Integrating metadata schema registries with digital preservation systems to support interoperability

1
Integrating metadata schema registries with
digital preservation systems to support
interoperability

• Michael DayUKOLN, University of Bath,
  UKm.day_at_ukoln.ac.uk
• 2003 Dublin Core Conference, Seattle, Washington,
  USA28 September - 2 October 2003

2
Presentation outline

• Preservation metadata
• Purpose
• Standards
• Concepts of interoperability
• Metadata capture and inheritance
• Object exchange
• Metadata schema registries
• Definitions
• Application to digital preservation systems
• Concluding thoughts

3
Preservation metadata (1)

• All digital preservation strategies depend - to
  some extent - on the creation, capture and
  maintenance of metadata
• "Preserving the right metadata is key to
  preserving digital objects" (ERPANET Briefing
  Paper, 2003)
• Defined as
• The various types data that will allow the
  re-creation and interpretation of the structure
  and content of digital data over time (Ludäsher,
  Marciano Moore, 2001)

4
Preservation metadata (2)

• Metadata fulfil various roles, e.g.
• " to find, manage, control, understand or
  preserve information over time" (Cunningham,
  2000)
• Descriptive information technical information
  about formats and structure information about
  provenance and context administrative
  information, e.g. for rights management
• Current schemas either very complex or only
  provide a basic framework (sometimes both!)
• Perception that different strategies and objects
  will need different metadata

5
Preservation metadata - standards

• Developed from many different perspectives
• Digital libraries
• METS, NISO Z39.87 (to support digitisation
  initiatives)
• OCLC/RLG Framework, Cedars, NEDLIB, NLA, NLNZ
• OAIS influence has been greatest in this area
• Records management and archival description
• Pittsburgh BAC, RKMS, NAA, VERS, PRO, EAD, etc.
• Also standards not specifically developed for
  preservation, but with some overlap
• Multimedia
• MPEG-7, SMPTE, etc
• Rights management
• ltindecsgt, MPEG-21, etc.

6
The OAIS model

• Reference Model for an Open Archival Information
  System (OAIS)
• ISO 147212003
• Established a common framework of terms and
  concepts
• Influential on the design of some schemas
• e.g., OCLC/RLG Metadata Framework
• Identified basic functions
• Ingest, Data Management, Archival Storage,
  Administration, Access, Preservation Planning

7
OAIS functional model
PRODUCER
CONSUMER
Preservation Planning
DIP
Descriptive info.
Access
Descriptive info.
queries
Data Management
SIP
result sets
Ingest
orders
Archival Storage
SIP
AIP
AIP
SIP
DIP
Administration
MANAGEMENT
OAIS Functional Entities (Figure 4-1)
8
OAIS information objects

• Information Object (basic concept)
• Data Object (bit-stream)
• Representation Information (permits the full
  interpretation of Data Object into meaningful
  information)
• Information Object Classes
• Content Information
• Preservation Description Information (PDI)
• Packaging Information
• Descriptive Information

9
OAIS information packages

• Information package
• Container that encapsulates Content Information
  and PDI
• Packages for submission (SIP), archival storage
  (AIP) and dissemination (DIP)
• AIP ... a concise way of referring to a set of
  information that has, in principle, all of the
  qualities needed for permanent, or indefinite,
  Long Term Preservation of a designated
  Information Object
• PDI other information (metadata) which will
  allow the understanding of the Content
  Information over an indefinite period of time
• Reference, Provenance, Context, Fixity

10
Draft categorisation (1)
NLA
CEDARS
NEDLIB
NLNZ
OCLC/RLG
OAIS
METS
Z39.87
Practical
Conceptual
DCMI
RKMS
PITT
VERS
PRO
MPEG-7
11
Draft categorisation (2)

• Earliest schemas were largely conceptual in
  nature
• e.g. Pittsburgh BAC model, Cedars outline
  specification, OCLC/RLG WG I
• Gradually moving towards a more practical focus
• e.g., VERS, NLNZ, METS, PREMIS WG
• Convergence on XML (DTDs and Schemas)
• But there is an urgent need for all this
  practical experience to be shared
• e.g., published schemas, advice on
  implementation, etc.

12
Implementation

• We need to prove the practical value of metadata
  frameworks and 'outline specifications'
• It can be difficult for implementers to use these
  as a guide to the design of real systems?
• We need to move from the conceptual to the
  practical, need to move beyond proof-of-concept
• Positive signs
• METS/NISO Z39.87
• OCLC/RLG PREMIS WG looking at implementation
  strategies for preservation metadata

13
Sustainability (1)

• Balance risks with costs
• There is a perception that metadata creation and
  maintenance will be expensive
• But costs associated with data recovery are not
  trivial
• Need to balance the risks of data loss with the
  cost of creating metadata
• Cost/benefit analysis
• Robust selection criteria
• Co-operation between repositories
• Re-use of existing metadata

14
Sustainability (2)

• Avoid imposing unnecessary costs
• Avoid large schemas (?)
• Need to identify the right metadata - 'core
  metadata' (?)

15
Interoperability (1)

• Heterogeneity
• The need to cope with a wide (and growing) range
  of preservation metadata standards, object types,
  formats, etc.
• No realistic prospect of a single standard
• Repositories will need to manage a range of
  metadata standards, at least within ingest and
  access functions

16
Interoperability (2)

• Metadata creation and capture
• Created by humans or captured automatically?
• Some metadata already exists, e.g.
• Embedded within objects
• In separate databases
• Generated by particular processes
• Need for this metadata to be captured at
  creation, ingest, migration, and at other
  appropriate points in object life-cycle

17
Interoperability (3)

• Benefits of interoperability
• To support the capture or inheritance of
  metadata, e.g. on ingest
• To support the management of multiple formats and
  metadata schema within a digital preservation
  system
• Current metadata specifications not entirely
  clear on how this should be done
• To support the exchange of information packages
  outside the repository, e.g. by converting to
  standard 'exchange formats'
• Networks of 'trusted repositories'

18
Registries (1)

• Registries of metadata schemas may offer one way
  to deal with this problem
• Parallel concept of format registries
• There is " a pressing need to establish
  reliable, sustained repositories of file format
  specifications, documentation, and related
  software" (Lawrence, et al., 2000)
• DSpace 'bitstream format registry'
• Typed Object Model (TOM) project
• Digital Library Federation, et al. recently
  proposed a Global digital format registry

19
Registries (2)

• Metadata schema registries
• " formal systems that can disclose authoritative
  information about the semantics and structure of
  the data elements that are included within a
  particular metadata scheme" (Heery, et al., 2000)
• Existing registries include the XML.org Registry
  and Repository (OASIS), and metadata registries
  set up by DCMI and SMPTE

20
Registry functions (1)

• Provides support for the ingest process
• Support conversion and metadata capture tools
• May also provide support for the access function
• The export of Dissemination Information Packages
• The exchange of information packages (AIPs?) with
  other repositories conversion to exchange
  standards
• Can link metadata where there are multiple
  instances within the system
• May help to manage schema evolution

21
Registry functions (2)
PRODUCER
CONSUMER
Preservation Planning
DIP
Descriptive info.
Access
Descriptive info.
queries
Data Management
SIP
result sets
Ingest
orders
Archival Storage
SIP
AIP
AIP
SIP
DIP
Administration
MANAGEMENT
OAIS Functional Entities (Figure 4-1)
22
Registry functions (2)
Registry
Schemas
Schemas
PRODUCER
CONSUMER
Preservation Planning
DIP
Descriptive info.
Access
Descriptive info.
queries
Data Management
SIP
result sets
Ingest
orders
Archival Storage
SIP
AIP
AIP
SIP
DIP
Administration
MANAGEMENT
OAIS Functional Entities (Figure 4-1)
23
Registry functions (2)
Registry
Schemas
Schemas
PRODUCER
CONSUMER
Preservation Planning
DIP
Descriptive info.
Access
Descriptive info.
queries
Data Management
SIP
result sets
Ingest
orders
Archival Storage
SIP
AIP
AIP
SIP
DIP
Administration
MANAGEMENT
OAIS Functional Entities (Figure 4-1)
24
Registries - organisational issues

• Registries are part of infrastructure
• Distributed vs. centralised approaches
• Concept of 'shared services'
• Experimental distributed registries are based on
  Resource Description Framework (RDF)
• CORES Registry
• Encourage re-use of metadata (the 'application
  profile' concept)
• Are other technologies more suitable?
• Who should be responsible for them?

25
Summing up

• Interoperability supports the reuse of metadata
  and the exchange of information objects
• There is a possible role for metadata registries
  to help manage these (and other) processes - but
  the concept needs extensive scoping and
  evaluation
• Registries are NOT a panacea

26
Acknowledgements

• UKOLN is funded by Resource the Council for
  Museums, Archives and Libraries, the Joint
  Information Systems Committee (JISC) of the UK
  higher and further education funding councils, as
  well as by project funding from the JISC and the
  European Union. UKOLN also receives support from
  the University of Bath, where it is based.
