Urodynamic Study in Lower Urinary Tract Dysfunction

1
Urodynamic Study in Lower Urinary Tract
Dysfunction

• Hann-Chorng Kuo
• Department of Urology
• Buddhist Tzu Chi General Hospital

2
Lower Urinary Tract Symptoms

• Storage symptoms
• Frequency, Urgency, Nocturia
• Incontinence
• Suprapubic fullness and pain
• Empty symptoms
• Hesitancy, Intermittency, Small caliber,
• Dysuria, Residual urine sensation

3
Urinary Incontinence

• Stress incontinence
• Urge incontinence
• Total incontinence
• Overflow incontinence
• Giggle incontinence
• Nocturnal enuresis

4
Bladder Diary
5
Physical Examination

• Abdominal physical examination
• Bladder, Operation scar
• Perineal examination
• Cystocele, Rectocele, Uterine prolapse
• Urine leakage on cough, fistula
• Vaginal mucosa, Vaginal tenderness
• Neurological examination
• B-C Reflex, PFM contractility, Anal tone

6
Laboratory examinations

• Urinalysis urine culture
• Blood chemistry, blood sugar
• KUB
• Uroflowmetry
• Cystoscopy
• Lower urinary tract sonography
• Uroradiology

7
Urodynamic study- Lower urinary tract

• Uroflowmetry
• Cystometrography
• External sphincter electromyography
• Pressure flow study
• Videourodynamic study
• Urethral pressure profilometry

8
Urodynamic study- Upper urinary tract
Special tests

• Whitaker test (upper tract pressure flow study)
• Ice water test
• Urecholine test
• Rapid cystometrography
• Potassium chloride test
• Other pharmacological test

9
Why Urodynamics?

• To obtain information of urinary tract function
  and dysfunction
• To confirm clinical diagnosis
• To compare treatment results
• To investigate pathophysiology of urinary tract
  diseases

10
Uroflowmetry Normal flow
11
Normal Uroflowmetry

• Qmax gt 15 ml/s in men
• Qmax gt 20 ml/s in women
• Tqmax is lt 1/3 of flow time
• Voided volume 200 500 ml
• A normal flow pattern
• Minimal residual urine (lt 50ml)

12
Uroflowmetry Parameters
13
Abnormal Flow Pattern

• Very high initial Qmax detrusor instability
  without BOO
• Obstructive flow pattern compressive,constrictive
  flow pattern
• Intermittent and straining pattern
• Saw-teeth flow pattern
• Terminal dribbling pattern

14
Uroflowmetry Intermittent flow
15
Uroflowmetry Straining flow
16
Uroflowmetry Low contractility
17
Uroflowmetry Obstructive flow
18
Pitfalls of Flow Interpretation

• Qmax is variable between several voids
• 7 of mean with LUTS and high Qmax might have
  bladder outlet obstruction
• Women with detrusor areflexia can have good Qmax
  by abdominal straining
• Embarrassment during examination can greatly
  influence Qmax expression

19
Cystometrography

• Measuring intravesical pressure (Pves) during
  bladder filling
• Physiological rate body weight/4 (ml/min)
• Non-physiological filling
• Combined with abdominal pressure (Pabd) and
  external sphincter electromyography (EMG)
• Detrusor pressure (Pdet) Pves- Pabd

20
Cystometry - technique
21
Cystometrography

• Bladder sensation FSF, FS, US,capacity
• Bladder compliance
• Detrusor pressure at end-filling stage
• Voiding pressure Men lt 50 cmH2O, Women lt35cmH2O
• Coordination of external sphincter EMG

22
Normal Cystometrogram

• Resting pressure lt 10 cm water
• FSF at 100-200ml, FS at 300-400 ml
• Cystometric capacity at 400-500 ml
• Voiding pressure lt 50 cm water in men and lt35 cm
  water in women
• A coordinated sphincter EMG activity

23
Cystometry- Neurogenic detrusor overactivity and
DESD
24
Cystometry- Idiopathic detrusor overactivity
25
Cystometry- after contraction
26
Bladder sensation

• Increased sensation with rapid filling, cold
  infusion, catheter placement, psychological
• Low detrusor contractility due to smaller bladder
  filling volume
• Vague bladder sensation from peritoneal surface
  in patients with detrusor areflexia
• Patient used abdominal straining to void

27
Bladder Compliance

• Compliance is related to filling rate
• Low compliance always combines with low
  contractility and large residuum
• Upper tract deterioration is associated with low
  bladder compliance
• A detrusor leak-point pressure gt40 cm water might
  endanger upper tract

28
Poor Bladder Compliance and Stress Urinary
Incontinence
29
Detrusor areflexia and Detrusor underactivity

• DA is limited to neuropathy
• Detrusor underactivity low detrusor pressure
  with low flow rate and large residual urine
• DHIC detrusor instability (hyperreflexia) and
  inadequate contractility
• Psychological embarrassment

30
Pressure Flow Study

• Measuring detrusor pressure, flow rate, EMG
  activity during voiding phase
• Concomitant recording of intra-abdominal pressure
• Calculation of resistance relation of P Q
• Calculation of Abrams-Griffiths number AG number
  Pdet 2 x Qmax

31
Pressure flow study - Technique
32
Multi-channel Pressure Flow Study
33
Relationship of Pressure Flow
34
Pressure flow study DHIC
35
Pressure flow studyCystocele and BOO in woman
36
Low contractility low flow
37
Detrusor overactivity voluntary PFM contraction
38
Detrusor overactivity in Storage phase
39
Detrusor overactivity in a contracted
bladder
40
Provoked DI in storage phase
41
Urethral Pressure Profilometry

• Measuring Intra-urethral resistance by perfusion
  technique or microtip transducer
• A static pressure measurement, but cannot
  predicting voiding efficiency
• Dynamic UPP
• Academic purpose and assessment of therapeutic
  results

42
Urethral Pressure Profilometry
43
Stress UPP in Continent woman
44
Stress UPP in Incontinent woman
45
Nitric oxide UPP in Neuropathic bladder
46
Voluntary Pelvic floor contraction
47
Leak-point Pressures

• Measuring the increased intravesical or
  intra-abdominal pressures that cause urine
  leakage per urethrum
• Detrusor LPP pressure causes leakage without
  detrusor contraction or increased intra-abdominal
  pressure
• Abdominal LPP- cough LPP, Valsalva LPP

48
Abdominal Leak point pressure in Type I SUI
49
Abdominal leak point pressure in Type II SUI
50
Cough vs Valsalva LPP in Type II/III SUI
51
Cough vs Valsalva LPP in Type II/III SUI
52
Cough vs Valsalva LPP in Pure Type III SUI
53
LPP Intravesical vs intra-abdominal recording
54
Valsalva LPP in Cystocele SUI
55
Videourodynamic Study

• Combined image and pressure flow study in
  assessing lower urinary tract dysfunction
• Suprapubic puncture in men
• A lt 6Fr intra-urethral catheter
• Repeat study if the result is equivocal
• Compare free flow rate with the flow expression
  during investigation

56
Clinical Application of Videourodynamics in LUTS

• Differential diagnosis of BOO
• Identify types of stress incontinence
• Confirm bladder neck dysfunction and DESD in
  neuropathic voiding dysfunction
• Upper tract dynamics and determine site of
  obstruction
• Analysis of pathophysiology of LUTS

57
Videourodynamic study in DI
58
Videourodynamic study in Female urethral stricture
59
Videourodynamic study in Female urethral stricture
60
Mixed DI and SUI
61
Poor relaxation of urethral sphincter
62
Low pressure and BOO
63
Dysfunctional voiding in woman with urge
incontinence
64
Videourodynamic study in SUI
65
Videourodynamic study in SUI after Pubovaginal
sling
66
Videourodynamics in Post-incontinence surgery BOO
