Rome, Italy

1
EVERGROW SP2Work package 2d
Temporal and Spatial Analysis of Network
Connectivity Data

• Rome, Italy
• March 6-7, 2006

2
Background

• 1st year focus was on building an ontology
  construction tool, that work is now over
• Our aim now is to develop temporal and spatial
  mining tools for exploring network connectivity
  data
• Tools should answer important question that are
  relevant to national ISP decision makers

3
The converging development paths

• Coarse grain data analysis
• Aggregate properties of the network, including
  pruning
• Fine grain data analysis
• Enriching the data by obtaining extra information
  about AS geographical locations from RIR
  databases
• Drawing the a picture of the internet from
  multiple perspectives

4
Coarse grain data analysisGlobal AS degree
connectivity
5
Fine grain data analysis Country to Country
connectivity
6
Fine grain data analysisAS connectivity within a
country (Italy)
7
Fine grain data analysisCountry AS connectivity
centrality
8
Fine grain data analysis Country AS connectivity
spread

• http//evergrow.claes.sci.eg/evergrow/
