Title: Mineralogy,%20Diffraction


1
Mineralogy, Diffraction
  • Carleton College

2
X-rays History
  • Nature of x-rays

3
(No Transcript)
4
(No Transcript)
5
History Wilhelm Conrad Roentgen
  • Roentgen was born on March 27, 1845 in Lennep
    (Germany).
  • He was educated in Utrect and Zurich and became
    professor of physics at Strassburg (1876),
    Giessen (1879), Würzburg (1888), and Munich
    (1899).

6
History Wilhelm Conrad Roentgen
  • He received the Nobel Prize in 1901. Roentgen
    refused to patent his discoveries and rejected
    all commercial offers relating to them.
  • In his later years, he was embittered by the
    suggestion that he had taken credit for his
    laboratory assistant's discovery, and withdrew
    from public life.
  • Roentgen died on February 10, 1923 of carcinoma
    of the rectum, and was buried beside his wife in
    the family grave in Giessen.

7
History Wilhelm Conrad Roentgen
  • Roentgen was working in his laboratory at the
    Physical Institute of the University of Würzburg,
    Germany, experimenting with a Crookes tube.

8
History Wilhelm Conrad Roentgen
  • This tube is a glass bulb with positive and
    negative electrodes, evacuated of air, which
    displays a fluorescent glow when a high voltage
    current is
  • passed though it. When he shielded the tube with
    heavy black cardboard, he found that a greenish
    fluorescent light could be seen from a platinum
    screen 9 feet away.

9
History Wilhelm Conrad Roentgen
  • He concluded that a new type of ray emitted from
    the tube, passed through the covering, and casted
    shadows of solid objects. The rays passes through
    most substances, including the soft tissues of
    the body, but left the bones and most metals
    visible.

10
History Wilhelm Conrad Roentgen
11
History Wilhelm Conrad Roentgen
  • One of his earliest photographic plate from his
    experiments was a film of his wife, Bertha's hand
    with a ring, was produced on Friday, November 8,
    1895.

12
X-ray production
  • X-rays are produced when an electron boiled
    from filament are caused to strike a target of
    atoms by the force of a high voltage field.
    Which is seen in the next slide

13
X-ray production
14
X-ray production
  • Deceleration of electrons as they approach atoms
    in the target creates a white background of
    x-rays called the Brehmstrallen radiation.

15
X-ray production
  • X-rays are produced when there is a sudden
    deceleration of electrons. In practice, X-rays
    are produced when an extremely high voltage
    (15-60
  • Kv) is applied to a filament (typically a
    tungsten cathode) in a vacuum. The electrons are
    then accelerated into a metal target (typically a
    copper
  • anode). The result is two particular types of
    X-radiation.

16
X-ray production
  • The first type is known as white radiation and
    consists of a broad, continuous spectrum
    containing many wavelengths of radiation. It is a
    result of the very rapid deceleration of
    electrons as they encounter the strong electric
    fields of target metal. As the electrons collide
    they lose energy (often designated delta-E) and
    that energy goes into making X-ray photons. That
    energy, delta-E is related to the frequency of
    the X-ray radiation by Planck's Constant,

17
X-ray production
  • ?E hv
  • Where h planks constant
  • Vfrequency of the x-ray
  • remember that v c/l
  • Cspeed of light, lwavelength
  • therefore, ?Ehc/ l

18
X-ray production
19
X-ray production
  • White radiation

20
X-ray production
  • Superimposed on this background are peaks of
    intense x-rays that have wavelengths that depend
    on the atoms involved.
  • These peaks of characteristic wavelengths are
    produced when an atom losses an electron from an
    inner orbital.

21
X-ray production
  • The peaks are labeled
  • Ka, Kb, La, Lb, etc
  • depending on the specific energy levels involved.

22
X-ray production
  • Laboratory production of X-rays

23
X-ray production
  • Target metal anode (pure element)
  • Filament cathode

24
X-ray Diffraction Experiments
  • Space group
  • Unit Cell

25
What is Diffraction?
  • Diffraction, generally defined as a departure of
    a ray from the path expected from reflection and
    refraction.

26
What is Diffraction?
  • Sets of narrow slits and ruled gratings were
    observed to produce diffraction patterns when
    the spacing of the slits is similar to the
    wavelength of light used.

27
What is Diffraction?
  • Because all of the slits in a diffracting grating
    are illuminated by the same source of light, the
    set of slits may be considered to be a set of
    light source all in phase with one another.
  • Light rays traveling perpendicular to the grating
    will remain in phase.

28
What is Diffraction?
  • Light rays traveling at an angle Ø to the will
    not be in phase, except for a special angles such
    that S sin Ø nl, where S is the spacing of the
    slits, l is the wavelength of light and n is an
    integer.
  • We may use this expression to find l for a laser
    or S for a diffraction grating.

29
Diffraction
  • Because of spacing of planes of atoms in crystals
    is similar to the wavelength of x-rays
  • Diffraction of X-rays by Crystals is possible.

30
Diffraction
  • Atoms in a crystal behave like little x-ray
    sources.

31
Diffraction
  • X-ray reflections

32
Diffraction
  • The figure to the left illustrates a modern X-ray
    diffraction pattern of the mineral vesuvianite
    (type locality is Mt. Vesuvius). The diffraction
    pattern is recorded on photographic film as a
    series of spots (this is actually a negative).
    The spots do not represent atoms. They do
    represent layers, or planes of atoms within the
    crystal structure. The spacing of the spots is
    proportional to the distance between the
    different diffracting layers in the crystal. Can
    you recognize any symmetry in this diffraction
    pattern? If you look carefully you should be
    able to convince yourself that the center of
    the pattern corresponds to a fourfold rotation
    axis perpendicular to the plane of the page. You
    should also be able to recognize that the axes
    a1 and a2 represent mirror planes. The symmetry
    of the crystal is reflected in the symmetry of
    the X-ray pattern. Although the symmetry
    elements are not sufficient to identify the
    mineral, you will soon be able to recognize
    that the symmetry observed implies that this
    mineral belongs to the tetragonal crystal
    system. The symmetry, together with a
    measurement of the separation of the spots would
    be sufficient to identify this diffraction
    pattern as belonging to the mineral vesuvianite.

33
Braggs equation
  • nl 2dsin Ø

34
Diffraction
  • Diffraction of x-rays by crystals is possible
    because the spacing of planes of atoms in
    crystals is similar to the wavelength of x-rays.

35
Powder Diffraction
  • X-ray diffraction by mineral powders is one of
    the mineral identification and characterization
    techniques most used by geologists.

36
Powder Diffraction
  • Powder diffraction experiment requires only as
    small quantity of a mineral.
  • 10-500mg
  • Sample preparation is very simple and fast
  • Reliable accurate results are obtained in a
    relatively short time, 10 minutes to 2 hours.

37
Powder Diffraction
  • The principle behind PD experiment is the random
    orientation of crystals in a mineral powder.

38
Powder Diffraction
  • If the powdered crystals are randomly oriented,
    then for all sets of planes (hkl) some of the
    crystals in the powder will be in the correct
    orientation (usually horizontal) with respect to
    the x-ray source to satisfy Braggs law.

39
Powder Diffraction
  • In other words, at least a few of the mineral
    grains will diffract for each of the planes (hkl)
    during a scan through 2 Ø angle.
  • The more the finely ground the powder, the more
    likely that all orientations are presented in
    abundance.

40
Powder Diffraction
  • The ideal powder size is 5-10 microns.

41
Powder Diffraction
  • Here at Carleton, we have an automated powder
    diffractometer that yields digital computer
    output.

42
Powder Diffraction
  • Unknown minerals my be identified from powder
    diffraction data using ICDD Powder Diffraction
    File.

43
Powder Diffraction
  • Intensity and 2 Ø or dhkl values are used in the
    search.
  • Computer searches of the file may lead to a
    unique match with a known powder diffraction
    patter.

44
Powder Diffraction
  • Because of the chemical composition of most
    minerals is variable and some aspects of a
    mineral structure may depend on its history, the
    obtained diffraction pattern may not exactly
    match the standard data for a given mineral
  • This makes identification more challenging

45
Powder Diffraction
  • Once a mineral has been identified, the Powder
    Diffraction File data card my be used to index
    the observed diffraction peaks.
  • Miller indices, 2 Ø, d values, may be used to
    determine the Unit Cell Parameters of the sample.

46
Diffraction Summary
  • Diffraction pattern is like a finger print of the
    crystal structure
  • d-values reflect the unit cell parameters
  • intensities reflect the atoms/molecules

47
Sample preparation for PD
  • Sample preparation procedures are critical inn
    being able to obtain accurate and reproducible
    XRD results.

48
Sample preparation for PD
  • Care should be exercise in order to avoid
    introducing errors resulting from factors such
    as
  • non-representative sampling
  • contamination
  • material loss

49
Sample preparation for PD
  • alteration of composition due to
  • Over grinding,
  • hydration
  • dehydration
  • oxidation

50
Sample preparation for PD
  • Sample height displacement
  • non-uniformity of the sample surface

51
Sample preparation for PD
  • The Backloading Technique

52
Sample Preparation of PD
  • Two-piece round sample holder

53
Sample Preparation of PD
  • PW1811/27 Sample holder and
  • PW1770/10 Sample Preparation Kit

54
Sample Preparation of PD
  • Use the following guidelines to prepare a
    back-mounted sample
  • Invert the holder ring and clamp it onto
    preparation table

55
Sample Preparation of PD
  • Spread Powder level using spatula. Do not pack
    or compress

56
Sample Preparation of PD
  • Press powder with block

57
Sample Preparation of PD
  • Remove excess powder with a knife blade

58
Sample Preparation of PD
  • Clean mating surface with small brush or edge of
    your thumb

59
Sample Preparation of PD
  • Affix back plate

60
Sample Preparation of PD
  • Invert the prep table while holding sample ring
    stationary and depress the release clamp, and
    remove the sample
