Distributed Computing and Analysis

1
Distributed Computingand Analysis

• Lamberto Luminari
• Italo Hellenic School of Physics 2004
• Martignano - May 20, 2004

2
Outline

• Introduction
• General remarks
• Distributed computing
• Principles
• Projects
• Computing facilities testbeds and production
  infrastructures
• Database Systems
• Principles
• Distributed analysis
• Requirements and issues

3
General remarks

• Schematic approach
• For the purpose of clarity, differences among
  possible alternatives are stressed in reality,
  solutions are often a mix or a compromise
• Only main features of relevant items are
  described no aim of exhaustivity
• HEP (LHC) oriented presentation
• Examples are mainly taken from HEP world
• Projects with HEP community involvement are
  preferred
• Options chosen by LHC

4
Distributed Computing
5
Distributed computing

• What is it
• processing of data and objects across a network
  of connected systems
• hardware and software infrastructure that
  provides pervasive (and inexpensive) access to
  computational capabilities.
• A long story
• mainframes more and more expensive
• cluster technology
• RISC machines very powerful.
• What makes it appealing now
• CPU power!
• Storage capacity!!
• Network bandwidth!!!
• ... but Distr. Comp. is not a choice,
• rather a necessity or an opportunity.

6
Network performances
7
Advantages of distributed computing

• Scalability and flexibility
• in principle, distributed computing systems are
  infinitely scalable simply add more units and
  get more computing power. Moreover you can add or
  remove specific resources and adapt the system to
  your needs.
• Efficiency
• private resources are usually poorly used
  pooling them greatly increases their
  exploitation.
• Reliability
• failure of a component little affects the overall
  performances.
• Load balancing and averaging
• distributing tasks according to the availability
  of resources optimize the behavior of the whole
  system and minimize the execution time
• load peaks arising from different user
  communities rarely sum up, then the use of
  resources is averaged (and optimized) over long
  periods.

8
Disadvantages of distributed computing

• Difficult integration and coordination
• many heterogeneous computing systems have to be
  integrated
• data sets are splitted over different storage
  systems
• many users have to cooperate and share resources.

• Unpredictability
• the quantity of available resources may largely
  fluctuate
• computing units may become unavailable or
  unreachable suddenly and for long periods, making
  unpredictable the completion time of the tasks
  running there.
• Security problems
• distributed systems are prone to intrusion.

9
Applications and distributed computing

• Suitable
• high compute to data ratio
• batch processes
• loosely coupled tasks
• statistical evaluations dependent on random
  trials
• data mining through distributed filesystems or
  databases.
• Unsuitable
• real time
• interactive processes
• strongly coupled
• sequential.

10
Distributed computing architectures

• Peer-to-peer
• flat organization of components, with similar
  functionalities, talking to each other
• suitable for
• independent tasks or poor inter-task
  communication
• access to sparse data organized in a non
  hierarchical way.
• Client - server
• components with different functionalities and
  roles
• processing unit (client) provided with a
  lightweight agent able to perform simple
  operations detect system status and notify it to
  the server, ask (or wait) for tasks, accept and
  send data, execute processes according to
  priorities or in spare cycles, ....
• dedicated unit (server) provided with complex
  software able to take or send computing
  requests, monitor the status of the jobs sent to
  the clients, receive the results and assemble
  them, possibly in a database. It also takes care
  of security and access policy, and stores
  statistics and accounting data.
• suitable for
• complex architectures and tasks.

11
Multi-tier computing systems

• Components with different levels of service,
  arranged in tiers
• computing centers (multi-processors, PC farms,
  data storage systems)
• clusters of dedicated machines
• individual, general use PCs.
• Different functionalities for each tier
• amount of CPU power installed and data stored
• quality and schedule of user support
• level of reliability and security.

12
(No Transcript)
13
Distributed computing models

• Clusters
• groups of homogeneous, tightly coupled
  components, sharing file systems and peripheral
  devices (e.g., Beowulf)
• Pools of desktop PCs
• loosely interconnected private machines (e.g.,
  Condor)
• Grids
• heterogeneous systems of (mainly dedicated)
  resources (e.g., LCG).

14
Comparison of computing models
15

• Condor is a specialized workload management
  system for compute-intensive jobs. It provides
• a job queueing mechanism
• scheduling policy
• priority scheme
• resource monitoring
• resource management.
• Users submit their serial or parallel jobs to
  Condor, which places them into a queue, chooses
  when and where to run the jobs based upon a
  policy, carefully monitors their progress, and
  ultimately informs the user upon completion.
• Unique mechanisms enable Condor to effectively
  harness wasted CPU power from otherwise idle
  desktop workstations. Condor is able to
  transparently produce a checkpoint and migrate a
  job to a different machine.
• Condor does not require a shared file system
  across machines if no shared file system is
  available, Condor can transfer the job's data
  files on behalf of the user, or Condor may be
  able to transparently redirect all the job's I/O
  requests back to the submit machine.

16
resources
data
network
17
Distributed computing environment

• DCE standards
• A distributed computing network may include many
  different systems. The Distributed Computing
  Environment (DCE) formulated by The Open Group
  formalizes the technologies needed to make the
  components communicate with each other, such as
  remote procedural calls and middleware. DCE runs
  on all major computing platforms and is designed
  to support distributed applications in
  heterogeneous hardware and software environments.
• DCE provides a complete infrastructure, with
  services, interfaces, protocols, encoding rules
  for
• authentication and security (Kerberos, Public Key
  certificate)
• objects interoperability across different
  platforms (CORBA Common Object Request Broker
  Architecture)
• directories (with global name and cell name) for
  distributed resources
• time services (including synchronization)
• distributed file systems
• Remote Procedure Call
• Internet/Intranet communications.

18
Grid computing specifications

• The Global Grid Forum (GGF) is the primary
  organization whose purpose is to define
  specifications about Grid Computing. It is a
  forum for information exchange and collaboration
  among people who are
• doing Grid research,
• designing and building Grid software,
• deploying Grids,
• using Grids,
• spanning technology areas scheduling, data
  handling, security
• The Globus Toolkit (developed in Argonne Nat.
  Lab. and Univ. of Southern California) is an
  implementation of these standards, and has become
  a de facto standard for grid middleware because
  of some attractive features
• a object-oriented approach, which allows
  developers of specific applications to take just
  what meets their needs, to introduce tools one at
  a time and to make programs increasingly
  "Grid-enabled
• the toolkit software is open-source this
  allows developers to freely make and add
  improvements.

19
Globus toolkit

• Practically all major Grid projects are being
  built on protocols and services provided by the
  Globus Toolkit, a software "work-in-progress"
  which is being developed by the Globus Alliance,
  which involves primarily Ian Foster's team at
  Argonne National Laboratory and Carl Kesselman's
  team at the University of Southern California in
  Los Angeles.
• The toolkit provides a set of software tools to
  implement the basic services and capabilities
  required to construct a computational Grid, such
  as security, resource location, resource
  management, and communications.
• Globus includes programs such as
• Computing Element receives job requests and
  delivers them to the Worker Nodes, which will
  perform the real work. The Computing Element
  provides an interface to the local batch queuing
  systems. A Computing Element can manage one or
  more Worker Nodes

20
Globus Toolkit

• The Globus toolkit provides a set of software
  tools to implement the basic services and
  capabilities required to construct a
  computational Grid, such as security, resource
  location, resource management, and
  communications
• GRAM (Globus Resource Allocation Manager), to
  convert a request for resources into commands
  that local computers can understand
• GSI (Grid Security Infrastructure), to provide
  authentication of the user and work out that
  person's access rights
• MDS (Monitoring and Discovery Service), to
  collect information about resource (processing
  capacity, bandwidth capacity, type of storage,
  etc)
• GRIS (Grid Resource Information Service), to
  query resources for their current configuration,
  capabilities, and status
• GIIS (Grid Index Information Service), to
  coordinate arbitrary GRIS services
• GridFTP, to provide a high-performance, secure
  and robust data transfer mechanism
• Replica Catalog, a catalog that allows other
  Globus tools to look up where on the Grid other
  replicas of a given dataset can be found
• Replica Management system, which ties together
  the Replica Catalog and GridFTP technologies,
  allowing applications to create and manage
  replicas of large datasets.

21
OGSA the future?
22
Grid projects
and many others!
23
Grid projects

• UK GRIPP
• Netherlands DutchGrid
• Germany UNICORE, Grid project
• France Grid funding approved
• Italy INFN Grid
• Eire Grid project
• Switzerland - Network/Grid project
• Hungary DemoGrid
• Norway, Sweden NorduGrid

• NASA Information Power Grid
• DOE Science Grid
• NSF National Virtual Observatory
• NSF GriPhyN
• DOE Particle Physics Data Grid
• NSF TeraGrid
• DOE ASCI Grid
• DOE Earth Systems Grid
• DARPA CoABS Grid
• NEESGrid
• DOH BIRN
• NSF iVDGL
• Grid2003
• .

• DataGrid (CERN, ...)
• EuroGrid (Unicore)
• DataTag (CERN,)
• Astrophysical Virtual Observatory
• GRIP (Globus/Unicore)
• GRIA (Industrial applications)
• GridLab (Cactus Toolkit)
• CrossGrid (Infrastructure Components)
• EGSO (Solar Physics)
• EGEE

24
Middleware projects relevant for HEP

• EDG
• European Data Grid (EU project)
• EGEE
• Enabling Grids for E-science in Europe (EU
  project)
• Grid2003
• joint project of the U.S. Grid projects iVDGL,
  GriPhyN and PPDG, and the U.S. participants in
  the LHC experiments ATLAS and CMS.

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
LCG hierarchical information service
29
Replica management
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
Job submission steps (1)
35
Job submission steps (2)
36
Portals

• Why a portal?
• It can be accessed from everywhere and by
  everything (desktop, laptop, PDA, phone).
• It can keep the same user interface independently
  of the underlying middleware.
• It must be redundantly secure at all levels
• secure for web transactions,
• secure for user credentials,
• secure for user authentication,
• secure at VO level.
• All available grid services must be incorporated
  in a logic way, just one mouse click away.
• Its layout must be easily understandable and user
  friendly.

37
(No Transcript)
38
(No Transcript)
39
Computing facilities (1)

• Computing facilities (testbeds or production
  infrastructures) are made up of one or more
  nodes. Each node (computer center or cluster of
  resources) contains a certain number of
  components, which may be playing different roles.
  Some are site specific
• Computing Element receives job requests and
  delivers them to the Worker Nodes, which will
  perform the real work. The Computing Element
  provides an interface to the local batch queuing
  systems. A Computing Element can manage one or
  more Worker Nodes
• Worker Node the machine that will actually
  process data. Typically managed via a local batch
  system. A Worker Node can also be installed on
  the same machine as the Computing Element.
• Storage Element provides storage space to the
  facility. The storage element may control large
  disk arrays, mass storage systems and the like
  however, the SE interface hides the differences
  between these systems allowing uniform user
  access.
• User Interface the machine that allows users to
  access the facility. This is typically the
  machine the end-user logs into to submit jobs to
  the grid and to retrieve the output from those
  jobs.

40
Computing facilities (2)

• Some other roles are shared by groups of users or
  by thwe whole grid
• Resource Broker receives users' requests and
  queries the Information Index to find suitable
  resources.
• Information Index resides on the same machine as
  the Resource Broker, keeps information about the
  available resources.
• Replica Manager coordinates file replication
  from one Storage Element to another. Useful for
  data redundancy but also to move data closer to
  the machines which will perform computation.
• Replica Catalog can reside on the same machine
  as the Replica Manager, keeps information about
  file replicas. A logical file can be associated
  to one or more physical files which are replicas
  of the same data. Thus a logical file name can
  refer to one or more physical file names.

41
Computing facilities relevant for HEP

• EDG
• Testbed
• LCG
• Production infrastructure
• EGEE
• Production infrastructure
• Grid3
• Production infrastructure operated jointly by the
  U.S. Grid projects iVDGL, GriPhyN and PPDG, and
  the U.S. participants in the LHC experiments
  ATLAS and CMS.

42
(No Transcript)
43
(No Transcript)
44
LCG hybrid architecture
Multi-tier hierarchy Grids
45
(No Transcript)
46
EGEE Timeline

• May 2003 proposal submitted
• July 2003 proposal accepted
• April 2004 start project

47
Grid3 infrastructure
48
Virtual Organizations (User Communities)
I. Foster
49
Multi-VO and one Grid
Grid (shared resources and services)
50
One VO and multi-Grid
ATLAS Production System
51
Multi-VO and multi-Grid
Shared Resources and Services
VO services and private resources
VO services and private resources
Shared Resources and Services
Shared Resources and Services
VO services and private resources
VO services
VO services
52
HEP Requirements

• User requirements
• Concerning services, the HEP community has
  already made a lot of work within EDG and LCG.
  The basic requirements have already been
  specified as use cases for HEP data processing (
  HEPCAL report, May 2002). Using the HEPCAL
  document to provide templates for requirements
  analysis, the EDG/AWG(Application Working Group)
  aim at defining requirements for a high level
  common application layer based on the needs of
  HEP, Bio-medicine and Earth Sciences, and is.
  High level APIs for Grid Services have also been
  defined by the EU funded project Gridlab.
• Concerning resources, the production service must
  provide a continuous, stable, robust environment
  and a controlled, reliable access to the
  resources. The agreed sharing policies must be
  fully implemented and easily changeable.
• Besides implementing the user requirements,
  practical help should be given in interfacing the
  experiment applications to grid services, and to
  evaluate the performance of the software
  deployed within the production environment, as
  well as in pre-production testbeds.

53
Security

• Security Policy
• The security organizational model, often tailored
  so far on the needs and characteristics of
  homogeneous communities, should in the future be
  based on service needs of many heterogeneous
  V.O.s, introducing in the Grid organizational
  and security model a new complexity.
• CA Policy
• A European Grid Policy Management Authority is a
  prerequisite for running a Grid infrastructure
  both in Europe and worldwide. The Grid Security
  Infrastructure relies on trusted Certification
  Authorities (CA). It is therefore essential that
  a network of CAs, based on a commonly agreed set
  of requirements, is established and maintained in
  Europe.

54
VO management

• As more and more communities will join common
  production infrastructures, VO management is
  becoming crucial.
• Current technology offers support for rather
  static and large communities. The assignment of
  access rights is separated into two parts local
  resource administrators grant rights to the VO as
  a whole, while VO administrators grant them to
  individual members of the community.
• In the future there will be the need for small
  (even only two people), short-lived (of the order
  of few days) and unforeseen (dynamically
  discovered) VOs. The goal would be to provide a
  very fine-grained authorization and access
  control mechanism, where applicable based on
  global standards.

55
Resource allocation and usage

• Resource allocation and reservation
• In order to meet the needs of all the different
  Grid users, mechanisms will be required to
  control and balance usage of the resources
  (including networks) by highly demanding
  applications, and to categorise and prioritise
  jobs so that they can receive the required level
  of service.
• In particular, users should be able to allocate
  resources both immediately and in advance.
  Allocations must be restricted to authenticated
  users acting within authorized roles, the
  services available must be determined by policies
  agreed with the user organisations, and the
  aggregate services made available to VOs must be
  monitored to ensure adherence to the agreements.
• Resource usage and accounting
• A major issue is the control of usage of
  resources, once access to them has been
  established. This includes interfaces to
  traditional Usage Control mechanisms such as
  quotas and limits, and also the extraction and
  recording of usage for Budgeting, Accounting and
  Auditing purposes.
• The usage quotas may be owned either by
  individuals or by VO's, and specified both in
  site-specific or Grid-wide protocols. This will
  include the ability to allow enforcement of
  quotas across a set of distributed resources.

56
Organizational issues

• The need for resource sharing gives rise to a set
  of organisational issues to be faced, analysed
  and solved. Indeed, when a given organisation
  makes its own resources available on line
• Each organisation has its own decision and
  management independence the resources to be
  shared with other organisations should not
  jeopardize such independence.
• Each organisation has its own access policies.
  It's not true that everybody in the Grid can use
  everything, but it's true that new generations of
  network and grid technologies allow to define new
  sharing models. Each organisation should be able
  to decide on each individual data, on each
  individual resource and on which organisation
  have the access/use right.
• Each organisation has its own security policies
  University security policies are usually
  completely different from those of physics
  laboratory that works in close co-operation with
  government and the army. In order to guarantee a
  real resources sharing among different kinds of
  organisations, it's necessary to ensure the
  maximum level of flexibility in the management of
  the above mentioned issues.

57
Requirements in LCG

• Requirements are set by Experiments in the SC2
• Requirements and Technical Assessment Groups
  (RTAGs)
• On applications
• data persistency
• software support process
• mathematical libraries
• detector geometry description
• Monte Carlo generators
• applications architectural blueprint
• detector simulation
• On Fabrics
• mass storage requirements
• On Grid technology and deployment area
• Grid technology use cases
• Regional Center categorization

58
HEPCAL
LCG RTAG Common Use Cases for a HEP Common
Application Layer Requirements are given as a
set of use cases free of implementation details

• GENERAL USE CASES
• Obtain Grid Authorization
• Revoke Grid Authorization
• Grid Login
• Browse Grid Resources

59
HEPCAL

• DATA MANAGEMENT USE CASES
• Data Set (DS) Metadata Update
• DS Metadata Access
• DS Registration
• Virtual DS Declaration
• Virtual DS Materialization
• DS Upload
• Catalogue Creation
• DS Access
• DS transfer to non-Grid storage
• DS Replica Upload
• DS Access Cost Evaluation
• DS Replication
• Physical DS Instance Deletion
• DS Deletion
• Catalogue Deletion
• Read from Remote DS
• DS Verification
• DS Browsing

60
HEPCAL

• JOB MANAGEMENT USE CASES
• Job Catalogue Update
• Job Catalogue Query
• Job Submission
• Job Output Access or Retrieval
• Job Error Recovery
• Job Control
• Steer Job Submission
• Job Resource Estimation
• Job Environment Modification
• Job Splitting
• Production Job
• Analysis
• DS Transformation
• Job Monitoring
• Conditions Publishing
• Software Publishing
• Simulation Job
• Expt Software Dev for Grid

61
HEPCAL

• VO MANAGEMENT USE CASES
• Configuring the VO
• Configuring the DS metadata catalogue (either
  initially or reconfiguring).
• Configuring the job catalogue (either initially
  or reconfiguring).
• Configuring the user profile (if this is possible
  at all on a VO basis).
• Adding or removing VO elements, e.g. computing
  elements, storage elements, etc
• Configuring VO elements, including quotas,
  privileges etc.
• Managing the Users
• Add and remove users to/from the VO.
• Modify the user information ( privileges, quotas,
  priorities) either for single users or for
  subgroups of users within a VO.
• VO wide resource reservation
• The Grid should provide a tool to estimate the
  time-to-completion given as input an estimate of
  the resources needed by the job. This is needed
  in particular to estimate the access cost.
• There should be use cases for releasing reserved
  resources, and system use cases for what to do in
  case a user does not submit a job for which
  resources are reserved.
• VO wide resource allocation to users or
  groups/users of a VO
• Software (or condition set) publishing, i.e.
  making it available on the Grid

62
Database Systems
63
Database Systems
CERN IT DB Group

• Database
• one or more, large structured sets of persistent
  data. Usually associated with software to update
  and query the data. A simple database might be a
  single file containing many records, each of
  which contains the same set of fields, where each
  field is a certain fixed width. A database is one
  component of a database management system.
• Database Management System (DBMS)
• a set of programs (functions) that allows to
  manage the large, structured sets of persistent
  data, which make up the database, and provide
  access to the data for multiple, concurrent users
  whilst maintaining the integrity of the data. The
  DBMS is in charge of all the functionalities
  related to the database access, security,
  storage

64
Database Management Systems
CERN IT DB Group

• DBMS provides
• security facilities to prevent unauthorized users
  from accessing the system, using names and
  passwords to identify operators, programs and
  individual machines and sets of privileges
  assigned to them these privileges can include
  the ability to read, write and update data in the
  database
• lock facilities to maintain data integrity locks
  are used for read and write to chunks of data by
  doing this only one user at a time can alter data
  or users can be prevented from accessing data
  being changed. These requirements are referred as
  ACID (Atomicity, Consistency, Isolation and
  Durability)
• Atomicity all the parts of a transaction's
  execution are either all committed or all rolled
  back. All changes take effect, or none do. This
  ensures that there is not erroneous data in the
  systems or data which does not correspond to
  other data as it should.
• Consistency the database is transformed from one
  valid state to another valid state. A transaction
  is legal only if it obeys user-defined integrity
  constraints. Illegal transactions aren't allowed
  and, if an integrity constraint can't be
  satisfied the transaction is rolled back to its
  previously valid state and the user informed that
  the transaction has failed.
• Isolation the results of a transaction are
  invisible to other transactions until the
  transaction is complete.
• Durability once a transaction has been
  committed (completed), the results of a
  transaction are permanent and can survive future
  system and media failures.

65
Database Systems
CERN IT DB Group

• Databases are based on many different models,
  each of which is designed with a specific
  problem, industry or set of functions in mind.
  Here we attempt to look at the main types in some
  depth
• Relational Databases data are structured in a
  series of tables, which have columns representing
  the variables and rows that contain specific
  instances of data. Currently the most wide spread
  model.
• Object Oriented Databases information is stored
  as a persistent object, and not as a row in a
  table. User defines objects and operations which
  can be executed on them.
• Object Relational Databases relational systems
  to which object oriented functions are added.
  They allow data to be manipulated in the form of
  objects, as well as providing the traditional
  relational interface.
• Distributed Databases data are stored on two or
  more computers, called nodes, and that these
  nodes are connected over a network across a
  country, continent or planet.
• Multimedia Databases model for storing several
  different types of file i.e. text, audio, video
  and images in a single database.
• Network Databases organizes data in a network of
  linked records. A very early form of database,
  fast but not very adaptable, which is little used
  at present.
• Hierarchical Databases data are stored as
  records, linked with Parent-Child Relationships.
  Mostly used in the past on mainframes.

66
Relational Database Systems
CERN IT DB Group

• The Relational Model is one of the oldest models
  used for creating a database, and the one that is
  used by the majority of businesses today. It was
  first outlined in a paper published by Ted Codd
  in 1970. The relational model is based on Set
  Theory and Predicate Logic
• set theory allows data to be structured in a
  series of tables, which have columns representing
  the variables and rows that contain specific
  instances of data. These tables are organized
  using normalization, which is a process (derived
  from Normal Forms theory) of reducing the
  occurrences of repeated data by breaking it into
  smaller pieces and creating new tables (e.g.,
  personal data of a customer).
• predicate logic is the basis of the query
  language, i.e. the set of commands that allows to
  insert, retrieve, modify or delete data,
  according to some specified criteria. Data can
  also be virtually or effectively joined in new
  tables.
• The current standard for relational databases is
  set out in the Structured Query Language. Version
  2 of the language is currently in use with
  Version 3 expected to be released in the near
  future by the International Standards
  Organization (ISO) and American National
  Standards Institution (ANSI).
• The most widely used relational database systems
  are produced by Oracle Corporation, Microsoft,
  Sybase, IBM, but there is a large number of other
  RDBMS designed to be either a general system or
  for specific applications used in HEP, like MySQL
  and PostgreSQL.

67
Object Oriented Database Systems
CERN IT DB Group

• The ODBMSs were introduced to overcome many
  restrictions imposed by the relational model on
  certain types of data (mainly in case of huge
  amounts or complex structures). Its main
  advantage is the degree of low level control of
  the system it allows the programmer. This gives
  the programmer control of how the data is to be
  store and manipulated
• information is stored as a persistent object (and
  not as a row in a table). This makes it more
  efficient in terms of storage space requirements
  and ensures that users can only manipulate data
  in the ways the programmer has specified. It also
  saves on the disk space needed for queries, as
  instead of having to allocate resources for the
  results, the space required is already there in
  the objects themselves.
• Because of the specific low level methods used in
  a ODBMS, it is very difficult for third parties
  to produce add-on products. Whilst relational
  databases can benefit from software which has
  been produced by other vendors, users of ODBMS's
  either have to produce additional software in
  house, by contracting other firms or in
  collaboration with other organizations using the
  same system.
• The first commercially available object oriented
  DBMS became available in the mid-1980's. By the
  early 1990's there were a range of ODBMS's
  available from a variety of vendors.
  Objectivity/DB is the most widely used in HEP
  community.

68
Distributed Database Systems
CERN IT DB Group

• Distributed databases have the common
  characteristics that they are stored on two or
  more computers, called nodes, connected over a
  network. They are classified as homogeneous and
  heterogeneous
• homogeneous databases use the same DBMS software
  and have the same applications on each node. They
  have a common schema (a file specifying the
  structure of the database), and can have varying
  degrees of local autonomy. They can be based on
  any DBMS which supports this function, but it is
  not possible to have more than one DBMS type in
  the system. To be efficient, they have to have
  very large network connections and a lot of
  processing power.
• heterogeneous databases have a very high degree
  of local autonomy. Each node in the system has
  its own local users, applications and data and
  dealing with them itself, and only connects to
  other nodes for information it does not have.
  This type of distributed database is often just
  called a federated system or a federation. It is
  becoming more popular with organizations, both
  for its scalability and the reduced cost in being
  able to add extra nodes when necessary and the
  ability to mix software packages. Unlike the
  homogenous systems, heterogeneous systems can
  include different database management systems in
  the system. This makes them appealing to
  organizations since they can incorporate legacy
  systems and data into new systems.

69
Beyond standard Database Systems
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
Distributed Analysis
74
Distributed Analysis

• Within LCG a working group, with representatives
  from all LHC experiments is working on a
  blueprint architecture for grid services ARDA (A
  Roadmap to Distributed Analysis). This will
  serve as a first input to the EGEE Architecture
  team. The HEPCAL work is continuing in the
  framework of the LCG/GAG (Grid Applications
  Group), developing use cases and requirements for
  the analysis of physics data. This will also
  give important input to architecture and design
  work.
• GAG reports
• Hepcal
• Systematic descriptions of HEP Grid Use Cases
• CERN-LCG-2002-020 (29 May 2002)
  lcg.web.cern.ch/LCG/sc2/RTAG4/finalreport.doc
• Hepcal-prime cern.ch/fca/HEPCAL-prime.doc
• Hepcal 2
• Analysis Use Cases
• CERN-LCG-2003-032 (29 October 2003)
  lcg.web.cern.ch/LCG/SC2/GAG/HEPCAL-II.doc

75
ARDA working group mandate

• To review the current Distributed Analysis
  activities and to capture their architectures in
  a consistent way
• To confront these existing projects to the HEPCAL
  II use cases and the user's potential work
  environments in order to explore potential
  shortcomings.
• To consider the interfaces between Grid, LCG and
  experiment specific services
• Review the functionality of experiment-specific
  packages, state of advancement and role in the
  experiment
• Identify similar functionalities in the different
  packages
• Identify functionalities and components that
  could be integrated in the generic GRID
  middleware
• To confront the current projects with critical
  GRID areas
• To develop a roadmap specifying wherever possible
  the architecture, the components and potential
  sources of deliverables to guide the medium term
  (2 year) work of the LCG and the DA planning in
  the experiments.

76
ARDA Architecture
77
SEAL Overview
Shared Environment for Applications at LHC

• SEAL aims to
• Provide the software infrastructure, basic
  frameworks, libraries and tools that are common
  among the LHC experiments
• Select, integrate, develop and support foundation
  and utility class libraries
• Develop a coherent set of basic framework
  services to facilitate the integration of LCG and
  non - LCG software
• The scope of the SEAL project is basically the
  scope of the LCG Applications Area.

78
PROOF (Parallel ROOT Facility)

• Collaboration between core ROOT group at CERN and
  MIT Heavy Ion Group
• Part of and based on ROOT framework
• Uses heavily ROOT networking and other
  infrastructure classes
• Currently no external technologies
• The PROOF system allows
• parallel analysis of trees in a set of files
• parallel analysis of objects in a set of files
• parallel execution of scripts
• on a cluster of heterogeneous machines

79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
Useful links

• Projects
• EDG (European Data Grid) http//eu-datagrid.web.
  cern.ch/eu-datagrid/
• GGF (Global Grid Forum) http//www.gridforum.org
  /
• Globus http//www.globus.org/
• LCG (LHC Computing Grid) http//lcg.web.cern.ch/
  LCG/
• Pool (Pool Of persistent Objects for LHC)
  http//pool.cern.ch/
