Hardware Compilation Pie In The Sky or The Next Big Thing?

1
Hardware CompilationPie In The Sky or The Next
Big Thing?

• Mike Roberts
• mroberts_at_altera.com
• mbr_at_compsoc.net
• Oxford University Computer Society - 2nd February
  2000

2
Agenda

• Semiconductors Overview
• Digital Design Overview
• Hardware Compilation
• Conclusions

3
Semiconductors Overview
4
In the Beginning...

• Originally all digital designs implemented using
  individual transistors
• Then using small Integrated Circuits (ICs) with 3
  or 4 simple gates per chip
• Still hundreds of chips required for each design!

5
Time Passed...

• The 1980s - Application Specific Integrated
  Circuits (ASICs)
• Either Gate Arrays or Full Custom
• Produced much better implementations, but slow
  and expensive to develop
• 1990s - cell based ASICs and a compromise of the
  two technologies
• But also...

6
A New Dawn!

• Programmable Logic - an alternative to custom
  chips
• Chips themselves are standard, but their
  behaviour is defined by the designer by selecting
  a configuration for the device.
• Known as PLDs or FPGAs

7
ASICs vs. PLDs

• Leading edge PLDs cannot be used for designs as
  large or fast as leading edge ASIC designs.
• But are still adequate for many tasks!
• Faster time-to-market
• Cheaper for small to medium volumes.
• Possibilities of in-field reconfiguration

8
PLD Density Roadmap
10,000
Beyond APEX
1,000
APEX
FLEX 10K
Usable Gates (K)
100
10
FLEX 8000 FLEX 6000
Classic MAX
1
'90
'91
'92
'93
'94
'95
'96
'97
'98
'99
'00
'01
'02
'03
'04
9
Intellectual Property in PLDs
R5000-Class RISC Processor
MPEG-2 Encoder
8-Port, 622-MHz ATM Switch
PCI Interface
40
43
45
46
40,000 Gates
400,000 Gates
2 Million Gates
4 Million Gates
10
Top 10 ASIC/PLD Suppliers 1998
1,655
Lucent IBM NEC LSI Fujitsu Altera Xilinx TI Toshib
a VLSI
1,645
1,638
1,526
1,094
654 (836.6 for
1999)
629
590
546
513
Sales (M)
Ranking Includes Both Merchant Market
Intracompany Sales Source Dataquest/Altera,
preliminary April 1999
11
Digital Design Overview
12
Aims of Digital Design

• To create digital hardware that is
• As fast as possible
• Using as little silicon as possible
• Correct
• Under a set of environmental constraints
• Interfaces with rest of system
• power consumption
• etc.
• Made possible using CAD (or Digitial Automation)
  Tools.

13
Design Entry

• All designs used to be described using schematics
  of gates.
• Schematics still in use today (using higher level
  blocks or primitives) - give a graphical way
  of describing the structure of a design.
• Hardware Description Languages invented to allow
  textual equivalent of schematics.
• More importantly, they can describe the behaviour
  of the design.

14
Simulation

• Simulation is critical in checking the
  correctness of a design, especially when
  designing for a non-programmable technology.
• Modern-day simulators can take anything from a
  high-level behavioural design to low-level
  netlist, and apply simulation vectors to allow
  the engineer to check the design is acting as
  they intended.

15
Synthesis

• Logic Synthesis is the task of taking a
  behavioural design at the Logical level (commonly
  known as the Register Transfer Level or RTL), and
  producing a low-level structural view of the
  design (a netlist).
• Synthesis Tools use various optimisation
  heuristics to try and produce the smallest and
  fastest logical structure.
• This is an intractable (or class NP) problem.

16
Technology Mapping

• Once the design has gone through logic synthesis,
  it must then be described in terms of the target
  technology.
• E.g. for Altera FLEX devices, the design will use
  Look-up Tables for Combinatorial Logic, EABs for
  RAM, etc.
• Again we try and optimise for most efficient use
  of hardware in terms of space and speed, and this
  is another intractable problem.

17
Place Route

• Finally the design must be given geometry
• Each small part of the design must be placed on
  the chip and must be routed in an optimal way to
  everything it is connected to in the design.
• We can no-longer make the design any smaller,
  however we need to make the design as fast as
  possible, under the constraint that there are not
  infinite routing resources.
• Another intractable problem!

18
Summary of Design Flow
Write RTL hardware design
Write fully behavioural test-bench
Final Design
19
Limits of Synthesis

• Synthesis Tools are the state of the art in
  Digital Design, but are not perfect.
• RTL still a comparatively low abstraction level.
• Very long design Cycle due to complexity of
  design that must be given.
• System Design Models (e.g. Hardware / Software
  Co-design systems) cannot be directly synthesised.

20
Hardware Compilation
21
What is Hardware Compilation?

• Hardware Compilation is bringing software
  compiler concepts to the design flow of digital
  hardware.

22
The Benefits of HC

• Raises the Design Entry abstraction level
• Shortens the Design Cycle due to lower complexity
  of original design.
• Allows the System Model to become an
  implementation in itself.
• Allows software engineers to design hardware!

23
The Challenges

• What language to use?
• Use HDLs like software languages.
• Use C/C and extend where necessary.
• Is using a software language a feasible entry
  point for hardware design?
• How do we interface with existing hardware
  designs?
• Behavioural and Architectural Synthesis
  incorporate more NP problems

24
Language choice using HDLs

• HDLs were originally invented as simulation
  languages.
• Their software features are limited to telling
  the simulator what to do.
• HDLs could be extended to be provide better
  implementable high-level features.
• Could lead to a very confused language.
• But hardware engineers may be able to use such a
  language better than they could a software based
  language.

25
Language choice using C

• C is quite a small language, and so in theory
  could be used fairly simply.
• Known by a very large number of hardware and
  software engineers.
• Contains higher-level constructs than allowed in
  RTL HDLs
• But has no concept of parallelism, communication
  or other hardware features.
• Incorporation of extra features could get messy!

26
Language choice using C / Java

• C based Object Oriented languages are used by a
  large subset of C-speaking engineers.
• Both have concepts of parallelism ranging from
  implied (distinct classes in a system) to
  explicit (as in Java)
• Class Hierarchies could be built up expressing
  the features of hardware.
• But both languages are huge - how do you define
  what is and isnt supported?
• Expressing Instruction Level Parallelism is hard.

27
Capturing the behavioural model

• The first stages in compiling hardware would be
  similar to those of compiling software and would
  result in an Abstract Syntax Tree representing
  the original source code.
• We then need to generate a behavioural model from
  this code tree. One such model is a sequencing
  graph, which is itself a hierarchy of data-flow
  graphs.

28
High-level Synthesis

• Once we have formed a model of our design we can
  apply various behavioural optimisations to it,
  similar to those in software.
• We then perform Architectural Synthesis to form
  an RTL description of our design.
• AS is performed with knowledge of the resources
  available to us, and consists of 2 tasks
• Scheduling
• Allocation

29
Difficulties

• There are known algorithms for AS when you have a
  fixed number of specific operation resources
  (adders, multipliers, registers), but the task is
  harder for generic hardware.
• What about pipelining?
• How do we express the interactive nature of our
  environment, such as bus protocols?
• For co-design tools, how do we decide what should
  be implemented in hardware, and what in software?

30
HC Activity in Industry

• ESL - HandelC http//www.embeddedsol.com/
• C Level Design http//www.cleveldesign.com/
• System C http//www.systemc.org/
• Cynapps http//www.cynapps.com/
• Frontier Design http//www.frontierd.com/
• Superlog http//www.co-design.com/

31
Conclusions (1)

• The Holy Grail of taking any program in C and
  producing a hardware / software implementation
  that is significantly faster than its equivalent
  software-only implementation looks highly
  unlikely.
• However, hardware compilation could work if the
  program is constrained to a specific style, or
  a suitable new language.
• But new languages are often never accepted!

32
Conclusions (2)

• Engineering never stops where it is.
• A higher level entry route is required for
  engineers because of the ever progressing size of
  hardware, and the increasing importance of
  time-to-market
• There is now significant interest in industry in
  a hardware-compilation approach.
• Programmable Logic is the most suitable target
  for hardware compilation, and so looks set to
  keep on making inroads into the ASIC market.

33
And finally

• If Hardware Compilation becomes reality then a
  whole new world opens up for Programmable Logic -
  Reconfigurable Computing.
• Tools would need to be extended, and new
  paradigms of programming may be required!
• But that remains in the sky for now!
