Serial Driver APIs

• Standard Serial API
• SPI
• HDLC API

2
Serial Driver State Diagram
open()
write()
Sending Data
Opened
Gathering Data
ioctl()
Configuration Change
read()
close()
Closed
3
Example open()
prototype int open(char port, int Options)
File_Descriptor open(/com/0, (O_RDWR
O_NONBLOCK) )
Note Returns Unique File Descriptor,
or -1 if unsuccessful.
Available Ports /com/0
/com/1
Available Options O_RDONLY O_WRONLY
O_RDWR O_NONBLOCK O_DMA
4
Example write(), read()
prototype int write(int fd, char Buffer, int
BufferSize)
Num_Bytes write(fd, SendBuffer, SizeBuffer)
Note Returns Number of bytes sent.
prototype int read(int fd, char Buffer, int
BufferSize)
Num_Bytes read(fd, SendBuffer, SizeBuffer)
Note Returns Number of bytes retrieved, or -1
if no data available.
5
Serial read() Blocking
Blocking
Non-Blocking
Wait here until driver returns at least one byte
Num read()
Num read()
Return Immediately
Num always gt 0
Num -1 if data not available
Note BSP Default
6
Serial I/O Options
prototype int ioctl(int fd, int command, void
args)
Result ioctl(fd, SIO_BAUD_SET, Options)
Note Returns -1 if error, otherwise 0.
Possible
Commands SIO_BAUD_GET SIO_BAUD_SET SIO_MODE_GET SI
O_MODE_SET SIO_HW_OPTS_GET SIO_HW_OPTS_SET
SIO_GET_STATUS_DCD SIO_GET_STATUS_DTR SIO_TERM_SE
ND_CR SIO_TERM_ECHO SIO_BAUD_ERROR_SET SIO_BAUD_ER
ROR_GET
7
Serial Driver for UART

• Serial Driver for standard UART MODE ONLY
• The following include files are required for the
  Serial Port APIs
• netosio.h
• netos_serl.h
• The standard device driver APIs are supported.
• Use the open(), write(), read(), close(), and
  ioctl() functions to access the serial ports.
• Example
• fd open ("/com/1", (O_RDWR O_ NONBLOCK))

8
Serial Driver For UART (Cont.)
The following example demonstrates calls used to
send data through a serial port. fd open
("/com/0", O_RDWR) -OPEN PORT / set to 57600
baud rate / iOptions SIO_57600_BAUD result
ioctl(fd, SIO_BAUD_SET, iOptions) -CONFIGURE
BAUD RATE / set to 8 bit / 2 stop bits / even
parity / hardwarehandshaking / iOptions
SIO_EIGHT_BIT_DATA_WIDTH SIO_TWO_STOP_BITS
SIO_EVEN_PARITY SIO_HW_RTS_CTS_HANDSHAKING re
sult ioctl(fd, SIO_HW_OPTS_SET, iOptions)-
CONFIGURE HARDWARE numBytesSent write (fd,
sndBuffer, szBuffer) - WRITE BUFFER numBytesRecv
read (fd, rcvBuffer, szBuffer) - READ
BUFFER close (fd) - CLOSE PORT

9
SPI - Serial Peripheral Interface

• Communication between 2 Integrated Circuit
• Full duplex, Synchronous interface
• Physical Layer (TXD, RXD, CLK, EN)
• Character-oriented data channel
• Shorter distances (6 inches)
• Maximum port rate (SYSCLK/8)
• SPI Driver

10
SPI cont.
SPI Device
Chip Select
Serial Input
? 0x06 0x05
Serial Clock
10.168.4.0 ?

• Clock signal
• Enable and disable signal
• Input and output channels

11
SPI Mode - Master

• Master (NETARM 40/50 is a controller)
• Provides the Enable
• Generate SPI enable signal by hardware
  (SPI-M-ENABLE-A and SPI-M-ENABLE-B)
• Manually generate enable signal by firmware thru
  GPIO
• SPI enable signal active until entire buffer is
  transferred NETARM 50
• SPI enable signal active until after each byte
  (NETARM 40 Master and possibly Slave Mode
• Provides the SPI Clock
• Generate SPI clock signal (SPI-M-CLK-IN-A and
  SPI-M-CLK-IN-B)
• Data Transfer
• Transfer output data from TX FIFO (TXDA)
• Receive input data into RX FIFO (RXDA)
• Receive and transfer same number of bytes
• Read and write simultaneously
• Control one or more SPI peripheral

12
Master Mode Controller
13
SPI Mode - Slave

• Slave (NETARM 40/50 is a peripheral)
• Controlled by external SPI clock
• Receive input clock signal ( SPI_S_CLK_IN_A and
  SPI_S_CLK_IN_B )
• Controlled by external SPI enable
• Receive input enable signal ( SPI_S_ENABLE_A
  and SPI_S_ENABLE_B )
• Data Transfer
• Transfer output data from TX FIFO ( TXDA )
• Receive input data into RX FIFO ( RXDA )

14
Slave Mode - Peripheral
15
SPI Driver Objective

• Objective
• Provide easy and faster access to SPI channels
• Make hardware transparent to the users
• Remove burden with manipulating internal
  registers
• No duplication of code

16
SPI Driver - Library

• Source files located in \netos\src\bsp\devices\SPI

• netos_spi.c
• netos_spi.h
• Include file located in \netos\h\
• include ltspiDev.hgt
• Enable SPI Library
• Undefined BSP_INCLUDE_SERIAL_DRIVER_2 in
  lt\netos\h\bspconf.hgt
• Undefined NETOS_LED in lt\netos\h\narmled.hgt
• Recompile BSP build file located
  lt\netos\src\bsp\bsp.bldgt

17
High Speed Serial Driver

• Uses DMA channels 7,8,9 and 10
• Reaches up to a speed of 518400 baud along with
  33.1776 Mhz crystal
• However the max baud rate for the 50 chip is
  691200 based on 44 MHz Clock.  Reminder that the
  speed varies with the system clock
• Sends and receives more than 500,000 bytes per
  single sendreceive function call
• Supports Hardware hand shaking only

18
HDLC Open and Close Channel

• Opening and Closing the HDLC Channel

19
HDLC Transmit

• Allocating and Freeing HDLC Frames
• To allocate a frame, call pframe
  naHdlcFrameAlloc(size).
• The size argument can be any number less than or
  equal to the large frame size. Size 0is used to
  allocate empty frames. The actual frame buffer
  size is equal to the largeframe size, the small
  frame size, or 0.
• To free the frame, call naHdlcFrameFree(pframe).
• Sending HDLC Frames
• Use naHdlcFrameSend() to send a frame. Use the
  following procedure
• 1. Allocate a frame.
• 2. Copy data to the frame buffer, if needed.
• 3. Set pframe-gtheader, pframe-gthlen ,
  pframe-gtdata and pframe-gtdlen.
• 4. Call naHdlcFrameSend(channel, pframe, urgent,
  release) to queue
• the frame to send.

20
HDLC Transmit

• Sending HDLC Frames

21
HDLC Receive

• Receiving HDLC Frames
• The HDLC driver processes received frames as
  follows
• 1. The driver calls the naHdlcAcceptFun routine
  if this callback has been
• registered. If the callback returns FALSE, the
  driver discards the frame.
• 2. The driver allocates a frame structure of the
  size to fit the received frame. If the driver
  cant allocate the frame structure, it discards
  the frame.
• 3. If a small frame has been allocated, the
  driver copies received frame data to the buffer
  of the allocated frame. If a large frame has been
  allocated, the driver swaps the DMA buffer with
  the allocated frame buffer.
• 4. The driver sets data pointer to the received
  frame buffer and dlen to the actual frame size.
  header, hlen, and flags are equal to zero.
• 5. The driver calls the naHdlcReceivedFun routine
  if this callback routine has
• been registered. Otherwise, the driver queues the
  received frame.
• The user application should call the naHdlcFrame
  naHdlcFrameRecv(int
• channel) function to retrieve a frame queued by
  the driver. An application should free all
  received frames by calling naHdlcFrameFree().
• .

22
HDLC Receive

• Receiving HDLC Frames
