Performance Technology for Component Software - TAU

1
Performance Technology for Component Software -
TAU

• Allen D. Malony (U. Oregon)
• Sameer Shende (U. Oregon)
• Craig Rasmussen (LANL)
• Jaideep Ray (SNL, CA)
• Matt Sottile (LANL)

2
Overview

• Complexity and performance technology
• TAU performance system
• Developing performance interfaces for CCA
• Performance modeling and prediction issues
• Conclusions

3
Focus on Component Technology

• Emerging component technology for HPC and Grid
• Component software object embedding
  functionality
• Component architecture (CA) how components
  connect
• Component framework implements a CA
• Common Component Architecture (CCA)
• Standard foundation for scientific component
  architecture
• Component descriptions
• Scientific Interface Description Language (SIDL)
• CCA ports for component interactions
• CCA framework services (CCAFEINE)

4
Problem Statement

• How do we create robust and ubiquitous
  performance technology for the analysis and
  tuning of component software in the presence of
  (evolving) complexity challenges?
• How do we apply performance technology
  effectively for the variety and diversity of
  performance problems that arise in the context of
  CCA components?

?
5

• Tuning and Analysis Utilities
• Performance system framework for scalable
  parallel and distributed high-performance
  computing
• Targets a general complex system computation
  model
• nodes / contexts / threads
• Multi-level system / software / parallelism
• Measurement and analysis abstraction
• Integrated toolkit for performance
  instrumentation, measurement, analysis, and
  visualization
• Portable, configurable performance
  profiling/tracing facility
• Open software approach
• University of Oregon, LANL, FZJ Germany
• http//www.cs.uoregon.edu/research/paracomp/tau

6
TAU Performance System Architecture
Paraver
EPILOG
7
TAU Instrumentation

• Flexible instrumentation mechanisms at multiple
  levels
• Source code
• Manual (TAU API, CCA Measurement Port API)
• automatic using Program Database Toolkit (PDT),
  OPARI (for OpenMP programs), Babel SIDL compiler
  (proposed)
• Object code
• pre-instrumented libraries (e.g., MPI using PMPI)
• statically linked
• dynamically linked (e.g., Virtual machine
  instrumentation)
• fast breakpoints (compiler generated)
• Executable code
• dynamic instrumentation (pre-execution) using
  DynInstAPI

8
Program Database Toolkit
9
Program Database Toolkit (PDT)

• Program code analysis framework for developing
  source-based tools for C99, C and F90
  U.Oregon, LANL, FZJ Germany
• High-level interface to source code information
• Widely portable
• IBM, SGI, Compaq, HP, Sun, Linux
  clusters,Windows, Apple, Hitachi, Cray T3E...
• Integrated toolkit for source code parsing,
  database creation, and database query
• commercial grade front end parsers (EDG for
  C99/C, Mutek for F90)
• Intel/KAI C headers for std. C library
  distributed with PDT
• portable IL analyzer, database format, and access
  API
• open software approach for tool development
• Target and integrate multiple source languages
• Used in CCA for automated generation of SIDL
  CHASM
• Use in TAU to build automated performance
  instrumentation tools (tau_instrumentor)
• Can be used to generate code for performance
  ports in CCA

10
Extended Component Design
Extended Component Design
genericcomponent

• PKC Performance Knowledge Component
• POC Performance Observability Component

11
Performance Observation

• Ability to observe execution performance is
  important
• Empirically-derived performance knowledge
• Does not require measurement integration in
  component
• Monitor during execution to make dynamic
  decisions
• Measurement integration is key
• Performance observation integration
• Component integration core and variant
• Runtime measurement and data collection
• On-line and off-line performance analysis

12
Performance Observation Component (POC)

• Performance observation in aperformance-engineere
  dcomponent model
• Functional extension of originalcomponent design
  ( )
• Include new componentmethods and ports ( ) for
  othercomponents to access measured performance
  data
• Allow original component to access performance
  data
• Encapsulate as tightly-couple and co-resident
  performance observation object
• POC provides port allow use optmized interfaces
  ( )to access internal'' performance
  observations

13
Performance Observation Component
Performance Component
Measurement Port

• One performance component per context
• Performance component provides a Measurement Port
• Measurement Port allows a user to create and
  access
• Timer (start/stop, set name/type/group)
• Event (trigger)
• Control (enable/disable groups)
• Query (get functions, metrics, counters, dump to
  disk)

14
Measurement Port in CCAFEINE
Performance Component API

• namespace performance
• namespace ccaports class Measurement
  public virtual classicgovccaPort
  public virtual Measurement ()
  / Create a Timer / virtual
  performanceTimer createTimer(void) 0
  virtual performanceTimer createTimer(string
  name) 0 virtual performanceTimer
  createTimer(string name, string type) 0
  virtual performanceTimer createTimer(string
  name, string type,
• string group) 0 / Create a Query
  interface / virtual performanceQuery
  createQuery(void) 0 / Create a User
  Defined Event interface / virtual
  performanceEvent createEvent(void) 0
  virtual performanceEvent createEvent(string
  name) 0 / Create a Control
  interface for selectively enabling and disabling
  the instrumentation based on groups
  / virtual performanceControl
  createControl(void) 0

15
CCA Timer Interface

• namespace performance
• class Timer public virtual
  Timer() / Start the Timer. Implement
  these methods in a derived class to
  provide required functionality. / virtual
  void start(void) 0
• / Stop the Timer./ virtual void
  stop(void) 0 virtual void
  setName(string name) 0
• virtual string getName(void) 0
  virtual void setType(string name) 0
  virtual string getType(void) 0
• /Set the group name associated with the
  Timer (e.g., All MPI calls can be
  grouped into an "MPI" group)/
• virtual void setGroupName(string name)
  0 virtual string getGroupName(void) 0
• virtual void setGroupId(unsigned long group
  ) 0 virtual unsigned long
  getGroupId(void) 0

16
Control Class Interface
CCA Instrumentation Control Interface

• namespace performance
• class Control public Control ()
  / Control instrumentation. Enable
  group Id./ virtual void enableGroupId(unsig
  ned long id) 0 / Control
  instrumentation. Disable group Id. /
  virtual void disableGroupId(unsigned long id)
  0 / Control instrumentation. Enable
  group name. / virtual void
  enableGroupName(string name) 0 /
  Control instrumentation. Disable group name./
  virtual void disableGroupName(string name)
  0 / Control instrumentation. Enable
  all groups./ virtual void
  enableAllGroups(void) 0 / Control
  instrumentation. Disable all groups./
  virtual void disableAllGroups(void) 0

17
Query Class Interface
CCA Performance Query Interface

• namespace performance
• class Query public virtual
  Query() / Get the list of Timer names
  / virtual void getTimerNames(const char
  functionList, int numFuncs)
• 0 / Get the list of Counter names
  / virtual void getCounterNames(const char
  counterList, int numCounters)
  0 / getTimerData. Returns lists of
  metrics./ virtual void getTimerData(const
  char inTimerList, int numTimers,
  double counterExclusive, double
  counterInclusive, int numCalls, int
  numChildCalls, const char counterNames,
  int numCounters) 0 virtual void
  dumpProfileData(void) 0 virtual void
  dumpProfileDataIncremental(void) 0 //
  timestamped dump virtual void
  dumpTimerNames(void) 0 virtual void
  dumpTimerData(const char inTimerList, int
  numTimers)
• 0 virtual void dumpTimerDataIncrementa
  l(const char inTimerList, int
  numTimers) 0

18
Event Class Interface
CCA User Defined Event Interface

• namespace performance
• class Event public /
  Destructor / virtual Event()
  / Register the name
  of the event / virtual void
  trigger(double data) 0
• / e.g., size of a message, error in an
  iteration, memory allocated /

19
Measurement Port Implementation

• TAU component implements the MeasurementPort
• Implements Timer, Control, Query and Control
  classes
• Registers the port with the CCAFEINE framework
• Components target the generic MeasurementPort
  interface
• Runtime selection of TAU component during
  execution
• Instrumentation code independent of underlying
  tool
• Instrumentation code independent of measurement
  choice
• TauMeasurement_CCA port implementation uses a
  specific TAU measurement library

20
Using MeasurementPort
Using the Timer Interface An Example

• include "ports/Measurement_CCA.h"
• double MonteCarloIntegratorintegrate (double
  lowBound, double upBound,
  int count)
  classicgovccaPort port double sum
  0.0 // Get Measurement port port
  frameworkServices-gtgetPort ("MeasurementPort")
  if (port) measurement_m
  dynamic_cast lt performanceccaportsMeasurement
  gt(port) if (measurement_m
  0) cerr ltlt "Connected to something
  other than a Measurement port" return
  -1 static performanceTimer t
  measurement_m-gtcreateTimer(
  string("IntegrateTimer")) t-gtstart()
  for (int i 0 i lt count i)
  double x random_m-gtgetRandomNumber ()
  sum sum function_m-gtevaluate (x)
  t-gtstop()

21
TAU Component in CCAFEINE

• repository get TauMeasurement
• repository get Driver
• repository get MidpointIntegrator
• repository get MonteCarloIntegrator
• repository get RandomGenerator
• repository get LinearFunction
• repository get NonlinearFunction
• repository get PiFunction
• create LinearFunction lin_func
• create NonlinearFunction nonlin_func
• create PiFunction pi_func
• create MonteCarloIntegrator mc_integrator
• create RandomGenerator rand
• create TauMeasurement tau
• connect mc_integrator RandomGeneratorPort rand
  RandomGeneratorPort
• connect mc_integrator FunctionPort nonlin_func
  FunctionPort
• connect mc_integrator MeasurementPort tau
  MeasurementPort

22
SIDL interface for Timers

• //
• // File performance.sidl
• //
• version performance 1.0
• package performance
• class Timer
• void start()
• void stop()
• void setName(in string name)
• string getName()
• void setType(in string name)
• string getType()
• void setGroupName(in string name)
• string getGroupName()
• void setGroupId(in long group)
• long getGroupId()

23
Using SIDL Interface for Timers

• // SIDL
• include "performance_Timer.hh"
• int main(int argc, char argv)
• performanceTimer t performanceTimer_crea
  te()
• ...
• t.setName("Integrate timer")
• t.start()
• // Computation
• for (int i 0 i lt count i)
• double x random_m-gtgetRandomNumber ()
• sum sum function_m-gtevaluate (x)
• ...
• t.stop()
• return 0

24
Performance Knowledge Component

• Describe and store known components
  performance
• Benchmark characterizations in performance
  database
• Empirical or analytical performance models
• Saved information about component performance
• Use for performance-guided selection and
  deployment
• Use for runtime adaptation
• Representation must be in common forms with
  standard means for accessing the performance
  information

25
Performance Knowledge Repository

• Component performance repository
• Implement in componentarchitecture framework
• Similar to CCA componentrepository Alexandria
• Access by componentinfrastructure
• View performance knowledge as component (PKC)
• PKC ports give access to performance knowledge
• to other components back to original
  component
• Store performance model for performance
  prediction
• Component composition performance knowledge

26
Component Performance Model

• User specified
• Inferred automatically by performance tool
• Prior performance data
• Expression
• Parametric model
• Estimate performance of a single component by
• Querying runtime performance data
• Passing this to performance model for evaluation
• Integration of performance observation and
  knowledge components key to runtime selection of
  components

27
Applications Uintah (U. Utah)
Scalability analysis
28
Applications VTF (ASCI ASAP Caltech)

• C, C, F90, Python
• PDT, MPI

29
Applications SAMRAI (LLNL)

• C
• PDT, MPI
• SAMRAI timers (groups)

30
TAU Status

• Instrumentation supported
• Source, preprocessor, compiler, MPI, runtime,
  virtual machine
• Languages supported
• C, C, F90, Java, Python
• HPF, ZPL, HPC, pC...
• Packages supported
• PAPI UTK, PCL FZJ (hardware performance
  counter access),
• Opari, PDT UO,LANL,FZJ, DyninstAPI U.Maryland
  (instrumentation),
• EXPERT, EPILOGFZJ,VampirPallas, Paraver
  CEPBA (visualization)
• Platforms supported
• IBM SP, SGI Origin, Sun, HP Superdome, HP/Compaq
  Tru64 ES,
• Linux clusters (IA-32, IA-64, PowerPC, Alpha),
  Apple, Windows,
• Hitachi SR8000, NEC SX, Cray T3E ...
• Compilers suites supported
• GNU, Intel KAI (KCC, KAP/Pro), Intel, SGI, IBM,
  Compaq,HP, Fujitsu, Hitachi, Sun, Apple,
  Microsoft, NEC, Cray, PGI, Absoft,
• Thread libraries supported
• Pthreads, SGI sproc, OpenMP, Windows, Java, SMARTS

31
Concluding Remarks

• Complex component systems pose challenging
  performance analysis problems that require robust
  methodologies and tools
• New performance problems will arise
• Instrumentation and measurement
• Data analysis and presentation
• Diagnosis and tuning
• Performance engineered components
• Performance knowledge, observation, query and
  control
• Integration of performance technology

32
Support Acknowledgement

• TAU and PDT support
• Department of Energy (DOE)
• DOE 2000 ACTS contract
• DOE MICS contract
• DOE ASCI Level 3 (LANL, LLNL)
• U. of Utah DOE ASCI Level 1 subcontract
• DARPA
• NSF National Young Investigator (NYI) award
