Impact of Sensor Networks on Future InterNet Design

1
Impact of Sensor Networks on Future InterNet
Design

• David E. Culler
• University of California, Berkeley
• culler_at_cs.berkeley.edu
• Arched Rock Corporation
• dculler_at_archedrock.com
• NSF FIND Info Meeting
• 12-5-2005

2
What does the Internet look like in 10 years?
3
In 10 years

• 90 of the nodes on the Internet will embedded
  devices connected to the physical world
• Universal, host-host file-transfer and console
  access is the dominant usage pattern..
• NOT!
• So does it make sense to pay attention to the
  characteristics of these kind of nodes and
  applications in designing the future Internet?

4
Canonical Sensor Net Architecture Today
Patch Network
Sensor Node
Sensor Node
Sensor Patch
Gateway
Gateway
Transit Network (IP or not)
Access point - Base station - Proxy
Verification links
Other information sources
Data Service

• An Analysis of a Large Scale Habitat Monitoring
  Application, Szewczyk, Polastre, Mainwaring,
  Anderson, and Culler, Sensys04

5
The Next Tier
Clients
Servers
Internet

• Small sensors will be the most common nodes on
  the internet
• How will they be represented and accessed?

6
How will SensorNets and IP play together?
XML / RPC / REST / SOAP / OSGI
?
HTTP / FTP / SNMP
TCP / UDP
IP
802.15.4, CC,
802.11
Ethernet
Sonet
7
Full IP stack throughout
XML / RPC / REST / SOAP / OSGI
HTTP / FTP / SNMP
TCP / UDP
IP
802.15.4, CC,
802.11
Ethernet
Sonet
8
Beware IP hype

• Transmitting HTML over a wireless connection to a
  serial port attached to a PC is NOT running IP on
  the sensor network

9
Where has Internet Research Reached and
struggled?

• Aggregate communication gt Multicast
• Resource constraints gt QoS, DIFFSERV
• Communicate with data or logical services, not
  just devices gt URNs (DHTs?)
• Mobility gt MobileIP, MANET
• In-network processing and storage gt ActiveNets
• Intermittent connectivity gt DTN ???

10
What are the main characteristics of Sensor
Networks?

• Aggregate communication
• dissemination, data collection, aggregation
• Resource constraints
• Limited bandwidth, limited storage, limited
  energy
• Communicate with data or logical services, not
  just devices
• Datacentric
• Mobility
• Devices moving, tags, networks moving through
  networks
• In-network processing and storage
• Really
• Intermittent connectivity
• Low-power operation, out of range, obstructions

11
Facing these challenges

• Today, we use a wide range of ad hoc, application
  specific techniques in the SensorNet patch
• Zillion different low-power MACs
• Many link-specific, app-specific multihop routing
  protocols
• Epidemic dissemination, directed diffusion,
  synopsis diffusion,
• All sorts of communication scheduling and power
  management techniques

12
Edge Network Approach
XML / RPC / REST / SOAP / OSGI
HTTP / FTP / SNMP
TCP / UDP
IP
802.15.4, CC,
802.11
Ethernet
Sonet
13
Hacking it in may not be so bad

• Security
• No IP to the nodes, attacks have to get through
  the gateway or be physically close
• Namespace management
• Name nodes, networks, services
• Hosts, URLs,
• Mask intermittent connectivity
• Terminate IP on the powered side
• Loosely couple, energy aware protocols on the
  other
• Distillation proxies
• Small binary packets where constrained
• Expanded to full text, XML, HTML, web services
• Rich suite of networking techniques in the Patch
  unimpeded by the ossification of the rest

14
Rethinking at Layer 7
15
Opportunity to rethink more deeply

• No dusty-decks yet
• Not a bunch of laptops running around with their
  sockets open trying to route through other
  laptops running around
• Meaningful set of applications and associated
  traffic loads
• Environments, individual objects, interactions
• Chance to think through control as well as
  monitoring
• Physical embedding matters
• Techniques are likely to apply to the rest of the
  Internet

16
Traditional Analysis
Delivered Performance
Offered Load
17
Analysis that really matters
Reliability
18
SensorNets need the Wisdom of the Internet
Architecture

• Design for change!
• Network protocols must work over a wide variety
  of links
• Links will evolve
• Network protocols must work for a variety of
  applications
• Applications will evolve
• Provide only simple primitives
• Dont confuse the networking standard with a
  programming methodology
• Dont try to lock-in your advantage in the spec
• Open process
• Rough consensus AND running code

19
XETF (Xternet Engineering and Technology Forum)
???

• Mission
• Foster an open, innovative, and technically sound
  ecosystem around interconnecting the physical
  world with modern networking and information
  technology through the creation of technical
  documents, protocols, reference implementations
  and APIs.
• Structure
• Lean. Volunteer BOD, steering comm., working
  groups.
• Membership
• Individuals, corporate, academic, and govt
• Participation
• Open. Role determined by contribution.
• IP Policy
• Non-confidential. Disclosure and Contribution
  process.
• Companies can develop own implementation.
• BSD? Apache-like credit? MPL? LGPL?
• Output
• RFC-like documents, reference implementations,
  forum for exchange and viz.
• Rough consensus AND running code

20
Uniting long-lost relatives
Instrumentation Computers
General Purpose Computing
21
Tides of Change
Innovation
Log Stuff
The Future Internet probably exists today go
find it
Time
22
Discussion
Thanks
