End to End Scientific Data Management Framework for Petascale Science

1
End to End Scientific Data Management Framework
for Petascale Science

• ESMF
• 9/23/2008
• Scott Klasky, Jay Lofstead, Mladen Vouk
• ORNL, Georgia Tech, NCSU

2
Outline

• EFFIS (Klasky)
• ADIOS.
• ADIOS Overview (Klasky)
• ADIOS Advanced Topics (Lofstead)
• Workflow. (Vouk)
• Dashboard. (Vouk)
• Conclusions. (Klasky)

3
Supercomputers creating a hurricane of data.

• Some simulations are starting to produce
  100TB/day on the 270 TF Cray XT at ORNL.
• Old way of run now, and look at results later has
  problems.
• Data will be eventually archived on tape.
• Lots of files from 1 run with multiple users
  gives us a data management headache.
• Need to keep track of data over multiple system.
• Extracting information from files needs to be
  easy.
• Example min/max of 100GB arrays needs to be
  almost instant.

4
Vision

• Problem Managing the data from a petascale
  simulation, and debugging the simulation, and
  extracting the science involves.
• Tracking the codes Simulation, Analysis.
• Tracking the input files/parameters
• Tracking the output files, from the simulation
  and then analysis programs.
• Tracking the machines and environment the codes
  ran on.
• Gluing everything together.
• Visualizing the results, and analyzing the
  results without requiring users to know all of
  the file names.
• Fast I/O which can be easily tracked.

5
Vision

• Workflow Automation to automate all of the
  mundane tasks.
• Analyzing the results, without knowing all of the
  file locations/names.
• Moving data from the simulation side to remote
  locations without knowledge of filename(s)/locatio
  ns.
• Monitoring results in real-time,
• Requirements.
• Want technologies integrated together easy to
  talk to one another.
• Want to make the system scalable in the I/O
  workflow, analysis, visualization, data
  management.

6
Outline

• EFFIS
• ADIOS.
• ADIOS Overview
• BP format, and compatibility with hdf5/netcdf.
• Workflow.
• Dashboard.
• Conclusions.

7
ADIOS Motivation

• Those fine fort. files!
• Multiple HPC architectures
• BlueGene, Cray, IB-based clusters
• Multiple Parallel Filesystems
• Lustre, PVFS2, GPFS, Panasas, PNFS
• Many different APIs
• MPI-IO, POSIX, HDF5, netCDF
• GTC (fusion) has changed IO routines 8 times so
  far based on performance when moving to different
  platforms.
• Different IO patterns
• Restarts, analysis, diagnostics
• Different combinations provide different levels
  of IO performance
• Compensate for inefficiencies in the current IO
  infrastructures to improve overall performance

8
ADIOS Overview

• Allows plug-ins for different I/O
  implementations.
• Abstracts the API from the method used for I/O.
• Simple API, almost as easy as F90 write
  statement.
• Best practices/optimize IO routines for all
  supported transports for free
• Componentization.
• Thin API
• XML file
• data groupings with annotation
• IO method selection
• buffer sizes
• Common tools
• Buffering
• Scheduling
• Pluggable IO routines

9
ADIOS Overview

• ADIOS is an IO componentization, which allows us
  to
• Abstract the API from the IO implementation.
• Switch from synchronous to asynchronous IO at
  runtime.
• Change from real-time visualization to fast IO at
  runtime.
• Combines.
• Fast I/O routines.
• Easy to use.
• Scalable architecture(100s cores) millions of
  procs.
• QoS.
• Metadata rich output.
• Visualization applied during simulations.
• Analysis, compression techniques applied during
  simulations.
• Provenance tracking.

10
ADIOS Philosophy (End User)

• Simple API very similar to standard Fortran or C
  POSIX IO calls.
• As close to identical as possible for C and
  Fortran API
• open, read/write, close is the core
• set_path, end_iteration, begin/end_computation,
  init/finalize are the auxiliaries
• No changes in the API for different transport
  methods.
• Metadata and configuration defined in an external
  XML file parsed once on startup.
• Describe the various IO grouping including
  attributes and hierarchical path structures for
  elements as an adios-group
• Define the transport method used for each
  adios-group and give parameters for
  communication/writing/reading
• Change on a per element basis what is written
• Change on a per adios-group basis how the IO is
  handled

11
Design Goals

• ADIOS Fortran and C based API almost as simple as
  standard POSIX IO
• External configuration to describe metadata and
  control IO settings
• Take advantage of existing IO techniques (no new
  native IO methods)
• Fast, simple-to-write, efficient IO for multiple
  platforms without changing the source code

12
Architecture

• Data groupings
• logical groups of related items written at the
  same time.
• Not necessarily one group per writing event
• IO Methods
• Choose what works best for each grouping
• Vetted, improved, and/or written by experts for
  each
• POSIX (Wei-keng Liao, Northwestern)
• MPI-IO (Steve Hodson, ORNL)
• MPI-IO Collective (Wei-keng Liao, Northwestern)
• NULL (Jay Lofstead, GT)
• Ga Tech DataTap Asynchronous (HasanAbbasi, GT)
• phdf5
• others.. (pnetcdf on the way).

13
Related Work

• Specialty APIs
• HDF-5 complex API
• Parallel netCDF no structure
• File system aware middleware
• MPI ADIO layer File system connection, complex
  API
• Parallel File systems
• Lustre Metadata server issues
• PVFS2 client complexity
• LWFS client complexity
• GPFS, pNFS, Panasas may have other issues

14
Supported Features

• Platforms tested
• Cray CNL (ORNL Jaguar)
• Cray Catamount (SNL Redstorm)
• Linux Infiniband/Gigabit (ORNL Ewok)
• BlueGene P now being tested/debugged.
• Looking for future OSX support.
• Native IO Methods
• MPI-IO independent, MPI-IO collective, POSIX,
  NULL, Ga Tech DataTap asynchronous, Rutgers DART
  asynchronous, Posix-NxM, phdf5, pnetcdf,
  kepler-db

15
Initial ADIOS performance.

• MPI-IO method.
• GTC and GTS codes have achieved over 20 GB/sec on
  Cray XT at ORNL.
• 30GB diagnostic files every 3 minutes, 1.2 TB
  restart files every 30 minutes, 300MB other
  diagnostic files every 3 minutes.
• DART lt2 overhead forwriting 2 TB/hour withXGC
  code.
• DataTap vs. Posix
• 1 file per process (Posix).
• 5 secs for GTCcomputation.
• 25 seconds for Posix IO
• 4 seconds with DataTap

16
Codes Performance

• June 7, 2008 24 hour GTC run on Jaguar at ORNL
• 93 of machine (28,672 cores)
• MPI-OpenMP mixed model on quad-core nodes (7168
  MPI procs)
• three interruptions total (simple node failure)
  with 2 10 hour runs
• Wrote 65 TB of data at gt20 GB/sec (25 TB for post
  analysis)
• IO overhead 3 of wall clock time.
• Mixed IO methods of synchronous MPI-IO and POSIX
  IO configured in the XML file

17
Chimera IO Performance (Supernova code)
2x scaling

• Plot minimum value from 5 runs with 9
  restarts/run
• Error bars show maximum time for the method.

18
Chimera Benchmark Results

• Why ADIOS is better than pHDF5?
• ADIOS_MPI_IO vs. pHDF5 w/ MPI Indep. IO driver


Use 512 cores, 5 restart dumps. Conversion time
on 1 processor for the 2048 core job 3.6s
(read) 5.6s (write) 6.9 (other) 18.8
s Number above are sum among all PEs (parallelism
not shown)
19
ADIOS Advanced Topics

• J. Lofstead

20
ADIOS API Fortan Example

• XML configuration file
• ltadios-configgt
• ltadios-group nameoutput coordination-communicat
  orgroup_commgt
• ltvar namegroup_comm typeinteger/gt
• ltvar nameg_NX typeinteger /gt
• ltvar nameg_NY typeinteger/gt
• ltvar namelo_x typeinteger/gt
• ltvar namelo_y typeinteger/gt
• ltvar namel_NX typeinteger/gt
• ltvar namel_NY typeinteger/gt
• ltglobal-bounds dimensionsg_NX,g_NY
  offsetslo_x,lo_ygt
• ltvar nametemperature dimensionsl_NX,l_NY/gt
• lt/global-boundsgt
• ltattribute nameunits path/temperature
  valueK/gt
• lt/adios-groupgt
• lt!-- declare additional adios-groups --gt
• ltmethod methodMPI groupoutput/gt
• lt!-- add more methods --gt

Fortan90 code ! initialize the system loading
the configuration file adios_init (config.xml,
err) ! open a write path for that type adios_open
(h1, output, restart.n1, w,
err) adios_group_size (h1, size, total_size,
comm, err) ! write the data items adios_write
(h1, g_NX, 1000, err) adios_write (h1, g_NY,
800, err) adios_write (h1, lo_x, x_offset,
err) adios_write (h1, lo_y, y_offset,
err) adios_write (h1, l_NX, x_size,
err) adios_write (h1, l_NY, y_size,
err) adios_write (h1, temperature, u, err) !
commit the writes for asynchronous
transmission adios_close (h1, err) ! do more
work ! shutdown the system at the end of my
run adios_finalize (mype, err)
21
ADIOS API C Example

• C code
• // parse the XML file and determine buffer sizes
• adios_init (config.xml)
• // open and write the retrieved type
• adios_open (h1, restart, restart.n1, w)
• adios_group_size (h1, size, total_size, comm)
• adios_write (h1, n, n) // int n
• adios_write (h1, mi, mi) // int mi
• adios_write (h1, zion, zion) // float zion
  10203040
• // write more variables
• ...
• // commit the writes for synchronous transmission
  or
• // generally initiate the write for
  asynchronous transmission
• adios_close (h1)
• // do more work
• ...
• // shutdown the system at the end of my run
• adios_finalize (mype)

XML configuration file ltadios-config
host-languageCgt ltadios-group
namerestartgt ltvar namen path/
typeinteger /gt ltvar namemi path/param
typeinteger/gt lt!-- declare more data
elements --gt ltvar namezion typereal
dimensionsn,4,2,mi/gt ltattribute nameunits
path/param valuem/s/gt lt/adios-groupgt lt!--
declare additional adios-groups --gt ltmethod
methodMPI grouprestart/gt ltmethod
priority2 methodDATATAP iterations1
typediagnosisgtsrvewok001.ccs.ornl.govlt/methodgt
lt!-- add more methods --gt ltbuffer size-MB100
allocate-timenow/gt lt/adios-configgt
22
BP File Format

• netCDF and HDF-5 are excellent, mature file
  formats
• APIs can have trouble scaling to petascale and
  beyond
• metadata operations bottleneck at MDS
• coordination among all processes takes time
• MPI Collective writes/reads add additional
  coordination
• Non-stripe-sized writes impact performance
• Read/write mode is slower than write only
• Replicate some metadata for resilience

23
BP File Format

• Solution Use an intermediate API and format
• ADIOS API and BP format
• API natively writes BP format (netCDF coming)
• converters to netCDF and HDF-5 available
• Convert files at speeds limited by the
  performance of disk and the netCDF/HDF-5 API

24
BP File Format

• File organization
• Move the header to the end
• last 28 bytes are 3 index locations and version
  endian-ness flag
• Each process writes completely independently
• First part of file a series of Process Groups,
  each the output from a single process for a
  single IO grouping
• Coordinate only twice
• Once at start for writing location
• Once at end for metadata collection to process 0
  and writing by process 0 only
• Replicate some metadata
• Each Process Group is fully self-contained with
  all related meta-data
• Indexes contain copies of highlights of the
  metadata

25
BP File Format

• Index Structure
• Process Group Index
• ADIOS group, process ID, timestep, offset in file
• Vars Index
• Set of unique vars listing group, name, path,
  datatype, characteristics (see next slide)
• Uniqueness based on group name, var name, var
  path
• Attributes Index
• Set of unique attributes listing group, name,
  path, datatype, characteristics (see next slide)
• Uniqueness based on group name, attribute name,
  attribute path

26
BP File Format

• Data Characteristics
• Idea collect information about the var/attribute
  for quickly characterizing the data
• Examples
• Offset in file
• Value (only for small data)
• Minimum
• Maximum
• Instance array dimensions
• Structure setup for adding more without changing
  file format

27
BP File Format

• Write operation (n processes)
• Gather data sizes to process 0
• Process 0 generates offset to write for each
  process
• Scatter offsets back to processes
• Everybody write data independently
• Gather the local index from each process to
  process 0
• Merge all indices together
• Process 0 write indices at the end of the file

28
BP File Format

• Compromises using BP Format
• Each Process Group can have different variables
  defined and written (also an advantage)

29
BP File Format

• Advantages using BP Format
• Each process writes independently
• Limited coordination
• File organization more natural for striping
• Rich index contents
• Append operations do not require moving data
• Indices read by process 0 on start and used as
  base index
• First new Process Group overwrites old indicies
• Index corruption does not potentially destroy
  entire file
• Process Group corruption isolated by still
  getting access to the rest of the process groups
  (via indices)

30
Outline

• EFFIS
• ADIOS.
• ADIOS Overview
• BP format, and compatibility with hdf5/netcdf.
• Workflow.
• Dashboard.
• Conclusions.

31
Scientific Workflow

• Capture how a scientist works with data and
  analytical tools
• data access, transformation, analysis,
  visualization
• possible worldview dataflow-oriented (cf.
  signal-processing)?
• Scientific workflows start where script-based
  data-management solutions leave off.
• Scientific workflow (wf) benefits (v.s.
  script-based approaches)
• wf automation
• wf component reuse, sharing, adaptation,
  archiving
• wf design, documentation
• built-in (model) concurrency
• (task-, pipeline-parallelism)
• built-in provenance support
• distributed parallel exec
• Grid cluster support
• wf fault-tolerance, reliability
• Other

Why a W/F System?
Higher-level language vs. assembly-language
nature of scripts
32
Two typical types of Workflows for SC

• Real-time Monitoring (Server Side Workflows)
• Job submission.
• File movement.
• Launch Analysis Services.
• Launch Visualization Services.
• Launch Automatic Archiving.
• Post Processing (Desktop Workflows).
• Read in Files from different locations.
• File movement.
• Launch Analysis Services.
• Launch Visualization Services.
• Connect to Databases.
• Obviously there are other types of workflows.
• Parameter study/sensitivity analysis workflows.

33
Workflow Provenance

• Process provenance.
• the steps performed in the workflow, the progress
  through the workflow control flow, etc.
• Data provenance.
• history and lineage of each data item associated
  with the actual simulation (inputs, outputs,
  intermediate states, etc.)
• Workflow provenance.
• history of the workflow evolution and structure
• System provenance.
• All external (environment) information relevant
  to a complete run.
• Compilation history of the codes.
• Information about the libraries.
• Source of the codes.
• Run-time environment settings.
• Machine information
• etc.

• Dashboard displays provenance information for
• Data lineage.
• Source Code for a simulation, analysis.
• Performance Data from PAPI.
• Workflow Provenance to determine if something
  went wrong with the workflow.
• Other

34
Modular Framework
Storage
Supercomputers Analytics Nodes
Kepler
Data Store
Rec API
Disp API
Dash
Management API
Orchestration
Meta-Data about Processes, Data, Workflows, Syst
em, Apps Environment
ADIOS is being modified to send the IO (
coupling) metadata to Kepler (e.g., file path,
variables, control commands, )
35
So what are the requirements?

• Reliability (autonomics)
• Usability (Must be EASY to use and functional)
• Good user support, and long-term DOE support. ?
• Universality and Reuse - The workflow should work
  for all of my workflows. (NOT just for the
  Petascale computers multiple platforms)
• Integration - Must be easy to incorporate my own
  services into the workflow.
• Customization and adaptability - Must be
  customizable by the users.
• Users need to easily change the workflow to work
  with the way users work.
• Other - You tell us!

36
Kepler Scientific Workflow System
http//www.kepler-project.org

• Kepler is a cross-project collaboration
• Latest release available from the website
• Builds upon the open-source Ptolemy II framework
• Vergil is the GUI, but Kepler also runs in
  non-GUI and batch modes.

37
Vergil is the GUI for Kepler
but Kepler can also run in batch mode as a
command-line engine.
Data Search
Actor Search

• Actor ontology and semantic search for actors
• Search -gt Drag and drop -gt Link via ports
• Metadata-based search for datasets

38
Actor-Oriented Modeling

• Actors
• single component or task
• well-defined interface (signature)
• generally a passive entity given input data,
  produces output data

• Ports
• each actor has a set of input and output ports
• denote the actors signature
• produce/consume data (a.k.a. tokens)
• parameters are special static ports

39
Actor-Oriented Modeling

• Dataflow Connections
• actor communication channels
• Directed edges
• connect output ports with input ports

40
Actor-Oriented Modeling

• Sub-workflows / Composite Actors
• composite actors wrap sub-workflows
• like actors, have signatures (i/o ports of
  sub-workflow)
• hierarchical workflows (arbitrary nesting levels)

41
Actor-Oriented Modeling

• Directors
• define the execution semantics of workflow graphs
• executes workflow graph (some schedule)
• sub-workflows may have different directors
• enables reusability

42
Some Directors

• Directed Acyclic Graph (DAG)
• Common among Grid workflows no loops, each actor
  fires at most once (no streaming / pipeline
  parallelism)
• Example DAGMan
• Synchronous Dataflow (SDF)
• Connections have queues for sending/receiving
  fixed numbers of tokens at each firing. Schedule
  is statically predetermined. SDF models are
  highly analyzable and used often in SWFs.
• Process Networks (PN)
• Generalize SDF. Actors execute as a separate
  thread/process, with queues of unbounded size.
  Related to Kahn/MacQueen semantics. The workflow
  is executed in parallel and pipeline parallel
  fashion.
• Continuous Time (CT)
• Connections represent the value of a continuous
  time signal at some point in time ... Often used
  to model physical processes.
• Discrete Event (DE)
• Actors communicate through a queue of events in
  time. Used for instantaneous reactions in
  physical systems.
• Dynamic Dataflow (DDF)
• Connections have queues for sending/receiving
  arbitrary numbers of tokens at each firing.
  Schedule is dynamically calculated. DDF models
  enable branching and looping/ (conditionals). The
  workflow is sequential.

43
Types

• tokens, ports have types
• available types
• int, float (double precision), complex, string,
  boolean, object
• array, record, matrix (2D only)
• type resolution at workflow start-up actors can
  support different types
• e.g. Count, Sleep, Delay work on any type
• a type lattice is pre-defined to determine
  relationships among types (casting)

string and int tokens are added as strings
int tokens are added as ints
44
Dashboard
45
Machine monitoring.

• Allow for secure logins with OTP.
• Allow for job submission.
• Allow for killing jobs.
• Search old jobs.
• See collaborators jobs.

46
Analysis Collaborative Features

• Base analysis which will workon both the
  portable dashboard and the mother-dashboard
  and will feature.
• Calculator for simple math, done inpython.
• Hooks into R for pre-set functions.
• Ability to save the analysis into anew function,
  available to otherusers.
• Calculator will create new movies that are
  viewable on the dashboard.
• First version will work with xy (t) plots.
• Second version will work with x,y,z (t)plots.
• Advanced analysis will contain.
• Parallel backend to VisIT server, VisTrails,
  Parallel R, and custom mpi/c/f90 code.
• We will allow users to place executable code into
  the dashboard. (Still working this out). How to
  execute, .

47
Conclusions

• ADIOS is an IO componentization.
• ADIOS is being integrated integrated into Kepler.
• Achieved over 20 GB/sec for several codes on
  Jaguar.
• Used daily by CPES researchers.
• Can change IO implementations at runtime.
• Metadata is contained in XML file.
• Kepler is used daily for
• Monitoring CPES simulations on Jaguar/Franklin/ewo
  k.
• Runs with 24 hour jobs, on large number of
  processors.
• Dashboard uses enterprise (LAMP) technology.
• Linux, Apache, MySQL, PHP

48
EFFIS

• From SDM center
• Workflow engine Kepler
• Provenance support
• Wide-area data movement
• From universities
• Code coupling (Rutgers)
• Visualization (Rutgers)
• Newly developed technologies
• Adaptable I/O (ADIOS)(with Georgia Tech)
• Dashboard (with SDM center)

Foundation Technologies
Enabling Technologies
Approach place highly annotated, fast,
easy-to-use I/O methods in the code, which can be
monitored and controlled, have a workflow engine
record all of the information, visualize this on
a dashboard, move desired data to users site,
and have everything reported to a database.
