Hot Wire Anemometer

1
Hot Wire AnemometerIntroduction to Heat
Transfer
2
Four Central Ideas of Engineering

• The Dual Variables of Effort and Flow
• how power flows between interacting objects,
  regardless of their domain (e.g. Electrical,
  Mechanical, Thermal, Biological, etc).
• State
• how systems remember the past, and which results
  from the time integration and storage of energy.
• Transduction
• the bidirectional transformation of effort and
  flow from one domain to another.
• Feedback
• used in almost all engineered devices to bring
  about desired behavior despite undesired
  disturbances.

3
What is heat?

• First Law of Thermodynamics
• Change in energy heat put in system work
  done on system.
• Attributed primarily to Joule in
  mid-1800s-overturned caloric theory
• Heat transfer energy in transit due to a
  temperature difference.
• So what is energy?

4
Conduction

• Transfer of energy from more energetic to less
  energetic particles of a substance due to
  interactions between particles.
• Gas T molecular motion, direct particle
  collisions equilibrate energy.
• Liquid same as gas, but molecular interactions
  are stronger and more frequent.
• Solid lattice vibrations.

5
Temperature distribution in a solid
heat flow
Inside of house is warm
Outside is cold
298 K
273 K
Temperature distribution is linear
k thermal conductivity (Watts/ m K) T
temperature (K) q heat flux vector (Watts/m2)
L distance (m)
6
Convection
Tair
y
Cool air flow
q
Tplate
T
Hot Plate
h convection coefficient Watts/m2
(function of everything)
7
Combined modes
Thot
T2
T1
Tcold
T
8
Radiation

• Energy emitted by matter that is at a finite
  temperature.
• Emission attributed to changes in electron
  configurations.
• Energy transported by electromagnetic waves.
• No medium needed.

9
Conservation of Energy
Energy in
Change in Energy stored
Energy out
Energy generated
10
We know how to compute the energy terms
Total energy out due to surface heat transfer.
Total energy generated in an electrical resistor.
Change in energy stored in the solid m is mass,
C is specific heat.
11
Model of cooling hot coffee in air
Control volume
12
Model Cooling hot coffee in air
13
Model Heating the stove coils
hA
14
Simulation

• What determines final T?
• What is the role of thermal mass?
• What determines the rate of T increase?

15
Hot wire/hot film anemometer
Hot film for liquids
Hot wire for gases
16
Why do we want the probe so small?

• Resolution in space
• Resolution in time (high frequency)
• Dont want to disturb what we are measuring.

17
Uses are found anywhere fluids flow

• Aerodynamics lift, drag
• Combustion IC, gas turbine engines
• Meteorology
• Fires and fire safety
• Ocean currents
• How bugs fly and how fish swim
• Turbulence (Richard Feynman, "the most important
  unsolved problem of classical physics." )
• Ordinary measurement tools, i.e. HVAC probes

18
The stove
Heat flow out
Power in
hA
T (K)
19
Results from changes..
T (K)
20
Constant power device
P
A
Response time dictated by the response of the
system.
Constant power mode needs to wait for steady
state to correlate T to h
21
Constant T device
P
Power is function of time
A
Constant T mode always at steady state -
instantly correlate P to h
22
Proportional Control
kp
Power input
dT/dt
T
hA(T-Tair)
h
T-Tair
Physical system
23
Proportional control
Kp1
Kp0.1
Kp0.01
Why cant p-gain be set to be very large?
24
Time delay can cause instability
25
What is happening?

• Cant make P-gain too high, time delay can cause
  instability.
• If P-gain is too low there is high offset.

26
Our lab

• Tungsten filament has resistance that changes
  with temperature if we measure the resistance we
  measure the T.
• Build a circuit to measure the filament
  resistance.
• Create a controller to provide a known amount of
  power (Voltage control does not work since R
  varies)
• Create a proportional controller to keep R
  constant.

27
Circuit to measure R and P
28
How do we get the actual power?
P
x
-1/R1
Circuit
simulink
29
Virtual op-amp
30
Power control
P
x
i lamp
-1/R1
Circuit
