Introduction to XSLT

1
Introduction to XSLT

• David G. Durand
• Director Electronic Publishing Services, Ingenta
  Inc.
• Adjunct Associate Professor, Brown University

2
Thanks

• Steven J. DeRose

3
What is XSLT?

• eXtensible Stylesheet Language for
  Transformations
• Language for transforming XML documents
• A programming language for XML documents
• A functional language, based on value
  substitution
• Augmented with pattern matching
• And also template substitution to construct
  output (based on namespaces
• Uses XML syntax

4
Why transform?

• Convert one schema to another
• I say potato, you say paragraph
• Rearrange data for formatting
• Present style languages cant re-order or copy
• see section ltxref sidsec37/gt
• Project or select document portions

5
Some special transforms

• XML to HTML for old browsers
• XML to LaTeXfor TeX layout
• XML to SVGgraphs, charts, trees
• XML to tab-delimitedfor db/stat packages
• XML to plain-textoccasionally useful
• XML to FOXSL formatting objects

6
Document Transformation

• The perspective is tree editing, not syntax
• Basic operations
• Changes to node properties
• Structural rearrangement
• Several models for this kind of task

7
Models for tree editing

• Functional
• Rewrite rule-based
• Template-based
• Imperative

8
Functional tree rewriting

• Recursive processing
• Invoke start function at the root, construct a
  new tree
• Can think of this as node functions
• Result is compositional substitution is
  generally nested
• Side effects often avoided caching values,
  clarity.

9
Rule-based (rewriting systems)

• A transformation is defined by a list of
  pattern/result pairs
• Each is a piece of a tree with holes
  (variables)
• A match leads to replacement of the matched tree
  nodes by a result tree
• Variables shared between pattern and result allow
  preservation and rearrangement of arbitrary data
• Poweful, incremental, definitions
  non-deterministic processing

10
Template based processing

• This is a model in which a pattern document is
  the starting point
• This model is very familiar from many web-based
  systems.
• It contains literal results interleaved with
  queries and sometimes imperative code
• Well-suited to repetitive or rigid structures
• Often requires extensions to deal with recursion
  and looping
• Frequently appropriate for database-style XML

11
Imperative

• Parser calls imperative code, which uses
• Stacks
• Global variables
• Explicit output commands
• Result is a side effect.
• Reasoning about the program may be hard, but
  creating it often starts out easily
• This approach makes it easy to create non-XML, or
  ill-formed XML documents

12
Whats the biggest drawback to tree editing?

• Buffering!
• You need a copy of the tree to edit
• This means that its very easy to build
  transformer for a document entirely in-memory
• Doing this from secondary storage is fairly
  subtle, and has its own performance penalties
• This is a complex speed/size/coding effort
  tradeoff
• This is one reason imperative approaches are
  sometimes appealing even to purists.

13
What side are we on?

• XSLT falls squarely in the middle
• Styles of XSLT transform
• Functional
• Rule-based
• Template-based
• Imperative (although unusual)

14
XSLT and transformation styles

• Rule-based substitution (but results are like
  template languages)
• XPath addressing also looks like queries in
  traditional template languages
• Limited non-determinism
• Sufficient control over rule evaluation order
  that functional transformations are easy

15
Where does XSLT fit?

• Dependencies
• XML -gt XPath -gt XSLT -gt XSL
• The WGs involved
• XSL Working GroupXML Linking for XPath
• Status
• Full W3C Recommendation, in wide use
• http//www.w3.org/TR/xsl/

16
XML Documents as trees of nodes

• Root
• Elements
• Attributes
• Text Nodes (not characters)
• Namespaces
• Processing Instructions
• Comments

17
XML Document order

• Root -- First
• Elements -- Occur in order of their starts
• Text Nodes -- As if children (leaves)
• Attributes, namespaces -- Attached to element,
  unordered
• PIs, comments -- Leaves like text nodes

18
Other XML notions

• XML declaration identifies a document as
  intending to conform to XML rules
• DTD or schema rules for permissible elements and
  attributes for a genre
• Well-formedness correct XML syntax, but maybe
  not valid to specified DTD
• XML name token ok as element/attr names
• Stylesheet PI hooks document to ss.

19
XPath and its use in XSLT

• An expression language over XML trees
• Used to identify sets of elements
• all paragraphs
• all paragraphs directly inside footnotes
• the section with IDsec37
• footnotes with authorKnuth
• first paragraph in each section
• the parent of each caption
• Then you can say what to do with them

20
The math

• For all nodes, gaps between children are
  numbered.
• Before first child counts as 0
• Text nodes count like elements
• So ltpgta ltemgtbiglt/emgtthinglt/pgt has three children
  in the p
• Characters count within text nodes
• Before the first character is 0

21
Counting locations
22
Basic kinds of pointing

• Directions of navigation/specification
• Finding elements by ID
• Finding nearby/related elements
• ancestors, children, following-siblings, etc.
• Finding attribute and namespaces applicable to an
  element
• Finding strings in content
• Qualifications
• Test properties of locations
• Attributes, types, content
• Combine all these in multiple "steps"

23
Anatomy of a location step
predicate
childpara_at_type"weak"3
node test
literalstring
position test
axisname
attributereference
Finds the third child of the current node that
(a) is an element of type 'para' and (b) has
a 'type' attribute whose value is 'weak'
Case matters
24
Location step details

• A node test tests
• The element type for axes of elements,
• attribute name for axes of attributes,
• or an explicit node-type test, e.g. text()
• Multiple predicates (left-to-right)
• Predicates can be arbitrary expressions
• Shorthhand
• Default axis is child
• Number in predicate is position test
• E.g. chap4/sec5/para

25
The simplest functions

• root()
• Locates the root of the containing resource
• (not the document element )
• lt?foo?gtltdocgt...lt/docgtlt!-- hi --gt
• Abbreviation /
• id()
• Locates element with that ID value
• Note Finding this requires DTD
• Cf descendantattribute(id)'foo'
• Can have multiple ID tokens in argument
• id('chap37 sec12 xyzzy')

26
root() and id()

root()/
id("p37")

27
Relative axes in general

• Locate nodes by genetic relationships
• Axis name specifies relationship
• Always count outward from starting point
• Predicates (more later) follow in
• Pick from candidates along the axis
• Test serial position
• Test element type name or attribute values
• Can have embedded XPointer expressions
• Special "node test" predicates after ""
• childpara tests element type
• childnodetype() tests node type

28
child axis

• childtypepredicate
• Locates direct substructures
• (only elements have children)
• (attributes are not children)
• First (eldest) child that is a para
• childpara1
• Last (youngest) child that is a para
• childparalast
• Abbreviation /
• sec2/para1

29
parent and self axes

• parent
• Gets direct parent of a node
• Only elements and root can be parents
• Every node but root has a parent
• Element containing one with id'foo'
• id('foo')/parent
• Can use predicates to filter
• id('foo bar')/parentsection
• self
• Returns the node you started at ('context')

30
child, parent, self

id('intro')/child2
id("summary")/self

id('p37')/parent
31
ancestor, ancestor-or-self

• ancestor
• Locates direct and indirect ancestors
• First ancestor (parent) that is a div
• ancestordiv1
• All ancestors that are divs
• ancestordiv
• ancestor-or-self(args)
• Same except the context node counts
• Example sec containing id foo, even if the id is
  on the sec itself
• id('foo')/ancestor-or-selfsec

32
ancestor()
id(p37)/ancestorchapter1

id(p37)/ancestor3
id(baz)/ancestor-or-self selfp or selfa
33
descendant axis

• Descendant (not descendent!)
• Locates direct and indirect sub-nodes
• Depth-first, left-to-right ( start-tag order)
• Third descendant that is a para
• descendantpara3
• All descendants that are FOOTNOTEs
• descendantFOOTNOTE
• Abbreviation //
• descendant-or-self
• Same except that context node counts

34
descendant, -or-self

/descendant-or-selfchapter id(intro)/descendant-
or-selfchapter

/descendantsection1
35
Preceding/following -sibling

• preceding-sibling, following-sibling
• Locate preceding (older)/following (younger)
  siblings
• Closest node is 1 farthest is "last"
• PIs, comments, text nodes count

36
preceding/following

• preceding and following
• Works in order of start-tags (pre-order)
• Locate many nodes other than ancestors
• Not frequently useful
• Can land you at odd places since the tree
  structure is not really involved
• One useful case
• Find prev/next element X, wherever
• ltmanuscript-page-start n"25" /gt
• ltfootnotegt

37
following-sibling() etc.

id(intro)/following-siblinglast

id(summary)/precedingp3
38
Preceding, another way
id(summary)/precedingp3

ltdocgt lttitlegtIntrolt/titlegt ltabstractgtlt/abstract
gt ltchapter ID''intro'gt lttitlegtlt/titlegt ltsecti
ongt lttitlegt lt/titlegt ltp ID'p377'gt lt/pgt
ltpgtlta name'baz'/gt lt/pgt ltlistgt lt/listgt ltpgt
ltxref href'id(intro)'gt lt/pgt lt/sectiongt ltsectio
ngt lt/sectiongt lt/chaptergt ltchapter
ID'concepts'gt lt/chaptergt ltchapter
ID'summary'gt lt/chaptergt lt/docgt
Real document would have lots of text nodes

"lt" indicates the candidate nodes counting back
to the right one
39
attribute axis

• attributename
• Locates attribute specification, not value
• Abbreviation _at_
• To refer to second attribute ofltp id"hello"
  status"draft"gt
• Use id(hello).attribute("status")
• Careful!
• Attributes of an element are unordered
• Attributes have parent elements, but are not
  their children

40
namespace axis

• XML namespaces are declared via attributes
• And apply throughout descendants
• ltsec xmlnsmy"http//"gtltmytitlegt...
• Much like attribute nodes
• All active namespaces are accessible via the
  namespace axis from a given element.
• Distinct elements do not share ns nodes

41
Summary axes and functions

• root( ), id( )
• parent, self, child
• ancestor, ancestor-or-self
• descendant, descendant-or-self
• preceding-, following-sibling
• preceding, following
• attribute, namespace

42
XPointer datatypes

• Strings
• Not the same as the location of some text
• Unicode abstract characters
• (implementers must normalize surrogate pairs)
• Quote literals with ' or "
• Numbers
• IEEE 754 standard floating point
• Booleans
• true() and false()
• Locations and location sets

43
XPointer operators/functions

• Math - div mod
• (- allowed in names, so precede by space)
• sum(location-set), floor(), ceiling(), round()
• id('foo')//img_at_height _at_width gt 100
• Logic or and not()
• id('foo')//_at_type'a' or _at_type'b'
• Comparisons ! lt gt lt gt
• id('foo')//img_at_height lt _at_width
• Escape when needed in XML
• lta href"http//www.example.com/foo.xml
  xpointer(id('foo')//img_at_height lt _at_width)"gt

44
Comparisons

• For node sets
• A comparison is true if there is a node in each
  set for which the comparison on the string values
  is true.
• For other things
• If at least one side is Boolean, compare Boolean
• If at least one side is a number, compare numeric
• Else convert to strings and compare

45
Specialty functions

• last() returns locations in current context
  (candidate set)
• position() returns where the current location is
  in the context
• name() returns the node's "expanded name"
  (including namespace)
• string(), boolean(), number()
• lang(string) to test a location's xmllang value

46
String functions

• concat(string,)
• starts-with(string, string)
• contains(string, string)
• substring-before (string, string)
• substring-after (string, string)
• contains(string, string) -- from 1!
• string-length(string)
• normalize-space(string)
• translate(string, from, to)

47
Advanced notes on strings

• Every node has a "string value"
• "" comparison does not mean "the same node"
• Concatenated text of all descendants
• No spaces inserted (e.g. between list items)

48
On to XSLT proper
49
Whats inside an XSLT transform?

• Any number of templates
• A template uses Xpath to match nodes
• Highest priority matching template selected
• Then the remplate takes over and generates
• Literal output XML (based on namespace)
• Computational results (of XSLT functions)
• Results of further template applications
• Results of queries on the document
• Many options

50
The process

• XSLT takes
• A source XML document
• A transform (XSLT program)
• XSLT applies templates to found nodes
• (may delete or include the rest)
• (may process in document or tree or any order)
• XSLT generates
• A result XML or text document

51
The boilerplate

• ltxslstylesheet version"1.0 xmlnsxsl
  "http//www.w3.org/1999/XSL/Transform"gt

• ltxsltemplate match"/_at_text()"gt
• ltxslcopy-ofgt
• ltxslapply-templates select"_at_"/gt
• ltxslapply-templates/gt
• lt/xslcopy-ofgt
• lt/xsltemplategt
• lt/xslstylesheetgt

52
From Copy to Transform

• lt?xml version1.0?gtlt!-- Rename all p elements
  to para --gtltxslstylesheet xmlnsxsl
  "http//www.w3.org/1999/XSL/Transform"gt
  ltxsltemplate match/_at_text() priority1gt
• ltxslcopygt
• ltxslapply-templates select"_at_"/gt
• ltxslapply-templates/gt
• lt/xslcopygt
• lt/xsltemplategt
• ltxsltemplate matchp priority2gt
  ltparagt ltxslapply-templates/gt
  lt/paragt   lt/xsltemplategtlt/xslstylesheetgt

53
How do you apply one?

• Refer via Stylesheet PI
• Defined in W3C xml-stylesheet rec
• lt?xml-stylesheet hrefURI type title
  media charset alternateyes ?gt
• Apply via standalone program
• E.g. XT, Xalon, Saxon (see Web for latest
  versions)

54
Caveats

• Many constructs have extra options
• These are more constructs
• We will not cover all these
• For example
• ltxslstylesheet idIDextension-element-prefixes
  my-Fnsenclose-result-prefixeshtmlversion
  1.0xmlspacedefaultgt

55
Template styles

• Push vs. Pull templates
• Or, per Michael Kay
• Fill-in-the-blanks
• Looks like output document with pulls to merge
• Navigation
• Adds top-level ltxsltransformgt, macros
• Rule-based
• Conceptually, a template for each elemet type
• Computational
• Gory processing to generate markup from none

56
At the top level

• Key thing templates
• Also several option-settings
• ltxslincludegt -- must be first
• ltxslimportgt
• ltxsl strip-spacegt or ltxslpreserve-spacegt
• ltxsloutputgt, ltxsldecimal-formatgt
• ltxslkeysgt, ltxslnamespace-aliasgt
• ltxslattribute-setgt, ltxslvariablegt, ltxslparamgt
• Most of these are more advanced.

57
Anatomy of a template

• XPath to select elements to apply template to
• (this is where programming/scripting comes in)
• XML to output, for each instance selected
• Embedded within that output
• XSLT instruction elements
• Literal output (including XML tags)
• References to content to transclude
• Place to put results of transforming the
  elements children (if desired)

58
Trivial Templates Tag Renaming

• ltxsltemplate matchdiv_at_typeidx"gt
  ltindexgt ltxslapply-templates/gt
  lt/indexgt lt/xsltemplategt
• ltxsltemplate matchdiv1"gt ltdiv levelgt
  ltxslprocess-children/gt
  lt/divgt lt/xsltemplategt

59
Trivial Templates Mapping to HTML

• ltxsltemplate matchfn_at_authKnuth"gt
  ltblockquote stylecolorredgt
  ltxslapply-templates/gt lt/blockquotegt lt/xsltemp
  lategt
• ltxsltemplate matchprice"gt ltugtltbgt
  ltxslapply-templates/gt lt/bgtlt/ugtlt/xsltemplate
  gt

60
Template options

• Match xpath
• Which elements to apply template to
• Name qname
• Name a template for later reference
• Mode -- (limit template to work in a certain
  named mode -- more later)
• xmlspace defaultpreserve
• Override inherited space-handling
• Priorityn -- for conflicting rules

61
The ultimate default

• Elements are not copied
• Attribute values and text are copied,
• Thus a transform with no templates except for the
  root, strips markup from a document
• ltxsltransformgt ltxsltemplate match//gt
  lt/xsltemplategtlt/xsltransformgt

62
Priority example

• Delete all nested ltlistgts
• ltxsltemplate matchlist/list
  priority2gt lt!-- deleted nested list
  --gtlt/xsltemplategt
• ltxsltemplate matchlist priority1gt
  ltlistgtltxslapply-templatesgtlt/listgtlt/xsltemplategt

63
Template priority

• Multiple templates may match an element
• lttemplate priority3 matchh1gtlttemplate
  priority5 match_at_classbiggtlttemplate
  priority9 matchh1_at_idS1gt
• Highest priority number wins
• Priorities are integers, including negative
• There are also default rules
• All have priority -0.5 lt p lt 0.5

64
What goes in a template?

• Literal XML to output
• Pull references to other content
• Instructions to generate more output
• Setting and using variables
• Invoking other templates like macros
• Manually constructed XML constructs
• Conditional instructions (if, choose, etc.)
• Auto-numbering hacks

65
Instructions apply-templates

• ltxslapply-templates selectxpath
  modeqnamegt
• Main use (no attributes or content)
• mark where to include result of processing
  children
• select
• Include certain children
• selectsecurepublic
• Pull (transclude) anything from elsewhere
• select//idwarning17
• Mode Apply only templates of this mode

66
Keeping things in variables

• 2 types (names are XML qnames)
• Variables are assigned once and for all
• Parameters can be overridden later
• Value types
• A template
• The result of instantiating a template
• Node-set, string, Boolean, or number
• An RTF is a restricted type of node-set
• References varname

67
Setting XSLT variables

• Default parameters declared at top level
• ltxslparam namep selects/gt
• or
• ltxslparam namepgt lttemplategtlt/templategtlt/
  xslparamgt
• Override via similar xslwith-param
• ltxslwith-param namepgt
  lttemplategtlt/templategt lt/xslparamgt

68
Instructions call-template

• Invoke a template (like a subroutine)
• ltxslcall-template nametgt ltxslwith-param
  namep selectxpathgt
  lt/xslcall-templategt

69
Using XSLT variables

• Limited processing can be done on RTFs
• Mainly string processing
• Embed variables via varname
• Can do for markup as well as content
• Can process via functions (later)

70
ltxslvalue-ofgt

• ltxslvalue-of selectexpr disable-output-esca
  pingyesnogt
• Outputs the string value of the selected node(s).
• Any type can be cast to string.

71
ltxslcopy-ofgt

• ltxslcopy-of selectexpr/gt
• No content allowed
• Select attribute picks what to copy
• Using the usual XPath method
• The result is copied
• A node-set is copied (entire forest of subtrees)
• An RTF is copied (likewise)
• Anything else is cast to a string that is copied
• No processing is allowed enroute

72
ltxslcopygt

• ltxslcopy use-attribute-sets qnamesgt
  ltxsltemplategtlt/xsltemplategtlt/xslcopygt
• Generates the start- and end-tags
• Does not include attributes or children
• May contain ltxslapply-templates/gt etc.

73
Conditional constructs
74
ltxslifgt

• ltxslif testboolean-exprgt
  ltxsltemplategtlt/xslifgt
• Applies the template only if the expression
  evaluates to true.
• These can be nested
• No else construct
• See also xslchoose (case or switch)
• E.g. Test_at_showT

75
ltxslchoosegt

• Like select/switch/case statement
• Good for handling enumerated attributes
• ltxslchoosegt ltxslwhen testboolean-exprgt
  ltxsltemplategt lt/xslwhengt
  ltxslotherwisegt ltxsltemplategt
  lt/xslotherwisegtlt/xslchoosegt

76
ltxslfor-eachgt

• ltxslfor-each selectnode-set-exprgt
• May contain
• Xslsort -- any number of keys
• Template
• Applies template to each node found
• ltxslsort selectstring-expr langlg
  data-typetextnumberqname
  orderascendingdescending
  case-orderupper-firstlower-firstgt

77
More macro-type instructions
78
ltxslapply-importsgt

• Affects templates imported via xslimport that
  would not otherwise by applied
• Imported templates have lowest priority
• Invoke from within a template

79
ltxslvariablegt

• Declares a variable
• Variables are scoped to where declared
• ltxslvariable nameqname selectexprgt
  ltxsltemplategt

80
ltxslmessagegt

• Issues a message to the output
• terminateyesno
• Message is specified via contained template
• Thus may include data from source

81
ltxslfallbackgt

• Provides backup for when an instruction fails
• Contains template to use
• Example
• trying to use an unknown extension instruction

82
ltxslnumbergt

• Used to generate auto-numbering
• ltxslnumber levelsinglemultipleany
  countpattern -- which nodes count?
  frompattern -- starting point
  valuenumber-expr -- force value formats
  -- (not covering) langlg -- lang
  to use letter-valuealphabetictraditional
  grouping-separatorchar -- 1,000
  grouping-sizenumber -- 3 in EN/gt

83
Numbering example

• ltxsltemplate selectlistgt ltxslelement
  nametoplistgt ltxslattribute
  namemarkergt ltxslnumber
  levelsingle/gt lt!--count defaults to
  siblings--gt lt/xslattributegt
  lt/xslelementgtlt/xsltemplategt
• multiple -- gathers up sibling numbers of
  ancestors
• ltxslnumber levelmultiple format1.1.1
  countchapsecssec/gt

84
Building XML from parts

• Why?
• Generate element type name, etc. by expression
• Content is any template
• ltxslelement nameqname namespaceuri use-
  attribute-setsqnamesgt
• ltxslattribute nameqname namespaceurigt
• ltxslprocessing-instruction namencnamegt
• ltxslcommentgt
• ltxsltext disable-output-escapingyesgt

85
Attributes for XML constructors

• name namesp u-a-s d-o-e
• ltxslelement gt
• ltxslattribute gt
• ltxslprocessing-instruction gt
• ltxslcomment gt
• ltxsltext gt

86
Examples

• Generate element attributes
• ltxslelement nameconcat(_at_type,-,_at_ngt
  ltxslattribute namestylegt
  font-size12pt displayinline
  lt/xslattributegt ltxslapply-templates/gtlt/xsle
  lementgt
• (more later on concat() later)

87
Data handling via functions

• For strings
• For numbers
• For truth values
• For XML information

88
String values

• Anything can be cast to a string
• Boolean true or false
• Numbers To decimal
• Nodes
• Root, Elements character content of all
  descendants
• Text nodes the character content
• Attributes the attribute value
• Comments, PIs the character content
• Namespaces the namespaces URI

89
For strings

• String(object) -- explicit type-cast
• Concat(s1, s2, s3,) -- concatenate
• Substring(s, offset, length)
• Substring-after(s,s), Substring-before(s,s)
• Translate(s,from,to)
• Substitute chars in from, with ones from to
• Normalize-space(s) -- nuke extra whitespace
• Contains(s1,s2), starts-with(s1,s2)
• Returns true or false
• String-length(s) -- length in characters

90
For numbers and logic

• Number
• Ceiling, Floor, Round, Sum
• Boolean
• True, False, Not

91
For XML information

• Id(object)
• If arg is a node-set, each node is cast to string
• E.g. context of //footnote/attr(ref) gets ref
  attributes
• Else arg is cast to a string
• Filters the context by picking node w/ ids in
  list
• Many space-separated Ids may be included
• Lang

92
For looking around the context

• Count(node-set)
• Returns number of nodes in the argument
• Last()
• Returns number of nodes in the context
• Position()
• Returns the position of the current node in the
  context

93
For names and namespaces

• Local-name(node-set?)
• Returns local part of the name of the first node
• Name(node-set?)
• Returns entire qualified name of the first node
• Namespace-uri(node-set?)
• Returns the uri identifying the namespace of the
  first node

94
A few examples

• Creating an SVG graphical overview of your
  document
• Counting and displaying document statistics
• Testing beliefs about document structure
• Merging in annotations or transcluded data

95
Oddities of XPath and XSLT

• Navigational language for specifying pattern
  matches
• You specify the tree pattern implicitly by
  specifying a query for a node where a pattern
  will be replaced
• This sometimes makes the structure less explicit
• You can invoke further processing on children
• You use template-style access functions rather
  than pattern variables

96
Surface Oddities

• The language is a mixture of predicate / query
  and structural pattern
• Unix path syntax and query syntax syntax make a
  peculiar mix
• Matching within XSLT is always relative to a
  particular node, so the first few times results
  can be very puzzling

97
Strategies for XSLT

• Try to pick a single style as much as possible
• May vary by project
• Mixing may be necessary but can get confusing
• Be sure you understand (and probably override the
  default rules)
• Shorter patterns are better
• ltxslvalue-ofgt and ltxslifgt may be easier to deal
  with than a complex path

98
Strategies

• Use several filters in row
• Its often easier to manage a series of global
  changes, than interactions between several
  complex conditions.
• Intermediate results make debugging easier
• Intermediate results may be cacheable
• Critical for online applications
• Where possible code things one element at a time

99
References

• Key siteshttp//www.w3.org/Style/XSL
  http//www.mulberrytech.com/xsl/xsl-list
  http//www.oasis-open.org/cover/xsl.html
• Interactive XSLT reference http//www.zvon.org/xxl
  /XSLTreference/Output/
• XSLT 2nd Edition Programmers Reference Michael
  Kay Good reference clear, but not really a
  tutorial
• XSLT XPath On the EdgeTennison And her other
  books
