Artificial Neural Networks

• PART A
• Introduction
• An overview of the biological neuron
• The synthetic neuron
• Structure and operation of an ANN
• Problem solving by an ANN
• Learning in ANNs
• ANN models
• Applications

• PART B
• Developing neural network applications
• Design of the network
• Training issues
• A comparison of ANN and ES
• Hybrid ANN systems
• Case Studies

3
Developing neural network applications

• Neural Network Implementations
• Three possible practical implementations of ANNs
  are
• A software simulation program running on a
  digital computer
• A hardware emulator connected to a host computer
  - called a neurocomputer
• True electronic circuits

4
Software Simulations of ANN

• Currently the cheapest and simplest
  implementation method for ANNs - at least for
  general purpose use.
• Simulates parallel processing on a conventional
  sequential digital computer
• Replicates temporal behaviour of the network by
  updating the activation level and output of each
  node for successive time steps
• These steps are represented by iterations or
  loops
• Within each loop, the updates for all nodes in a
  layer are performed.

5
Software simulations of ANN (contd)

• In multilayer ANNs, processing for a layer is
  completed and its output used to calculate states
  of the nodes in the following layer
• Typical additional features of ANN simulators
• Configuring the net according to a chosen
  architecture and node operational characteristic
• Implementation of training phase using a chosen
  training algorithm
• Tools for visualising and analysing behaviour of
  nets
• ANN simulators are written in hi-level languages
  such as C, C and Java.

6
Advantages and possible problems with software
simulators

• Advantages and possible problems with software
  simulators
• Main attraction of ANN simulators is the
  relatively low cost and wide availability of
  ready-made commercial packages
• They are also compact, flexible and highly
  portable.
• Writing your own simulator requires programming
  skills and would be time consuming (except that
  you don't have to now!)
• Training of ANNs using software simulators can be
  slow for larger networks (greater than a few
  hundred)

7
Commercially available neural net packages

• Prewritten shells with convenient user interfaces
• Cost a few hundred to tens of thousands of
  dollars
• Allow users to specify the ANN design and
  training parameters
• Usually provide graphic interfaces to enable
  monitoring of the nets training and operation
• Likely to provide interfacing with other software
  systems such as spreadsheets and databases.

8
Neurocomputers

• Dedicated special-purpose digital computer (aka
  accelerator boards)
• Optimised to perform operations common in neural
  network simulation
• Acts as a coprocessor to a host computer and is
  controlled by a program running on the host.
• Can be tens to thousands of times faster than
  simulators
• Systems are available with approx. 1000 million
  IPS connection updates per second for networks
  with 8,192 neurons e.g ACC Neural Network
  Processor

9
Neurocomputers

• Genobyte's CAM-Brain Machine was developed
  between 1997 and 2000

10
True Networks in Hardware

• Closer to biological neural networks than
  simulations
• Consist of synthetic neurons actually fabricated
  on silicon chips
• Commercially available hardwired ANNs are limited
  to a few thousand neurons per chip1.
• Chips connected in parallel to achieve larger
  networks.
• Problems interconnection and interference,
  fixed-valued weights - work progressing on
  modifiable synapses.
• 1 Figures more than five years old.

11
Neural Network Development Methodology

• Aims to add structure and organisation to ANN
  applications development for reducing cost,
  increasing accuracy, consistency, user confidence
  and friendliness
• Split development into the following phases
• The Concept Phase
• The Design Phase
• The Implementation Phase
• The Maintenance Phase

12
Neural Network Development Methodology - the
Concept Phase

• Involves
• Validating the proposed application
• Selecting an appropriate neural paradigm.
• Application validation
• Problem characteristics suitable for neural
  network application are
• Data intensive
• Multiple interacting parameters
• Incomplete, erroneous, noisy data
• Solution function unknown or expensive
• Requires flexibility, generalisation,
  fault-tolerance, speed

13
ANN Development Methodology - the Concept Phase
(contd)

• Common examples of applications with above
  attributes are
• pattern recognition (eg, printed or handwritten
  character, consumer behaviour, risk patterns),
• forecasting (eg, stock market), signal (audio,
  video, ultrasound) processing
• Problems not suitable for ANN-based solutions
  include
• A mathematically accurate and precise solution is
  available
• Solution involving deduction and step-wise logic
  appropriate
• Applications involving explaination or reporting
• One application area that is unsuitable for ANNs
  is resource management eg, inventory, accounts,
  sales data analysis

14
Selecting an ANN paradigm

• Decision based on comparison of application
  requirements to capabilities of different
  paradigms
• eg, the multilayer perceptron is well known
  for its pattern recognition capabilities,
• Kohonen net more suited for applications
  involving data clustering
• Choice of paradigm also influenced by the
  training method that can be employed
• eg. supervised training must have adequate
  number of input-correct output pairs available
  and training may take a relatively long time
• Technical and economic feasibility assessments
  should be carried out to complete the concept
  phase

15
The Design Phase

• The design phase specifies initial values and
  conditions at the node, network and training
  levels
• Decisions to be made at the node level include
• Types of input binary (0,1), bipolar (-1,1),
  trivalent (-1, 0, 1), discrete,
  continuous-valued
• Transfer function - step or threshold,
  hyperbolic tangent, sigmoid, consider possible
  use of lookup tables for speeding up calculations
• Decisions to be made at the network architecture
  level
• The number and size of layers and their
  connectivity
• (fully interconnected, or sparsely
  interconnected, feedforward or recurrent, other?)

16
The Design Phase (contd)

• 'Size' of a layer is the number of nodes in the
  layer
• For the input layer, size is determined by number
  of data sources (input vector components) and
  possibly the mathematical transformations done
• The number of nodes in the output layer is
  determined by the number of classes or decision
  values to be output
• Finding optimal size of the hidden layer needs
  some experimentation
• Too few nodes will produce inadequate mapping,
  while too many may result in inadequate
  generalisation

17
The Design Phase (contd)

• Connectivity
• Connectivity determines the flow of signals
  between neurons in the same or different layers
• Some ANN models, such as the multilayer
  perceptron, have only interlayer connections -
  there is no intralayer connection
• The Hopfield net is an example of a model with
  intralayer connections

18
The Design Phase (contd)

• Feedback
• There may be no feedback of output values, eg,
  the multilayer perceptron
• or
• There may be feedback as in a recurrent network
  eg, the Hopfield net
• Other design questions include
• Setting of parameters for the learning phase
  eg, stopping criterion, learning rate.
• Possible addition of noise to speed up training.

19
The Implementation phase

• Typical steps
• Gathering the training set
• Selecting the development environment
• Implementing the neural network
• Testing and debugging the network
• Gathering the training set
• Aims to get right type of data in adequate amount
  and in the right format

20
Gathering training data (contd)

• How much data to gather?
• Increasing data amount increases training time
  but may help earlier convergence
• Quality more important than quantity
• Collection of data
• Potential sources - historical records,
  instrument readings, simulation results
• Preparation of data
• Involves preprocessing including scaling,
  normalisation, binarisation, mapping to
  logarithmic scale, etc.

21
Gathering training data (contd)

• Type of data to collect should be representative
  of given problem including routine, unusual and
  boundary-condition cases
• Mix of good as well as imperfect data but not
  ambiguous or too erroneous.
• Amount of data to gather
• Increasing data amount increases training time
  but may help earlier convergence
• Quality more important than quantity

22
Gathering training data (contd)

• Collection of data
• Potential sources - historical records,
  instrument readings, simulation results
• Preparation of data
• Involves preprocessing including normalisation
  and possible binarisation

23
Selecting the development environment

• Hardware and software aspects
• Hardware requirements based on
• speed of operation
• memory and storage capacity
• software availability
• cost
• compatibility
• The most popular platforms are workstations and
  high-end PC's (with accelerator board option)

24
Selecting the development environment

• Two options in choosing software
• Custom-coded simulators which requires more
  expertise on part of the user but provides
  maximum flexibility
• Commercial development packages which are
  usually easy to use because of a more
  sophisticated interface

25
Selecting the development environment (contd)

• Selection of hardware and software environment
  usually based on following considerations
• ANN paradigm to be implemented
• Speed in training and recall
• Transportability
• Vendor support
• Extensibility
• Price

26
Implementing the neural network

• Common steps involved are
• Selection of appropriate neural paradigm
• Setting network size
• Deciding on the learning algorithm
• Creation of screen displays
• Determining the halting criteria
• Collecting data for training and testing
• Data preparation including preprocessing
• Organising data into training and test sets

27
Implementation - Training

• Training the net, which consists of
• Loading the training set
• Initialisation of network weights usually to
  small random values
• Starting the training process
• Monitoring the training process until training is
  completed
• Saving of weight values in a file for use during
  operation mode

28
Implementation Training (contd)

• Possible problems arising during training
• Failure to converge to a set of optimal weight
  values
• Further weight adjustments fail to reduce output
  error, stuck in a local minimum
• Remedied by resetting the learning parameters and
  reinitialising the weights
• Overtraining
• Net fails to generalise, i.e., fails to classify
  less than perfect patterns
• Mix of good and imperfect patterns for training
  helps

29
Implementation Training (contd)

• Training results may be affected by the method of
  presenting data set to the network.
• Adjustments may be made by varying the layer
  sizes and fine-tuning the learning parameters.
• To ensure optimal results, several variations of
  a neural network may be trained and each tested
  for accuracy

30
Implementation - Testing and Debugging

• Testing can be done by
• 1. Observing operational behaviour of the net.
• 2. Analysing actual weights
• 3. Study of network behaviour under specific
  conditions
• Observing operational behaviour
• Network treated as a black box and its response
  to a series of test cases is evaluated
• Test data
• Should contain training cases as well as new
  cases
• Routine, unusual as well as boundary condition
  cases should be tried

31
Implementation - Testing and Debugging (contd)

• Testing by weight analysis
• Weights entering and exiting nodes analysed for
  relatively small and large values
• In case of significant errors detected in
  testing, debugging would involve examining
• the training cases for representativeness,
  accuracy and adequacy of number
• learning algorithm parameters such as the rate at
  which weights are adjusted
• neural network architecture, node
  characteristics, and connectivity
• training set-network interface, user-network
  interface

32
The Maintenance Phase

• Consists of
• placing the neural network in an operational
  environment with possible integration
• periodic performance evaluation, and maintenance
• Although often designed as stand-alone systems,
  some neural network systems are integrated with
  other information systems using
• Loose-coupling preprocessor, postprocessor,
  distributed component
• Tight-coupling or full integration as embedded
  component

33
The Maintenance Phase

• Possible ANN operational environments

34
System evaluation

• Continual evaluation is necessary to
• ensure satisfactory performance in solving
  dynamic problems
• check for damaged or retrained networks.
• Evaluation can be carried out by reusing original
  test procedures with current data.

35
ANN Maintenance

• Involves modification necessitated by
• Decreasing accuracy
• Enhancements
• System modification falls into two categories
  involving either data or software.
• Data modification steps
• Training data is modified or replaced
• Network retrained and re-evaluated.

36
ANN Maintenance (contd)

• Software changes include changes in
• Interfaces
• cooperating programs
• the structure of the network.
• If the network is changed, part of the design and
  most of the implementation phase may have to be
  repeated.
• Backup copies should be used for maintenance and
  research.

37
A comparison of ANN and ES

• Similarities between ES and ANN
• Both aim to create intelligent computer systems
  by mimicking human intelligence, although at
  different levels
• Design process of neither ES nor ANN is automatic
• Knowledge extraction in ES is a time and labour
  intensive process
• ANNs are capable of learning but selection and
  preprocessing of data have to be done carefully.

38
A comparison of ANN and ES (contd)

• Differences between ANN and ES
• Differ in aspects of design, operation and use
• Logic vs. brain
• ES simulate the human reasoning process based on
  formal logic
• ANNs are based on modelling the brain, both in
  structure and operation
• Sequential vs. parallel
• The nature of processing in ES is sequential
• ANNs are inherently parallel

39
A comparison of ANN and ES (contd)

• External and static vs. internal and dynamic
• Learning is performed external to the ES
• ANN itself is responsible for its knowledge
  acquisition during the training phase.
• Learning is always off-line in ES - knowledge
  remains static during operation
• Learning in ANNs, although mostly off-line, can
  be on-line
• Deductive vs. inductive inferencing
• Knowledge in an ES always used in a deductive
  reasoning process
• An ANN constructs its knowledge base inductively
  from examples, and uses it to produce decision
  through generalisation

40
A comparison of ANN and ES (contd)

• Knowledge representation explicit vs. implicit
• ES store knowledge in explicit form -possible to
  inspect and modify individual rules
• ANNs knowledge stored implicitly in the
  interconnection weight values
• Design issues simple vs. complex
• Technical side of ES development relatively
  simple without difficult design choices.
• ANN design process often one of trial and error

41
A comparison of ANN and ES (contd)

• User interface white box vs. black box
• ES have explanation capability
• Difficulty in interpreting an ANN's
  knowledge-base effectively makes it a black box
  to the user
• State of maturity and recognition
  well-established vs. early
• ES already well established as a methodology in
  commercial applications
• ANN recognition and development tools at a
  relatively early stage.

42
Hybrid systems

• Neuro-symbolic computing utilises the
  complementary nature of computing in neural
  networks (numerical) and expert systems
  (symbolic).
• Neuro-fuzzy systems combine neural networks with
  fuzzy logic
• ANNs can also be combined with genetic algorithm
  methodology
• Hybrid ES-ANN systems
• The strengths of the ES can be utilised to
  overcome the weaknesses of an ANN based system
  and vice versa.
• For example, ANNs extraction of knowledge from
  data
• ESs explanation capability

43
Hybrid ES-ANN systems

• Rule extraction by inference justification in an
  ANN
• MACIE, an ANN based decision support system
  described in (Gallant 1993)
• Extracts a single rule that justifies an
  inference in an ANN
• Inference in an ANN is represented by output of a
  single node
• This output is based upon incomplete input values
  fed from a number of nodes as shown in the
  diagram below.

44
Hybrid ES-ANN systems (contd)

• A node ui is defined to be a contributing node to
  node uj if wij ui ? 0.

45
Hybrid ES-ANN systems (contd)

• In this example, the contributing variables are
  u2, u3, u5, u6 .
• The rule produced in this example is
• IF u6 Unknown
• AND u2 TRUE
• AND u3 FALSE
• AND u5 TRUE
• THEN conclude u7 TRUE.

46
Hybrid ES-ANN systems (contd)

• One approach to hybrid systems divides a problem
  into tasks suitable for either ES and ANN
• These tasks are then performed by the appropriate
  methodology
• One example of such a system (Caudill 1991) is an
  intelligent system for delivering packages
• ES performs the task of producing the best
  loading strategy for packages into trucks
• ANN works out best route for delivering the
  packages efficiently.

47
Hybrid ES-ANN systems (contd)

• Hybrid ES-ANN systems with ANNs embedded within
  expert systems
• ANN used to determine which rule to fire, given
  the current state of facts.
• Another approach to hybrid ES-ANN uses an ANN as
  a preprocessor
• One or more ANNs produce classifications.
• Numerical outputs produced by ANN are interpreted
  symbolically by an ES as facts
• ES applies the facts for deductive reasoning

48
Case Study

• Case Application of ANNs in bankruptcy
  prediction (Coleman et al, AI Review, Summer
  1991, in Zahedi 1993)
• Predicts banks that were certain to fail within
  a year
• Predicts certainty given to bank examiners
  dealing with the bank in question.
• ANN has 11 inputs, each of which is a ratio
  developed by Peat Marwick.
• Developed by NeuralWares Application Development
  Services and Support Group (ADSS)
• Software used - the NeuralWorks Professional
  neural network development system.
• Uses the standard backpropagation (multiplayer
  perceptron) network.

49
Case Study (contd)

• ANN has 11 inputs, each a ratio developed by Peat
  Marwick.
• Inputs connected to a single hidden layer, which
  in turn is connected to a single node in the
  output layer.
• Network outputs a single value denoting whether
  the bank would or would not fail within that
  calendar year
• Employed the hyperbolic-tangent transfer function
  and a proprietary error function created by the
  ADSS staff.
• Trained on a set of 1,000 examples, 900 of which
  were viable banks and 100 of which were banks
  that had actually gone bankrupt
• Training consisted of about 50,000 iterations of
  the training set.
• Predicted 50 of banks that are viable, and 99
  of banks that actually failed.

50
REFERENCES

• AI Expert (special issue on ANN), June 1990.
• BYTE (special issue on ANN), Aug. 1989.
• Caudill,M., "The View from Now", AI Expert, June
  1992, pp.27-31.
• Dhar, V., Stein, R., Seven Methods for
  Transforming Corporate Data into Business
  Intelligence., Prentice Hall 1997
• Kirrmann,H., "Neural Computing The new gold rush
  in informatics", IEEE Micro June 1989 pp. 7-9
• Lippman, R.P., "An Introduction to Computing with
  Neural Nets", IEEE ASSP Magazine, April 1987
  pp.4-21.
• Lisboa, P., (Ed.) Neural Networks Current
  Applications, Chapman Hall, 1992.
• Negnevitsky, M. Artificial Intelligence A Guide
  to Intelligent Systems, Addison-Wesley 2005.

51
REFERENCES (contd)

• Bailey, D., Thompson, D., How to Develop Neural
  Network Applications, AI Expert, June 1990, pp.
  38-47.
• Caudill Butler, Naturally Intelligent Systems,
  MIT Press,1989, pp 227-240.
• Caudill, M., Expert networks, BYTE pp.109-116,
  October 1991.
• Dhar, V., Stein, R., Seven Methods for
  Transforming Corporate Data into Business
  Intelligence., Prentice Hall 1997.
• Gallant, S., Neural Network Learning and Expert
  Systems, MIT Press 1993.
• Medsker,L., Hybrid Intelligent Systems, Kluwer
  Academic Press, Boston 1995
• Zahedi, F., Intelligent Systems for Business,
  Wadsworth Publishing, , Belmont, California, 1993.
