Digital Repository Projects at the North Carolina State University Libraries

1
Digital Repository Projects at the North
Carolina State University Libraries

• James Jackson Sanborn
• Jim Tuttle
• Open Repositories/DSpace User Group 07

2
Early Repository Planning

• Digital Repository Planning Committee
• What it wouldnt be (at least to start)
• Distributed community structure
• Open submission
• Institutional Repository
• What it would be (at least to start)
• Library-managed collections
• Building block for campus partnership
• Learning opportunity

3
Repository Building Blocks

• NCSU Electronic Theses and Dissertations
• Started 1997
• Mandatory since 2002
• Virginia Techs ETDdb
• 3,000 ETDs
• NCSU Authors Database
• Started 1995
• Access Database/Cold Fusion front-end
• 22,000 citations

4
Repository Building Blocks (contd)

• Technical Reports Print Collection
• Campus Institutes and Departments
• Massive fall-off in print distribution
• Special Collections Resource Center
• Digitized texts and photographs
• Campus Newsletters
• GIS Data
• Library managed/acquired data collection
• Homegrown data layer database/discovery tools

5
Repository Plan

• Target Research collections first
• Technical Reports
• ETDs
• Faculty Publications/Citations
• Treat each collection as its own project
• Actively pursue common technological solutions

6
Technical Reports

• DSpace Application
• Lightly Customized
• Library Harvested
• Local Cataloging/Metadata database
• Scripted Ingest Object Creation
• Batch Ingest
• Mix of ongoing submission by institute/departmenta
  l personnel and Library capture.

7
Tech Rep Screenshot
8
Technical Reports Item Detail
9
Electronic Theses Dissertations

• Partnership with Graduate School
• Hybrid System DSpace and ETD-db
• ETD-db submission/approval/management
• Direct database extract for DSpace Ingest Object
  creation
• Scheduled Batch Ingest process
• DSpace Considerations/Alterations
• Metadata Mapping
• Author Browse (exclude contributor.advisor)
• Various interface changes

10
ETD-DB screenshot
11
ETD DSpace screenshot
12
Faculty Publications

• Built on Existing Author Database
• Rebuilt Authors DB from Access/ColdFusion to
  Oracle/PHP
• Re-modeled data
• Added Functionality
• OpenURL
• Vita-like citation display
• Full-text or submission links
• Full-text stored in DSpace
• Citation metadata and file exported by script
• DSpace Identifier currently manually entered

13
Faculty Publications Schematic
Scholar
Submit Citations and/or Text

View full-text
SR Citations
Web interface (php)
DSpace Item Display
Web Submission Form
PostgreSQL (metadata)
DSpace Java/JSP (full-text only)
Oracle Faculty Publications DB (citations)
Handle IDs
File System (files)
Access
ISI Ann. Reps Etc.
Add/Edit data
Cataloging and Coll. Mgt.
14
FacPubs Search Screen
15
FacPubs result screenshot
16
FacPubs Item screenshot
17
Repository Governance

• Internal
• Digital Repository Planning Committee
• Data Repository Architect
• External
• Faculty Repository Advisory Committee
• Partnerships with departments and institutes

18
NCGDAP Overview

• NDIIPP National Digital Information
  Infrastructure and Preservation Program
• Collaboration with Library of Congress
• 1 of 8 three year projects to study long-term
  (50 years) digital preservation
• Objective engage existing state/federal
  geospatial data infrastructures in preservation
• Project approaches Technical and Social

19
Repository Requirements

• Dim archive with possible future access
• minimal IR/access component
• Minimal repository imprint on data
• repository agnostic ingest and export
• Simple digital curation functions
• Periodic MD5 checksum validation
• Structured metadata index
• Expected archived-data exchange
• Leverage existing investments
• Free Software with active community

20
Automation Threat and format analysis,
validation

• Python wrappers for the following
• Anti-virus ClamAV
• Compressed files (tar, zip, gzip, bzip)
• At-risk formats
• Executable files (magic numbers)
• Jhove validation

21
AutomationArchive package organization

• ESRI ArcGIS toolbar for selected formats

22
AutomationArchive package organization

• Rule-based python logic
• filestem
• extension relationships ( multi-file format
  validation)
• directory structure
• Manual intervention
• NOID assignment

23
MetadataSeed file form

• 'Transfer set' metadata capture in 'Seed file'
• communicates with DSpace backend, generates xml
  used to inform later scripts

24
MetadataCommunities and Collections

• Search by type for 100 communities
• Facilitates creation and reduces errors

25
Curation Processing

• At-risk format migration, original retained
• Agency-specific XML templates in ArcCatalog with
  synchronization flags
• Provenance and curation metadata scripted

26
Source Metadata Translation

• Repository agnostic approach
• Spokes for each transformation
• Facilitates export from Dspace into other
  repositories
• Generate Dspace QDC, METS populate Workflow
  database

27
Extra-repository AIP management

• Workflow Management Database (WMD) populated as a
  spoke on the metadata/ingest hub
• External tracking of NOID, Handle, ISO keywords,
  other metadata for interaction with other systems
• Integrates with existing GIS Lookup tool

28
Repository Architecture Overview
PostgreSQL
One shared username. Separate database for each
app
repository tomcat instance
Tomcat DSpace Internal
Faculty Publications PHP/DSpace hybrid
NDIIPP (DSpace)
SCRC (DSpace)

• Repository
• (DSpace)
• Technical Reports
• ETDs

Collections (DSpace) SCRC --Course Catalogs
--Green N Growing
Asset Store/ ATABeast (sub-directory for each
DSpace app)
29
Upcoming Repository Related Projects

• Enhancements to current system
• XTF search interface
• Inter-archive exchange
• Digital Collections Repository
• Special Collections Research Center
• Other non-faculty collections
• Data Repository
• Scientific data
• Statistical resources

30
For More Information

• James Jackson Sanborn
• james_sanborn_at_ncsu.edu
• Jim Tuttle
• jim_tuttle_at_ncsu.edu
