IP and ICMP

1
IP and ICMP

• Internet Protocol
• Internet Control Message Protocol

2
About Internet Protocol

• Internet Protocol Network Layer, end-to-end
  communications
• IP version 4 (IPv4) - widely implemented
• Internet Protocol version 6 (IPv6) not widely
  used yet
• Requirements for building an IP datagram packet
  to transmit on the wire
• IP addresses of the source and (final)
  destination
• Hardware address of the source and
• Destination hardware address (if on the local
  network)
• Hardware address of the next-hop router (if not
  local)
• IP host
• Can use a manually entered destination IP address
  or the DNS to obtain a destinations IP address

3
If Remote, Which Router?

• Types of route table entries
• Host route entry
• Network route entry
• Receiving gateway typically does one of the
  following
• Forwards packet
• Sends an ICMP reply
• Sends an ICMP reply indicating that it is unclear
  where to send the packet

4
Lifetime of an IP Datagram

• IP packets
• Have a pre-defined lifetime indicated in each
  packets Time to Live (TTL) field
• TTL can range from 0 to 255
• TTL supposedly represents seconds, but router
  hops is more accurate
• TTL is intended to avoid infinite loops in
  circular routes
• 64
• Recommended starting TTL value
• 128
• Default TTL in Windows 2000, Windows 2003, and
  Windows XP

5
Fragmentation and Reassembly

• IP fragmentation
• Enables a larger packet to be automatically
  fragmented by a router
• Once fragmented
• No reassembly occurs until fragments arrive at
  destination
• All fragments are given the same TTL value

6
Service Delivery Options

• Precedence
• Used by routers to determine what packet to send

• Type of Service
• Used to select routing path when multiple paths
  exist
• Routing protocols
• OSPF and Border Gateway Protocol (BGP)
• RFC 2474, RFC 2475, and RFC 3168
• Offer a new use of the TOS field bits
• Suggest that TOS and Precedence field bytes be
  replaced by a Differentiated Services Code Point
  (DSCP) field
• Diffserv
• Uses DSCP value to enable routers to offer
  varying levels of service to traffic based on
  marker placed in the DSCP field
• Example Voice over IP (VoIP) needs to be
  forwarded by routers more quickly than ordinary
  data packets

7
IP Header Fields And Functions

• Version Field
• First field in IP header
• Header Length Field
• Denotes the length of the IP header only
• Type of Service Field
• Has two components precedence and Type of
  Service
• Total Length Field
• Defines length of the IP header and any valid data

8
IP Header Fields And Functions
9
IP Header Fields And Functions (continued)

• Identification Field
• Each packet is given a unique ID value when sent
• Flags Field
• Three bits long
• Typically, fragmentation is allowed
• Fragment Offset Field
• Shows where to place packets data when
  fragments are reassembled

10
IP Header Fields And Functions (continued)

• Time to Live (TTL) Field
• Denotes the remaining lifetime of the packet
• Protocol Field
• Indicates what is coming up next
• Header Checksum Field
• Provides error detection on the contents of the
  IP header only
• Source Address Field
• The IP address of the IP host that sent the packet

11
IP Header Fields And Functions (continued)

• Destination Address Field
• Can include a unicast, multicast, or broadcast
  address
• Final destination of the packet
• Options Fields
• Exist primarily to provide additional IP routing
  controls
• Can be useful when testing or debugging code or
  specific connections

12
Internet Control Message Protocol

• ICMP
• Provides information about network connectivity
  and routing behavior
• Provides a way to return information to senders
• Messages are nothing more than specially
  formatted IP datagrams
• RFC 792
• Provides basic specification for all ICMP
  messages
• Provides mechanism for gateways (routers) or
  destination hosts to communicate with source
  hosts
• Takes the form of specially formatted IP
  datagrams
• Reports errors about processing of non-ICMP IP
  datagrams

13
ICMPs Role in IP Networks

• ICMPs job is to provide information about
• IP routing behavior
• Reachability
• Routes between specific pairs of IP hosts
• Delivery errors

14
(No Transcript)
15
Testing And Troubleshooting Connectivity
Testing with Ping

• PING and TRACEROUTE
• Rely on ICMP to perform connectivity tests and
  path discovery
• PING
• Actually a form of ICMP Echo communication
• ICMP Echo Request
• Connectionless process with no guarantee of
  deliveryMost PING utilities
• Send series of several Echo Requests to the
  target in order to obtain average response time
• PING utility
• Sends series of four ICMP Echo Requests with a
  one-second ICMP Echo Reply Timeout value
• Supports IP addresses and names (e.g. www.uwp.edu)

16
(No Transcript)
17
Connectivity Testing with PING (contd)

• Parameters available with the PING utility
• -l size
• -f
• -i TTL
• -v TOS,
• -w timeout

18
Path Discovery with TRACEROUTE

• TRACEROUTE utility
• Uses route tracing to identify a path from sender
  to target host
• Available parameters
• -d
• -h
• -w

19
(No Transcript)
20
Path Discovery with PATHPING

• PATHPING utility
• Command-line utility
• Uses ICMP Echo packets to test router and link
  latency, as well as packet loss
• PMTU Discovery
• Enables source to learn the currently supported
  MTU across an entire path
• MTU maximum transmission unit the biggest
  chunk of data that can be carried across a
  network
• Use ping f l MTU host-address
• -f (dont fragment)
• Replace MTU with a number of a MTU (e.g. 1500)
• Ex ping f l 1500 131.210.1.15

21
Routing Sequences for ICMP

• ICMP
• Can provide some routing information to hosts
• Used by routers to provide a default gateway
  setting to a host
• Routers
• Can send ICMP messages
• Routing Discovery
• IP hosts
• Typically learn about routes through manual
  configuration of
• Default gateway parameter and redirection
  messages
• Send ICMP Router Solicitations and routers reply
  with ICMP Router Advertisements
• By default
• ICMP Router Solicitation packet is sent to the
  all-routers IP multicast address 224.0.0.2

22
(No Transcript)
23
Security Issues For ICMP

• ICMP
• Can be used as an information-gathering tool
• IP address scanning process
• One method of obtaining a list of the active
  hosts
• IP host probe
• Performed by sending a PING packet to each host
  within a range and noting the responses

24
ICMP Packet Fields and Functions

• Value 1 in IP header Protocol field
• Denotes that an ICMP header follows the IP header
• ICMP header portions
• Constant portion
• Variable portion

25
(No Transcript)
26
Constant ICMP Fields

• ICMP packets contain three required fields after
  the IP header
• Type
• Code
• Checksum

27
The Variable ICMP Structures and Functions

• ICMP Type 0
• Used for Echo Reply packets
• ICMP Type 8
• Used for Echo Request packets
• RFC 792
• Identifier and Sequence fields are used to aid in
  matching Echo messages with Echo Replies

28
(No Transcript)
29
(No Transcript)
30
Type 3 Destination Unreachable Packets

• Network troubleshooters
• Often closely track ICMP Destination Unreachable
  packets
• Host that sends Destination Unreachable packet
• Must return IP header and eight bytes of original
  datagram that triggered this response
• Total of 16 (0 through 15) possible codes
• Currently assigned to ICMP Destination
  Unreachable type number

31
(No Transcript)
32
(No Transcript)
33
Type 4 Source Quench

• Router or host
• May use Source Quench to indicate that it is
  becoming congested or overloaded
• By default
• Most current routers do not issue Source Quench
  messages

34
(No Transcript)
35
Type 5 Redirect

• Routers
• Send ICMP Redirect messages to hosts to indicate
  that a preferable route exists
• ICMP Redirect packet
• Four-byte field for the preferred gateways
  address
• Ideally
• Clients should update routing tables to indicate
  optimal path

36
Types 9 and 10 Router Advertisement and Router
Solicitation

• ICMP Router Advertisement packets include the
  following fields
• of Addresses
• Address Size
• Lifetime
• Router Address 1
• Precedence Level 1
• Router Address 2 and Precedence Level 2

37
Type 11 Time Exceeded

• Routers or hosts
• Can send these ICMP packets
• Codes that can be used
• Code 0 and Code 1
