Persistence of Memory How Hard Is It To Erase Data?

1
Persistence of MemoryHow Hard Is It To Erase
Data?

• Dr. Victor Ralevich
• Sheridan College

2
Did I Delete Sensitive Data?

• Last year, MIT graduate students Simson Garfinkel
  and Abhi Shelat revealed findings of a two-year
  project in which they collected and analyzed 158
  hard drives bought from computer stores,
  businesses, and eBay.
• The researchers discovered that most computer
  users did not properly wipe their hard drives
  before selling them. On the 129 drives they found
  thousands of credit card numbers, emails, medical
  information, love letters, and other information.


3
Delete Command (1)

• All operating systems have some form of delete,
  erase, or remove command.
• Most of these commands never even touch the
  actual data that is recorded on the disk drive.
• They typically remove the index entry and
  pointers to the data file so that it appears the
  file is no longer there, and the space allocated
  to that file is made available for future write
  commands.

4
Delete Command (2)

• Commonly available utilities allow any
  knowledgeable technician to move beyond the
  operating system's file indexing scheme and
  examine or rebuild previously deleted
  information.
• Some advanced DELETE programs are available that
  go out of their way to actually overwrite the
  sectors used by a file to store data. These are
  an improvement, but still pose a security threat.


5
Delete Command (3)

• There are usually bits and pieces of data not
  associated or indexed with the actual file that
  can be missed.
• For example, most application programs (and many
  operating systems) will open temporary or
  swap/cache files while working on the data from a
  file.
• When the program is closed or exited, the
  application "deletes" these temp files. So even
  if the original file has been overwritten,
  multiple copies of the raw data may still exist
  in various unused parts of the disk drive.

6
Disk Formatting

• The word format has come to describe several
  different processes in the set-up and
  initialization of a hard disk drive. There are
  physical or low level formats, operating system
  formats, quick formats, partitioning formats,
  etc...
• Depending on the technology of the disk drive and
  the format utility that is used, each of these
  may perform a different function. In many cases,
  previously written data is unaffected.
• The format creates a new blank indexing scheme
  for the operating system, making all the sectors
  available for the writing of new files, making it
  appear that there are no files on the drive.

7
Data Deletion by Overwriting

• Overwriting of the data means replacing
  previously stored data on a drive or disk with a
  predetermined pattern of meaningless information.

• This is an accepted and effective means of
  rendering data unrecoverable but the process must
  be correctly understood and carefully
  implemented.

8
Data Clearing

• Clearing is the removal of sensitive data from
  storage devices in such a way that there is
  assurance that the data may not be reconstructed
  using normal system capabilities, i.e., through
  the keyboard.
• Data reconstruction may include use of data
  recovery utilities and advanced diagnostic
  routines.

9
Disk Cleaning Software (1)Clean Disk Security

• Clean Disk Security
• Completely eliminates the contents of deleted
  files.
• Gutmann disk cleaning method is now available as
  an option.
• Can clean the Window's swap file, and unneeded
  temporary files from the hard disk, such as your
  Internet browser cache, files in system's
  Recycle Bin, and "recent files" list.
• Comes with a direct disk viewer for discovering
  exactly what is on your hard disk.

10
Disk Cleaning Software (2)WhiteCanyon SecureClean
11
Data Recovery and Forensics Tools

• Guidance Software
• EnCase Forensic
• AccessData-
• Forensic Toolkit
• Password Recovery Toolkit
• Registry Viewer
• Distributed Network Attack

12
Data Purging (Sanitization)

• Purging is the removal of sensitive data from a
  system or storage device in such a way that there
  is assurance that the data may not be
  reconstructed through open-ended laboratory
  techniques.
• The United States Department of Defense (DoD) has
  approved both overwriting and degaussing for
  purging data, although the effectiveness of
  overwriting cannot be guaranteed without
  examining each specific situation.

13
Degaussers

• Mag EraSURE ME-P3E NSA Listed Degausser

14
Destruction

• It is good practice to purge media before
  submitting it for destruction. Media may
  generally be destroyed by one of the following
  methods
• Destruction at an approved metal destruction
  facility, i.e., smelting, disintegration, or
  pulverization
• Incineration.
• Application of corrosive chemicals, such as
  acids, to recording surfaces.
• Application of an abrasive substance (emery wheel
  or disk sander) to a magnetic disk or drum
  recording surface. Make certain that the entire
  recording surface is completely removed before
  disposal.

15
Can Overwritten Data be Recovered? (1)

• It is commonly quoted that data can be recovered
  if it has been only overwritten once or twice and
  that it actually takes up to ten overwrites to
  securely protect previous data.
• If a head positioning system is not exact enough,
  new data written to a drive may not be written
  back to the precise location of the original
  data.
• Due to this track misalignment, it is possible to
  identify traces of data from earlier magnetic
  patterns alongside the current track. (At least
  that was the case with high capacity floppy
  diskette drives, which have a rudimentary
  position mechanism.)

16
Can Overwritten Data be Recovered? (2)

• When 1 is written to disk the actual effect is
  closer to obtaining a 0.95 when a zero is
  overwritten with 1, and a 1.05 when 1 is
  overwritten with 1.
• Normal disk circuitry is set up so that both
  these values are read as 1, but using specialised
  circuitry it is possible to work out what
  previous "layers" contained.
• It turns out that each track contains an image of
  everything ever written to it, but that the
  contribution from each "layer" gets progressively
  smaller the further back it was made.
• Intelligence organizations have a lot of
  expertise in recovering these palimpsestuous
  images.

17
Scanning Probe Microscopy (SPM)

• Scanning Tunneling Microscopy
• Atomic Force Microscopy
• Contact AFM
• Non-contact AFM
• Intermittent-contact AFM
• Magnetic Force Microscopy
• Lateral Force Microscopy

18
Other SPM Techniques

• Force Modulation Microscopy
• Phase Detection Microscopy
• Electrostatic Force Microscopy
• Scanning Capacitance Microscopy
• Thermal Scanning Microscopy
• Near-field Scanning Optical Microscopy
• Nanolithography

19
(No Transcript)
20
Atomic Force Microscopy (1)

• The atomic force microscope (AFM), or scanning
  force microscope (SFM) was invented in 1986 by
  Binnig, Quate and Gerber. The AFM utilises a
  sharp probe moving over the surface of a sample
  in a raster scan.
• In the case of the AFM, the probe is a tip on the
  end of a cantilever which bends in response to
  the force between the tip and the sample.
• As the cantilever flexes, the light from the
  laser is reflected onto the split photo-diode. By
  measuring the difference signal (A B), changes
  in the bending of the cantilever can be measured.


21
Atomic Force Microscopy (2)

• Since the cantilever obeys Hooke's Law for small
  displacements, it is possible to estimate the
  interaction force between the tip and the sample.

• The movement of the tip or sample is performed by
  an extremely precise positioning device made from
  piezo-electric ceramics, most often in the form
  of a tube scanner. The scanner is capable of
  sub-angström resolution in x-, y- and
  z-directions. The z-axis is conventionally
  perpendicular to the sample.
• The AFM can be operated in two principal modes
• with feedback control
• without feedback control

22
Atomic Force Microscopy (3)

• The electronic feedback mode of operation is
  known as constant force, and usually enables a
  fairly faithful topographical image to be
  obtained (hence the alternative name, height
  mode).
• If the feedback electronics are switched off,
  then the microscope is said to be operating in
  constant height or deflection mode. This is
  particularly useful for imaging very flat samples
  at high resolution.

23
Atomic Force Microscopy (4) Tip-sample
interaction

• The image contrast can be achieved in many ways.

• The three main classes of interaction are
• contact mode,
• tapping mode, and
• non-contact mode.

24
Sample of Atomic Force Microscopy Image

• Height (contact) image of a 100 µm piece of
  floppy disc (T.J. McMaster et al.)

25
Magnetic Force Microscopy (1)

• Magnetic force microscopy (MFM) images the
  spatial variation of magnetic forces on a sample
  surface.
• For MFM, the tip is coated with a ferromagnetic
  thin film. The system operates in non-contact
  mode, detecting changes in the resonant frequency
  of the cantilever induced by the magnetic field's
  dependence on tip-to-sample separation.
• MFM can be used to image naturally occurring and
  deliberately written domain structures in
  magnetic materials.

26
Magnetic Force Microscopy (2)
27
Magnetic Force Microscopy (3)

• MFM images of overwritten tracks on a textured
  hard disk.
• The topography (left) was imaged using Tapping
  Mode the magnetic force image of the same area
  (right) was captured with Lift Mode (lift height
  35 nm) by mapping shifts in cantilever resonant
  frequency.
• Acquisition time was about five minutes. Track
  width and skew, transition irregularities, and
  the difference between erased and virgin areas
  are visible. 25 µm scan.

28
Magnetic Force Microscopy (4)

• The bright and dark lines indicate transition
  between the longitudinal bits Field of view 100
  µm x 100 µm Magnetic force microscopy image of
  magnetic domains in the servo tracks of a hard
  disk.

29
Magnetic Force Microscopy (5)

• The Magnetic Force Microscope senses the magnetic
  field just above the disk surface.  20 micron
  scan.
• Magnetic force images of a 100 µm piece of floppy
  disc (T.J. McMaster et al.)

30
Magnetic Media Data Erasure (1)

• Concept behind an overwriting scheme is to flip
  each magnetic domain on the disk back and forth
  as much as possible without writing the same
  pattern twice in a row.
• If the data was encoded directly, we could simply
  choose the desired overwrite pattern of ones and
  zeroes and write it repeatedly.
• However, disks generally use some form of
  run-length limited (RLL) encoding, so that the
  adjacent 1s won't be written.

31
Magnetic Media Data Erasure (2)

• To erase magnetic media, we need to overwrite it
  many times with alternating patterns in order to
  expose it to a fast oscillating magnetic field.
• We need to saturate the disk surface to the
  greatest depth possible, but very high frequency
  signals only "scratch the surface" of the
  magnetic medium.
• Disk drive manufacturers, in trying to achieve
  ever-higher densities, use the highest possible
  frequencies.
• The best we can do is to use the lowest frequency
  possible for overwrites, to penetrate as deeply
  as possible into the recording medium.

32
Magnetic Media Data Erasure (3)

• Disk data encoding schemes
• FM (Frequency Modulation) oldest
• MFM (Modified FM)
• RLL (Run Length Limited)
• PRML (Partial Response, Maximum Likelihood)
• EPRMS (Extended PRML)

33
Magnetic Media Data Erasure (4)

• FM, MFM and 2,7 RLL encoding write waveform for
  the byte "10001111".
• RLL improves further on MFM by reducing the
  amount of space required for the same data bits
  to one third that required for regular FM
  encoding.

34
Magnetic Media Data Erasure (5)

• We now have a set of 22 overwrite patterns which
  should erase everything, regardless of the raw
  encoding. The basic disk eraser can be improved
  slightly by adding random passes before and after
  the erase process, and by performing the
  deterministic passes in random order to make it
  more difficult to guess which of the known data
  passes were made at which point.
• Secure Deletion of Data from Magnetic and
  Solid-State Memory Peter Gutmann, Department of
  Computer Science, University of Auckland, 1996

35
Gutmanns Algorithm

• Peter Gutmann suggested that we use the sequence
  of 35 consecutive writes with predefined
  patterns.
• The MFM-specific patterns are repeated twice
  because MFM drives have the lowest density and
  are thus particularly easy to examine.
• The deterministic patterns between the random
  writes are permuted before the write is
  performed, to make it more difficult for an
  opponent to use knowledge of the erasure data
  written to attempt to recover overwritten data.

36
Hard Disc Organization

• TrackA concentric set of magnetic bits on the
  disk is called a track. Each track is divided
  into 512 bytes (usually) sectors.
• SectorA part of each track defined with magnetic
  marking and an ID number. Sectors have a sector
  header and an error correction code (ECC).
• CylinderA group of tracks with the same radius
  is called a cylinder (red tracks on the picture
  belong to one cylinder).
• Data addressingThere are two methods for data
  addressing CHS (cylinder-head-sector) and LBA
  (logical block address).

37
Other Problems with Magnetic Media (1)Defective
Sector Handling

• There are several techniques which are used to
  mask the defects in the defect list.
• Alternate tracks, moves data from tracks with
  defects to known good tracks.
• Alternate sectors, allocates alternate sectors at
  the end of the track to minimise seeks caused by
  defective sectors.
• Inline sector sparing, allocates a spare sector
  at the end of each track, but resequences the
  sector ID's to skip the defective sector and
  include the spare sector at the end of the track.


38
Other Problems with Magnetic Media (2)Ageing

• Long-term ageing can also have an effect on the
  erasability of magnetic media.
• Some types of magnetic tape become increasingly
  difficult to erase after being stored at an
  elevated temperature.
• The erasability of the data depends on the amount
  of time it has been stored on the media, not on
  the age of the media itself.

39
Other Problems with Magnetic Media (3)Temperature

• The dependence of media coercivity on temperature
  can affect overwrite capability.
• This is important in hard disk drives, where the
  temperature varies depending on how long the unit
  has been used and, in the case of drives with
  power-saving features enabled, how recently and
  frequently it has been used.
• The overwrite performance depends also on
  temperature-dependent changes in the read/write
  head.

40
Other Problems with Magnetic Media
(4)Error-correction Schemes

• Newer storage devices are, through the use of
  various error-correction schemes, able to recover
  from having a remarkable amount of damage
  inflicted on them.
• Error-correction codes (ECC's) are capable of
  correcting multiple error bursts.

41
Recovering Data stored in ROM

• Volatile" semiconductor memory does not entirely
  lose its contents when power is removed.
• Both static (SRAM) and dynamic (DRAM) memory
  retains some information on the data stored in it
  while power was still applied.
• Older SRAM chips could often "remember" the
  previously held state for several days.

42
Erasing Data stored in ROM

• Heat Both DRAM and SRAM will lose their
  content much faster on 1400C than on room
  temperature.
• Constantly flip the bits in memory ensure that
  a memory cell never holds a charge long enough
  for it to be "remembered".
• It is possible to do this for small amounts of
  very sensitive data such as encryption keys.

43
Conclusion (1)

• Data overwritten once or twice may be recovered
  by subtracting what is expected to be read from a
  storage location from what is actually read.
• Data which is overwritten an arbitrarily large
  number of times can still be recovered provided
  that the new data isn't written to the same
  location as the original data (for magnetic
  media), or that the recovery attempt is carried
  out fairly soon after the new data was written
  (for RAM).
• For this reason it is effectively impossible to
  sanitise storage locations by simple overwriting
  them, no matter how many overwrite passes are
  made or what data patterns are written.

44
Conclusion (2)

• Data recovery can be made significantly more
  difficult, if not prohibitively expensive.
• The best way to make sure that you got rid of
  data is to destroy the disk.
• Encrypt data whenever possible.
• For sensitive information prevent paging of
  memory to the hard drive.

45
Links

• Peter Gutmann Secure Deletion of Data from
  Magnetic and Solid-State Memory
• www.cs.auckland.ac.nz/pgut001/pubs/secure_del
  .html
• Clean Disk Security - www.theabsolute.net/sware/cl
  ndisk.html
• WipeDrive, Secure Clean www.whitecanyon.com/
• Data Forensics Software (EnCase)
  www.guidancesoftware.com/
• AccessData Forensic Toolkit www.accessdata.com/
• A Practical Guide to Scanning Probe Microscopy
  mechmat.caltech.edu/kaushik/park/contents.htm
