Java Business Integration JSR 208

1
Java Business IntegrationJSR 208

• Chin-Yi Tsai
• cyt_at_pmlab.iecs.fcu.edu.tw
• http//140.134.26.25/cyt

2
Integration Difficulties
3
Integration Solution
Services (WS-I)
(interoperability)
Components (pluggable) (interoperability)
4
Specification(?Java EE 5????)Java Business
IntegrationJSR 208
JBI-Compliant Component1
JBI-Compliant Component2
5
ESB, SOA, JBI

• ESB
• Architecture technique to integrate incompatible
  business applications over a common messaging
  bus.
• Unlock and extend your existing systems and
  technology investments on a modern Service
  Oriented and Event Driven Architecture
• SOA
• An architectural principle for structuring
  systems that SOA emphasizes the de-coupling of
  system components
• ESB SOA
• ESB is one architecture style that abides by the
  rules of a Service Orientated Architecture.
• JBI
• Defines common interfaces (SPI) for components
  and message exchanges and service deployment.

6
What Does a Service Do

• Transform data
• Route messages
• Query databases
• Orchestrate conversations
• Apply business logic
• Apply business policy
• Handle business exceptions
• Solicit approvals

How Is a Service Implemented?

• XSLT
• Enterprise JavaBeans. (EJB.) technology
• BPEL
• SQL
• XQuery
• Routing Table
• Business Rules
• EDI Transform

7
Outline

• Overview of JBI
• integration
• JBI Architecture
• SE
• BC
• NMR
• JMX (Management)
• Conclusion (Keywords)
• Reference
• Appendix

8
Overview of JBI

• Standard meta-container for services
• Standard SPI for plug-in
• Service Engines provide and aggregate services
• Binding Components provide protocols and
  transports
• Loose coupling via WSDL message exchanges
• JBI defines an environment for plug-in components
  that interact using a services model based
  directly on WSDL 2.0

??????? (plug-in) ????????
9
Component as Container

• JBI directly supports the deployment of artifacts
  to plug-in components, using an archive (ZIP
  file) package called a service unit.

10
Component as Container (Contd)

• Groups of service units are often developed or
  collected together, to form parts of a larger
  application or new service that are tested and
  deployed together.
• A group of JBI service units, along with a
  description of their relationships and target
  components, is called a service assembly.

11
Overview of JBI

• Java Business Integration (JBI) is a
  specification developed under the Java Community
  Process (JCP) for an approach to implementing a
  service-oriented architecture (SOA).
• Creating a standards-based architecture for
  integration solutions
• A suitable standard technology instead of
  proprietary vendor solution
• JBI defines an architecture that allows the
  construction of integration systems from plug-in
  components, that interoperate through the method
  of mediated message exchange.

12
Overview of JBI (Contd)

• JBI plug-in components are responsible for
  providing and consuming services.

13
JBI Architecture

• JBI provides an environment in which plug-in
  components reside.
• The environment provides a set of services to
  facilitate execution of provided services,
  interaction between components, as well as
  management of the overall system created by a JBI
  installation and all installed components.
• JBI provides for interoperation between plug-in
  components by means of message-based service
  invocation, described using a standard service
  description language.
• JBI provides a set of services to facilitate
  management of the JBI environment, including the
  installed components. This includes component
  installation and life cycle management services.

Plug-in component Message exchange Management
14
High-level View of JBI Architecture
Single JVM
Other JVM
SE BC NMR JMX (Management)
15
Component Framework

• JBI components (service engines and binding
  components) provide interfaces for the use of
  JBI, and use interfaces provided by JBI.
• The JBI framework provides the following for the
  use of components
• Component installation context
• Component context
• Class loading
• Error indication

16
Standardized Integration

• SPI (Service Provider Interface) not API
• Allow for proprietary black boxes as
  integration services

17
Service Engine

• Hosts business logic implementing services
• Exposes service endpoints
• Is a target for deployment a container

18
Binding Component

• Handles protocol-specific message re-formatting
• Should contain no business logic
• ????????

19
Normalized Message Router

• The normalized message router, or NMR, receives
  message exchanges from JBI components (engines or
  bindings), and routes them to the appropriate
  component for processing.
• decoupling
• The JBI environment's primary function is to
  route normalized message exchanges from one
  component to another.
• Messages are delivered in a normalized form.

NMR
normalize
normalize
component
component
De-normalize
De-normalize
20
Normalized Message Router (Contd)
21
Message Exchange

• A Message Exchange (ME) serves as a container
  for the normalized messages that are part of a
  service invocation.
• JBI supports a fixed set of message exchange
  patterns
• a well-defined sequence of message exchanges
  between the consumer and the provider.
• A message exchange pattern (or MEP) no matter
  what contents (or type) of the messages
  themselves. By supporting a limited set of MEPs,
  the JBI standard ensures that components have a
  simple, well known interaction model to
  implement, ensuring interoperability.

22
JBI Messaging Architecture
23
Normalized Message Exchange (1)

• External Service Consumer Message Processing

24
Normalized Message Exchange (2)

• External Service Provider Message Processing

25
Example

• One-way Message Adapter
• A message is sent to the JBI environment,
  transformed, then sent to a destination outside
  of the environment.

26
Service Invocation to MEP Mapping
27
Message Exchange Patterns (MEPs)

• An MEP defines the sequence, direction, and
  cardinality of all messages that occur in the
  course of invoking and performing the operation.
• All message exchanges between consumer and
  provider are mediated by the NMR.
• The components interact with the NMR, using their
  individual DeliveryChannels
• Sending MessageExchange instance
• Accepting MessageExchange instance
• MEPs
• In-only Message Exchange Pattern
• Robust In-Only Message Exchange Pattern
• In-Out Message Exchange Pattern
• In-Optional-Out Message Exchange Pattern

28
In-only Message Exchange Pattern

• Describing a one-way messaging pattern

29
Robust In-Only Message Exchange Pattern (fault
scenario)

• Allowing the provider to easily return error
  responses to in-only message exchange

30
In-Out Message Exchange Pattern

• Normal response

31
In-Out Message Exchange Pattern (Contd)

• Fault response

32
In-Optional-Out Message Exchange Pattern

• Normal response 1

33
In-Optional-Out Message Exchange Pattern (Contd)

• Normal response 2

34
In-Optional-Out Message Exchange Pattern (Contd)

• Provider fault response

35
In-Optional-Out Message Exchange Pattern (Contd)

• Provider done response

36
One-way Service Invocation Between two Service
Engines
37
SE Invokes Service Provided by Remote JBI
Instance Robust In with Fault
38
SE Invokes Remote Service
39
Management (JMX)

• The JBI environment, including bindings and
  engines, is administered through JMX. (MBean)
• Installation of engines and bindings (components)
• Life cycle management of components (start/stop
  controls)
• Deployment of component artifacts to engines and
  bindings that support dynamic additions to their
  internal execution environments.
• Monitoring and control.

40
Conclusion (Keywords)

• JSR 208 (SOA infrastructure/enabler)
• Meta-container (JBI Environment / JBI Container)
• Plug-in
• WSDL 2.0
• JMX (Management)
• Messaging (NMR)
• SE BC
• ESB enabler
• Assembling JBI-compliant component
• Installation (AP server, EJB Container, BPEL
  engine)
• Installing it into the JBI environment thanks to
  JMX based administrative tools
• Deployment (BPEL process definition)
• JBI component can be seen as a container (ex
  BPEL engine)
• Services (ex BPEL) must be deployed into the
  component thanks to JBI administrative tools
• Activation
• After deployment, services are accessible through
  the JBI environment as Endpoints

41
Reference
42
Reference

• Sun SOA Home
• http//www.sun.com/products/soa/index.jsp
• The Java EE 5 Tutorial
• http//java.sun.com/javaee/5/docs/tutorial/doc/
• Java EE At a Glance
• http//java.sun.com/javaee/
• Project Open ESB
• https//open-esb.dev.java.net/
• LogicBlaze FUSE Open source SOA platform
• http//www.logicblaze.com/index.jsp
• ServiceMix Home
• http//servicemix.org/site/home.html

• ActiveMQ Home
• http//www.activemq.org/site/home.html
• PETALS Services Platform
• http//petals.objectweb.org/
• Mule Home
• http//mule.codehaus.org/
• Celtix
• http//celtix.objectweb.org/
• JBoss JEMS - The Open Source Platform for SOA
• http//www.jboss.com/products/soa
• Oracle Service-Oriented Architecture Technology
  Center
• http//www.oracle.com/technology/tech/webservices/
  index.html

43
Reference (Contd)

• Sun SOA Home
• http//www.sun.com/products/soa/index.jsp
• JCP (Java Community Process)
• http//jcp.org/en/home/index
• JSR 208 (JBI)
• http//jcp.org/en/jsr/detail?id208

44
Appendix
45
ESB
ServiceMix Apache Synapsele Mule Celtix Suns
Java Open Enterprise Service Bus
46
ServiceMiX

• Open Source JBI Container based on JBI
  Specification (JSR208)
• Supports Transaction Management through Jencks
  andJava Transaction API (JTA)
• Supports Java Message Service (JMS) through
  ActiveMQ
• Can extend any J2EE compliant Server with JBI by
  simply deploying Servicemix (e.g. Geronimo)

47
ServiceMix
48
(ServiceMix) Standard Component-Binding Component

• HTTP
• FTP
• File
• RSS
• Email
• SOAP
• WSIF (Web Service Invocation Framework)
• SAAJ (Soap With Attachments and Apache Axis)
• JAX WS (Java API for XML Web Services)
• XSQL (XML Query Language)
• JMS (Java Message Service)

49
(ServiceMix) Standard Component-Service Engine

• BPE (Container for BPEL)
• EIP (Enterprise Integration Patterns)
• Groovy (Container for Scripting)
• JCA (Java Connector Architecture)
• JSR181 (Container for annotated POJOs)
• Quartz (Timer)
• XPath (Message Transformation with XPath)
• XSLT (Message Transformation with XSLT)

50
ServiceMix
51
(ServiceMix) Straight-throw flow
52
(ServiceMix) Seda Flow
53
(ServiceMix) JMS Flow
54
Basic Example Message Flow Diagram
55
Basic Example Message Flow Diagram

• Messages flow through the components as follows
• The timer component sends a message to
  inputSender through the Normalized Message Router
  (NMR).
• inputSender converts the message (marshals it)
  into a JMS message, then uses the jmsTemplate
  bean to publish the message.
• jmsTemplate uses the jmsFactorybean to get a
  connection to the port associated with the JMS
  topic called "demo.org.servicemix.source." The
  message is published on the "demo.org.servicemix.s
  ource" topic.
• jencks (the JCA resource adapter) listens on port
  61616 for messages.
• inputReceiver subscribes to the
  "demo.org.servicemix.source" topic via jencks and
  receives the JMS message.
• inputReceiver normalizes the JMS message and
  sends it to outputSender via the NMR.
• outputSender marshals the normalized message to a
  JMS message and uses jmsTemplate to publish the
  message on the "demo.org.servicemix.result"
  topic.
• jmsTemplate publishes it on the
  "demo.org.servicemix.result" topic using
  jmsFactory to get a connection to the result
  topic.
• jencks listens on port 61616 for messages.
• jmsTrace subscribes to the "demo.org.servicemix.re
  sult" topic and receives the JMS message via
  jencks.
• jmsTrace converts the JMS message into a
  normalized message and sends it to trace via the
  NMR.
• trace transforms the normalized message into a
  string and logs it to the console.

56
Basic Example Message Flow Diagram

1. Using the distributoraposs web interface, a
   department store customer submits an order for
   multiple products. An HTTP request is sent to the
   OrderReceiver, an HTTP binding component (BC). 3
2. The OrderReceiver sends the message to an
   OrderRouter service engine (SE) 4 component. This
   SE is responsible for parsing the order and
   deciding, based on the message content, which
   OrderTransformer should receive which part of the
   message (i.e., an order for a product).
3. The OrderRouter publishes the orders to the
   appropriate message topics based on the message
   content. Specifically, the OrderRouter publishes
   the messages based on which wholesaler sells the
   item.
4. The OrderTransformer is a service engine
   component, which modifies the message and puts it
   in a format which is readable by the wholesaler
   interface that will fulfill the order.
5. Each OrderTransformer sends the modified message
   to the OrderProcessor.
6. The OrderProcessor is a binding component that
   has two functionsa. It places an order to the
   appropriate wholesaler through the
   wholesaleraposs Webservice or proprietary
   interface. b. It also publishes a message about
   the order on a topic.
7. The message on the topic is subsequently picked
   up by the BusinessMonitor component via the
   jmsTrace component.
8. The BusinessMonitor component monitors the orders
   for quality assurance and business analytics,
   such as data mining.

57
Basic Example Message Flow Diagram
58
BPEL Logical Flow Diagram
59
File Binding Logical Flow Diagram
60
HTTP Binding Example Message Flow Diagram
61
JMS Binding Example Message Flow Diagram
62
Quartz Example Message Flow Diagram
63
RSS Binding Example Message Flow Diagram
64
Department Store Distributor Order Processing
System
65
(No Transcript)
66
Online Ticket Reservation System
67
Online Application for Tax ID No. System
68
Department of Public Works Project Monitoring
System
69
Network Status Indicator
70
News Feed Monitoring System
71
(No Transcript)
72
Mule

• Implementing ESB

73
Reliable One-way MEP with Fault Message Sequence
Chart
74
Reliable Two-way Exchange Message Sequence Chart
75
One-way Transactional Message Exchange
76
A simple integration problem using JBI

• Example Adapter Pattern

77
JBI Components for Adapter Application
78

• SU
• SE-Tx Transformation Service
• BC-Y Provider Service Proxy
• SE-Seq Adapter Logic
• BC-X Client Service Proxy

79
Graphic View of Adapter Service Assembly

• SA

80
Adapter Pattern Message Sequence Diagram
81
JBI Component Installation Time
82
(No Transcript)
83
JBI Component Execution Time
84
Component Interaction -- Service Consumer

• Find a service endpoint
• Create a message exchange
• Send the message

85
Component Interaction -- Service Provider

• Activate an endpoint
• Receive a message
• Send the response
• Close the exchange

86
(No Transcript)
87
SOA Architecture Principles

• Well-defined service interfaces
• Loose coupling
• Document-based, mostly asynchronous,
  conversational interactions
• Service registration and discovery

88
To Form Ideal SOA Infrastructure

• Combine the best of previous technologies

89
JBI Architecture
90
Bring it Together
91
Assembling Services into Processes
92
Events-Driven Application Models

• Asynchronous One-way Communication
• Simple Events
• Brokered Events
• Enterprise Service Busses
• Event Stream Processing Engines

93
Simple Events

• Simple Events
• Simulating Request/Reply

94
Brokered Event

• Brokered Event
• Point to point (Send to One Interested Party )

95

• Enterprise Service Bus - Orchestration Service
• Event Stream Processing (ESP)

96
SOA and Events
Event Sink
Event Source
Service Consumer
Service Provider
Notification
Event Sink
Event Source
Service Consumer
One-way
97
ESB enables SOA and EDA

• SOA Service Oriented Architecture
• Distributed, Web Services
• WSDL, SOAP, XML, XSD
• Registry Lookup, UDDI
• Request / Reply
• EDA Event Driven Enterprise
• Message Oriented
• Qualities of Service
• Asynchronous Publish / Subscribe

98
JBI Messaging

• JBI defines a model and the APIs for messaging
  between JBI components
• All types of interaction
• One-Way
• Reliable One-Way
• Request Response
• Request Optional-Response
• Messaging API
• Components send messages to the JBI container
• Components read messages from the JBI container
• JBI vs JMS

99
JBI Addressing

• An interface is a group of operations
• A service implements an interface represented by
  qualified name and its WSDL definition
• A service has one or more endpoints accessible by
  different bindings
• Endpoints can be
• external for services accessible via a binding
  component
• internal for services provided by a service engine

100
JBI Component Packaging (installation)

• Write an XML descriptor for the component
• the deployment descriptor
• Package the descriptor with component logic in a
  JAR archive
• Install the component in JBI environment
• Component deployment descriptor

101
Deployment

• Provide services to JBI environment through the
  JBI component
• Service (component artifact) is described by XML
  descriptor and packaged as Service Unit (SU)
• Services that have to be deployed into different
  components to produce a new application can be
  grouped into a Service Assembly (SA).
• The SA contains an XML descriptor to describe how
  each SU is deployed on its target component
• Service assembly deployment descriptor

102
Components and Artifacts Lifecycle

• Components and artifacts are managed with the
  same unified lifecycle
• Lifecycle management is accessible by admin tools
  via standard JMX MBean defined by the
  specification

103
Applying JBI With ESB

• Open ESB
• Sun's Open Source Enterprise Service Bus
• A standard, distributed integration
  infrastructure
• Highly distributed scalable JBI services
• Uses JBI Reference Implementation code
• Based on MOMasync XML message exchanges
• Centralized management
• Standard deployment of composite services
• QOS characteristics
• Open ESB Architecture

104
Integration Solution Proxy Service
105
Integration Solution Proxy Service

• Composite App Service Assembly
• A collection of service unit
• Proxy service deployment

106
Composite Application Using JBI
107
(No Transcript)
108
BPEL
109
JBI

• Service based
• Plug-in components serve roles
• Service provider, consumer, both
• Providers supply self-description
• Messages
• Operations and message exchange patterns
• Services
• Endpoints
• All using WSDL
• Service Engines
• Provide local services
• Business Processes (orchestration BPEL4WS)
• Transformation (XSLT, EDI)
• Business Logic (EJBs)
• Integrated Java technology-based apps
• Consume services

• Binding Components
• Proxy for remote service providers
• Protocol SOAP, AS2, ebXML MSH, XML-over-HTTP,
  EDI, etc.
• Access for remote service consumers
• Protocol access to
• SE-provided services
• BC-proxied services
• Contain no business logic
• Convention break at your peril
• No Restrictions

110
Normalized Message Router

• Key to interoperation between components
• Mediated Message Exchange
• Normalized Message
• Abstract Message (payload) Message Properties
  (metadata)
• WSDL Abstract Message
• WSDL interface operation message definition
• Properties (metadata)
• Protocol-supplied context information
• Security tokens
• Transaction information
• Data other components may recognize
• Message Exchange Pattern
• Support for simple communications primitives
• Message exchange patterns are defined from the
  providers perspective

111
Inside Message Exchange Handling
112
JBI

• JBI is a messaging-based plug-in architecture
• JBI does not define the pluggable component
  themselves, but
• Defines the framework, container interface,
  behavior, and common services
• JBI allows anyone to create JBI compliant
  integration plug-in component and integrate them
  dynamically into the JBI infrastructure
• Key pieces of the JBI environment
• SE
• BC
• NMR
• JBI runtime environment (JBI meta container)

113
JBI

• JBI is an architecture for integration systems
  specifying plug-in components that interoperate
  by exchanging messages, rather than by
  interacting directly. This decoupling increases
  flexibility because each component needs to know
  how to interact with the JBI bus only and not
  with n number of other components. JBI components
  provide services, consume services, or sometimes
  both. There are two types of components Service
  Engines (SE) and Binding Components (BC). The SEs
  provide business logic and transformation
  services. The BCs provide connectivity for
  applications that are external to the JBI. The
  separation of business and processing logic from
  communication logic makes the implementation of
  components much less complex.
• The mediated message exchange between components
  is provided by the Normalized Message Router
  (NMR). The NMR routes normalized messages between
  service providers and consumers. A normalized
  message consists of two parts the message
  content (payload) and the message metadata. The
  message metadata contains information such as
  security information, that can affect the
  processing of the message as it routes through
  the JBI. Messages flowing into the JBI, via
  binding components, are translated into a
  normalized (neutral) format, then routed to their
  destination. Prior to final delivery the
  normalized message is translated into the
  appropriate format for the recipient. A message
  can be routed through several JBI components
  depending on what processing is needed.
• The JBI environment also supplies a set of
  services for self management, including services
  for component installation and life cycle
  management of components.
• In summary, the JBI specification creates a
  standards-based technology for enterprise
  application integration.

114
JBI

• LogicBlaze has implemented the ServiceMix ESB
  based on the JBI (JSR 208) specification in order
  to create a standards based ESB and the
  ServiceMix ESB combines the functionality of both
  a Service Oriented Architecture (S0A) and Event
  Driven Architecture (EDA) to achieve an agile,
  enterprise ESB.
• ServiceMix supports event driven architecture for
  events occurring both internal and external to
  the bus. In other words, JMS binding components
  can listen for the arrival of messages, i.e., the
  "event" on topics or queues which are external to
  the bus, while other components can listen for
  messages on the normalized message bus.
• JSR 208 describes a set of Java APIs to interact
  with an implementation of a Java-based Enterprise
  Service Bus (ESB). This ESB must provide for the
  integration of disparate service components,
  enabling them to communicate with their consumers
  or clients through a myriad of communications
  modules.
• It is specified as a set of Java based APIs and
  component packaging conventions that all JBI
  compliant ESB implementations must follow. The
  JBI 1.0 APIs attempt to ensure that Java
  components developed can be deployed and executed
  across different vendors ESB implementations.
• All plug-in components on the ESB, regardless of
  type (SE or BC), and regardless of role (consumer
  or provider), all communicate in the same way.
• All components on the ESB communicate with one
  another by passing messages.

115

• The ESB will only work with normalized messages,
  i.e. ones with protocol specificity removed. This
  means that you cannot tell, from examining the
  message, the connection or protocol over which it
  was sent.
• A component must normalize any message before
  sending it to the ESB. Similarly, if a BC needs
  to send a message to an external system (outside
  of the ESB), the message must be denormalized
  before further routing or use. Denormalization
  puts back communications protocol-dependent
  frames, headers, and other information. This is
  the reason why an ESB is often also called a NMR
  or Normalized Message Router.

116

• Services that need to be accessed by the ESB are
  accessed as endpoints.
• Endpoint is how a service is addressed by the
  ESB.
• Service is the actual business entity the
  performs the desired function
• Service units provide information about the
  services and their endpoints to the component
• Service assembly is how several service units are
  packaged and deployed on to target components
• Integrating old and new components and services
  using a service-oriented architecture requires an
  infrastructure that can connect any component or
  service, regardless of location, messaging
  protocol, and message format. To orchestrate
  existing services and components to meet the
  needs of today's dynamic business climate, this
  infrastructure must be highly customizable. The
  enterprise service bus (ESB) infrastructure
  fulfills these requirements.

117

• Enterprise service bus (ESB) is a centralized,
  logical, architectural component that operates in
  a distributed, heterogeneous environment to
  facilitate the requirements of a highly scalable,
  fault-tolerant, service-messaging framework.
• JBI embodies a messaging model based on Web
  Services Description Language (WSDL) for easy
  mapping to Web services, HTTP, email, and JMS.
  JBI integrates with legacy systems, binary
  transports, document-oriented transports, and RPC
  (remote procedure call) systems.
• Message normalization is the process of mapping
  context-specific data to a context-neutral
  abstraction to transport data in a standard
  format. All messages handled by the NMR are
  normalized.
• An NMR is not embodied by any concrete object. It
  is abstracted as a set of APIs, SPIs (service
  provider interfaces), and components. The NMR
  APIs include
• JBI Message API
• JBI Service API
• JBI Message Exchange Factory API
• Service Description SPI
• Message Exchange Patterns API
• Endpoint Reference API

118

• JBI supports two kinds of components, service
  engines and binding components. Components
  interact with JBI in two ways
• SPIs Interfaces implemented by a binding or
  engine
• APIs Interfaces exposed to bindings or engines
  by the framework
• An external service consumer sends a service
  request across a specific protocol and transport
  to a binding component. The binding component
  converts the request to a normalized message. The
  binding component then creates a message packet
  called a message exchange (ME) and sends it
  across the binding component's delivery channel
  to the NMR for delivery to a service provider.
