Title: Chapter 14: Wireless WANs


1
Chapter 14Wireless WANs
  • Business Data Communications, 5e

2
Reasons for Wireless Networks
  • Mobile communication is needed.
  • Communication must take place in a terrain that
    makes wired communication difficult or
    impossible.
  • A communication system must be deployed quickly.
  • Communication facilities must be installed at low
    initial cost.
  • The same information must be broadcast to many
    locations.

3
Problems with Wireless Networks
  • Operates in a less controlled environment, so is
    more susceptible to interference, signal loss,
    noise, and eavesdropping.
  • Generally, wireless facilities have lower data
    rates than guided facilities.
  • Frequencies can be more easily reused with guided
    media than with wireless media.

4
Cellular Wireless Networks
  • One of the most revolutionary developments in
    telecommunications
  • Supports users in locations that are not easily
    served by wired networks
  • Used for mobile telephones, personal
    communications systems, wireless Internet and
    wireless Web applications, and more

5
Cellular Network Organization
  • Uses multiple low-power transmitters (100W)
  • Areas divided into cells, each one served by its
    own antenna.
  • Each cell allocated a band of frequencies, and is
    served by a base station
  • Adjacent cells are assigned different frequencies
    to avoid interference or crosstalk
  • Cells sufficiently distant from each other can
    use the same frequency band

6
Cellular Geometries
7
Frequency Reuse Patterns
8
Increasing Capacity
  • Adding new channels
  • Frequency borrowing Frequencies are taken from
    adjacent cells by congested cells
  • Cell splitting Cells in areas of high usage can
    be split into smaller cells.
  • Cell sectoring Cell divided into wedge-shaped
    sectors. Each sector is assigned a separate
    subset of the cell's channels, and directional
    antennas at the base station are used to focus on
    each sector.
  • Microcells Useful in city streets in congested
    areas, along highways, and inside large public
    buildings

9
Cellular System Overview
10
Mobile to Base Channels
  • Control channels are used to exchange information
    having to do with setting up and maintaining
    calls and with establishing a relationship
    between a mobile unit and the nearest BS
  • Traffic channels carry a voice or data connection
    between users

11
Steps in a Mobile Call
  • Monitor for strongest signal
  • Request for connection
  • Paging
  • Call accepted
  • Ongoing call
  • Handoff

12
Mobile Telephony
  • First Generation
  • analog voice communication using frequency
    modulation.
  • Second Generation
  • digital techniques and time-division multiple
    access (TDMA) or code-division multiple access
    (CDMA)
  • Third Generation
  • evolving from second-generation wireless systems
  • will integrate services into one set of standards.

13
Multiple Access
  • Four ways to divide the spectrum among active
    users
  • frequency-division multiple access (FDMA)
  • time-division multiple access (TDMA)
  • code-division multiple access (CDMA)
  • space-division multiple access (SDMA)
  • FDMA and TDMA discussed in Chapter 17
  • CDMA and SDMA discussed here

14
CDMA
  • Based on direct sequence spread spectrum (DSSS)
  • Provides immunity from various kinds of noise and
    multipath distortion. (The earliest applications
    of spread spectrum were military, where it was
    used for its immunity to jamming.)
  • Can be used for hiding and encrypting signals.
  • Several users can independently use the same
    (higher) bandwidth with very little interference

15
Cellular Multiple Access Schemes
16
Third Generation Systems
  • Intended to provide provide high speed wireless
    communications for multimedia, data, and video
  • Reflects trend toward universal personal
    telecommunications and communications access
  • Personal communications services (PCSs) and
    personal communication networks (PCNs) are
    objectives for 3G wireless.
  • Planned technology is digital using TDMA or CDMA
    to provide efficient spectrum use and high
    capacity

17
Wireless Application Protocol (WAP)
  • Programming model based on the WWW Programming
    Model
  • Wireless Markup Language, adhering to XML
  • Specification of a small browser suitable for a
    mobile, wireless terminal
  • A lightweight communications protocol stack
  • A framework for wireless telephony applications
    (WTAs)

18
WAP Programming Model
19
Wireless Markup Language
  • Does not assume a standard keyboard or a mouse
    designed to work with telephone keypads,
    styluses, and other input devices common to
    mobile, wireless communication
  • Documents are subdivided into small, well-defined
    units of user interaction called cards users
    navigate by moving back and forth between cards.
  • Uses a small set of markup tags appropriate to
    telephony-based systems

20
Microbrowser
  • Based on a user interface model appropriate for
    mobile, wireless devices.
  • Traditional 12-key phone keypad is used to enter
    alphanumeric characters
  • Users navigate among the WML cards using up and
    down scroll keys rather than a mouse.
  • Navigation features familiar from the Web (e.g.,
    Back, Home, and Bookmark) are provided as well.

21
Wireless Telephony ApplicationsA Sample
Configuration
22
Satellite Communications
  • Two or more stations on or near the earth
    communicate via one or more satellites that serve
    as relay stations in space
  • The antenna systems on or near the earth are
    referred to as earth stations
  • Transmission from an earth station to the
    satellite is an uplink, from the satellite to the
    earth station is downlink
  • The transponder in the satellite takes an uplink
    signal and converts it to a downlink signal

23
Geostationary Satellites
  • Circular orbit 35,838 km above the earths
    surface
  • Rotates in the equatorial plane of the earth at
    exactly the same angular speed as the earth
  • Remains above the same spot on the equator as the
    earth rotates

24
Advantages of Geostationary Orbits
  • Satellite is stationary relative to the earth,
    so no frequency changes due to the relative
    motion of the satellite and antennas on earth
    (Doppler effect).
  • Tracking of the satellite by its earth stations
    is simplified.
  • One satellite can communicate with roughly a
    fourth of the earth three satellites separated
    by 120 cover most of the inhabited portions of
    the entire earth excluding only the areas near
    the north and south poles

25
Problems withGeostationary Orbits
  • Signal can weaken after traveling that distance
  • Polar regions and the far northern and southern
    hemispheres are poorly served
  • Even at speed of light, the delay in sending a
    signal 35,838 km each way to the satellite and
    back is substantial

26
LEO and MEO Orbits
  • Alternatives to geostationary orbits
  • LEO Low earth orbiting
  • MEO Medium earth orbiting

27
Satellite Orbits
28
LEO Characteristics
  • Circular or slightly elliptical orbit lt 2000 km
  • Orbit period is in the range of 1.5 to 2 hours
  • Diameter of coverage is about 8000 km
  • Round-trip signal propagation delay is lt 20 ms
  • Maximum time that the satellite is visible from a
    fixed point on earth (above the radio horizon) is
    up to 20 minutes
  • System must be able to cope with large Doppler
    shifts, which change the frequency of the signal
  • Significant atmospheric drag on a LEO satellite
    results in gradual orbital deterioration.

29
LEO Advantages
  • Reduced propagation delay
  • Received LEO signal is much stronger than that of
    GEO signals for the same transmission power
  • LEO coverage can be better localized so that
    spectrum can be better conserved.
  • On the other hand, to provide broad coverage over
    24 hours, many satellites are needed.

30
Types of LEOs
  • Little LEOs Intended to work at communication
    frequencies below1 GHz using no more than 5 MHz
    of bandwidth and supporting data rates up to 10
    kbps
  • Big LEOs Work at frequencies above 1 GHz and
    supporting data rates up to a few megabits per
    second

31
MEO Characteristics
  • Circular orbit at an altitude of 5000 to 12,000
    km
  • Orbit period is about 6 hours
  • Diameter of coverage is 10,000 to 15,000 km
  • Round trip signal propagation delay lt 50 ms
  • Maximum time that the satellite is visible from a
    fixed point on earth (above the radio horizon) is
    a few hours

32
Satellite Network Configurations
33
Satellite Network Applications
  • Television distribution
  • Long-distance telephone transmission
  • Private business networks
