Forensic Geology and

1
Forensic Geology and Industrial Materials
2
Building Materials

• Building materials are made of or derived
• from geological materials
• Stone, gravel, sand, slate, etc.
• Roofing granules
• Bricks, roof and floor tiles
• Cement, concrete, cinder blocks
• Wallboard, plaster
• Glass
• Cleansing powders, abrasives
• Insulation

3
Brick Making
The basic process Find a suitable clay
Press it into a brick mold Dry the bricks
Fire the bricks to 1000C
4
Cement Manufacture

• Cement is made by mixing limestone, sand, clay,
  and sometimes coal fly ash, with minor amounts of
  iron and aluminum compounds
• Mixture is fired in a kiln to 1500C where the
  limestone is calcined into lime which reacts with
  the silicates to form di-and tri calcium
  silicates, and tri-
• and tetra calcium aluminates

5
Cement Manufacturing Process
6
Concrete Manufacture

• Concrete is made by mixing cement with sand,
  gravel, and water.
• Cement slurry coats the aggregate and hardens
  into a solid mix.

7
Cinder Blocks -manufactured by mixing cement
with coal fly-ash. NOTE many industrial
materials are manufactured close to end-users
using local materials.
8
Plaster Manufacture

• Plaster is made by calcining gypsum CaSO4 2H2O
  at 150ºC to its hemi-hydrate CaSO4 ½H2O
• This is an ancient process again going back to
  the beginning of civilization.

9
(No Transcript)
10

• After the great fire of London in 1666, the King
  of France ordered that all of the wooden
  structures be coated with plaster to make them
  fire resistant.
• Modern processing adds various additives, filler,
  conditioners with the result that most plasters
  can be differentiated from each other.

11

• 88 of the gypsum mined is used in the
  manufacture of wallboard.

12
(No Transcript)
13
Abrasives

• Abrasive materials are used in a variety of ways
  sanding wood, polishing diamonds, cutting steel.
• Diamonds are the hardest abrasives.
• Corundum, garnet, SiC, cubic boron nitride, Zi/Al
  alloys, pumice, and colloidal silica are also
  used.

14
Pumice
Diamond
Silicon Carbide
Garnet
Corundum
15
The Role of the Forensic Geologist

• Industrial materials have textural and
  compositional properties suited to petrographic,
  chemical, x-ray diffraction (except for glass),
  and spectral analytical methods familiar to
  geologists
• Geologists are ideally suited to perform such a
  variety of analysis.

16
Building Materials Cases

• An attempted rape case
• -the rescuer of the victim was followed by
  the suspect, beaten with an aluminum baseball
  bat, and the windows of his car were smashed out.
• Glass adhering to the suspects bat matched glass
  from the rescuers car
• (Murray, 2004, page 101)

17

• Case a home owner who had insulated his attic
  with a variety of fiber glass insulation
  purchased from different sources.
• An intruder who entered through the attic was
  found to have a similar variety of insulation
  particles on his clothes (Murray, 2004, page 103)


18

• Diplomatic case the neutral Dutch were accused
  by British in WWI of allowing the Germans to ship
  sand and gravel through Holland.
• British geologist, Capt. W. B. R. King, took 39
  samples of concrete aggregate from captured
  German pillboxes.
• -found that 32 of them came from German not
  Dutch sources
• (Murray, 2004, page 107)

19

• A case in Israel
• - a safe cracker stole a safe tried to cut
  into it using a carbide grinding wheel with two
  different abrasive discs.
• Investigators recovered the grinder and were able
  to match the grinder to the grinding marks on the
  safe.
• -also matched metal particles found on the
  suspects shirts to the grinding debris at the
  scene.
• (Zeichner et al., 1993, J. For. Sci., p.
  1516-1522)

20
Wood Identification

• Wood is not generally considered a geological
  material however, wood properties and
  characteristics have been used in forensic cases.

21
Elm Wood Under the Hand Lens
Elm Wood Under the Microscope
22
Hardwood (Sugar Maple) with Large Pores
Softwood (Sequoia) with Large Pores
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
The Lindbergh Kidnapping Case

• In 1932, the infant son of aviator Charles
  Lindbergh was kidnapped and later found dead.
• A major piece of evidence, a home-made ladder
  found at the scene, was found to match the
  boards in the attic of the suspect Bruno
  Hauptmann
• Hauptmann was convicted and executed in 1936


27
(No Transcript)
28
Sarsaparilla Case

• DEA agents asked a wood expert to examine some
  roots that they thought were illicit drugs.
• -the suspect said plants were sassafras.
• Examination revealed that they were the roots of
  the sarsaparilla plant and the case was dropped
• (Science News Online, 2002,
• v. 162)
