Database Systems: Design, Implementation, and Management Eighth Edition

1
Database Systems Design, Implementation, and
ManagementEighth Edition

• Chapter 4
• Entity Relationship (ER) Modeling

2
Lecture 4

• We will complete some topics from Lecture 3
  (these were available in last weeks download,
  but repeated here) and begin ER Modeling from
  Chapter 4

3
Relational Algebra Operators (continued)

• UNION
• INTERSECT
• DIFFERENCE
• PRODUCT
• SELECT
• PROJECT
• JOIN
• DIVIDE

4
Relational Algebra Operators (continued)

• Union
• Combines all rows from two tables, excluding
  duplicate rows
• Tables must have the same attribute
  characteristics (this property is expressed as
  the tables must be union-compatible
• Intersect
• Yields only the rows that appear in both tables
• Again, tables must be union-compatible

5
Relational Algebra Operators (continued)
6
Relational Algebra Operators (continued)
7
Relational Algebra Operators (continued)

• Difference
• Yields all rows in one table not found in the
  other table that is, it subtracts one table
  from the other
• Tables must be union-compatible
• Product
• Yields all possible pairs of rows from two tables
• Also known as the Cartesian product

8
Relational Algebra Operators (continued)
9
Relational Algebra Operators (continued)
10
Relational Algebra Operators (continued)

• Select
• Yields values for all rows found in a table
• Can be used to list either all row values or it
  can yield only those row values that match a
  specified criterion
• Yields a horizontal subset of a table
• Project
• Yields all values for selected attributes
• Yields a vertical subset of a table

11
Relational Algebra Operators (continued)
12
Relational Algebra Operators (continued)
13
What do we mean by an algebra?

• "Ordinary" algebra works on numbers, and contains
  operators that work on numbers 24, 6-3, 95/5,
  87.
• Relational Algebra works on relations (tables),
  and has operators which work on relations
  (tables).

14
Relational Operators

• Relational operators are applied to one or two
  relations, and produce a new relation as a result
• Def A predicate is a statement which is either
  true or false, depending on the substitution for
  a variable.

15
Definition of the Select Operator

• The SELECT operator ?
• Syntax for the Select operator is ?
  (relation)

predicate
16
What does the Select Operator do?

• The Select operator, s , selects rows (tuples)
  from the relation (table) which satisfy (make
  TRUE) the specified predicate. So, we start with
  a given relation (table), and produce a new
  relation (table) which is a (horizontal) subset
  of the old one, depending upon which rows are
  extracted from the old relation (table).

17
The Student Relation

• STUID

STUNAME
MAJOR
CREDITS
151234
Jones,Ted
MGMT
47
241504
Smith, Jane
CS
101
310927
Kool, Bill
MATH
68
428541
Lan, Jackie
IS
93
529624
Witt, Stu
COE
75
629632
Kahn, Fran
CS
65
The query s (STUDENT)
STUID 241504
STUID
STUNAME
MAJOR
CREDITS
241504
Smith, Jane
CS
101
18
STUNAME
MAJOR
CREDITS

• STUID

151234
Jones,Ted
MGMT
47
241504
Smith, Jane
CS
101
310927
Kool, Bill
MATH
68
428541
Lan, Jackie
IS
93
529624
Witt, Stu
COE
75
629632
Kahn, Fran
CS
65
s (Student)
MAJOR 'CS'
STUID
STUNAME
MAJOR
CREDITS
241504
Smith, Jane
CS
101
629632
Kahn, Fran
CS
65
19
The Usual Comparisons are Allowed in the Predicate

• We may include the "usual" comparison operators
  ( lt , gt , , etc.) in the predicate.
• We can form "compound" predicates with an AND (
  L ) and the OR ( V ).

20

• STUID

STUNAME
MAJOR
CREDITS
151234
Jones,Ted
MGMT
47
241504
Smith, Jane
CS
101
310927
Kool, Bill
MATH
68
428541
Lan, Jackie
IS
93
529624
Witt, Stu
COE
75
629632
Kahn, Fran
CS
65
s
(Student)
((MAJOR 'CS' ) L (CREDITS lt 100))V(MAJOR'IS')
STUID
STUNAME
MAJOR
CREDITS
428541
Lan, Jackie
IS
93
629632
Kahn, Fran
CS
65
21
The Project Operator

• a unary operator (works on a single relation)
• produces a vertical subset of a relation,
  extracting the values of the attributes we
  specify, eliminating duplicates, and placing the
  values in a new relation

22
The Project Operator
p (relation)
attribute(1),attribute(2),...attribute(n)
This will produce a list of the attribute values
given, for all entities in the specified relation.
23

• p (Student)

STUNAME, MAJOR
Query states What are the names and majors of
all students?
STUNAME
MAJOR
Jones,Ted
MGMT
Smith, Jane
CS
Kool, Bill
MATH
Lan, Jackie
IS
Witt, Stu
COE
Kahn, Fran
CS
24
Use the Relational Algebra to write a query which
lists the names and ids of all students who are
IS majors
p ( s (student))
STUNAME, STUID MAJOR'IS'
The innermost (select expression) produces
STUID
STUNAME
MAJOR
CREDITS
428541
Lan, Jackie
IS
93

The "project" is applied to this relation,
yielding
STUNAME
STUID
Lan, Jackie
428541
25
The Natural JOIN Operator in Relational Algebra

• "the heart of the relational algebra"
• a binary operator
• we "join" together two tables, based on a common
  attribute (the Join attribute)
• the new relation will contain the columns of both
  tables which have been joined, and its rows will
  be the concatenation of a row from the first
  table and a row from the second table which
  matches the Join attribute

26
The Natural JOIN Operator

• A B means the Natural Join of relations A
  and B
• Note that if there is a tuple in relation A in
  which its attribute to be joined does not match
  any value of the attribute to be joined in
  relation B, it will not appear in the joined
  relation.

27
PC
EMPLOYEE

• TAGNUM

COMPID
EMPNUM
EMPNUM
EMPNAME
124
Alvarez, R.
32808
M759
611
37691
B121
124
258
Lopez, M.
57772
C007
567
567
Feinstein, B.
59836
B221
124
611
Dinh, M.
77740
M759
567
80269
C007
852
PC Ä EMPLOYEE would then be
TAGNUM
COMPID
EMPNUM
EMPNAME
32808
M759
611
Dinh. M.
37691
B121
124
Alvarez, R.
57772
C007
567
Feinstein, B.
59836
B221
124
Alvarez, R.
77740
M759
567
Feinstein, B.
28
List the tag number and computer ID together with
the name of the employee to whom the PC is
assigned
p ( PC Ä EMPLOYEE )

• TAGNUM, COMPID, EMPNAME

29

• Answer to the Query

TAGNUM
COMPID
EMPNAME
32808
M759
Dinh. M.
37691
B121
Alvarez, R.
57772
C007
Feinstein, B.
59836
B221
Alvarez, R.
77740
M759
Feinstein, B.
30
Other Types of Joins

• There are other types of Joins
• Equijoin (join attribute appears twice)
• Theta-Join (join on condition other than
  equality)
• Outer Join( rows in one relation which do not
  match any rows in the other relation on the Join
  attribute will be maintained, with null values
  for the attributes in the other relation).

31
Two Types of Outer Joins

• Left Outer Join Displays all records from the
  left side of the join, and those records from the
  right side which match records from the left.
• Right Outer Join Displays all records from the
  right side of the join, and only those records
  from the left which have matching values from the
  right side.

32
Some Examples With Our PC and EMPLOYEE relations

• Theta Join Display tagnums and employee names
  for PC's belonging to employees with EMPNUMs gt
  500.
• Left Outer Join of PC EMPLOYEE This will
  reveal those PC's (if any) which have not been
  assigned to Employees.
• Right Outer Join of PC EMPLOYEEThis will
  reveal those Employees (if any) who have not been
  assigned a PC.

33
PC
EMPLOYEE
TAGNUM
COMPID
EMPNUM
EMPNUM
EMPNAME
32808
M759
611
124
Alvarez, R.
37691
B121
124
258
Lopez, M.
57772
C007
567
567
Feinstein, B.
59836
B221
124
77740
M759
567
611
Dinh, M.
80269
C007
857
The Left Outer Join of PC and EMPLOYEE would
be
TAGNUM
COMPID
EMPNUM
EMPNAME
32808
M759
611
M. Dinh
37691
B121
124
R. Alvarez
57772
C007
567
B. Feinstein
59836
B221
124
R. Alvarez
77740
M759
567
B. Feinstein

80269
C007
857

34

• PC

EMPLOYEE
TAGNUM
COMPID
EMPNUM
EMPNUM
EMPNAME
32808
M759
611
124
Alvarez, R.
37691
B121
124
258
Lopez, M.
57772
C007
567
567
Feinstein, B.
59836
B221
124
77740
M759
567
Dinh, M.
611
80269
C007
857
The Right Outer Join of PC and EMPLOYEE would be
EMPNAME
EMPNUM
TAGNUM
COMPID
R. Alvarez
124
37691
B121
R. Alvarez
124
59836
B221
M. Lopez
258


B. Feinstein
567
57772
C007
B. Feinstein
567
77740
M759
M. Dinh
611
80269
C007


35
The DIVIDE Relational Algebra Operator

• DIVIDE requires that we have
• one single-column table and
• one two-column table
• Both tables must have a common attribute
• The resulting table will have only one column
  (the non-common attribute) and will contain the
  values associated with the division

36
The DIVIDE Relational Operator

• DIVIDE is a binary operator, requiring a table
  with 2 attributes (Table I) and a table with 1
  attribute (Table 2), each having one attribute in
  common, and producing a table with 1 attribute
  (the non-common attribute) , as follows
• We look at the intersection in Table 1 of the
  rows for the common attribute, and pick the
  intersection of the non-common attribute column,
  and this becomes Table 3.

37
The DIVIDE relational operator
38
Homonyms

• Two words are homonyms if they are pronounced or
  spelled the same way but have different meanings
• Example C_Name representing a customer name in
  the CUSTOMER table, and C_Name, representing a
  consultant name in the CONSULTANT table, are
  homonyms.
• You should avoid database homonyms (the data
  dictionary is very useful in this regard)

39
Relationships within the Relational Database

• 1M relationship
• Relational modeling ideal
• Should be the norm in any relational database
  design
• 11 relationship
• Should be rare in any relational database design
• MN relationships
• Cannot be implemented as such in the relational
  model
• MN relationships can be changed into two 1M
  relationships

40
The 1M Relationship

• Relational database norm
• Found in any database environment

41
The 1M Relationship (continued)
42
The 1M Relationship (continued)
43
The 1M Relationship (continued)
44
The 1M Relationship (continued)
45
The 11 Relationship

• One entity can be related to only one other
  entity, and vice versa
• Sometimes means that entity components were not
  defined properly
• Could indicate that two entities actually belong
  in the same table
• As rare as 11 relationships should be, certain
  conditions absolutely require their use

46
The 11 Relationship (continued)
47
The 11 Relationship (continued)
48
The MN Relationship

• Can be implemented by breaking it up to produce a
  set of 1M relationships
• Can avoid problems inherent to MN relationship
  by creating a composite entity or bridge entity

49
The MN Relationship (continued)
50
The MN Relationship (continued)
51
The MN Relationship (continued)
52
Problems with this model

• Note that STU_NUM has to be repeated many times
  (once for each course the student is enrolled in)
  in the STUDENT table, along with other student
  attributes, such as name, email, major, etc.
• And note the same issue in the CLASS table.

53
Bridge Entity Table (a.k.a. Composite Enity Table
or Linking Table)

• Implementation of a composite entity
• Yields required MN to 1M conversion
• Composite entity table must contain at least the
  primary keys of original tables
• Linking table contains multiple occurrences of
  the foreign key values
• Additional attributes may be assigned as needed

54
The MN Relationship (continued)
55
The MN Relationship (continued)
56
The MN Relationship (continued)
57
The MN Relationship (continued)
58
Data Redundancy Revisited

• Data redundancy leads to data anomalies
• Such anomalies can destroy the effectiveness of
  the database
• Foreign keys
• Control data redundancies by using common
  attributes shared by tables
• Crucial to exercising data redundancy control
• Sometimes, data redundancy is necessary

59
Data Redundancy Revisited (continued)
60
Data Redundancy in this Database

• Notice that the product price (PROD_PRICE)
  appears in both the PRODUCT relation and also the
  LINE relation.
• Is this redundancy? Is this crucial to the
  systems success?
• (We want to maintain the historical accuracy of
  the transactions in the LINE relation!)
• Is the attribute LINE_NUMBER required in the LINE
  relation?
• Line numbers are often automatically generated by
  invoicing software
• We might wish to retrieve the precise order of
  the invoice lines!
• Example customer calls and refers to the item
  on line 2 !

61
Data Redundancy Revisited (continued)
62
Indexes

• An index is an orderly arrangement used to
  logically access rows in a table
• Example Libraries have a card catalog where
  books are indexed by title, topic and author.
• An index is composed of an index key and a set of
  pointers. An index is an ordered arrangement of
  keys and pointers.
• Index key
• Indexs reference point
• Points to data location identified by the key
• Unique index
• Index in which the index key can have only one
  pointer value (row) associated with it
• Each index is associated with only one table

63

• Suppose we wished to obtain all painting by a
  given painter. Rather than going row by row in
  the PAINTING relation to sear for the
  PAINTER_NUM, we could maintain an index.

64
Indexes (continued)
65
Codds Relational Database Rules

• In 1985, Codd published a list of 12 rules to
  define a relational database system
• The reason was the concern that many vendors were
  marketing products as relational even though
  those products did not meet minimum relational
  standards

66
Codds Relational Database Rules (Continued)
67
Summary

• Tables are basic building blocks of a relational
  database
• Keys are central to the use of relational tables
• Keys define functional dependencies
• Superkey
• Candidate key
• Primary key
• Secondary key
• Foreign key

68
Summary (continued)

• Each table row must have a primary key which
  uniquely identifies all attributes
• Tables can be linked by common attributes. Thus,
  the primary key of one table can appear as the
  foreign key in another table to which it is
  linked
• The relational model supports relational algebra
  functions SELECT, PROJECT, JOIN, INTERSECT,
  UNION, DIFFERENCE, PRODUCT, and DIVIDE.
• Good design begins by identifying appropriate
  entities and attributes and the relationships
  among the entities. Those relationships (11,
  1M, and MN) can be represented using ERDs.

69
(Now Beginning Chapter 4)Goals for our study of
ER Modeling to learn

• The main characteristics of entity relationship
  components
• How relationships between entities are defined
  and refined and how those relationships are
  incorporated into the database design process
• How ERD components affect database design and
  implementation
• That real-world database design often requires
  the reconciliation of conflicting goals

70
The Entity Relationship (ER) Model

• ER model forms the basis of an ER diagram
• ERD represents conceptual database as viewed by
  end user
• ERDs depict databases main components
• Entities
• Attributes
• Relationships

71
Entities

• Refers to entity set and not to single entity
  occurrence
• In both Chen and Crows Foot models, entity is
  represented by rectangle containing entitys name
• Entity name, a noun, is usually written in
  capital letters

72
Attributes

• Characteristics of entities
• In Chen model, attributes are represented by
  ovals and are connected to entity rectangle with
  a line
• Each oval contains the name of the attribute it
  represents
• In Crows Foot model, attributes are written in
  attribute box below entity rectangle

73
Attributes (continued)
74
Domains

• Attributes have domain
• Domain is attributes set of possible values
• Attributes may share a domain

75
Identifiers (Primary Keys)

• Underlined in the ERD
• Key attributes are also underlined in frequently
  used table structure shorthand

76
Composite Primary Keys

• Primary keys ideally composed of only single
  attribute
• Possible to use a composite key
• Primary key composed of more than one attribute

77
Composite Primary Keys (continued)
78
Representing the CLASS entity set

• CLASS (CLASS_CODE, CRS_CODE, CLASS_SECTION,
  CLASS_TIME, CLASS_ROOM, PROF_NUM)or, using a
  composite primary key,
• CLASS (CRS_CODE, CLASS_SECTION, CLASS_TIME,
  CLASS_ROOM, PROF_NUM)

79
Composite and Simple Attributes

• Composite attributes, also known as group
  attributes, are attributes which can be
  subdivided
• Example the group attribute ADDRESS can be
  subdivided into STREETADDRESS, CITY, STATE,
  ZIPCODE, COUNTRY
• Simple attributes are attributes which cannot be
  subdivided
• In database design, it is preferable to decompose
  group attributes into their simple attribute
  componenets
• Useful for queries on part of the group
  attributes

80
Single-Valued Attributes

• Single-value attribute can have only a single
  value

81
Multivalued Attributes

• Multivalued attributes can have many values

82
Multivalued Attributes (continued)
83
Resolving Multivalued Attribute Problems

• Although conceptual model can handle MN
  relationships and multivalued attributes, you
  should not implement them in relational DBMS. Two
  approaches for handling this
• Within original entity, create several new
  attributes, one for each of the original
  multivalued attributes components
• or
• Create new entity composed of original
  multivalued attributes components (this approach
  is usually the preferred approach).

84
Resolving Multivalued Attribute Problems
(Approach 1 create new attributes)
85
Resolving Multivalued Attribute Problems
(Approach 2 create a new entity composed of the
original multivalued attributes components the
new entity is then related to the original entity
in a 1 to Many relationship)
86
Resolving Multivalued Attribute Problems
(continued)
87
Derived Attributes

• Attribute whose value may be calculated (derived)
  from other attributes
• Need not be physically stored within database
• Can be derived by using an algorithm
• Represented in an E-R model by a dotted line

88
Derived Attributes (continued)
89
Derived Attributes (continued)
90
Relationships

• Association between entities
• Definition Participants are entities that
  participate in a relationship
• Relationship name is often an active or passive
  verb
• takes, teaches, employs, manages
• Relationships between entities always operate in
  both directions
• Relationship classification is often difficult to
  establish if know only one side of the
  relationship

91
Connectivity and Cardinality

• Connectivity
• Used to describe the relationship classification
  (i.e., one-to-many, etc.)
• Cardinality
• Expresses minimum and maximum number of entity
  occurrences associated with one occurrence of
  related entity, by placing the min,max numbers
  beside the entity set, using the format (min,max)
• In (min,max), min represents the minimum number
  of associated entities, while max represents the
  maximum number of associated entities

92
Connectivity and Cardinality (continued)

• A professor teaches (is associated with) at least
  1, but at most, 4 classes, while a class is
  associated with exactly (at least one, at most
  one) professor
• Cardinalities are established by business rules.

93
Existence Dependence

• Existence dependence
• Means an entity can exist in the database only
  when it is associated with another related entity
  occurrence
• In relationship EMPLOYEE claims DEPENDENT, the
  DEPENDENT is existence dependent upon EMPLOYEE
  (the DEPENDENT would not exist in the database
  unless the EMPLOYEE existed)
• Implies that DEPENDENT must have a non-null
  foreign key pointing to its EMPLOYEE
• Existence independence
• Entity can exist apart from one or more related
  entities
• Sometimes refers to such an entity as strong or
  regular entity

94
Relationship Strength

• Weak (non-identifying) relationships
• Exists if PK of related entity does not contain
  PK component of parent entity
• Strong (identifying) relationships
• Exists when PK of related entity contains PK
  component of parent entity

94
Database Systems, 8th Edition
95
95
Database Systems, 8th Edition
96
96
Database Systems, 8th Edition
97
Weak Entities

• Weak entity meets two conditions
• Existence-dependent
• Primary key partially or totally derived from
  parent entity in relationship
• Database designer determines whether an entity is
  weak based on business rules

97
Database Systems, 8th Edition
98
98
Database Systems, 8th Edition
99
99
Database Systems, 8th Edition
100
Relationship Participation

• Optional participation
• One entity occurrence does not require
  corresponding entity occurrence in particular
  relationship
• Mandatory participation
• One entity occurrence requires corresponding
  entity occurrence in particular relationship

100
Database Systems, 8th Edition
101
101
Database Systems, 8th Edition
102
102
Database Systems, 8th Edition
103
Relationship Degree

• Indicates number of entities or participants
  associated with a relationship
• Unary relationship
• Association is maintained within single entity
• Binary relationship
• Two entities are associated
• Ternary relationship
• Three entities are associated

103
Database Systems, 8th Edition
104
104
Database Systems, 8th Edition
105
105
Database Systems, 8th Edition
106
Recursive Relationships

• Relationship can exist between occurrences of the
  same entity set
• Naturally found within unary relationship

106
Database Systems, 8th Edition
107
107
Database Systems, 8th Edition
108
108
Database Systems, 8th Edition
109
Associative (Composite) Entities

• Also known as bridge entities
• Used to implement MN relationships
• Composed of primary keys of each of the entities
  to be connected
• May also contain additional attributes that play
  no role in connective process

109
Database Systems, 8th Edition
110
110
Database Systems, 8th Edition
111
111
Database Systems, 8th Edition
112
Developing an ER Diagram

• Database design is an iterative process
• Create detailed narrative of organizations
  description of operations
• Identify business rules based on description of
  operations
• Identify main entities and relationships from
  business rules
• Develop initial ERD
• Identify attributes and primary keys that
  adequately describe entities
• Revise and review ERD

112
Database Systems, 8th Edition
113
113
Database Systems, 8th Edition
114
114
Database Systems, 8th Edition
115
115
Database Systems, 8th Edition
116
116
Database Systems, 8th Edition
117
117
Database Systems, 8th Edition
118
118
Database Systems, 8th Edition
119
119
Database Systems, 8th Edition
120
120
Database Systems, 8th Edition
121
121
Database Systems, 8th Edition
122
122
Database Systems, 8th Edition
123
Enroll is the composite entity that implements
the MN relationship STUDENT enrolls IN CLASS
123
Database Systems, 8th Edition
124
Database Design Challenges Conflicting Goals

• Database designers must make design compromises
• Conflicting goals design standards, processing
  speed, information requirements
• Important to meet logical requirements and design
  conventions
• Design of little value unless it delivers all
  specified query and reporting requirements
• Some design and implementation problems do not
  yield clean solutions

124
Database Systems, 8th Edition
125
125
Database Systems, 8th Edition
126
Summary

• Entity relationship (ER) model
• Uses ERD to represent conceptual database as
  viewed by end user
• ERMs main components
• Entities
• Relationships
• Attributes
• Includes connectivity and cardinality notations

126
Database Systems, 8th Edition
127
Summary (continued)

• Connectivities and cardinalities are based on
  business rules
• MN relationship is valid at conceptual level
• Must be mapped to a set of 1M relationships
• ERDs may be based on many different ERMs
• Database designers are often forced to make
  design compromises

127
Database Systems, 8th Edition
