Network-level Malware Detection

1
Network-level Malware Detection

• Mike McNett, Matthew Spear, Richard Barnes
• CS-851 Malware
• 23 October 2004

2
Outline

• Introduction Design of a System for Real-Time
  Worm Detection
• Example 1 Detecting Early Worm Propagation
  through Packet Matching (DEWP)
• Example 2 Fast Detection of Scanning Worm
  Infections
• Example Application Therminator
• Conclusions

3
Introduction

• Questions Being Considered
• Why network level detection?
• What are the alternatives?
• Are there reasonable solutions?
• What are the limitations, advantages,
  disadvantages compared to the alternatives?

4
Introduction

• Malware Detection Options?
• Prevention vs. Treatment
• Signature vs. Anomaly
• Host-based containment
• Network containment
• Packet Header vs. Packet Payload
• What are the advantages, disadvantages, and
  limitations of the above?

5
Network-level Detection
6
Design of a System for Real-Time Worm Detection

• Hash
• Count Vector
• Character Filter
• SRAM Analyzer
• Alert Generator
• Periodic Subtraction of Time Averages

7
Design of a System for Real-Time Worm Detection

• Scalable to high throughput
• Solution depends on specialized hardware
• Low false positive rate
• What are the problems?
• What are the advantages?
• Are there other, more simplistic signatures?
• Can similar attacks be detected at the host level?

8
Detecting Early Worm Propagation through Packet
MatchingXuan Chen and John Heidemann
ISI-TR-2004-585February 2004
9
DEWP

• Router-based system
• automatically detects and quarantines Internet
  worm propagation
• matches destination port numbers between incoming
  and outgoing connections (automated signature
  creation)
• detects and suppresses worms due to unusual
  traffic patterns
• detects worm propagation within about 4 seconds
• protects gt 99 hosts from random-scanning worms

10
DEWP Thesis

• Matches destination port numbers between incoming
  and outgoing connections. Two observations on
  worm traffic
• Worms usually exploit vulnerabilities related to
  specific network port numbers
• Infected hosts will probe other vulnerable hosts
  exploiting the same vulnerability
• So high levels of bi-directional probing traffic
  with the same destination port number ? new worm
• Scalable Matching destination port numbers
  consumes low computational power

11
DEWP

• Two components of DEWP worm detector and packet
  filter
• Two step detection destination port matching and
  destination address counting
• Uses packet filtering to suppress worm spreading
• Can deploy at different levels of network

12
Worm Containment

• DEWP uses traffic filtering routers drop
  packets with the automatically discovered
  destination port
• Worm containment protect internal hosts from
  internal and external threats notify other
  networks about attacks

13
Design

• Maintains one port-list for each direction
  (incoming and outgoing) records number of
  connections to different destination ports
• Timer for each entry in port-lists
• If port has not been accessed for certain time
  interval, reset corresponding list entry
• Monitor outgoing destination addresses of
  non-zero entries in both port-lists
• Every T seconds, check number of unique addresses
  observed within last time interval. Worm traffic
  detected with the following condition
• N is the number of unique addresses observed.
• Long-term average
• ? is the system sensitivity to changes

14
Effectiveness of Worm Detection and Quarantine

• Random scanning worm detects worm traffic in 4.8
  seconds when fully deployed with a 1 second
  detection interval.
• Always detects worm probing traffic in 4-5
  seconds when deployed to different layers.
• Number of infected hosts in the protected network
  primarily determined by the number of probing
  packets received from outside
• Can protect almost all hosts from infection when
  only deployed on the access router.

15
Local Scanning

• Local scanning Can detect worm probing traffic
  in 3.87 seconds. But, almost all vulnerable hosts
  in the protected network are compromised
• Deployment has little impact on either detection
  delay or infection percentage.
• The infection percentage increases as number DEWP
  deployed layers are reduced When only on the
  access router ? all vulnerable hosts compromised
  within 10 seconds
• More frequent detection reduces vulnerability to
  local-scanning worms
• DEWP quickly detects worm attacks regardless
  probing techniques.
• With full deployment about 9 vulnerable hosts
  compromised in the protected network
• Due to difficulty to effectively quarantine
  local-scanning worms ? a very small detection
  interval and wide deployment is critical to
  protect vulnerable hosts

16
Effect of Detection Intervals

• Address-counting with an interval of T seconds.
• Different detection intervals affect detection
  delay and infection percentage
• Random-scanning worm. Detection delay and the
  number of infected hosts increases with detection
  intervals.
• Local-scanning worms 1) No significant
  difference in detection delay 2) Infection
  percentage increases dramatically at larger
  intervals
• So, automatic system needs to react to worm
  traffic within small time intervals

17
False Detections

• No false positives
• Discovered 10 suspicious destination ports
  including 21 (FTP), 53 (DNS), and 80 (Web)
• Depends on address-counting to reduce false
  positives
• Worm scan rate C affects false negatives when
  worm scan at low rate, probing traffic has less
  effect on overall traffic. DEWP routers have
  more difficulty distinguishing them from normal
  traffic.
• With C 500 ? worm traffic stands out compared
  to regular traffic
• DEWP is not able to detect worms with scanning
  rate lower than C 25.

18
Conclusions

• Detects and quarantines propagation of Internet
  worms
• Uses port-matching and address-counting as the
  signature.
• Detects worm attack within 4-5 seconds
• By automatically blocking worm traffic, it
  protects most vulnerable hosts from
  random-scanning worms.
• Authors believe that an automatic worm detection
  and containment system should be widely deployed
  and have very small detection intervals
• Not realistic to deploy DEWP on all routers for
  random scanning worms sufficient to put on
  access router.

19
Worm Detection
Fast Detection of Scanning Worm Infection
20
Detection Techniques

• Reverse Sequential Hypothesis Testing (TH)
• Detects worms based upon number of failed
  connection attempts
• Uses probability to determine if a local host is
  scanning
• Designed to be tied into a containment system
• Signature Based Analysis (Early Bird System
  (EBS))
• Detects worms based upon Rabin signatures of
  content/port
• Used in conjunction with a containment system

21
Definitions
l Local Host
d Destination Address
FCC First contact connection
Yi Indicator variable of ith FCC
H0 Hypothesis that l is not scanning
H1 Hypothesis that l is scanning
?k Pr(Yi 0 Hk) k ? 0,1
?0 Upper bound to accept H1
?1 Lower bound to accept H0
22
Definitions


PD Probability of detecting an infected host
PF Probability of host as infected when it is not
a Upper bound on PF (a PF)
ß Lower bound on PD (ß PD)
Cl Credits for l
23
Basic Algorithm

• Maintain separate state information for each host
  (l) being monitored ( ), the hosts that
  have been previously contacted, and an FCC queue
  (FCCQ) of first contact attempts that have been
  attempted but have not been recorded in the
  observation (PCH).
• When a packet is observed check to see if d is in
  the PCH of l, if not then add d ? PCH and add the
  attempt to FCCQ as PENDING.
• When an incoming packet is sent to l and the
  source address exists in FCCQ update the record
  to SUCCESS in the FCCQ unless the packet is a TCP
  RST.
• When the head entry of FCCQ has status of PENDING
  and has been in queue for longer than a
  predefined time limit set its status to FAILURE.
• If the entry at the head of FCCQ has status other
  than PENDING update and compare it to
  ?1

24
Basic Algorithm
Credit Based Connection Rate Limiting (CBCRL)

• Simple scheme to limit the amount of connections
  l can make in a given slot of time by allotting
  each l a set number of credits (Cl) that is
  modified given events.

Event Change to Cl
Initial Cl ? 10
FCC issued by l Cl ? Cl - 1
FCC succeeds Cl ? Cl 2
Every second Cl ? if Cl gt 10
Allowance Cl ? 1 if Cl 0 for 4 seconds

• Used in conjunction with TH to limit number of
  connections a host can make allowing TH time to
  determine if a host is infected.

25
Experiment

• Conducted two experiments in 2003 (isp-2003) and
  2004 (isp-04).
• Worms identified via comparing traffic to known
  worm descriptions.

isp-03 isp-04
Date APR 10 2003 JAN 28 2004
Duration 627 min 66 min
Total Outbound connection attempts 1402178 178518
Total Active Local hosts 404 451
?0 .7 .7
?1 .1 .1
a 5E-5 5E-5
ß .99 .99
26
Results
isp-03 isp-04
Worms Detected (Total) 5 6
CodeRed II 2 0
Blaster 0 1
MyDoom 0 3
Minmail.j 0 1
HTTP (other) 3 1
False Alarms (Total) 0 6
HTTP 0 3
SMTP 0 3
P2P Detected (Total) 6 11
Total Identified 11 23
Alarms Detection Efficiency Effectiveness
TH 34 11 .324 .917
27
Limitations, Future Work?
Are there any serious flaws in this
algorithm? Future work?

• Warhol type scanning
• Network outages can cause TH to decide that a
  host is a worm
• Worms could conceivably collaborate to defy
  detection
• Worms could remember hosts that it can contact
  and defy detection through them
• Spoofing attack to get an uninfected host blocked
• Interleave scanning with benign activities (i.e.
  for every scan visit a website that is known to
  be running)

• Can trivially modify to work with the containment
  strategies discussed earlier

28
THERMINATOR!!!

• Science comes to the aid of network-level anomaly
  detection

29
Network behavior is complicated

• How do we use microscopic packet-level data to
  make macro network-level decisions?
• Too broad, e.g. keeping track of global traffic
  patterns.
• Too refined, e.g. looking at individual packets.
• Hmm who else tries to make sense of the overall
  behavior of millions of single objects?
• Physicists and Chemists!

30
Idea

• Given a computer network with gt1000 nodes,
• Want to detect anomalous traffic, without any
  foreknowledge.
• Idea of THERMINATOR
• Take advantage of lots of packet-level data.
• Use physical techniques to distill information
  into relevant statistics Temperature, entropy,
  etc.

31
Data Reduction

• Take the set of hosts and group them into
  buckets or conversation groups.
• Observe communication among buckets.
• Calculate physical statistics based on these
  higher-level communications.
• By virtue of the mathematics, these are
  guaranteed to be the same as if wed just looked
  at hosts.

32
Physical Network Visualization

• Based on reduced data, we know pseudo-physical
  statistics
• Bucket size
• Temperature
• Entropy
• Heating rate
• Work rate
• Visualizing these data shows network events.

Image courtesy of DISA
33
Network Event Detection
34
THERMINATOR Implementation

• Jointly developed by DISA, NSA, and Lancope Inc.
• Uses Lancopes data-collection hardware to
  provide data to THERMINATOR.
• THERMINATOR reduces data, computes stats, and
  provides visualization.
• Research tests validated that THERMINATOR
  detected anomalies that the intrusion detection
  systems did not capture. -- NSA

35
Conclusion

• Combined approaches (host-based, network-based,
  visualization)?
• Can signatures be automatically generated?
• Can attacks be visualized?
• Potential impacts of false positives (is the
  medicine worse than the sickness) and automated
  containment?
• Need different solutions for local-scanning vs.
  non-local scanning worms?
• Are there other scientific areas that malware
  research can leverage?
