Discriminative Model Checking

1
Discriminative Model Checking

• Peter Niebert
• Doron Peled
• Amir Pnueli
• CAV 2008

2
Discriminative Model Checking

• Peter Niebert
• Doron Peled
• Amir Pnueli
• CAV 2008

Warwning inside this talk hides another talk!
Automatic Generation of Programs Using Model
Checking and Genetic Programming
Gal Katz Doron
Peled
3
Which logic to use?

• Linear each execution is an alternating sequence
  of states/actions.
• Use LTL/Buchi automata.
• Counterexample if property fails.
• Branching a tree repsresents all executions,
  including the points where they branch.
• Allows expressing possibility, e.g., of services.

4
Linear Temporal Logic

• ?????
• ????
• O ?
• ?U??

5
Computation Tree Logic
EG p
AF p
p
p
p
p
p
p
p
p
p
p
. . .
. . .
. . .
. . .
. . .
. . .
. . .
. . .
6
Our point of view

• Linear time is sufficient for specifying most
  properties.
• A counterexample is often not enough
• Gives very little clue about the location of the
  error.
• Does not give information about how good and bad
  executions are related to each other.
• Thus, for analysis beyond finding the existence
  of an error, we promote a deeper search.

7
Our suggestion

• Primary or base specification ? in LTL, for the
  base property.
• Analysis specification, quantifies over
  executions that satisfy or do not satisfy the
  base specification.
• Syntaxp ?\/? ?? ?? ??? ???? (and
  others)
• Semantics- ??? there exists a continuation
  satisfying the property ?, where ? holds from the
  beginning. - ??? there exists a continuation not
  satisfying the property ?, where ? holds from the
  beginning.

8
Semantics illustration

• Semantics- ??? there exists a continuation
  satisfying the property ?, where ? holds from the
  beginning. - ???? there exists a continuation
  not satisfying the property ?, where ? holds
  from the beginning.

? holds
? holds
. . .
. . .
. . .
. . .
9
Examples for specifications

• Bad executions depend on infinitely many bad
  choices ??ltgt??true
• Before executing a, there are good and bad
  executions. Once a is executed, things things are
  persistently bad ?((Execa/\??true)W(Execa/\??fa
  lse))
• Properties such as from some point all
  continuations are good/bad.

10
How to do model checking?

• We need to remember some information about the
  path so far to verify that with the rest of the
  computation it is (not) satisfying ?.
• Suppose we would have run a Buchi automaton for
  ?, but with nondeterministic, maybe it is running
  on the wrong branch to be completed.
• Thus, we would be running a subset construction
  (determinization) of the Buchi automaton.
• At the point of branching, we continue with a
  state consistent with one of the Buchi states in
  the current subset.
• Apply CTL model checking to this structure.

11
Complexity

• EXSPACE-complete even for AG ??true
• Reduction shown for related logic mCTLKV LICS
  2006 (this logic has different semantics, where
  quantification always start from the initial
  state).
• But EXSPACE-complete in size of LTL formula,
  PSPACE-complete in size of branching formula.

12
Application

• Why do we need such an analysis?
• and now we go to another lecture

13
Automatic Generation of Programs Using Model
Checking and Genetic Programming

• Gal Katz
• Doron Peled

TACAS 2008
14
Agenda

• Introduction motivation
• Genetic Programming
• Model Checking
• Combined method
• Application to mutual exclusion
• Conclusions future work

15
Introduction

• Genetic programming
• A methodology for automatic programming inspired
  by Darwinian evolution Koza 92.
• Used for automatic generation of programs in
  various fields.
• Mostly used for optimization related problems.
• Fitness is usually calculated by checking program
  performance against test cases.
• Less used for problems with a strict
  specification.

16
Introduction (2)

• Model Checking
• An automatic formal verification technique used
  mainly with finite-state software and hardware
  systems.
• Can be used to verify communication and
  concurrent protocols.
• Models are checked against a strict
  specification. The result is either
• A confirmation that the model satisfies the
  specification, or
• A counterexample of that fact.

17
Introduction (3)

• How to construct a model from the spec.?
• Synthesis
• Transforms spec. directly to a model that
  satisfies it.
• Complicated.
• Currently not practical for automatic program
  generation.
• Brute-force enumeration
• All possible programs of a specific domain and
  size are generated and model-checked.
• All existing solutions will eventually be found.
• Very time-intensive. Not practical for programs
  with more than few lines of code.

18
Our MethodCombining GP Model Checking
User
1. Specification
2. Configuration
6. Final Model / Results
GP Engine
EnhancedModel Checker
3. Initial population
4. Verification results
5. New programs
19
Main Steady-state GP Algorithm

• Create initial program population.
• Randomly choose µ programs.
• Create ? new programs by applying genetic
  operations to the above µ programs.
• Calculate fitness function for µ ? programs,
  and use it to select µ new programs.
• Replace the old µ programs by the selected ones.
• Repeat steps 2-5 until either
• a perfect solution is found, or
• maximum allowed number of iterations is reached.

20
Program Representation

• Programs are represented as trees.
• Internal nodes represent expressions or
  instructions with parameters (assignment, while,
  if, block).
• Terminal nodes represent constants or expressions
  without any parameter (0, 1, 2, me, other).
• Strongly-typed GP is used Montana 95.

While (A2 ! 0) Ame 1
21
Initial Population Creation

• Population usually contains 100 1000 programs.
• Program are created recursively using the grow
  method KOZA 92.
• The root is randomly selected from instruction
  nodes.
• Offspring are randomly selected from allowed node
  or terminals as long as rules are preserved.
• If max allowed tree depth is reached, a terminal
  must be chosen.

22
Genetic Operations

• At each iteration of the GP algorithm, the
  following genetic operations are applied to the
  selected programs
• Reproduction programs are copied without any
  change
• Mutation
• Crossover

23
Mutation Operation

• The main operation we use.
• Allows performing small modifications to an
  existing program by the following method
• Randomly choose a program node (internal, or
  leaf).
• According to the node type, apply one of the
  following operations with respect to the chosen
  node (strong typing must be kept)

24
Replacement Mutation type (a)
while

• Replace the sub-tree rooted by node with a new
  randomly generated sub-tree.
• Can change a single node or an entire sub-tree.

assign
!
0
A
A
1
me
2
While (A2 ! 0) Ame 1
While (A2 ! 0) Ame A0
25
Insertion Mutation type (b)

• Add an immediate parent to the selected node.
• Randomly create other offspring to the new
  parent, if needed.
• According to the selected parent type, can cause
• Insertion of code,
• Wrapping code with a while loop,
• Extending Boolean expressions.

While (A2 ! 0) Ame 1
While (A2 ! 0) A2 other Ame 1
26
Reduction Mutation Type (c)

• Replace the selected node by one of its
  offspring.
• Delete the remaining offspring of the node.
• Has the opposite effect of the previous insertion
  mutation, and reduces the program size.

27
Deletion Mutation Type (d)
while

• Delete the sub-tree rooted by the node.
• Update ancestors recursively.

!
0
A
2
While (A2 ! 0) Ame 1
28
Crossover Operation

• Creates new programs by merging building blocks
  of two existing programs.
• Crossover steps are
• Randomly choose a node from the 1st program.
• Randomly choose a node from the 2nd program, that
  has the same type as the 1st node.
• Exchange between the sub-trees rooted by the two
  nodes, and use the two newly created programs.

29
Crossover Example
block
if
assign
!
1
A
me
A
me
2
A2 me while (ame other)
If (Ame ! 1) a0 other
A2 me a0 other
If (Ame ! 1) while (ame other)
30
Crossover (cont.)

• Heavily used by traditional GP Koza.
• Tries to mimic biological sexual recombination,
  but
• Unlike biology (and unlike GA), GP lacks the
  notion of genes Banzhaf et al. 01.
• Often acts only as a macro-mutation.
• Various methods were developed in order to turn
  it into a more fruitful operation (Brood,
  Inteligent crossover).
• Still, not a significant operation for small
  programs like those of Mutual Exclusion.

31
Selection

• At each iteration, selection is applied to all µ
  ? programs (over-production selection).
• Program are selected using a fitness-proportional
  (roulette) method Holland 92.
• Elitism is used to ensure that the best program
  is always selected.
• Similar to Evolution Strategies Rechenberg 94
  and Brood Recombination method Tackett 94 -
  better protection from harmful operations.

32
Model Checking
33
?-automata

• Runs on infinite words, and consist of
• A finite alphabet S,
• A finite set of states S,
• A set of initial states S0 ? S,
• A transition relation ? ? S x S,
• A labeling function L S ? ?,
• An acceptance condition O.
• In this version, the labels are on the states
  instead of on the arcs.

34
Acceptance conditions

• For a run p, inf(p) denotes the states appearing
  infinitely on p.
• Buchi condition
• A set of states F ? S,
• A run p over A is accepted if inf(p) n F ? Ø
• Streett condition
• A set of k pairs (Ei,Fi), 1 i k, Ei, Fi ? S,
• A run p over A is accepted if for all pairs
• inf(p) n Ei ? Ø ? inf(p) n Fi ? Ø.

35
?-automata Closure

• Buchi automata can be converted into Streett
  automata, and vice versa.
• Both Buchi and Streett automata are closed under
  intersection and complement.
• Streett automata are less simple to use, but are
  closed under determinization, while Buchi
  automata are not.

36
Building Programs State-graph

• Each state consists of values of variables,
  program counters, buffers, etc.
• Edges represent atomic transitions caused by
  program instructions.

• Can be built by a DFS algorithm.
• Can be decomposed into SCCs Tarjan 72.

37
Converting Model to ?-automaton

• We use the states, initial state and transitions
  of the programs state-space.
• Acceptance condition can allow all runs, or
  impose fairness conditions.
• Streett automata can be used in order to define
  various fairness conditions (weak strong).

38
Safety Properties

• Basic properties can be checked by simply
  analyzing the state graph
• Invariants can be checked on every visited
  state.
• Deadlocks states without outgoing edges.
• Unreachable code instructions that are not
  represented on any transition.
• Liveness properties require a more complicated
  process.

39
Specification

• We use Linear Temporal Logic (LTL) Pnueli 77 to
  define specification properties.
• LTL formulas are interpreted over an infinite
  sequences of states, and consist of
• Propositional variables,
• Logical connectives, such as ? , ? , ? , ?, and
• Temporal operators, such as
• ?(p) p will eventually occur.
• ?(p) p always occurs.
• A model M satisfies a formula f (M f) if every
  (fair) run of M satisfies f.

40
Converting specification to ?-automaton

• Every LTL property can be converted into a Buchi
  automaton with a size exponential to the LTL
  formula size Vardi Wolper 94.
• For deterministic Streett automata, a
  determinization process is also required Safra
  88.
• May result in a doubly exponential blowup from
  LTL property.

41
The Model Checking Process Vardi Wolper 86

• Both model and speciation are converted to
  ?-automata over the same alphabet.
• The alphabet is 2AP, where AP denotes a set of
  atomic propositions that may hold on the system
  states.
• Every word accepted by M (a fair run) should be
  accepted by the spec, therefore we have to check
  whether L(M) ? L(f(.

42
Model Checking Results

• Its easier to check whether
• L(M) n L(f( Ø, or
• L(M) n L(?f( Ø.
• Case 1
• Intersection is empty.
• M satisfies f .
• Case 2
• Intersection is not empty.
• Runs contained in the intersection can be used
  for generating counterexamples.

43
Checking for Non-Emptiness

• Easy with Buchi automata
• Decompose intersection graph into maximal SCCs
  reachable from the root.
• Check ff an accepting state from F occurs
  infinitely often inside a reachable SCC.

• More complicated with Streett automata.
• Alg. can be used for a single SCC or an entire
  automaton

44
Model Checking and GP

• Can standard model checking results be used as a
  GP fitness function?
• Yes, but it was done so far with a limited
  success Johnson 07.
• A fitness function with just two values is a poor
  one.
• We wish to analyze the model checking graph in
  order to quantify the level of satisfaction.
• When using nondeterministic Buchi automata, a
  single program computation may have multiple
  accepting and non-accepting paths ? difficult to
  analyze.
• Deterministic Streett automata are not more
  expensive, but ensure symmetry between accepting
  and non-accepting paths.

45
Enhanced Model Checking Algorithm

• The idea
• We assume that an hostile scheduler (or
  environment) chooses the execution path.
• For each spec. property, we check the amount of
  work the scheduler has to make in order to cause
  a property violation.
• The results are used for setting the fitness
  level scores.

46
Fitness Level 0
A

• All SCCs are empty (not accepting).
• Property is never satisfied.
• No scheduler choices are needed.

C
B
E
D
47
Fitness Level 1
A

• At least one accepting SCC.
• At least one empty bottom SCC.
• Finite number of scheduler choices can lead the
  execution into the empty BSCC (D in the example).
• The program will stay there forever.
• BSCC with only 1 node means a deadlock ? gets
  worse score.

C
B
E
D
48
Fitness Level 2
A

• All BSCCs are accepting.
• At least one empty SCC.
• Infinite scheduler choices are needed for keeping
  the program inside the empty SCC (B in the
  example).

C
B
E
D
49
Fitness Level 3

• All SCCs are accepting.
• There still may be SCCs that are not universal,
  and contains violating paths.
• Therefore, the graph universality is checked.
• If the graph is not universal, we are still at
  level 2.
• Otherwise, level 3 is assigned.
• In this case, even infinite scheduler choices
  cannot cause a violation, since the property is
  always satisfied.

A
C
B
E
D
50
Overall Fitness Function

• Fitness levels scores are calculated for each
  specification property.
• How to merge into a single fitness function?
• Naïve summing can bias the results, since some
  properties may be trivially satisfied when more
  basic properties are violated.
• Thus, spec. properties are divided into levels,
  starting from level 1 for most basic properties.
• As long as not all properties at level i are
  satisfied, properties at higher level gets
  fitness of 0.
• This algorithm also saves running time by
  skipping unneeded checks.

51
Parsimony

• GP programs tend to grow up over time to the
  maximal allowed tree size (bloating).
• Large portions of the code become introns
  (junk DNA).
• To avoid that, we use parsimony as a secondary
  fitness measure.
• Number of program nodes small factor is
  subtracted from the fitness score.
• The factor should be carefully chosen.
• Should encourage programs to reduce their size,
  but
• Should not harm the evolutionary process.
• Therefore, programs cannot get a score of 100,
  but only get close to it. The run can be stopped
  when all properties are satisfied.
• Programs can be reduces either by mutations, or
  directly by detecting dead code by the model
  checking process, and then removing it.

52
Vacuity
?(p ? ?q)

• A special care is needed for implication
  properties of the form ?(p ? ?q).
• Some (or all) executions may be vacuously
  satisfied if p never happens.
• We are usually interested only on runs when p
  eventually occurs.
• Other runs are neither good nor bad. They are
  irrelevant.
• Thus, in these cases, the program automata is
  first intersected with the property ?p.
• Some SCC might be marked irrelevant.

p?q
?p
p??q
?(p ? ?q)
?p

• If all SCCs are irrelevant, fitness level 0 is
  assigned.
• A similar mechanism is used for excluding unfair
  runs.

53
The Mutual Exclusion Problem

• Originally described by Dijkstra 65.
• Many variants and solutions exist.
• Modeled using the following program parts
• Non Critical Section
• Pre Protocol
• Critical Section
• Post Protocol
• We wish to automatically generate correct code
  for the pre and post protocol parts.

54
Spec. Properties

• The specification includes the following LTL
  properties
• The properties are converted into Streett
  automata.

55
Runs Configuration

• 3 different sets of runs
• The following parameters were used
• Population size 150
• Max number of iterations 2000
• µ 5
• ? 150

56
An Example of a Run (1st variant)
Score 0.0

• Randomly created.
• Does not satisfy mutual exclusion property.
• Higher level properties are set to 0.

57
An Example of a Run (1st variant)
Score 66.77

• Randomly created.
• While loop guarantees mutual exclusion.
• Only process 0 can enter the critical section.

58
An Example of a Run (1st variant)
Score 75.77

• Last line changed by a mutation.
• The naïve mutual exclusion algorithm.
• Processes uses a turn flag, but depend on each
  other.
• A local maximum point in the search space.

59
An Example of a Run (1st variant)
Score 70.17

• An important building block common to many
  algorithms.
• Each process set its own flag and wait for
  others flag, but
• The flag is not turned off correctly.
• Might eventually deadlock, thus, properties 4 and
  5 get fitness level of 1.

60
An Example of a Run (1st variant)
Score 76.10

• Last line is replaced by a mutation.
• Now, process 0 correctly turns its flag off.
• Property 5 is fully satisfied

61
An Example of a Run (1st variant)
Score 92.77

• A single node is changed by a mutation.
• Both processes turn off their flag.
• Properties 4 and 5 are fully satisfied.
• Still, deadlock occurs if both processes enter
  simultaneously.

62
An Example of a Run (1st variant)
Score 93.20

• A mutation added a line to the empty while loop.
• This turns the deadlock into a live lock, and
  causes a slight fitness improvement.

63
An Example of a Run (1st variant)
Score 94.37

• Another line is added to the while loop.
• No more dead or live locks, but property can
  still be violated by some infinite scheduler
  choices.

64
An Example of a Run (1st variant)
Score 96.50

• Created by some random mutations.
• All properties are satisfied.
• Still, not the shortest solution.

65
An Example of a Run (1st variant)
Score 97.10

• Created by more mutations.
• The shortest found algorithm.
• Identical to the known One bit protocol Burns
  Lynch 93.

66
Fitness Graph

• Best fitness is alternately improved by
• Major leaps due to changes in fitness levels.
• Small improvements caused by parsimony pressure.

67
More experiments

• Successfully found Dekker's algorithm. Dijkstra
  65.
• Successfully found Petersons algorithm.
  Peterson Fisher 77.
• Found a shorter algorithm than Dekker's.

68
Performance

• First variant was easiest to solve.
• Other variants are much harder to find.
• Still, much better than brute-force methods.
• Less significant on small programs (Peterson).
• Crucial on large programs (Dekker).

69
Conclusions and Future Work

• GP and model checking were successfully combined.
  To achieve that, a specific tool was developed.
• Found solutions are guaranteed to completely
  satisfy the specification.
• Scoring system can be further refined.
• More information can be extracted from the model
  checking results, for assisting the evolutionary
  process.
• A similar method can be used for correcting a
  given program, or at least showing where the
  error is.
• Next step use discriminative model checking
  properties to refine grading and to find where in
  program to make changes.
