EET 3350 Digital Systems Design Textbook: John Wakerly Chapter 8: 8'5

1
EET 3350 Digital Systems Design Textbook John
Wakerly Chapter 8 8.5

• Shift Registers
• Serial Communications

2
Agenda for Today

• Shift Registers
• Definitions
• I/O Types serial, parallel, combinations
• Direction left, right, bidirectional
• Applications
• VHDL implementations
• MSI Shift Registers
• Serial Communications

3
Shift Registers

• Using registers to store, manipulate and transfer
  data

4
Definition

• A register is a digital circuit with two basic
  functions Data Storage and Data Movement
• A shift register provides the data movement
  function
• A shift register shifts its output once every
  clock cycle
• A shift register is a group of flip-flops set up
  in a linear fashion with their inputs and outputs
  connected together in such a way that the data is
  shifted from one device to another when the
  circuit is active

5
Shift Register Applications

• communications
• UART
• converting between serial data and parallel data
• temporary storage in a processor
• scratch-pad memories
• some arithmetic operations
• multiply, divide

• some counter applications
• Johnson counter
• ring counter
• LSFR counters
• time delay devices
• more

6
Shift Register Characteristics

• Types
• Serial-in, Serial-out
• Serial-in, Parallel-out
• Parallel-in, Serial-out
• Parallel-in, Parallel-out
• Universal
• Direction
• Left shift
• Right shift
• Rotate (right or left)
• Bidirectional

7
Data Movement

• The bits in a shift register can move in any of
  the following manners

8
Data Movement

• Block diagrams for shift registers with various
  input/output options

9
Serial-In Serial-Out

• Data bits come in one at a time and leave one at
  a time
• One Flip-Flop for each bit to be handled
• Movement can be left or right, but is usually
  only a single direction in a given register
• Asynchronous preset and clear inputs are used to
  set initial values

10
Serial-In Serial-Out

• The logic circuit diagram below shows a
  generalized serial-in serial-out shift register
• SR Flip-Flops are shown
• Connected to behave as D Flip-Flops
• Input values moved to outputs of each Flip-Flop
  with the clock (shift) pulse

11
Shift Registers

• The simplest shift register is one that uses only
  Flip-Flops
• The output of a given Flip-Flop is connected to
  the D input of the Flip-Flop at its right.
• Each clock pulse shifts the contents of the
  register one bit position to the right.
• The Serial input (SI) determines what goes into
  the leftmost Flip-Flop during the shift. The
  Serial output (SO) is taken from the output of
  the rightmost Flip-Flop.

12
Serial-In Serial-Out

• A simple way of looking at the serial shifting
  operation, with a focus on the data bits, is
  illustrated at right
• The 4-bit data word 1011 is to be shifted into
  a 4-bit shift register
• One shift per clock pulse
• Data is shown entering at left and shifting right

13
Serial-In Serial-Out

• The diagram at right shows the 4-bit sequence
  1010 being loaded into the 4-bit serial-in
  serial-out shift register
• Each bit moves one position to the right each
  time the clocks leading edge occurs
• Four clock pulses loads the register

14
Serial-In Serial-Out

• This diagram shows the 4-bit sequence 1010 as
  it is unloaded from the 4-bit serial-in
  serial-out shift register
• Each bit moves one position to the right each
  time the clocks leading edge occurs
• Four clock pulses unloads the register

15
Serial-In Serial-Out

• Serial-in, serial-out shift registers are often
  used for data communications
• such as RS-232
• modem transmission and reception
• Ethernet links
• SONET
• etc.

16
Serial-In Serial-Out in VHDL

• Following is the VHDL code for an 8-bit
  shift-right register with a positive-edge clock,
  serial in, and serial out.

library ieeeuse ieee.std_logic_1164.allentity
shift is port(C, SI in std_logic SO
out std_logic)end shift architecture archi
of shift is signal tmp std_logic_vector(7
downto 0) begin process (C) begin
if (C'event and C'1') then for i in 0 to
6 loop tmp(i1) tmp(i) end
loop tmp(0) SI end if end
process SO tmp(7)end archi
17
Serial-to-Parallel Conversion

• We often need to convert from serial to parallel
• e.g., after receiving a series transmission
• The diagrams at right illustrate a 4-bit
  serial-in parallel-out shift register
• Note that we could also use the Q of the
  right-most Flip-Flop as a serial-out output

18
Serial-to-Parallel Conversion

• We would use a serial-in parallel-out shift
  register of arbitrary length N to convert an
  N-bit word from serial to parallel
• It would require N clock pulse to LOAD and one
  clock pulse to UNLOAD

19
Serial-to-Parallel Conversion

• These two shift registers are used to convert
  serial data to parallel data
• The upper shift register would grab the data
  once it was shifted into the lower register

20
Parallel-to-Serial Conversion

• We usa a Parallel-in Serial-out Shift Register
• The DATA is applied in parallel form to the
  parallel input pins PA to PD of the register
• It is then read out sequentially from the
  register one bit at a time from PA to PD on each
  clock cycle in a serial format
• One clock pulse to load
• Four pulses to unload

21
Parallel-to-Serial Conversion

• Logic circuit for a parallel-in, serial-out shift
  register

0
1
0
1
0
1
22
Parallel-In Parallel-Out

• Parallel-in Parallel-out Shift Registers can
  serve as a temporary storage device or as a time
  delay device
• The DATA is presented in a parallel format to the
  parallel input pins PA to PD and then shifted to
  the corresponding output pins QA to QD when the
  registers are clocked
• One clock pulse to load
• One pulse to unload

23
Universal Shift Register

• Universal shift register
• Can do any combination of parallel and serial
  input/output operations
• Requires additional inputs to specify desired
  function
• Uses a Mux-like input gating

0
0
1
1
24
Universal Shift Register

• Parallel-in, parallel-out shift register

0
1
0
1
0
1
25
Universal Shift Register

• Parallel shift register (can serve as converting
  parallel-in to serial-out shifter)

26
MSI Shift Registers

• 74LS164 is an 8-Bit Serial-In Parallel-Out Shift
  Register
• Typical Shift Frequency of 35 MHz
• Asynchronous Master Reset
• Gated Serial Data Input
• Fully Synchronous Data Transfers

27
MSI Shift Registers

• 74LS164 8-Bit Serial-In Parallel-Out Shift
  Register

28
MSI Shift Registers

• The 74LS164 is an edge-triggered 8-bit shift
  register with serial data entry and an output
  from each of the eight stages.
• Data is entered serially through one of two
  inputs (A or B)
• either of these inputs can be used as an active
  HIGH Enable for data entry through the other
  input
• an unused input must be tied HIGH, or both inputs
  connected together

29
MSI Shift Registers

• Each LOW-to-HIGH transition on the Clock (CP)
  input shifts data one place to the right
• This also enters into Q0 the logical AND of the
  two data inputs (AB) that existed before the
  rising clock edge.

30
MSI Shift Registers

• 74LS164 logic diagram

A LOW level on the Master Reset (MR) input
overrides all other inputs and clears the
register asynchronously, forcing all Q outputs
LOW.
31
MSI Shift Registers

• 74LS166 is an 8-Bit Shift Register
• Parallel-in or serial-in
• shift/load input establishes the parallel-in or
  serial-in mode
• Serial-out
• Synchronous Load
• Serial data flow is inhibited during parallel
  loading
• Direct Overriding Clear

32
MSI Shift Registers

• 74LS166 is an 8-Bit Shift Register

33
MSI Shift Registers

• 74LS166 8-Bit Shift Register is a parallel-in or
  serial-in, serial-out shift register

34
MSI Shift Registers

• 74LS166 is an 8-Bit Shift Register

35
MSI Shift Registers

• 74LS166 is an 8-Bit Shift Register

36
MSI Shift Registers

• 74LS194 4-Bit Bidirectional Universal Shift
  Register
• may be used in
• serial-serial,
• shift left,
• shift right,
• serial-parallel,
• parallel-serial,
• and parallel-parallel
• data register transfers

37
MSI Shift Registers

• 74LS194 4-Bit Bidirectional Universal Shift
  Register

38
MSI Shift Registers

• 74LS194 control inputs S1 and S0

39
MSI Shift Registers

• 74LS194 4-Bit Bidirectional Universal Shift
  Register

40
MSI Shift Registers

• 74LS194 4-Bit Bidirectional Universal Shift
  Register

41
Universal shift register74x194

• Shift left
• Shift right
• Load
• Hold

42
MSI Shift Registers

• One stage of the 74x194

43
VHDL Dhift Register

• Universal shift register design
• The 3-bit function select determines the
  operation of the register
• Serial in and Parallel load available

library IEEE use IEEE.std_logic_1164.all use
IEEE.std_logic_unsigned.all entity Vshftreg is
port (CLK, CLR, RIN, LIN in STD_LOGIC
S in STD_LOGIC_VECTOR (2 downto 0) --
function select D in STD_LOGIC_VECTOR
(7 downto 0) -- data in Q out
STD_LOGIC_VECTOR (7 downto 0) -- data out) end
Vshftreg architecture Vshftreg_arch of Vshftreg
is signal IQ STD_LOGIC_VECTOR (7 downto
0) begin process (CLK, CLR, IQ) begin if
(CLR'1') then IQ lt (othersgt'0') elsif
(CLK'event and CLK'1') then case
CONV_INTEGER(S) is when 0 gt null
-- Hold when 1 gt IQ lt
D -- Load when 2 gt
IQ lt RIN IQ(7 downto 1) -- Shift right
when 3 gt IQ lt IQ(6 downto 0) LIN --
Shift left when 4 gt IQ lt IQ(0) IQ(7
downto 1) -- Shift circular right when 5
gt IQ lt IQ(6 downto 0) IQ(7) -- Shift
circular left when 6 gt IQ lt IQ(7)
IQ(7 downto 1) -- Shift arithmetic right
when 7 gt IQ lt IQ(6 downto 0) '0' -- Shift
arithmetic left when others gt null
end case end if Q lt IQ end
process end Vshftreg_arch
44
MSI Shift Registers

• 74LS299 is an 8-bit universal shift/storage
  register with 3-state outputs
• Four modes of operation are possible
• hold (store)
• shift left
• shift right
• load data

45
MSI Shift Registers

• 74LS299 universal shift/storage register

46
MSI Shift Registers

• 74LS299 universal shift/storage register

47
MSI Shift Registers

• 74LS299 logic circuit diagram
• The parallel load inputs and flip-flop outputs
  are multiplexed to reduce the total number of
  package pins.
• Separate outputs are provided for flip-flops Q0
  and Q7 to allow easy cascading.
• A separate active LOW Master Reset is used to
  reset the register.

48
Serial Communications

• A practical application of Registers / Shift
  Registers

49
Serial data systems (e.g., TPC)

• Read discussion and study circuits in text.

50
Serial Data Transmission

• Parallel-to-serial conversion for serial
  transmission

Destination module
Source module
serial transmission media
51
Serial data in the phone system (E-1)

• 2.048 Mb/s links between phone switches and
  subscribers
• partitioned into 32 64 Kb/s channels
• Each channel gets a timeslot in a frame where
  it can send 8 bits every 125 ?sec.
• 8000 frames/sec

52
Timeslot details
53
Parallel-to-serial conversion
54
Serial-to-parallel conversion
55
Destination timing
56
Serial communication on ONE wire

• Serial communication requires three signals
  CLOCK, SYNC, and DATA. Yet only one wire is
  used. How?
• One solution Manchester code.

• Or use a phase-locked loop (analog circuit)to
  extract clock from the data

57
Still a couple of problems

• Framing -- SYNC signal
• Solution Use a unique data pattern for SYNC
• PLL clock recovery -- what if too many zeroes are
  transmitted? PLL cant stay in sync.
• Solution Use a code that guarantees a minimum
  number of ones
• Phone system Map 00000000 --gt 00000010 (creating
  slight voice distortion)
• Gigabit Ethernet Uses 8B10B code, solving both
  problems
• Map each byte into 8 bits
• Use only a good subset of 210 code words
• Use another code word for synchronization

58
Assignments

• Completed Part 2 Midterm problems due Wednesday
• Continue working on the MIPS project
• Description available on the course web page
