OSAPARLAY TRAINING SESSION

1
OSA/PARLAY TRAINING SESSION

• Mårten Lundgren M.Sc
• System Developer
• Service Layer Development Ericsson AB
• marten.lundgren_at_ericsson.com

2
The overall agenda

• Morning
• OSA/Parlay Development
• Benefits using Parlay and Parlay X
• Afternoon
• OSA/Parlay exercises
• Parlay X exercises
• All of you interested in joining the afternoon
  session are welcome to copy the teaching material
  as soon as possible to save time later on.

3
OSA/Parlay Agenda

• Examples of Parlay Services
• Some market potential
• Fundamentals of Parlay application development
• Key factors for killer services
• A Parlay application development process
• Know the possibilities
• Identify a need
• Develop the service
• Use Case
• Sequence
• Pattern
• Structure
• Lifecycle
• Test and Tools
• Deploy
• Summarization

4
Some service examples
etc
5
Market potential

• The Chinese new year holiday of 2006 generated
  12.6 billion sent SMS messages. Source Interfax
  China IT Telecom Report, 2006
• Penetration of unique individuals in Latin
  America with mobile wireless access will increase
  from 27 to 41 between 2004-9. Source Yankee
  Group, January 2006

Source Yankee Group, January 2006
6
Market potential
Forecast split of mobile service revenue in
Western Europe by broad service category, 20039
Source Analysys Research, 2004
100
90
80
70
Mobile content
60
50
Other non-voice
40
Voice
30
20
10
0
2003
2004
2005
2006
2007
2008
2009
7
Motivation Why get involved?

• HTML for the WWW
• Global availability
• Access to anywhere, whenever
• Fat clients (PC)
• Often fixed

• Parlay for the Telecom
• Personal availability
• Access to anywhere, whenever from wherever
• Thin clients (Phone)
• Often portable

Getting access to the bank in the middle of the
night in a taxi from the airport.
Getting access to the bank in the middle of the
night.
Mobility adds a new dimension for service
creation!
8
How to create the next killer service?

• Need for a foundation consisting of
• technology competence
• ingenuity
• clear roles
• joined effort
• process understanding
• visibility

joined effort
clear roles
Reach out
ingenuity
Deploy
Develop service
technology
Identify need
Know the possibilities
9
Know the possibilities

• Parlay specifications
• Framework (access and authentication)
• Call Control (voice)
• User Interaction (SMS, MMS, WAP, email)
• Mobility (geographic location, general status)
• Terminal Capabilities (phone features)
• Generic Messaging (message system)
• Charging (payment)
• Data Session Control (typically GPRS session
  management)
• Connectivity Manager (quality of service, virtual
  private network)
• Account Management (charging event notification)
• Presence and Availability Management (status on
  various devices)
• Multi-Media Messaging (voice mail, email,
  multimedia)
• Policy Management (policy enabled network access)

10
Know the possibilities

• Parlay X specifications
• Third Party Call (application generated calls)
• Call Notification (call information)
• Short Messaging (sms)
• Multimedia Messaging (mms)
• Payment (charging)
• Account Management (balance information)
• Terminal Status (state of terminal)
• Terminal Location (geographic position)
• Call Handling (rule management)
• Audio Call (playing audio)
• Multimedia Conference (group broadcasts)
• Address List Management (user group management)
• Presence (messaging availability)

11
Know the possibilities

• Locate Operator / Service Enabler
• List supported Parlay services
• Get the preferred Gateway Supplier resources
• Locate Gateway Supplier
• Get compliance statement from current Gateway
  Supplier
• Get Parlay SDK (API, Simulators, Examples)
• Choose implementation specifics
• Programming language
• Good IDE (Borland JBuilder, Eclipse, Visual
  Studio .NET)

12
Identify a need

• Innovate on mobility as a key differentiator
• Reuse existing resources and technologies (simple
  solutions may yet be very powerful)
• Limit the service dependency service by service
  approach

13
Develop service

• Consider various PGW vendors for their support
  in
• Code libraries, Application Program Interfaces
  (APIs)
• Test tools, Simulators, Emulators
• Documentation, Guides, Trainers
• Parlay Standard compliance
• Partnership program availability
• Example applications
• Access to online forums and customer support
• Certification
• Access standard specifications and download IDL
  (Parlay) or WSDL (Parlay X) files to generate
  code stubs.

14
Deploy

• To mass market and/or to target a specific PGW /
  Operator
• Network protocol considerations
• Visibility to the end user (how to promote
  service)
• Visibility for the developer (who are buying)
• Visibility for the operator / service enabler
  (who are selling)

15
A Parlay example - Foundation

• Know the possibilities
• Parlay User Interaction (SMS MMS)
• Parlay Mobility (User Location)
• Identify a need
• Hard to find somewhere to eat (mobility)
• Develop service
• Java development on Eclipse using the Ericsson
  Network Resource Gateway Software Development
  Kit.
• Deploy
• Local Swedish operator agrees to become the
  first offer customer.

16
A Parlay example Use Case

• Sending SMS to a service number will return a MMS
  with directions for the nearest restaurant that
  matches the criteria of the search. User can then
  optionally decide to call the restaurant to make
  reservations.

17
Parlay example Sequence
Consumer
Application
PGW
1. create notification
2. send sms
2. report notification
3. get user location
4. report user location
5. get info
5. send mms
6. receive mms
18
Parlay example Patterns
GUI
IpApp_XX
Configuration
Main
IpApp_XX_Adapter
Feature
XX_Processor
Ip_XX
19
Parlay example Structure
IpAppUIManager
_IpAppHosaUIManagerImplBase
SMSProcessor
GUI
-gui
-smsProcessor
-feature
-feature
Main
MMSProcessor
Feature
-mmsProcessor
-feature
-framework
-ulProcessor
LocationProcessor
Framework
ConnectionMgr
_IpAppUserLocationImplBase
_IpClientAPILevel AuthenticationImplBase
IpAppUserLocation
IpClientAPILevel Authentication
20
Parlay Gateway Access
A P P
application server(s)
application
Parlay/OSA
P G W
service(s))
framework
service capability server(s)
SMPP
SMTP
PAP
MM7
N E T
WAP GW
MMC
SMSC
EMAIL
21
Parlay Gateway Lifecycle

• Restaurant analogy
• Where do you want to eat? (IP on port?)
• Request menu (Get PGW services)
• Call on waiter (Chose service manager)
• Order food (Send service request)
• Receive food (Receive response)
• Eat food (Perform action on response)
• Start all over again (optional)
• Pay and leave (Dispose resources and disconnect)

Initialization phase
Execution phase
Termination phase
22
Parlay example - Initialization

• Getting access to services

Application
Framework
1 initiateAuthentication
2 selectEncryptionMethod
3 authenticate
4 authenticationSucceeded
5 authenticate
6 authenticationSucceeded
7 requestAccess
8 obtainInterfaceWithCallback
9 obtainInterface
10 discoverService
11 selectService
12 initiateSignServiceAgreement
13 signServiceAgreement
14 signServiceAgreement
23
Parlay example Execution
Application
PGW
1 createNotification

• Create notification
• Sending requests

2 reportNotification( )
3 extendedLocationReportReq( )
4 extendedLocationReportRes( )
5 hosaSendMessageReq( )
6 hosaSendMessageRes
24
Parlay example Termination

• Disposing resources and ending access

Application
HosaUIService
Framework
1 destroyNotification
2 terminateServiceAgreement (HOSA UI)
3 terminateServiceAgreement (UL)
4 endAccess
25
Develop service Test and Verification

• Many tools available from many different vendors
• PGW Simulators
• Network simulators
• Example applications
• Programmer Guides
• Demonstrational tools
• Code libraries / Utility classes
• Test labs
• Meetings and Seminars
• Web based forums / Mailing lists
• Partnership programs

26
Tools available from Ericsson

• Ericsson Network Resource Gateway Software
  Development Kit
• http//www.ericsson.com/mobilityworld/sub/open/tec
  hnologies/parlay/index.html
• Includes
• Parlay Simulator with integrated Network
  Simulator
• Automated Test Tool
• Example applications for various Parlay services
• API libraries
• Standards and Specifications
• Forum
• Ericsson Partnership Program

27
Demo of the example application
28
Deployment
The Internet (potentially unsafe)
Operator Domain (safe)
Trusted Applications
Parlay/OSA
Firewall
Third Party Applications
In house Applications
PGW
Parlay/OSA
Parlay/OSA
GSM
IP
GPRS
29
Summorization

• Market is still growing for services and it is a
  huge market.
• Parlay adds a new dimension of mobility to
  application development new and exiting
  possibilities!
• Learning what the Parlay services are about is
  the first threshold to overcome (join this
  afternoon session!).
• Pick an choose tools from many vendors.
• Any software developer can start making Parlay
  applications today!

30
(No Transcript)
31
PARLAY PARLAY X BENEFITS
Part One General Parlay / Parlay X benefits
32
Agenda Parlay and Parlay X benefits

• IT and Telecom
• Some background
• Current problem
• Parlay and Parlay X as solutions
• Cross dependencies between the players in the
  telecom industry
• The importance of cooperation
• Some roles at a glance
• Application Developer definition and key
  benefits
• Network Operator definition and key benefits
• Service Provider definition and key benefits
• End User (Consumer) definition and key benefits
• Summarization

33
IT and Telecom

• Traditionally two very different kinds of beast
• Many standards and rapid changes
• More and more going through the same wire
• TV
• WWW
• Telephony
• All in one approach wanted by the consumer
• Richer services, more personalized and
  interactive
• Easy for the consumer, complex for the developer
• Higher development costs since more complex
  systems
• Overlap between old and new systems

34
Application environment
Applications ApplicationsServers

• Availability of different interfaces (versions)
  on the AS
• Multiple integration
• Hard to reuse
• Expensive maintenance and updates

SMPP
PAP
SMTP
MM7
SMS-C
WAP GW
MMC
Email Server
35
Application environment
Applications ApplicationsServers
SMPP
PAP
SMTP
MM7
MMC
SMS-C
WAP GW
Email Server
36
Benefit for the whole industry

• Public interface to access the telecom network
  resources (availability)
• Any IT application on any telecom network
  (portability)
• Off-the-shelves market
• computer components (ATX standard) analogy
• batteries analogy
• Definition of roles and business processes ? Key
  actor specialization

37
Cross dependencies
clear requirements
Parlay / Parlay X
Application Developer
Service Provider
enhanced services
easier implementation
loyalty
easier maintenance
increased traffic
richer services
Network operator
Consumer
cheaper traffic
LESS TEAMWORK LESS BENEFIT
38
Application Developer

• Definition
• Software oriented innovator and creator of stable
  and easy manageable services for the telecom
  community
• Rights
• Limit requirement scope together with Service the
  Provider and decide technology consideration
  together with the Network Operator.
• Responsibilities
• Must verify and test implementation as agreed
  with the Service Provider and Network Operator

39
Application Developer

• Parlay / Parlay X benefits
• Simple
• Effortless startup - easy to learn!
• Notifications, Requests and Responses
• No need for telecom specific knowledge
• CAPv2, CAPv3, CS1, CS1, SIP are available only
  for voice communication
• Learn one! Thats enough!
• Similar pattern for all Parlay and Parlay X
  services
• Shared common data (TpAddress)
• Common programming language of choice
• IDL/WSDL generation
• Less code easier debugging
• Full set APIs, Utility classes simplify
  reoccurring events

40
Application Developer

• Parlay / Parlay X benefits
• Powerful
• Access to capabilities new to the IT industry
• positioning
• availability / access
• Wide variety of intuitive mappings towards
  available telecom services
• Location, Status, Messaging, Voice, Charging
• Stable
• Create once, run anywhere
• Isolation from network changes
• Farewell spaghetti code!

41
Application Developer

• Parlay / Parlay X benefits
• Revolutionizes the developer possibilities
• Less operator dependency
• Free market, everyones invited!
• Free development tools small risks low costs!
• Possible to develop a new service for your mobile
  phone within days instead of weeks
• True integration of IT and Telecom

42
Network Operator

• Definition
• Infrastructure oriented enabler of stable and
  accessible services for the telecom community
• Rights
• Determine access distributed in the system
• Runtime and maintenance considerations
• Responsibilities
• Authorization, Availability, Authentication

43
Network Operator

• Parlay / Parlay X benefits
• Popular services increase traffic
• Increased traffic equals higher revenues
• Easier maintenance with presumably fewer bugs
• Statistical information of the traffic
• Simple control over network resources

44
Service Provider

• Definition
• Market analyzer close to the telecom service
  consumer
• Rights
• Decides requirements together with the
  Application Developer and the Network Operator
• To receive fully tested and verified service
  solutions that are persistently available to the
  consumer
• Responsibilities
• Discover needs and foresee future expectations

45
Service Provider

• Parlay / Parlay X benefits
• Less development costs
• Faster time to market
• New types of services, increased level of
  interaction
• New markets
• Increased customer loyalty
• Business monitoring and surveillance through
  statistics
• Business rules (load etc.)

46
Consumer

• Definition
• User of the telecom system, predominantly
  uninterested in the technology and implementation
  specifics
• Rights
• Stable and accessible services at justified
  prices
• Responsibilities
• Financier of the telecom network system
  maintenance, operating costs and research and
  development.

47
Consumer

• Parlay / Parlay X benefits
• Timelier deliveries
• World Cup in football
• Fuller range of personalized services
• Richer, more satisfying experience
• Cheaper services (??)

48
Summarization

• An off-the-shelves solution makes common sense!
• Need for a teamwork understanding of the telecom
  industry
• Definition of once role(s) is the first step to
  become true specialists in a certain area too
  broad scope may slow down progress
• Lot of benefits throughout the telecom community
  biggest risk is that networks will not open up
• Parlay is the standard to make this happen

49
(No Transcript)
50
PARLAY PARLAY X BENEFITS
Part Two Parlay and Parlay X at a comparison
51
Agenda Parlay and Parlay X overview

• Web Services
• Fitting Parlay X into the picture
• Technologies overview
• Comparison between Parlay and Parlay X
• Simple working example
• Summarization

52
Web Services

• Web services, in the general meaning of the term,
  are services offered by one application to other
  applications via the World Wide Web.
• Clients of these services can aggregate them to
  form an end-user application, enable business
  transactions, or create new Web services.
• In a typical Web services scenario, a business
  application sends a request to a service at a
  given URL using the SOAP protocol over HTTP. The
  service receives the request, processes it, and
  returns a response.

53
Web Services

• Web services are software components that
• Are described and found using XML technologies
• Can be accessed with standards-based internet
  protocols
• HTTP
• HTTPS
• SMTP
• Exchange XML-formatted data
• Client and service may be implemented with
  different languages on different hardware and
  software platforms

54
Web Service technologies

• Accessing Web Services SOAP (XML)
• Describing Web Services WSDL
• Publishing Web Services UDDI

Web Services vs. CORBA

• Web Service
• WSDL
• SOAP
• UDDI

• CORBA
• IDL
• IIOP
• Name Server

55
XML

• Language for defining structured data
• Example...

ltcustomergt ltfirstnamegtJohanlt/firstnamegt
ltlastnamegtSvenssonlt/lastnamegt
ltbirthdaygt1967-04-09lt/birthdaygt lt/customergt
56
SOAP

• Simple Object Access Protocol
• XML-based message format
• Defines a message between the sender and an
  ultimate receiver
• possibly via intermediaries
• Envelope
• Header
• Body
• Headers can be targeted at certain intermediaries
• The SOAP message transfer is done by another
  underlying protocol. HTTP is standardized but
  SMTP and other are possible

57
SOAP the envelope metaphor
Functional aspects
SOAP

• -- --- - -- - -- - -- -- -- - -- -- -- --- -- --
  -- -- ---- - --
• Send MMS to User X
• -- --- - -- - -- - -- -- -- - -- -- -- --- -- --
  - -- -- ---- - -

Ericsson
Application
Msg 12 TransId 352
To Vodafone From Yahoo Verified by Verisign
Approved by User X
Authentication Authorization Confidentiality Integ
rity Privacy Transaction (Coordinated) Reliable
Maybe payments?
Non-functional aspects
58
SOAP
SOAP Envelope

• Message structure

SOAP Header
Information individually targeted for
intermediaries and end points
SOAP Body
Information for the ultimate receiver
59
WSDL

• Web Service Description Language
• Describes what a service does
• Available operations
• Input and output messages
• How a service is accessed
• Data encoding format
• Protocols supported
• Where a service is located
• Service endpoint URL
• In our case the Parlay X WSDLs are standardized
  and downloadable from internet (e.g.
  www.parlay.org)

60
UDDI

• Universal Description, Discovery and Integration
• Registry for businesses and their Web Services
• Name of business
• Contact information
• Type of business
• Interfaces (WSDL)
• Access information (URL)

61
Parlay X

• A set of simple Web Services
• Simple and high level access to widely used
  telecom functions
• Aimed at Web developers
• Leading to
• A principle Keep Interface Specifications Simple
• Limited sets of building blocks for web
  developers

Number of developers
Thousands
Parlay-X
Parlay/OSA
Hundreds
Voice data protocols
Network detail
62
Parlay overview
A P P
application server(s)
application
Parlay/OSA
P G W
service(s))
framework
service capability server(s)
SMPP
SMTP
PAP
MM7
N E T
WAP GW
MMC
SMSC
EMAIL
63
Parlay X overview
W E B
application server(s)
application
Parlay X
A P P
application server(s)
application
Parlay/OSA
P G W
service(s))
framework
service capability server(s)
SMPP
SMTP
PAP
MM7
N E T
WAP GW
MMC
SMSC
EMAIL
64
Parlay and Parlay X compared

• Parlay
• More complex
• More complete functionality
• CORBA based
• Publish/Find via Parlay Framework
• SLA/Policy negotiation via Parlay Framework
• Authentication via Parlay Framework

• Parlay X
• Simple
• Limited functionality
• Web Services based
• Publish/Find via UDDI Industry standard
• SLA/Policy negotiation via local bind process
  (not the same level)
• Authentication via WS-Security

65
Parlay application development and execution
Web Services (Parlay and Parlay X)
Parlay
Java/J2EE IDE
Java IDE
Application Developer


Parlay X WSDL
Parlay SDK
Service Provider and/or Network Operator
Java Application
Java Application
Parlay SDK
JRE
JRE
ORB
SOAP, RMI
CORBA
Network Operator
Parlay
Parlay X
Parlay Gateway
66
A Parlay X example
SmsSender
SmsSender
WSDL Stub
Sao Paulo / Brazil
JRE
x2
Send SMS
SOAP / HTTP
193.180.251.1257001
Send
Parlay
Parlay X
Network
OK
Parlay Gateway
Stockholm / Sweden
67
A Parlay X example

• Send SMS message
• Find the appropriate WSDL file(s)
  (http//www.parlay.org)
• Find a suitable WSDL compiler for the programming
  language of choice (http//ws.apache.org/axis/)
• Compile the WSDL files to get the stubs and
  interfaces needed to create the SOAP message
• Make certain that proper security credentials are
  added as SOAP message headers (operator specific)
• Use a URL to identify where the service is
  located
• Invoke the service interface method to send the
  SOAP message

68
Parlay X benefits

• No need to authenticate all requests towards the
  PGW
• Simplified, more abstract less detailed
• Easy popular functions (good enough)
• Targets web based applications and Web Services
• Easy network configurations (http posts)
• Good tools available for WSDL stub generation
  (AXIS or JWSDP)

69
Summarization

• Parlay X services are Web Service components sent
  by SOAP calls defined by WSDL usually over HTTP
• Main benefits are the simplification of access
  and authorization
• Component based programming
• Much of the implementation is done by the WSDL
  compiler that generate stubs to use in your code
• Parlay X makes network resource access faster and
  simpler than ever before!

70
(No Transcript)
71
PARLAY PARLAY X DEVELOPMENT TRAINING
Part One
72
Preparation

• Copy the parlay_training_course.zip file onto
  your computer
• Unzip it to any location without spaces in the
  path (C\Documents and Settings should be
  avoided!) Preferably use something similar to
  c\parlay
• Disable any firewall currently active on your
  laptop as it might disallow certain ports to be
  used

73
How to work with this package

• Use runEclipse to start the Eclipse IDE.
• In Eclipse there are several projects, either for
  Parlay or Parlay X that will illustrate a certain
  feature of the standard.
• Each exercise has a solution. Use the solution to
  compare your results but try your best before
  doing so.
• Each exercise will take about 30 minutes. (Some
  less some more). First there will be an
  introduction and last will be a summarization of
  the intended solution.

74
How to work with this package

• Use runSimulator to start the Ericsson Network
  Resource Gateway Simulator, this will act as a
  PGW, phones and a network emulator on your local
  laptop.
• The Simulator needs to be running in order for
  the Parlay applications to work.
• In order to run the Parlay X applications you
  need to have an Internet access.

75
Pattern
GUI
IpApp_XX
Configuration
Main
IpApp_XX_Adapter
Feature
XX_Processor
Ip_XX
76
General sequence Start Notification
77
General sequence Stop Notification
78
Exercise one

• List all available services at this PGW
• Get access to the PGW framework
• Get a list of all services
• Connect to each service
• Disconnect from all services
• Illustrates Framework access and service
  retrieving

79
Exercise one
80
Exercise one

• Make sure that the Simulator is running and that
  you have started Eclipse
• In Eclipse right click on Parlay_Exercises and
  select Open Project
• Sort the tasks at the bottom of the screen after
  their folder name and double click on the first
  one named TODO close the framework
  communication
• Your task is now to fill in the blanks in the
  code, you may need to shift between Problems and
  Tasks to correct all blanks for an assignment.
• After filling all the gaps in the code, right
  click on the assignments Main class and choose
  Run as?Application to run the application.
• Populate the Simulator with the right phones and
  follow the instructions that show in the
  application window.

81
Exercise two

• Create an application that sends SMS messages
  towards a certain number.
• Illustrates SendMessageReq, SendMessageRes and
  SendMessageErr

82
Exercise two
83
Exercise three

• Finish the application that receives a SMS from a
  specified friend and converts it into an MMS
  before sending it onwards to the destination.
• Illustrates Create Notification, report
  notification, sending MMS MIME messages

84
Exercise three
85
Exercise three
86
Exercise four

• Finish an application that tracks two terminals
  each other second. When the terminals are within
  a specified distance send SMSs to them both to
  indicate that the friend is close by.
• Illustrates extendedLocationReportReq

87
Exercise five

• Finish the application that upon changing the
  status of the terminal starts listening for
  incoming calls. If a call is made to a terminal
  that is switched off a SMS will be generated
  indicating that a call was missed.
• Illustrates triggeredUserStatus

88
Exercise six

• Finish the application that acts as a redirection
  service. When calling the service number a
  message is played and the user is prompted to
  choose a destination. When typing in the
  destination the caller is redirected.
• Illustrates Multiparty Call Control and User
  Interaction

89
What Are Legs Calls ?
90
What Are Network Initiated Calls?
91
What Are Application Initiated Calls?
92
Exercise six
93
Exercise six
94
Parlay X exercise

• Complete the SimpleLogoSender, SimpleMessageSender
  and SimpleRingtoneSender by completing the
  following steps
• Create URL to identify the service
• Create a locator specifically for this service
• Retrieve the SMS service
• Add security header information
• Invoke the desired method on the remote service
• Optionally get extra information from the
  returned correlator

95
Parlay X development for Java

• Download and install Java
• http//java.sun.com/downloads/
• Decide service
• Download involved service WSDL files
• http//www.parlay.org/en/specifications/
• http//www.3gpp.org/ftp/Specs/html-info/29-series.
  htm
• Generate client side stubs from WSDL
• http//ws.apache.org/axis/java/user-guide.html
• http//java.sun.com/webservices/downloads/webservi
  cespack.html
• Develop application on top of stubs
• http//www.eclipse.org/downloads/
• http//www.netbeans.org/downloads/
• Compile and package
• Deploy
• Test and Verify

96
(No Transcript)
