Hemodynamic Disorders

1
Happy Year
2
Pathology 301

• Awatif Jamal, MD, MSc, FRCPC, FIAC
• Consultant Associate Professor
• Department of Pathology
• King Abdulaziz University Hospital

3
(No Transcript)
4
(No Transcript)
5
Hemodynamic Disorders Thrombosis Shock

• Edema
• Hyperemia and Congestion
• Hemorrhage
• Hemostasis Thrombosis
• Embolism
• Infarction
• Shock

• Edema

6
INTRODUCTION

• The health of cells and tissues depend on
• 1-Intact circulation to deliver oxygen
  and remove wastes.
• 2-Normal fluid homeostasis which
  encompasses the following
• A- maintenance of BV wall integrity .
• B- maintenance of intravascular pressure.
• C- maintenance of protein content or osmolarity
  within BV.
• D- maintenance of blood as a liquid until such
  time as injury necessitates clot formation.

7
EDEMA

• Fluid extravasations and accumulation in the
  interstitial spaces

60 of body weight is water, distributed as
follow Two thirds intracellular 5
intravascular The rest is interstitial
8
EDEMA

• Increased fluid in the interstitial tissue
  spaces
• Fluid may also accumulate in body cavities
• Hydrothorax
• Hydropericardium
• Hydroperitoneum is also called Ascites
• Massive generalized edema is called Anasarca

9
Pathogenesis

• The opposing effects of vascular hydrostatic
  pressure and plasma colloid osmotic pressure are
  the major factors that control the movement of
  fluid between vascular and interstitial tissues.
• Normally, the exit of fluid into the interstitium
  from the arteriolar end of microcirculation is
  nearly balanced by inflow of fluid at the venular
  end a small residual amount of excess
  interstitial fluid is drained by the lymphatics

10
Fluid Homeostasis
Lymphatics
11
Fluid Homeostasis

• Homeostasis is maintained by the opposing effects
  of
• Vascular Hydrostatic Pressure
• and
• Plasma Colloid Osmotic Pressure

12
Edema Fluid TRANSUDATE

• transudate is protein-poor (specific gravity
  lt1.012)
• An exudate is protein-rich (specific gravity
  gt1.020) (inflammatory edema)

13
(No Transcript)
14
Pathophysiologic Categories of Edema
I. Increased Hydrostatic Pressure

• II. Reduced Plasma Oncotic
• Pressure
• III. Inflammation
• IV. Others

15
Patho-physiologic Categories of Edema

• Increased Hydrostatic Pressure
• Increased intravascular pressure may be due to
• 1- Impaired venous return
• Localized Venous Thrombosis in lower extremities
  (local edema).
• Generalized Congestive Heart Failure
  (generalized edema).
• 2- Increased arteriolar dilatation
• Heat
• Neurohumoral dysregulation

16
Increased Hydrostatic Pressure

• Congestive Heart Failure
• Congestive Heart Failure is the most common
  cause of EDEMA due to Increased Hydrostatic
  Pressure
• Generalized increased venous pressure, resulting
  in systemic edema, occur most commonly in
  CONGESTIVE HEART FAILURE

17
Increased Hydrostatic Pressure Congestive Heart
Failure

• Mechanism
• The Pump is FAILING!!! ? ? Cardiac output
• Blood backs up, first into the lungs
• ? then into the venous circulation
• ? increasing Central Venous Pressure (CVP)
• ? increased capillary pressure (Hydrostatic
  Pressure)
• Leading to Generalized Edema

18
Congestive Heart Failure Decreased Renal
Perfusion

• Congestive heart failure ?
• Decreased Cardiac Output ?
• Decreased ARTERIAL blood volume ?

Less arterial bloodLess renal perfusion... The
Kidney doesnt see enough blood coming through .
19
Congestive Heart Failure Decreased Renal
Perfusion

• Decreased Renal Perfusion activates
• the Renal Defense Mechanisms
• Renin-Angiotensin-Aldosterone axis ?
• ? Na H2O retention
• Renal Vasoconstriction
• Increased Renal Anti-diuretic Hormone (ADH)

20
Congestive Heart Failure Decreased Renal
Perfusion

• The net result will be increased intravascular
  volume to increase the COP.
• The failing heart cant increase the COP so the
  extra fluid load will lead to additional increase
  in the venous pressure and More EDEMA .

21
Congestive Heart Failure
22
(No Transcript)
23
Pathophysiologic Categories ofEdema

• I. Increased Hydrostatic Pressure

II. Reduced Plasma Oncotic Pressure

• III. Inflammation
• IV. Others

24
II. Reduced Plasma Oncotic Pressure

• Albumin
• the serum protein MOST responsible for the
  maintenance of colloid osmotic pressure.
• A decrease in osmotic pressure can result from
• ? Protein Loss
• or
• ? Protein Synthesis

25
II. Reduced Plasma Oncotic Pressure

• Increased albumin Loss
• Nephrotic Syndrome
• Increased permeability of the glomerular basement
  membrane ? loss of protein
• Reduced albumin synthesis
• Cirrhosis
• Protein malnutrition
• EFFECT
• is movement of fluid into the interstitial tissue
  with resultant plasma volume contraction.

26
(No Transcript)
27
Pathophysiologic Categories ofEdema
I. Increased Hydrostatic Pressure
II. Reduced Plasma Oncotic Pressure
III. Inflammation Localized Edema Increased
Vascular Permeability

• IV. Others

28
(No Transcript)
29
Pathophysiologic Categories ofEdema
I. Increased Hydrostatic Pressure
II. Reduced Plasma Oncotic Pressure
III. Inflammation

• IV. Others
• Lymphatic Obstruction
• Water and Sodium Retention

30
Lymphatic Obstruction

• Impaired lymphatic drainage with resultant
  lymphedema
• LOCALIZED EDEMA
• caused by
• INFLAMMATION
• or
• NEOPLASTIC OBSTRUCTION

31
Inflammatory Lymphatic Obstruction

• Filariasis
• A parasitic infection which leads to lymphatic
  and lymph node fibrosis in the inguinal region
  resulting in edema of the external genitalia and
  lower extremity called ELEPHANTIASIS

32
Neoplastic Lymphatic Obstruction

• In cases of CA breast the resection and/or
  radiation of axillary lymphatic channels and
  lymph nodes can lead to -- arm edema
• Carcinoma of breast with obstruction of
  superficial lymphatics can lead to edema of the
  skin with an unusual appearance of the breast
  skin -
• peau dorange (orange peel)

33
EDEMA - Summary
INCREASED HYDROSTATIC PRESSURE Congestive Heart
Failure Ascites Venous Obstruction
DECREASED ONCOTIC PRESSURE Nephrotic
Syndrome Cirrhosis Protein Malnutrition

• HEART
• LIVER
• KIDNEY

LYMPHATIC OBSTRUCTION Inflammatory Neoplastic
INCREASED PERMEABILITY Inflammation
34
Edema Fluid
Exudate Transudate
Inflammatory High hydrostatic pr. Cause
High Low Protein content
gt1.020) lt1.012) Specific gravity
Rich Absent Inflammatory cells
35
GENERALIZED EDEMA

• HEART
• LIVER
• KIDNEY

36
Subcutaneous Edema

• Edema of the subcutaneous tissue is most easily
  detected Grossly (not microscopically)
• Push your finger into it
• and a depression remains
• Annoying but Points to
• Underlying Disease
• It can impair wound healing
• or clearance of Infection

37
Edema

• Dependent Edema is a prominent feature of
  Congestive Heart Failure in legs if standing or
  sacrum in sleeping patient
• Periorbital edema is often the initial
  manifestation of Nephrotic Syndrome, while late
  cases will lead to generalized edema.

38
Pulmonary Edema

• is most frequently seen in Congestive Heart
  Failure
• May also be present in renal failure, adult
  respiratory distress syndrome (ARDS), pulmonary
  infections and hypersensitivity reactions

39
Pulmonary Edema

• The Lungs are typically 2-3 times normal weight
• Cross sectioning causes an outpouring of frothy,
• sometimes blood-tinged fluid
• It may interfere
• with pulmonary function

40
Normal lung
41
Pulmonary Edema
42
Pulmonary Edema

• Clinical Correlation
• May cause death by interfering with Oxygen and
  Carbon Dioxide exchange
• Creates a favorable environment for infection
• THINK it resembles Culture Media!!!

43
Brain Edema

• Trauma, Abscess, Neoplasm, Infection
  (Encephalitis due to say West Nile Virus), etc

44
Brain Edema

• Clinical Correlation The big problem is There
  is no place for the fluid to go!
• Herniation into the foramen magnum will kill

45
Clinical Correlation of Edema

• The effect of edema may be just annoying to fatal
  condition.
• It usually points to an underlying disease.
• However, it can impair wound healing or clearance
  of Infection.
• Creates a favorable environment for infection.
• THINK Culture Media
• May cause death by interfering with Oxygen and
  Carbon Dioxide exchange.

46
Thank you
