Goals

1

• Rendering Dynamic Terrain

• For Modeling MOUT
• in Military Simulations

2
Background

• The U.S. Militarys involvement in urban
  operations has escalated significantly over the
  past several years.
• MOUT simulation requires modeling complex
  environments and dynamic physical interactions of
  individuals/units within and with the
  environment.
• A considerable weakness is the inability to
  compatibly and accurately model diverse entity
  interactions with the environment.

Dynamic Structural Terrain
2
3
Objectives

• Represent structure-entity interactions
  structural-weapons effects for improved MOUT
  modeling.
• Model/describe complex environments
• - Visual Attributes (apertures, enclosures)
• - Physical Attributes (materials,
  characteristics)
• - Expandable/extensible
• Physics-based effects/results
• - Algorithm population (airblast, penetration)
• - Dynamic results are visual and documented

Dynamic Structural Terrain
3
4
Project Goal
Dynamic Structural Terrain
4
5
Project Goals

• Assess current/emerging methodologies and models
  for representing munitions effects on structures
• Proof of principle demonstration
• Develop a framework to enable deformations and
  dynamic effects within entity-level MS
• Generalized for additional structural weapons
  effects
• Contributes to KA/KE efforts for developing
  simulations
• Develop a computational data form to overcome
• current limitations to enable dynamic effects

Dynamic Structural Terrain
5
6
Resources

• Models
• WALTS/MEA
• BlastFX
• SWE/AT Planner
• Methods
• BRL CAD/ACIS
• Volume Vis
• Polygons

• Algorithms
• BlastX, PENCURV3D, HE Blast, SCIPUFF, SAMPLL,
  STEP, FOIL,HazL
• Source Data
• NIMA/DTED
• CTDB/WARSIM
• OpenFlight/Scene/GL
• STF (SEDRIS)
• VRML/X3D
• CAD

Dynamic Structural Terrain
6
7
Current Status

• Crude representation of damage to buildings
• Physics based models not rendered in real time
• Creation of rubble has been a problem
• Some advances made in the gaming industry

Dynamic Structural Terrain
7
8
Off-the-Shelf/Gaming Technology
Dynamic Structural Terrain
8
9
On-Going Work

• Don Nelson (ERDC)
• Structural Weapons
• Effects implemented
• in OneSAF TestBed (OTB)
• Mike Pace (ERDC)
• Rapid Building Generation in OneSAF TestBed (OTB)

Dynamic Structural Terrain
9
10
Structural Weapons Effects
Structural Weapons Effects (SWE) The response
of structures to conventional weapons effects

• Typical weapons effects
• Airblast
• Groundshock
• Penetration
• Fragmentation
• Cratering

• Typical structures
• Typical urban structures
• Hardened facilities
• Field fortifications
• Buried structures
• Bridges, towers

Conventional Weapon
SWE
Dynamic Structural Terrain
10
11
Structural Weapons Effects
Conventional Weapon
Blast wave / Gas Internal Airblast External
Airblast Ground Shock
Impact / Penetration Fragments Small
Arms Projectiles
Applied load results in
Conventional weapons effects can be divided into
two broad categories
Area response
Localized response
Dynamic Structural Terrain
11
12
Structural Weapons Effects
Weapon
Blast wave / Gas Internal Airblast External
Airblast Ground Shock
Impact / Penetration Fragments Small
Arms Projectiles
Structural response
SWE includes a wide range of phenomena and
structural responses

• Whole structure response
• Accelerations
• Displacement
• Whole component response
• Wall or slab damage from
• flexure, shear, spalling
• Frame damage
• Window fragments
• Breaching

• Impact response
• Spalling
• Ejecta
• Secondary fragments
• Breaching
• Structural supports
• Penetration response
• Internal effects
• Structural supports
• Breaching

Dynamic Structural Terrain
12
13
Structural Weapons Effects
Structural damage assessment is dependent on
structural details such as dimensions and
material properties, and the ability to calculate
or estimate the applied loads.

• Technical Issues
• Structural details - Material types, material
  properties, component details suchas wall
  thickness, steel ratios, spans, etc., are
  necessary for structural damageassessment. May
  have to rely on estimates.
• Urban layout effects - Calculation of external
  airblast loads can be complicated by the
  arrangement of adjacent buildings which can focus
  or shield airblast loads causing load enhancement
  or reduction.
• Building internal geometries - In general MS
  apps need better definition of building interior
  layout for assessing damage to direct hits and
  internal detonations. Rapid building generation
  is an important stepping-stone towards this end.

Dynamic Structural Terrain
13
14
Structural Weapons Effects
Structural damage assessment is non-existent or
overly simplistic in many MS applications. The
payoff of realistic structural damage assessment
is greatly improved usefulness of MS
applications for MOUT and the enhancement a wide
range of MOUT scenarios.

• Structural weapons effects positively impact many
  MOUT related issues
• Mobility - Rubble, building access, breaching,
  line of sight
• Casualties - Primary and secondary fragments,
  collateral damage, structural collapse
• Weapon effectiveness - Focusing (enhancement),
  shielding (attenuation), penetration
• Vulnerability - Enemy and friendly positions in
  structures, equipment, utilities

All of these benefit from improved structural
damage assessment
Dynamic Structural Terrain
14
15
Rapid Building Generation

• Rapid generation of building geometry
• Use of COTS,
• GOTS packages

Dynamic Structural Terrain
15
16
Creating a CTDB with an MES Building
Rapid Building Generation

• Model the building in Floorplan 3D
• - Take out extraneous objects
• Model windows and doors as openings with only a
  facing
• Export the geometry as a DXF file (contains
  3DFACE objects)
• Group 3DFACE objects by enclosure and aperture
• - Objects from FloorPlan 3D are grouped as walls,
  doors, windows, floors, ceilings

Dynamic Structural Terrain
16
17
Creating a CTDB with an MES Building
Rapid Building Generation

• Run MES Toolkit
• - Import DXF file
• - Execute mes_out function to produce .rdr file
• Modify .rdr file header with appropriate
  positional information and scale factor
• Run recompile program using the .rdr file and
  desired database
• Must use the no_mesrel switch for proper
  operation of the MES

Dynamic Structural Terrain
17
18
Commercial Software
Dynamic Structural Terrain
18
19
Building an Urban Database

• Model buildings using Creator Pro to use SAICs
  tool to make an .rdr file from Openflight.
• Model terrain using Terratools
• Place Openflight models from Creator Pro on
  terrain using Terratools
• Export Openflight from Terratools for visual
  database
• Export database from Terratools as SEDRIS file
• Use Litton/TASC translator from SEDRIS to CTDB
• User recompile tool with .rdr files to place
  buildings on CTDB
• View visual database using RBD SVS2

Dynamic Structural Terrain
19
20
SAIC - McKenna MOUT
Dynamic Structural Terrain
20
21
SAIC IDA VERTS
Dynamic Structural Terrain
21
22
What is X3D?

• Extensible 3D (X3D) Graphics
• Virtual Reality Modeling Language (VRML) updated
• Third-generation ISO specification
• Both XML and .wrl encodings, compatibly
• Deliverables
• Specification updates, with compatible XML tagset

• Multiple implementations, including open-source
  example
• Scene Authoring Interface (SAI) strongly typed
  API
• Conformance suite and examples
• Authoring capability X3D-Edit

23
Further X3D motivations

• Authoring is hard, Content is King
• X3D is not competing with specialty formats,
  instead provide common interoperability/interchang
  e
• Strong validation checks eliminate most authoring
  errors before content escapes
• Plays well with next-generation Web languages
• 3D hardware problem is already solved ?

24
Primary benefits of XML

• Simpler parsing, with lots! of software tools
• Validation of content
• Nodes can only go together in legal ways
• Validate values (e.g. color-triplet arrays)
• Broken content cant escape
• Fixes the garbage in, garbage out problem
• XML finally enables structured data
• hmmm, structured programming was important

25
XML in 10 Pointshttp//www.w3.org/XML/1999/XML-in
-10-points

• XML is for structuring data
• XML looks a bit like HTML
• XML is text, but isn't meant to be read
• XML is verbose by design
• XML is a family of technologies

• XML is new, but not that new
• XML leads HTML to XHTML
• XML is modular
• XML is the basis for RDF and the Semantic Web
• XML is license-free, platform-independent and
  well-supported

26
XML tool design IBMs Xeena

• X3D-Edit constructed using IBMs Xeena
• XML-based tool builder for editing XML tagsets
• Configured via XML Document Type Definition (DTD)
• Implemented in Java, portable Windows Mac Linux
• Tagset and XML configuration profile determines
  syntax, rules within customized interface
  functionality
• Multilingual customization possible
• Scalable approach for other XML tools
• http//www.alphaWorks.ibm.com/tech/xeena .
  thank you IBM!

27
X3D-Edit complete interface
28
Website content archive

• Root content is X3D in XML encoding
• Validation checking for all nodes, attributes
• Conversions
• Extensible Stylesheet Language for
  Transformations (XSLT) rule-based pattern
  matching, fast, flexible
• .html, .wrl (VRML encoding), others possible
• Website archives
• Long-term maintainability
• Solves content rust problem, which never sleeps

29
(No Transcript)
30
Content archive
31
SAVAGE archive
32
VRML 97 import capability

• Embeds NIST translator
• converts VRML scenes to X3D encoding
• Qiming Wang, author
• Open-source Java
• includes PW parser
• http//ovrt.nist.gov/v2_x3d.html

1
2
3
33
Other XML-based tools

• Next-generation tagset X3D Schema
• XML Schema specification includes tooltip and URL
  annotation mechanisms already
• Will merge various tooltips into master X3D
  schema
• Other XML-based authoring tools
• Editors read schema and become X3D capable
• Thus numerous XML editors can become 3D-aware,
  without effort

34
XML Spy tool editing X3D
35
Open source available for X3D Xj3D

• Xj3D is a Java implementation of a 3D browser
• VRML/X3D scene graph extensions
• Now working on Java-OpenGL bindings
• Unadvertised, 26 downloads/day
• SIGGRAPH 2002 distribution X3D Software
  Development Kit (SDK)
• LGPL license unrestricted use, private or
  commercial
• http//www.web3d.org/TaskGroups/source/xj3d.html
• Open sources has completely changed our working
  processes for the better, both for small
  contributors and big companies
• no more possibility of single-point failure
• guarantees that third-generation VRML/X3D will
  ship

36
Online resources

• X3D-Edit
• http//www.web3D.org/x3d.html
• http//www.web3d.org/TaskGroups/x3d/translation/RE
  ADME.X3D-Edit.html
• http//www.web3d.org/TaskGroups/x3d/translation/X3
  D-Edit.zip, .gz
• http//www.web3d.org/TaskGroups/x3d/translation/X3
  D-Examples.zip
• http//www.web3d.org/TaskGroups/x3d/translation/X3
  dTooltips.html
• http//www.web3d.org/TaskGroups/x3d/translation/X3
  D-EditAuthoringTool.pdf
• http//www.web3d.org/TaskGroups/x3d/translation/X3
  D-EditAuthoringTool.ppt
• oh yeah its all free and open
• Help
• http//www.web3d.org/TaskGroups/x3d/translation/ex
  amples/help.html

37
Web3D Consortium

• Leading forum for open 3D graphics development
• Partner membership of companies, agencies,
  universities and professional members
• Hosts multiple working groups X3D, GeoVRML,
  Humanoid Animation, Distributed Interactive
  Simulation (DIS)
• New group organized by member Intel CAD-Web3D
  organizational meeting Thursday September 5 Santa
  Clara
• Annual Web3D Symposia
• Cosponsor with ACM SIGGRAPH, host France Telecom
• February 9-12, Saint Malo France

38
Web3D X3D Software Development Kit CDs

• Extensive exemplar content, open-source Xj3D, more

http//sdk.web3D.org
39
X3D Press Release, SIGGRAPH 2002
40
CAD-Web3D press releasehttp//www.intel.com/pres
sroom/archive/releases/20020723.htm
41
Two Track Approach

• Secure/Hi-Resolution
• Server-Based
• API
• Source, Maintenance
• Open/Unconstrained
• Publicly available codes
• Leverage MOVES curriculum/model archives

Dynamic Structural Terrain
42
Spectrum Of Fidelity
Dynamic Structural Terrain
43
Extensible Terrain Representation Authoring for
the Synthetic and Natural Environment (EXTRA SNE)
Future Work

• Terrain Representations and vehicular movement
  rates
• Structural Weapons API
• - Airblast - Penetration - Rubbling
• - Cratering - Glass Damage - Structural
  Collapse
• Rapid Building Generation
• - GUI
• - Import
• Future Implementations
• - Worldwide Construction Practices - At Planner
• - NATO Reference Mobility Model - CAD imports

Dynamic Structural Terrain
44
Contact

• Nick Wittwer
• Nick.wittwer_at_trac.nps.navy.mil
• TRADOC Analysis Center
• Naval Postgraduate School
• PO Box 8692
• Monterey California 93943-5000 USA
• [phone] voice
• [phone] fax

Dynamic Structural Terrain
45
Contact

• Don Brutzman
• brutzman_at_nps.navy.mil
• http//web.nps.navy.mil/brutzman
• Code UW/Br, Naval Postgraduate School
• Monterey California 93943-5000 USA
• 831.656.2149 voice
• 831.656.3679 fax
