Software Testing Basics

1
Software Testing Basics

• Elaine Weyuker
• ATT Labs Research
• Florham Park, NJ
• November 11, 2002

2
What is Software Testing?

• Executing software in a simulated or real
  environment, using inputs selected somehow.

3
Goals of Testing

• Detect faults
• Establish confidence in software
• Evaluate properties of software
• Reliability
• Performance
• Memory Usage
• Security
• Usability

4
Software Testing Difficulties

• Most of the software testing literature equates
  test
• case selection to software testing but that is
  just one
• difficult part. Other difficult issues include
• Determining whether or not outputs are correct.
• Comparing resulting internal states to expected
  states.
• Determining whether adequate testing has been
  done.
• Determining what you can say about the software
  when testing is completed.
• Measuring performance characteristics.
• Comparing testing strategies.

5
Determining the Correctness of Outputs

• We frequently accept outputs because they are
  plausible
• rather than correct.
• It is difficult to determine whether outputs are
  correct because
• We wrote the software to compute the answer.
• There is so much output that it is impossible to
  validate it all.
• There is no (visible) output.

6
Dimensions of Test Case Selection

• Stages of Development
• Source of Information for Test Case Selection

7
Stages of Testing

• Testing in the Small
• Unit Testing
• Feature Testing
• Integration Testing

8
Unit Testing

• Tests the smallest individually executable code
  units.
• Usually done by programmers. Test cases might be
• selected based on code, specification, intuition,
  etc.
• Tools
• Test driver/harness
• Code coverage analyzer
• Automatic test case generator

9
Integration Testing

• Tests interactions between two or more units or
• components. Usually done by programmers.
• Emphasizes interfaces.
• Issues
• In what order are units combined?
• How do you assure the compatibility and
  correctness of externally-supplied components?

10
Integration Testing

• How are units integrated? What are the
  implications of this order?
• Top-down gt need stubs top-level tested
  repeatedly.
• Bottom-up gt need drivers bottom-levels tested
  repeatedly.
• Critical units first gt stubs drivers needed
  critical units tested repeatedly.

11
Integration Testing

• Potential Problems
• Inadequate unit testing.
• Inadequate planning organization for
  integration testing.
• Inadequate documentation and testing of
  externally-supplied components.

12
Stages of Testing

• Testing in the Large
• System Testing
• End-to-End Testing
• Operations Readiness Testing
• Beta Testing
• Load Testing
• Stress Testing
• Performance Testing
• Reliability Testing
• Regression Testing

13
System Testing

• Test the functionality of the entire system.
• Usually done by professional testers.

14
Realities of System Testing

• Not all problems will be found no matter how
  thorough or systematic the testing.
• Testing resources (staff, time, tools, labs) are
  limited.
• Specifications are frequently unclear/ambiguous
  and changing (and not necessarily complete and
  up-to-date).
• Systems are almost always too large to permit
  test cases to be selected based on code
  characteristics.

15
More Realities of Software Testing

• Exhaustive testing is not possible.
• Testing is creative and difficult.
• A major objective of testing is failure
  prevention.
• Testing must be planned.
• Testing should be done by people who are
  independent of the developers.

16
Test Selection Strategies
Every systematic test selection strategy can be
viewed as a way of dividing the input domain into
subdomains, and selecting one or more test case
from each. The division can be based on such
things as code characteristics (white box),
specification details (black box), domain
structure, risk analysis, etc. Subdomains are
not necessarily disjoint, even though the testing
literature frequently refers to them as
partitions.
17
The Down Side of Code-Based Techniques

• Can only be used at the unit testing level, and
  even then it can be prohibitively expensive.
• Dont know the relationship between a
  thoroughly tested component and faults. Can
  generally argue that they are necessary
  conditions but not sufficient ones.

18
The Down Side of Specification-Based Techniques

• Unless there is a formal specification, (which
  there rarely/never is) it is very difficult to
  assure that all parts of the specification have
  been used to select test cases.
• Specifications are rarely kept up-to-date as the
  system is modified.
• Even if every functionality unit of a
  specification has been tested, that doesnt
  assure that there arent faults.

19
Operational Distributions

• An operational distribution is a probability
  distribution
• that describes how the system is used in the
  field.

20
How Usage Data Can Be Collected For New Systems

• The input stream for this system is also the
  input stream for a different already-operational
  system.
• The input stream for this system is the output
  stream for a different already-operational
  system.
• Although this system is new, it is replacing an
  existing system which ran on a different
  platform.
• Although this system is new, it is replacing an
  existing system which used a different design
  paradigm or different programming language.
• There has never been a software system to do this
  task, but there has been a manual process in
  place.

21
Operational Distribution-Based Test Case Selection

• A form of domain-based test case selection.
• Uses historical usage data to select test cases.
• Assures that the testing reflects how it will be
  used in the field and therefore uncovers the
  faults that users are likely to see.

22
The Down Side of Operational Distribution-Based
Techniques

• Can be difficult and expensive to collect
  necessary data.
• Not suitable if the usage distribution is uniform
  (which it never is).
• Does not take consequence of failure into
  consideration.

23
The Up Side of Operational Distribution-Based
Techniques

• Really does provide a user-centric view of the
  system.
• Allows you to say concretely what is known about
  the systems behavior based on testing.
• Have metric that is meaningfully related to the
  systems dependability.

24
Domain-Based Test Case Selection

• Look at characteristics of the input domain or
  subdomains.
• Consider typical, boundary, near-boundary cases
  (these can sometimes be automatically generated).

• This sort of boundary analysis may be meaningless
  for non-numeric inputs. What are the boundaries
  of Rome, Paris, London, ?
• Can also apply similar analysis to output values,
  producing output-based test cases.

25
Domain-Based Testing Example

• US Income Tax System
• If income is Tax is
• 0 - 20K 15 of total income
• 20 -50K 3K 25 of amount over 20K
• Above 50K 10.5K 40 of amount over 50K
• Boundary cases for inputs 0, 20K, 50K

26
Random Testing

• Random testing involves selecting test cases
  based
• on a probability distribution. It is NOT the same
  as
• ad hoc testing. Typical distributions are
• uniform test cases are chosen with equal
  probability
• from the entire input domain.
• operational test cases are drawn from a
  distribution
• defined by carefully collected historical usage
  data.

27
Benefits of Random Testing

• If the domain is well-structured, automatic
  generation can be used, allowing many more test
  cases to be run than if tests are manually
  generated.
• If an operational distribution is used, then it
  should approximate user behavior.

28
The Down Side of Random Testing

• An oracle (a mechanism for determining whether
  the output is correct) is required to determine
  whether the output is correct.
• Need a well-structured domain.
• Even a uniform distribution may be difficult or
  impossible to produce for complex domains, or
  when there is a non-numeric domains.
• If a uniform distribution is used, only a
  negligible fraction of the domain can be tested
  in most cases.
• Without an operational distribution, random
  testing does not approximate user behavior, and
  therefore does not provide an accurate picture of
  the way the system will behave.

29
Risk-based Testing

• Risk is the expected loss attributable to the
  failures
• caused by faults remaining in the software.
• Risk is based on
• Failure likelihood or likelihood of occurrence.
• Failure consequence.
• So risk-based testing involves selecting test
  cases
• in order to minimize risk by making sure that the
  most
• likely inputs and highest consequence ones are
  selected.

30
Risk-based Testing

• Example ATM Machine
• Functions Withdraw cash, transfer money, read
  balance, make payment, buy train ticket.
• Attributes Security, ease of use, availability

31
Risk Priority Table
Features Attributes Occurrence Likelihood Failure Consequence Priority (L x C)
Withdraw cash High 3 High 3 9
Transfer money Medium 2 Medium 2 4
Read balance Low 1 Low 1 1
Make payment Low 1 High 3 3
Buy train ticket High 3 Low 1 3
Security Medium 2 High 3 6
32
Ordered Risk Priority Table
Features Attributes Occurrence Likelihood Failure Consequence Priority (L x C)
Withdraw cash High 3 High 3 9
Security Medium 2 High 3 6
Transfer money Medium 2 Medium 2 4
Make payment Low 1 High 3 3
Buy train ticket High 3 Low 1 3
Read balance Low 1 Low 1 1
33
Acceptance Testing

• The end user runs the system in their environment
  to
• evaluate whether the system meets their criteria.

• The outcome determines whether the customer will
• accept system. This is often part of a
  contractual
• agreement.

34
Regression Testing

• Test modified versions of a previously validated
• system. Usually done by testers. The goal is to
• assure that changes to the system have not
• introduced errors (caused the system to regress).
• The primary issue is how to choose an effective
• regression test suite from existing,
  previously-run
• test cases.

35
Prioritizing Test Cases

• Once a test suite has been selected, it is often
• desirable to prioritize test cases based on some
• criterion. That way, since the time available for
• testing is limited and therefore all tests cant
  be
• run, at least the most important ones can be.

36
Bases for Test Prioritization

• Most frequently executed inputs.
• Most critical functions.
• Most critical individual inputs.
• (Additional) statement or branch coverage.
• (Additional) Function coverage.
• Fault-exposing potential.

37
White-box Testing

• Methods based on the internal structure of code
• Statement coverage
• Branch coverage
• Path coverage
• Data-flow coverage

38
White-box Testing

• White-box methods can be used for
• Test case selection or generation.
• Test case adequacy assessment.
• In practice, the most common use of white-box
• methods is as adequacy criteria after tests have
  been
• generated by some other method.

39
Control Flow and Data Flow Criteria

• Statement, branch, and path coverage are examples
  of control flow criteria. They rely solely on
  syntactic characteristics of the program
  (ignoring the semantics of the program
  computation.)
• The data flow criteria require the execution of
  path segments that connect parts of the code that
  are intimately connected by the flow of data.

40
Issues of White-box Testing

• Is code coverage an effective means of detecting
  faults?
• How much coverage is enough?
• Is one coverage criterion better than another?
• Does increasing coverage necessarily lead to
  higher fault detection?
• Are coverage criteria more effective than random
  test case selection?

41
Test Automation

• Test execution Run large numbers of test
  cases/suites without human intervention.
• Test generation Produce test cases by processing
  the specification, code, or model.
• Test management Log test cases results map
  tests to requirements functionality track test
  progress completeness

42
Why should tests be automated?

• More testing can be accomplished in less time.
• Testing is repetitive, tedious, and error-prone.
• Test cases are valuable - once they are created,
  they can and should be used again, particularly
  during regression testing.

43
Test Automation Issues

• Does the payoff from test automation justify the
  expense and effort of automation?
• Learning to use an automation tool can be
  difficult.
• Tests, have a finite lifetime.
• Completely automated execution implies putting
  the system into the proper state, supplying the
  inputs, running the test case, collecting the
  results, and verifying the results.

44
Observations on Automated Tests

• Automated tests are more expensive to create and
  maintain (estimates of 3-30 times).
• Automated tests can lose relevancy, particularly
  when the system under test changes.
• Use of tools require that testers learn how to
  use them, cope with their problems, and
  understand what they can and cant do.

45
Uses of Automated Testing

• Load/stress tests -Very difficult to have very
  large numbers of human testers simultaneously
  accessing a system.
• Regression test suites -Tests maintained from
  previous releases run to check that changes
  havent caused faults.
• Sanity tests - Run after every new system build
  to check for obvious problems.
• Stability tests - Run the system for 24 hours to
  see that it can stay up.

46
Financial Implications of Improved Testing

• NIST estimates that billions of dollars could be
  saved each year if improvements were made to the
  testing process.
• NIST Report The Economic Impact of Inadequate
  Infrastructure for Software Testing, 2002.

47
Estimated Cost of Inadequate Testing
Cost of Inadequate Software Testing Potential Cost Reduction from Feasible Improvements
Transportation Manufacture 1,800,000,000 589,000,000
Financial Services 3,340,000,000 1,510,000,000
Total U.S. Economy 59 billion 22 billion
NIST Report The Economic Impact of Inadequate
Infrastructure for Software Testing, 2002.
