Classes, Objects, and Methods

1
Classes, Objects, and Methods
2
Overview

• What are classes, objects, and methods?
• Using objects and methods
• Declaring classes and methods
• Information hiding and encapsulation
• Objects and references
• Review

3
What are classes, objects, and methods
4
What are objects and classes?

• Objects can represent any particular object in
  the real world. Books, houses, automobiles,
  people, foods, etc. Sometimes called
  instantiations or instances.
• A class is a definition of a kind of object, like
  you could have a Book class that you define what
  kinds of objects books will be. It is like a
  blueprint.

5
What makes objects different from variables?

• Objects, like variables, have places to store
  data.
• Objects, unlike variables, have methods or
  actions that can be performed on those objects.
  We will see examples later.

6
Class example Book

• Data
• name of book
• author
• is it checked out
• who its checked out by
• Methods
• checkOut
• checkIn

7
Objects(instantiations) of Book
Like variable names. Identifies the
particular object.
Object name book1
name The Hobbitt author J.R.R. Tolkien is It
Checked Out Yes checked Out By Fred Stevens
Like the value or data stored inside of a
variable.
Object name ericsFav
name Dark Optimism author Alex Stein is It
Checked Out Yes checked Out By Eric Davis
Object name boringBook
name War and Peace author Leo Tolstoy is It
Checked Out No checked Out By null
8
Class definition of Automobile

• Data
• amount of fuel
• speed
• license plate
• Methods(actions)
• increaseSpeed
• stop

9
Instantiations(objects) of Automobile
Object name car1
Object name car2
fuel 10 gallons speed 15 mph license 1XV54
fuel 5 gallons speed 65 mph license SMOOD
Object name forSale
Object name ericsCar
fuel 2 gallons speed 0 mph license 142FG
fuel 12 gallons speed 45 mph license RVG224
10
What are methods?

• Methods are the actions that we call on the
  object to do (invoke).
• We tell a book to check itself out(by scanning
  it).
• We ask an automobile to accelerate(by pushing the
  gas).

11
Method examples
Object
Method
ericsCar.accelerate()
Ask ericsCar to accelerate. Only applies to this
one object. None of the other cars accelerate.
book1.checkIn()
12
Using objects and methods
13
Using objects and methods

• We have already been using objects and
  methods(possibly without realizing it).
• String is a class. .equals() is a method
• SavitchIn is a class. All of the readLine(),
  readLineInt(), readLineNonwhiteChar(), etc. are
  methods.

14
Declaring objects

• We declare objects of a class the same way that
  we declare variables of a type(we initialize them
  differently, though)

ltClassNamegt ltvariableNamegt String
userInput Book book1, book2, boringBook Automobi
le ericsCar, suesCar
15
Initializing objects

• Just as we would initialize variables to some
  default value(such as 0, or whatever), we also
  want to be able to initialize objects to a
  default value.
• Since objects can have lots of different types in
  them, we cant just set the object to a simple
  data value (such as 0). Instead we use the new
  operator.

16
Initializing objects
ltobjectNamegt new ltClassNamegt() or ltClassNamegt
ltobjectNamegt new ltClassNamegt()
userInput new String() //empty string book1
new Book() //default book Automobile newCar
new Automobile() Automobile usedCar new
Automobile()
17
Calling methods of an object

• Once we have an object initialized to something,
  we can start calling methods on that particular
  object(often called invoking). Usually need an
  object to call a method of the class

ltobjectNamegt.ltmethodNamegt(ltparametersgt) string1.
equals(string2) book1.checkIn() ericsCar.stop()

Sometimes the methods need some extra
information. This info is taken in through the
use of parameters.
Calling object
18
What about SavitchIn? We never declare objects
there and we use methods...

• Some classes have special methods (called static
  methods) that allow you to use the methods
  without requiring you to have an object.
• SavitchIn has static methods, as well as the Math
  class. So we can use the methods in these classes
  without declaring Math objects or SavitchIn
  objects.

19
Declaring classes and methods
20
Creating classes

• Every class that is usable by another program is
  called a public class.
• We can have only one public class per file, and
  the class name must match the filename(just like
  we have always been doing).
• As long as we keep the classes in the same
  directory, we should not have any problems with
  using other classes.

21
Declaring classes- general form
public class ltClassNamegt ltinstance variable
declarationsgt ... ltmethod declarations
and definitionsgt
Like author or title in the Book class, or
speed or gallons in the Automobile class.
Like checkIn or checkOut in Book, or
accelerate or stop in Automobile.
22
A first class- The Book example.

• The code in the following Book class (along with
  the BookTest class) can be found at
• www.cs.uaf.edu/cs103/Handouts/Book.java
• www.cs.uaf.edu/cs103/Handouts/BookTest.java

23
Book example instance variable declaration.
Means that others outside of the class have
access to read/write to this variable. Well
change this soon.
public class Book public String
author public String name public boolean
isCheckedOut public String checkedOutByWho ...
ltmethod declarations and definitionsgt
Variables usually arent initialized here. They
are usually initialized in a method or outside
the class
24
Class methods, declaration/definition

• Declaration of methods is giving the header of
  the method, that is telling whether the method is
  public, what it accepts as arguments or
  parameters, and what it returns. (interface)
• Definition of methods is the actual code that
  does the work for the method. (implementation)

25
Book example, methods
Usable by anyone
Doesnt return anything, just does something.
... public void checkOut() System.out.print("En
ter the name of the person that wants to
check " bookName " out") checkedOutBy
SavitchIn.readLine() isCheckedOut true ...
Whole line is the method declaration. (interface)
This whole section(often called the body) is
the definition of the method, the code that
actually does stuff.(implementation)
26
Book examples, methods
... public void checkOut() System.out.print("En
ter the name of the person that wants to
check " bookName " out") checkedOutBy
SavitchIn.readLine() isCheckedOut true ...
Imagine that this method was called using book1
as the calling object (book1.checkOut()). Then
the variables in this method would be book1s
version of the variables. So the variables in
this method would be the same as
... book1.checkedOutBy SavitchIn.readLine() b
ook1.isCheckedOut true ...
27
The this parameter.

• As we saw in the last slide, the instance
  variables used in a method refer to the
  particular calling objects variables (thus
  isCheckedOut referred to book1.isCheckedOut).
• Sometimes we write this.isCheckedOut to
  explicitly refer to the calling object (in this
  case it means the computer replaces the word
  this with book1.)
• Not used horribly often, but sometimes necessary.

28
Methods that take return values

• Unlike our Book example, not all methods take no
  information(no parameters) or return no
  information(void methods).
• Methods that require information be passed to
  them have a parameter list.
• Methods that return information have non-void
  types.

29
Methods that takereturn valuesTriangle
Example.
Returns nothing
... public void setBase(double baseIn) if(baseI
n gt 0) base baseIn else System.out.prin
tln("Incorrect base size. Must be
positive.") System.exit(0) ...
Parameter list requires that a double be
passed to this method when it is called.
30
Methods the takereturn valuesTriangle Example
continues
By the time this method finishes it will return a
double value.
... public double getHeight() return
height ...
Method takes no parameters
Gives the value height to whoever called this
method.
31
More on return statements

• You must always return the same type as is
  mentioned in the method declaration. If it says
  it is going to return a double, return a double
  variable.
• You may need to cast variables to return them.
• return (double)integer1
• If you are in a void method, you can still use
  return to exit the method, just dont have any
  value that is returned.
• return

32
More on parameters
public void someMethod(int x, double y)

• The above method declaration states that the
  method requires an int and a double to be passed
  to it, when called, in that order.
• int int1 1
• double double1 2.0 someObject.someMethod(
  int1,double1)
• The types of the variables need to match, but the
  names do not!
• In fact, the variable names are local to the
  method(they are not meaningful outside the
  method).

33
Local variables.

• All declared variables are local to the block
  in which they were declared. This means that they
  can not be used outside of that block. In Java,
  we also have the restriction that two variables
  can not have the same name inside a single
  method, whether they are in the same block or
  not.
• You can use the same variable name in two
  different methods, and each variable is
  completely unrelated to the other.

34
Local variable examples
...//variable i not initialized yet. for(int i
0 ilt10 i) System.out.println(i) System.o
ut.println(i) //wont work. ... if(true) int
k 10 System.out.println(k) //wont work ...
35
Local variables and parameters
public void someMethod(int x, double y)

• When we use the above method by calling it
• someObject.someMethod(4, 5.0)
• the computer takes the arguments that we pass
  in (the 4, and the 5.0) and it replaces the
  formal arguments (x, y) with the numbers wherever
  they occur in the method.

36
Local variable examples
... //in class SomeClass public void method1(int
x) double y 0.0 System.out.println(y
, x) public void method2(int x)
double y 10.0 System.out.println(y ,
x) ... //in another file using
SomeClass SomeClass x, y x.method1(1) x.method2(
1) y.method1(5) y.method2(5)
37
Local variable examples
... //in class SomeClass public void method1(int
x) double y 0.0 System.out.println(y
, x) public void method2(int x)
double y 10.0 System.out.println(y ,
x) ... //in another file using
SomeClass SomeClass x, y x.method1(1) x.method2(
1) y.method1(5) y.method2(5)
0.0, 1 10.0, 1 0.0, 5 10.0, 5
38
Parameter/argument rules

• You must specify the type before each formal
  parameter, even if they are all the same type
• public void someMethod(int x, int y, int z)
• When calling the method, you must specify the
  same number of arguments, as the same types, in
  the same order as is listed in the method
  declaration.
• someObject.someMethod(1,2) //wont work
• someObject.someMethod(1, c, 3) //wont work
• someObject.someMethod(1,2,3) //will work.

39
Declaring classes review

• Can we have more than one public class per file?
• How do we declare instance variables for a class?
• How do we declare methods for a class?
• If a method asks for 5 integers when it is
  invoked(5 integer parameters), do we have to
  supply all 5 when calling it?
• Can we access variables declared inside of a loop
  when we are outside the loop?

40
Information Hiding and Encapsulation
41
Information Hiding

• Information hiding, sometimes called
  abstraction, is the idea of hiding the details
  of the implementation (or how something is done)
  from the user, only giving them the what the
  method accomplishes.
• Information hiding is good.
• If you write a class with good information
  hiding, you can completely change the
  implementation without the user noticing a thing
  on their end.

42
Examples of information hiding

• You can drive a car without knowing anything
  about internal combustion engines, transmissions,
  or anti-lock brakes.
• You can read a watch without knowing about gear
  ratios, crystals, etc.
• Someone could rip out the guts of these objects
  and replace them with another implementation(a
  bigger engine, an atomic clock) and you likely
  would not know the difference.

43
Our goals as information hiders

• Create classes and methods that people can use
  without knowing the details of our code.
• Have classes and methods such that we can later
  change the implementation to something completely
  different without the user ever knowing.

44
Methods of information hiding

• Good comments!
• Private instance variables.
• Mutator and accessor methods.

45
Commenting

• Comment before each class and before each method
  in the class.
• For methods
• Preconditions What conditions must be satisfied
  before using this method. If the conditions are
  not satisfied, there is not guarantee that the
  method will work correctly.
• Postconditions What actions the method performs
  on the data. What is returned.
• If your commenting is good, you can use javadoc
  on your code to produce documentation.

46
public vs. private modifiers

• Up till now, we have used public modifiers for
  everything(methods, instance variables, classes).
  This means anyone can access them.
• To follow good information hiding techniques, we
  should always have only private instance
  variables (NO public instance variables).
• The private modifier makes it so only members of
  the class can access the private data(or
  methods). This means other objects of the same
  class can access private data.

47
How to get at private data.

• If all of the data in the class is private, how
  can a user get access to the data? Through our
  methods.
• If the user will need to be able to read the
  data(or you dont mind them reading it at least),
  then you can include an accessor method (a get
  method) for the data.
• If the user needs to write to the data, then you
  can include a mutator method (a set method).

48
A BetterBook
public class BetterBook private String
authorName private String bookName ... /
Get author
name /
public String getAuthorName() return
authorName /
set author name
/
public void setAuthorName(String newAuthorName)
authorName newAuthorName ...
49
A BetterBook example
... book2.setAuthorName("Alex Stein")//the hard
way. book2.setBookName("Dark Optimism") ...
50
Encapsulation

• Encapsulation is a form of information hiding.
• The idea is to split the class definition into
  two parts user interface and the implementation.

• We have already been talking about good ways to
  do encapsulation.
• Though you need the implementation to run a
  program that uses a class, you should not need to
  know anything about the implementation to write
  code that uses the class.

51
Encapsulation review- ways to have good
encapsulation

• Good Comments! Before each class and method.
• Private instance variables (and any helper
  functions the user doesnt need, but you like).
• Mutator and accessor methods(if necessary).

52
Did I do encapsulation well?

• Does the user require knowledge of your
  implementation to use your class?
• Can you make a program using your class, change
  the implementation of the class, and still have
  your other program run correctly? If so, then you
  have created good encapsulation/information
  hiding for your class.

53
Review- Encapsulation and Information Hiding

• What is information hiding?
• What keyword do we use to hide our information?
• How do we allow others access to our hidden
  information?
• What kinds of instance variables should we never
  have anymore?
• What should we have at the beginning of every
  class and method?

54
Objects and References- The nitty gritty of
Objects.
55
Objects- what are they really?

• When we declare an object in our program, the
  variable name that we use for it doesnt really
  refer to the whole object, it only refers to the
  memory address that contains the information in
  our object.
• Thus assignment() and equality() statements
  between objects are looking at only the memory
  addresses of the objects, not the actual data
  inside the object.

56
Objects and primitive storage
int i 0 BetterBook book1 new BetterBook()
i
0
2054
book1
book2
1036
BetterBook book2 new BetterBook()
1036
? ? ? ?
2054
? ? ? ?
57
Objects and primitive storage
int i 0 BetterBook book1 new BetterBook()
i
0
2054
book1
book2
1036
BetterBook book2 new BetterBook() book1.setAut
horName( Roald) book1.setBookName( Some) b
ook2.setAuthorName( Stein) book2.setBookName(
Short)
1036
Stein Short ? ?
2054
Roald Some ? ?
58
Objects and primitive storage
int i 0 BetterBook book1 new BetterBook()
i
0
1036
book1
book2
1036
BetterBook book2 new BetterBook() book1.setAut
horName( Roald) book1.setBookName( Some) b
ook2.setAuthorName( Stein) book2.setBookName(
Short) book1book2
1036
Stein Short ? ?
2054
Roald Some ? ?
Garbage. Not accessible.
59
Moral of the story

• Dont use or when using classes. It wont
  work like you expect.
• So we need ways of assigning the value of one
  object to another and of comparing two objects.
• We do these operations by defining an equals()
  method in every class and by defining a clone()
  method.

60
Defining an equals()

• For class SomeClass we would define an equals as
  follows

public boolean equals(SomeClass
otherObject) //compares all the data to see if
it // is true.
61
Triangle example
public boolean equals(Triangle otherTri) if((th
is.base otherTri.base) (this.height
otherTri.height)) return true else retur
n false
tri1
tri2
Triangle tri1 new Triangle(), tri1 new
Triangle() tri1.setBase(1) tri2.setBase(1) tri1
.setHeight(2) tri2.setHeight(3) if(tri1.equals(t
ri2)) System.out.println(They are
equal) else System.out.println(They are
different)
62
The difference between Class parameters and
primitive parameters.

• Primitive values are passed by value so you are
  not allowed to make any changes to the parameter
  value that will last outside the method.
• Class parameters are passed by reference so you
  can make changes to the data in the object and it
  will still be changed after the method is over.

63
Triangle example.
public void makeEqual(Triangle otherTri) otherT
ri.base this.base otherTri.height
height public void tryMakeEqual(int inbase,
int inheight) inbase this.base inheight
this.height ... tri1.tryMakeEqual(tri2.getBas
e(), tri2.getheight()) tri1.makeEqual(tri2)
Does nothing to tri2
Sets tri2 equal to tri1
64
Class details review

• What does the object name really store in memory?
• How do we compare two objects?
• What is the difference between Class parameters
  and primitive parameters?

65
Review
66
Review questions to ask yourself

• What are classes? What are objects? What are
  methods?
• How are classes and objects related?
• How many public classes can I have in a file?
• What keyword do we use to initialize a new object
  of some class?

67
Review questions to ask yourself

• What are instance variables?
• What keyword should I put before all of my
  instance variables?
• What is the difference between public and
  private?
• Why do we want to encapsulate or hide our
  information?

68
Review questions to ask yourself

• What are parameters and arguments?
• What keyword do you use if your method is not
  going to return any data?
• What keyword do you use if your method is going
  to return data?
• What does the this keyword refer to?
• How many arguments need to be passed to the
  following method? What types are they?

public void someMethod(int x, double y, char x)
69
Review questions to ask yourself

• What do we call the methods that let us get at
  private data (2 of them)?
• What should we have at the beginning of every
  class and method?
• What does an object name actually store in
  memory?
