Jerry Held

1
(No Transcript)
2
Brajesh GoyalPrincipal Product Manager, Grid
Computing
Ravi Animi Technical Marketing Engineer Network
Appliance, Inc.
3
Oracle Database 10g Grid Computing Focus on
Storage
4
Grid Vision

• Computing as a utility
• A network of clients and service providers
• Client-side Simplicity
• Request computation or information and receive it
• Server-side Sophistication
• Availability, load balancing, utilization
• Information sharing, data management
• Virtualization
• Nothing more virtual than a utility
• Massive potential

5
Oracle 10g Grid Computing Platform

• Virtualization and provisioning now
• Storage
• CPU
• Data
• Standardize on low-cost modular hardware
  components
• Scale out incrementally

6
Align Storage with Business

• Islands of storage
• My storage is underutilized and growing 50 a
  year

7
Align Storage with Business

• Islands of data
• My storage is 30 utilized and growing 50 a
  year
• Disk farms of industry standard disks
• Consolidate intoSAN or NAS
• Manually provisionas needed

8
Storage Grid

• Oracle Automatic Storage Manager
• Provisions storage capacity automatically to
  Oracle 10g as needed
• Stripes and Balances I/O
• Mirrors Immune to disk failure
• Oracle Automatic Backup and Recovery
• Single backup areafor all Grid databases
• Archive to tape

9
Align Processing with the Business

• Islands of computation
• 15 utilization of CPU is exceptional

10
Align Processing with the Business

• Islands of computation
• 15 utilization of CPU is exceptional

• Pick a standard, buy the standard
• Farms of industry standard blades
• Lowest cost, highest performance
• Interconnected
• Not Self-healing, Disposable
• Linux and bladesresonate

11
CPU Provisioning on Demand
All Data
21
12
Data Provisioning

• Access to data when and where you need it
• Consolidate, federate, and share
• Provide a single global view of data in the Grid
• Optimizes information access regardless of
  physical location of data
• Move data to process locally
• Leave data in place and process remotely
• Enables virtualization of data in Grids
• Host an application anywhere regardless of
  physical data location
• Integrates information off the Grid

13
Big Tablespaces

• Oracle Database10g supports 128PB data files
• Fewer files to manage and move when transporting
  tablespaces
• Simplifies storage management
• Ultra Large Database Support
• Large files increase maximum database size to 8
  exabytes
• Store the vast quantities of data to feed the
  computing power of the grid

14
Transportable Tablespaces

• Unplug and plug database data files
• Move and share data without unload and reload
• Plug/unplug performance independent of tablespace
  size
• Mount read-only tablespaces on multiple databases
• Cross-platform support
• Rename Tablespaces
• Storage vendors file system, volume manager
  snapshot technology complementary to this

24
15
Oracle Streams

• Share information throughout the Grid
• Move data when and where needed
• Share messages
• Notify or invoke user procedures on events
• Subscribe to messages and database changes
• Interoperate with other vendors
• Stream database and incrementally maintain it
  with a single call

MQ
16
Grid Migration with no Downtime

• With one command tell Oracle Streams to
• Copy your tablespaces
• Apply incremental changes made since the start of
  the copy
• Wait until all changes applied, then re-point
  your application
• Easy to get to the Grid
• Incrementally scale out

17
Shared Storage Technologies

• File-based protocols
• NAS NFS, CIFS
• Block-based protocols
• SAN/iSAN Fibre Channel, iSCSI
• High-speed transport
• 10 Gbps Ethernet
• Infiniband 4x (10 Gbps)

18
Infiniband

• Simplicity and performance
• Low latency high-bandwidth
• Less cabling
• Easy provisioning

19
Over to NetApp

• How Network Appliances makes Grid Computing
  possible with its shared storage technologies?

20
(No Transcript)
21
Ravi Animi Technical Marketing Engineer
Network Appliance, Inc.
22
NetApp and Oracle Power the Grid
23
Why Grid Computing? Spend Less Store More

• On-Demand provisioning
• Lower Costs through efficient use of computing
  resources
• Fault Tolerant and Scaleable
• Redundant shared resources makes Grid computing
  inherently more resilient
• Better Performance
• Through use of application clustering and high
  performance interconnects

24
NetApps Solutions for the Grid

• Next Generation Protocols
• Data Consolidation
• Data Protection
• Data Provisioning
• High Availability Solutions

25
High Performance Storage for the Grid
NetApp brings RDMA over Infiniband to Oracle 10g
Grid Computing Platform
Oracle RAC DB Node1 on DAFS
Oracle RAC DB Node2 on DAFS
Linux
Linux
10 Gbps Infiniband Storage Interconnect
10 Gbps Infiniband Storage Interconnect
Infiniband Switch
NetApp Storage Appliance DAFS over Infiniband

• NetApp brings the promise of RDMA over Infiniband
  to Oracle database access.
• RDMA based protocols such as DAFS or NFSv4 over a
  high bandwidth, low latency protocol such as
  Infiniband

26
Oracle 10g and RDMA
DAFS File Server

10G
SGA Buffers
Buffers
DAFS Engine
Oracle Disk Manager
Oracle File I/O API
DAFS API
DAFS user-level I/O library
DAPL Provider
DAT library vector
DAT
Direct Access Provider Libraries
DAPL Provider
DAPL Provider
. . .
HCA Driver
HCA Driver
HCA Driver
Transport-specificDevice Drivers
RDMA NIC (RNIC)
InfiniBand Adapter
InfiniBand Adapter
Control
Direct Data
27
Data Consolidation on a Grid
Multiple database servers that are diskless or
with disk connected to shared NetApp networked
storage in heterogeneous grid environment

• Unified Storage (NAS or SAN)
• Protocol independent database access over a
  blocks (iSCSI or FCP) or a files (NFS, DAFS)
  based protocol
• Easy to provision, easy to manage
• Boot grid clients
• Provision new CPUs on-demand using bootp and tftp
• Enables database resonance in 10g Grid database

28
Oracle 10g and Unified Storage
ODM, OCFS, RAW I/O, ASM
BLOCKS RAW Devices or File System
Fibre Channel
WAFL File System
Fibre Channel
iSCSI HBA or Software Initiator
iSCSI Software Target Ethernet
InfiniBand Adapter
InfiniBand Adapter
ODM, DAFS/DAT/DAPL
NFS TCP/IP Ethernet
NFS TCP/IP Ethernet
NFS, General File System
29
Data Protection for the Grid
GigE Ethernet / FCP Switch
GigE / FCP
GigE / FCP
Storage Interconnect
SnapVault
NDMP TapeBackupClient
Up to 256 Volume-level Snapshots
NetApp NAS/SANStorage Appliance
TapeArchive
NearStoreR100/R150 Disk-Based Storage

• Removes complexity from the storage management
  side of data provisioning for data protection in
  a grid computing environment.

30
Data Provisioning for the Grid Snapshots
GigE / FCP Switch
GigE / FCP
Storage Interconnect
SnapMirror/ SnapVault
InternetIP WAN
Remote Storage Appliance powering remote Grid
NetApp NAS/SANStorage Appliance

• NetApps Snapshot and SnapRestore makes it a
  snap to implement plug and play transportable
  tablespaces on multiple databases in a
  heterogeneous grid environment.

31
Data Provisioning for the Grid Cloning
10g RAC powered Database Grid
10g RAC powered Database Grid
Primary Database or Applications Instance
Cloned Database or Applications Instance
Blade Server node interconnect or other Grid
Interconnect

• NetApps Snapshots power rapid Database and
  E-Business Suite11i Apps Instance Cloning through
  shared APPL_TOP

32
High Availability for the Grid RAC

• Supports RAC DB on NFS, DAFS or iSCSI, FCP over
  raw or a CFS on multiple OS platforms with Oracle
  and Third Party Cluster Managers
• Supports Oracle 10gs platform independent
  Portable Cluster Layer (PCL)

33
Disaster Recovery for the Grid

• Robust datacenter site disaster recovery
  solutions
• Enterprise strength disk mirroring over IP WANs

34
Why Oracle and NetApp?

• Lowest TCO Upto 75 lower TCO than the
  competition
• Simplest to manage True Storage Appliance
• Proven Mission Critical Unified Storage Platform
  for the Enterprise
• 100s of joint customers on Oracle-NetApp platform
• Over 1 PB running within Oracle Corporation!
• Commitment to Oracle 10g Grid Initiatives
• Source Input Study 2001, IDC Study, 2003

35
Why Grid Computing? Market Opportunity
Storage Market 12.2 Billion by 2006
12,211M
12,000
NAS
10,000
NAS
6,169M
8,000
NAS
NAS
6,000
NAS
4,000
SAN
SAN
SAN
SAN
SAN
2,000
0
2002
2003
2004
2005
2006
Source IDC, May 2002
36
Questions?

• NetApp Presence at Oracle World San Francisco
• Demos at Booth 1702
• Oracle 10g Demo
• Unified Storage Demo
• Oracle 10g with DAFS (RDMA) protocol over
  Infiniband
• Key NetApp-Oracle Presentations
• Oracle-NetApp Grid Presentation (this one)
• 10g with DAFS over Infiniband Presentation
• Oracle Grid Computing 5 i i
• Oracle 10g Grid Database Demo Booth
• Featuring data and CPU provisioning (resonance)
• Key Oracle Grid Presentations
• Larrys 10g Launch Keynote
• Benny Souder, VP, Oracle Grid Computing

37
