High Voltage Laboratory

1
High Voltage Laboratory

• Department of Electrical Engineering,
• Indian Institute of Technology,Kharagpur.

2

• One of the Oldest laboratories of Electrical
  Engineering Department, IIT Kharagpur
• Maximum rating is 600 kV
• Major Activities
• Research Development
• Consultancy
• Classes for Undergraduates and
  Postgraduates

3
Equipments In the Laboratory
4

• Transformer Oil Test Kit 60 kV
• High Voltage AC Test Source
• 10 kVA , 0.2 / 200 kV , 50/0.05 A, 50 Hz
• Impulse Voltage Generator
• 600 kV , 18 kJ

5

• Impulse Current Generator
• 15 kA , 5 kJ
• Partial Discharge Measurement
• Capacitance and Tan Delta Measurement
• Up to 12 kV level

6

• Rectangular Current Pulse Generator
• 120 A , 15 ms ,4.5 kJ
• High voltage DC source
• 10 kV , 0.3 A
• Sphere Gap 50 cm diameter
• Point, Plane, Sphere Electrodes 200 kV

7

• Distribution Transformers
• 25 kVA, 11 kV/400 V, 50 Hz
• 100 kVA, 11 kV/433 V, 50 Hz
• Pressure and temperature Measurement
• Three Phase Variac
• 415/0-470 V, 200 A, 50 Hz

8

• Single Phase Variac
• 240/0-270 V, 28 A, 50 Hz
• Measuring Equipments
• Oscilloscopes 25 GS/s, 150 MHz
• 1 GS/s, 500 MHz
• 1 GS/s, 100 MHz
• Current Probes 2000 A(peak), 400 volts
• Electrometer 2 V - 200 V, 20 pA 20 mA, 2 k?
  200 G?,
• 20 nCoulomb 20
  µCoulomb

9
Various Activities of the Laboratory
10
Impulse Tests on Transformers
Impulse Voltage Generator 600 kV , 18 kJ
11
Corona discharges and breakdownObservations
High Voltage AC Test Source 10 kVA , 0.2 / 200
kV , 50/0.05 A, 50 Hz

• Sphere Sphere
• Point Plane
• Plane Plane
• Point Point

12
Partial Discharge Measurements of Transformer
windings and Cables

• Amount of Partial Discharge
• Source of Partial Discharge

13
Condition Monitoring Of Transformers

• HVAC testing up to 50 kV,
• 100 mA AC
• Acoustic based Partial
• Discharge measurement up to
• 50 kV

14
Capacitance Measurement of Cables
Capacitance and Tan delta measurement set up
15
Compaction of Nanomaterials using Rectangular
Pulse Generator( 120 Amps, 15 msec, 4.5 kJ)
16
Design of Super Conducting Cables (CIC Type)

• Sponsored RD project by Institute of Plasma
• Research (IPR), Gujarat under National
  Fusion
• Program (NFP)
• To be used for Fusion Grade Magnets

17
Electroporation of microbial cells
Electrostatic separation of carbon from fly ash

• 10 kV HVDC source for separation
• Collects carbon from fly ash

• 10 kV , 0.2 amp Impulse voltage Generator
• Sterilization of food and water by killing
  bacteria cell membrane

18

• Transformer oil Testing
• Finding out breakdown strength of oil
• Insulation testing and finding surface
• resistance of various insulators
• Sources calibration and testing for other
• departments
• Doctoral work in the area of electrical field
• computations employing Charge Simulation
• Method
