Title: Lecture on Flip-Flops


1
Lecture on Flip-Flops
2
Level-Sensitive Flip-Flop
  • Level-sensitive flip-flop (also called a latch)
  • Q changes whenever clock is high

CLK
D
Q
6 Transistors
CLK
CLK
D
Q
3
Level-Sensitive Flip-Flop
  • NMOS transistor often replaced with transmission
    gate
  • Transmission gate includes both NMOS and PMOS
    transistors because NMOS good at passing 0 and
    PMOS good at passing 1

6 Transistors
CLK
Transmission Gate
8 Transistors
CLK
4
Master-Slave Edge-Triggered Flip-Flop
  • Can connect two level-sensitive latches in
    Master-Slave configuration to form edge-triggered
    flip-flop
  • Master latch catches value of D at QM when
    CLK is low
  • Slave latch causes Q to change only at rising
    edge of CLK

QM
Master Latch
Slave Latch
D
Q
CLK
2 x 8 16 Transistors
CLK
CLK
D
QM
Q
5
Master-Slave Edge-Triggered Flip-Flop
SLAVE
MASTER
QM
Q
D
CLK
CLK
2 x 8 16 Transistors
6
More Efficient Master-SlaveEdge-Triggered
Flip-Flop
  • Called a C2MOS (Clocked CMOS) design

MASTER
SLAVE
VDD
VDD
CLK
CLK
Q
D
CLK
CLK
8 Transistors
GND
GND
7
Using Logic Gates to Build Flip-Flops
  • From previous slides, you can see that its
    possible to build an edge-triggered flip-flop
    using just 8 transistors
  • In a conventional Digital Logic course,
    transistor-level flip-flop designs are not
    usually taught
  • Instead, flip-flop designs using cross-coupled
    logic gates are usually taught

8
RS-Latch as Cross-Coupled NOR Gates
  • If R 1, Q resets to 0
  • If S 1, Q sets to 1
  • If RS 00, no change
  • RS 11 is not allowed because leads to
    oscillation

R
Q
Q
S
S R
Q
0 0
No change
0 1
0
1 0
1
1 1
Undefined
9
Level-Sensitive RS-Latch
  • Q only changes when CLK is high (i.e.
    level-sensitive)
  • When CLK is high, behavior same as RS latch

S
Q
CLK
Q
R
CLK S R
Q
0 X X
No change
1 0 0
No change
1 0 1
0
1 1 0
1
1 1 1
Undefined
10
Level-Sensitive D-Latch
  • Make level-sensitive D-latch from level-sensitive
    RS-latch by connecting S D and R not D
  • Compared to transistor version

D
Q
CLK
Q
18 Transistors
8 Transistors
11
Master-Slave Edge-Triggered Flip-Flop
  • Master-Slave configuration
  • Compared to transistor version

MASTER
SLAVE
D
Q
CLK
CLK
36 Transistors
VDD
VDD
CLK
CLK
Q
D
CLK
CLK
8 Transistors
GND
GND
12
Alternative Edge-Triggered Flip-Flop
VDD
VDD
CLK
CLK
Q
Q
D
CLK
CLK
CLK
Q
GND
GND
D
8 Transistors
24 Transistors
13
JK Flip-Flop from D-Latch
  • Same as RS-Latch except toggle on 11

J
D Latch
Q
K
Q
CLK
CLK J K
Q
JK-FF
J
Q
0 X X
No change
CLK
1 0 0
No change
1 0 1
0
K
1 1 0
1
1 1 1
Toggle
14
Toggle Flip-Flop from D-Latch
  • Toggles stored value if T 1 when CLK is high

D Latch
Q
T
CLK
CLK T
Q
T-FF
T
Q
0 X
No change
1 0
No change
CLK
1 1
Toggle
