1
  for horizontal wood structural panel diaphragms
  shall be increased 40 percent for wind design

23
Some Definitions

• Nailing
• Boundary nailing Nailing at all intersections
  with shear walls. (parallel to direction of
  force.)
• Edge nailing nailing along any other supported
  plywood edge.
• Field nailing nailing along supports but not at
  a plywood edge.
• Layup cases (See IBC Table 2306.3.1)

24
Nailing Definitions
25
Chord Design

• The chords are axial force members that generally
  have full lateral support in both principle
  directions.
• The top plates of the supporting walls are
  generally used as the chord members.
• Due to the reversing nature of the loads being
  resisted, the chord forces are considered to be
  both tension and compression.
• Design as an axial force member.

26
Typical Chord

• Roof Chord Member

27
Example

• Consider the building introduced in the lecture
  on structural behavior

We spent some time determining forces in the
horizontal and vertical diaphragms (shear walls)
in an earlier lecture.
28
Applied Forces Wind
Direction 1 Roof 12,000 200 plf 2nd flr
6,300 105 plf
Direction 2 Roof 5,200 60 plf to 200
plf 2nd flr 4,200 105 plf
29
Roof Diaphragm Direction 1

• Parameters
• ½ C-DX plywood
• 2x Hem Fir Framing
• Vmax 150 plf
• Case I layup
• Design nailing for the diaphragm (IBC)
• Unblocked, 8d nails
• Vallow 1.4240 (1-(.5-.43))
• Vallow 313 plf gt Vmax

30
Roof Diaphragm Direction 2

• Parameters
• ½ C-DX plywood
• 2x Hem Fir Framing
• Vmax 43.3 plf
• Case 3 layup

• Design nailing for the diaphragm
• Unblocked, 8d nails
• Vallow 1.4180(1-(.5-.43))
• Vallow 234 plf gt Vmax

31
Roof Diaphragm Sheathing Summary

• After determining the needs in each direction the
  design of the roof can be specified.

• Result
• ½ C-DX plywood
• Unblocked
• 8d _at_ 6 O.C. Edge and Boundary nailing
• 8d _at_ 12 O.C. Field nailing

32
Roof Diaphragm Chords Direction 1

• Moment 90 ft-k
• Depth 40 ft
• Chord Force 2.25 k

33
Roof Diaphragm Chords Direction 2

• Moment 82.7 ft-k
• Depth 60 ft
• Chord Force 1.38 k

34
Chord DesignHem Fir 2

• Try (1) 2x4
• Check Tension
• Ft (525 psi)(1.6)(1.5)
• Ft 1260 psi
• ft 2250 / 5.25 in2
• ft 429 psi lt Ft

• Try (1) 2x4
• Check Compression
• Fc (1300 psi)(1.6)(1.15)
• Fc 2392 psi
• fc 2250 / 5.25 in2
• fc 429 psi lt Fc

(1) 2x4 is adequate in both directions
