Claire DeVaughan

1
Integrating Local Data Sets into The National Map

• Claire DeVaughan
• U.S. Geological Survey
• NSDI Partnership Office
• Austin, Texas

COGNA
October 20, 2004
2
Collaborative Projects

• Hospital Preparedness Data Set
• - Texas Department of Health (TDH)
• Critical Infrastructure Data Collection
• - Texas State University graduate level
  GIS class
• - TX Dept of Information Resources

3
Hospital Data Project Background

• Hospital Preparedness File owned by Texas
  Department of Health (TDH)
• Created for Homeland Security
• 577 hospitals
• Geocoded locations
• Variable accuracy
• Goal To improve the positional accuracy of the
  data

4
Geocoding
Process of assigning latitude and longitude to an
address
1100 W 49th Street, Austin TX 78756 gets
converted to 30.8215N Latitude and 97.735514W
Longitude
5
The Geocoding Process

• Requires
• Address file (e.g. street address)
• Street reference file (e.g. GDT, TIGER)
• Geocoding software
• GIS applications
• Stand-alone applications

6
Geocoding Accuracy Levels

• Street
• County
• Census block
• 5-digit Zip Code
• 9-digit Zip Code

7
Editing Process

• Utilizing ESRIs ArcMap 8.3
• View hospital data and Digital Ortho Quarter
  Quads (DOQQs)
• Zoom in to each hospital (stored as a point
  feature)
• Move the point feature to the correct location

8
North Austin Medical Center, Austin
9
Problems encountered

• Unable to locate hospital on DOQQs
• Cluttered urban areas
• DOQQs are dated 1995/1996
• Address data not complete or inaccurate
• Misspelled street name
• Street reference data quality issues
• Incomplete
• Incorrect

10
Alternative sources of information

• Geographic Names Information System (GNIS)
• Local data sets
• Websites (mapping and hospital)
• Telephone

11
Texas Medical Center, Houston
12
(No Transcript)
13
Huntsville Memorial Hospital, Huntsville
14
Fisher County Hospital District, Rotan
15
North Runnels Hospital, Winters
16
Pecos County Memorial Hospital, Fort Stockton
17
For this project, the average distance from each
geocoded point to each hospitals approximate
centroid was

• 9-digit Zip Code accuracy level
• 2.6 kilometers (1.5 miles)
• Street accuracy level
• 221 meters (725 feet)

18
Critical Infrastructure Project

• Goal Establish methodology for collection of
  location and attributes
• San Marcos study area 21.5 sq mi, population of
  40,000
• Base data was provided to the class, including
  GNIS, a local dataset, and USGS 124K topographic
  maps

19
Methods

• City of San Marcos street data and geocoding
  service in ArcMap
• Geocoding using geocode.com (Tele Atlas address
  database)
• GPS data collection variety of GPS receivers,
  ranging from 200- 4,000

20
San Juan Cemetery, Caldwell County
21
Redwood Cemetery, Guadalupe County
22
San Pedro Cemetery, Hays County
23
Pitts Cemetery, Hays County
24
York Creek Cemetery, Comal County
25
Guadalupe Cemetery, Hays County
26
Who has State GIS data sets?

• Education agencies (schools)
• Health department (hospitals, clinics)
• Dept. of Transportation (bridges)
• Parks and Wildlife Dept.
• Dept. of Environmental Quality
• Historical Commission
• Universities
• Department of Public Safety

27
Who has local GIS data sets?

• Council of Government (fire and police stations,
  libraries, schools)
• Counties, cities
• Tax Appraisal District

28
Comments orQuestions?

• Claire DeVaughan
• cdevaugh_at_usgs.gov
• 512-927-3583
