Chapter 3 Basic Concepts in Statistics and Probability

1
Chapter 3Basic Concepts in Statistics and
Probability
2
3.1 Probability

• Definition An experiment is a process that
  results in an outcome that cannot be predicted in
  advance with certainty.
• Examples
• rolling a die
• tossing a coin
• weighing the contents of a box of cereal.

3
Sample Space

• Definition The set of all possible outcomes of
  an experiment is called the sample space for the
  experiment.
• Examples
• For rolling a fair die, the sample space is 1,
  2, 3, 4, 5, 6.
• For a coin toss, the sample space is heads,
  tails.
• Imagine a hole punch with a diameter of 10 mm
  punches holes in sheet metal. Because of
  variation in the angle of the punch and slight
  movements in the sheet metal, the diameters of
  the holes vary between 10.0 and 10.2 mm. For
  this experiment of punching holes, a reasonable
  sample space is the interval (10.0, 10.2).

4
More Terminology

• Definition A subset of a sample space is called
  an event.
• A given event is said to have occurred if the
  outcome of the experiment is one of the outcomes
  in the event. For example, if a die comes up 2,
  the events 2, 4, 6 and 1, 2, 3 have both
  occurred, along with every other event that
  contains the outcome 2.

5
Combining Events

• The union of two events A and B, denoted
• A ? B, is the set of outcomes that belong either
• to A, to B, or to both.
• In words, A ? B means A or B. So the event
• A or B occurs whenever either A or B (or both)
• occurs.
• Example Let A 1, 2, 3 and B 2, 3, 4.
• What is A ? B?

6
Intersections

• The intersection of two events A and B, denoted
• by A ? B, is the set of outcomes that belong to A

• and to B. In words, A ? B means A and B.
• Thus the event A and B occurs whenever both
• A and B occur.
• Example Let A 1, 2, 3 and B 2, 3, 4.
• What is A ? B?

7
Complements

• The complement of an event A, denoted Ac, is
• the set of outcomes that do not belong to A. In
• words, Ac means not A. Thus the event not
• A occurs whenever A does not occur.
• Example Consider rolling a fair sided die. Let
  A be the event rolling a six 6.
• What is Ac not rolling a six?

8
Mutually Exclusive Events

• Definition The events A and B are said to be
  mutually exclusive if they have no outcomes in
  common.
• More generally, a collection of events A1, A2, ,
  An
• is said to be mutually exclusive if no two of
  them have
• any outcomes in common.
• Sometimes mutually exclusive events are referred
  to as disjoint events.

9
Probabilities

• Definition Each event in the sample space has a
  probability of occurring. Intuitively, the
  probability is a quantitative measure of how
  likely the event is to occur.
• Given any experiment and any event A
• The expression P(A) denotes the probability that
  the event A occurs.
• P(A) is the proportion of times that the event A
  would occur in the long run, if the experiment
  were to be repeated over and over again.

10
Axioms of Probability

• Let S be a sample space. Then P(S) 1.
• For any event A, .
• If A and B are mutually exclusive events, then
  . More generally,
  if
• are mutually exclusive
  events, then

11
A Few Useful Things

• For any event A, P(AC) 1 P(A).
• Let ? denote the empty set. Then P( ? ) 0.
• If S is a sample space containing N equally
  likely outcomes, and if A is an event containing
  k outcomes, then P(A) k/N.
• Addition Rule (for when A and B are not mutually
  exclusive)

12
Conditional Probability and Independence

• Definition A probability that is based on part
  of the sample space is called a conditional
  probability.
• Let A and B be events with P(B) ? 0. The
  conditional
• probability of A given B is

13
Conditional Probability
Venn Diagram
14
Independence

• Definition Two events A and B are independent if
  the probability of each event remains the same
  whether or not the other occurs.
• If P(A) ? 0 and P(B) ? 0, then A and B are
  independent if P(BA) P(B) or, equivalently,
  P(AB) P(A).
• If either P(A) 0 or P(B) 0, then A and B are
  independent.
• These concepts can be extended to more than two
  events.

15
The Multiplication Rule

• If A and B are two events and P(B) ? 0, then
• P(A ? B) P(B)P(AB).
• If A and B are two events and P(A) ? 0, then
• P(A ? B) P(A)P(BA).
• If P(A) ? 0, and P(B) ? 0, then both of the above
  hold.
• If A and B are two independent events, then

• P(A ? B) P(A)P(B).

16
Extended Multiplication Rule

• If A1, A2,, An are independent results, then for
  each collection of Aj1,, Ajm of events
• In particular,

17
Example

• A system contains two components, A and B,
  connected in series. The system will function
  only if both components function. The
  probability that A functions is 0.98 and the
  probability that B functions is 0.95. Assume A
  and B function independently. Find the
  probability that the system functions.

18
Example

• A system contains two components, C and D,
  connected in parallel. The system will function
  if either C or D functions. The probability that
  C functions is 0.90 and the probability that D
  functions is 0.85. Assume C and D function
  independently. Find the probability that the
  system functions.

19
Example

• P(A) 0.995 P(B) 0.99
• P(C) P(D) P(E) 0.95
• P(F) 0.90 P(G) 0.90, P(H) 0.98

20
Random Variables

• Definition A random variable assigns a numerical
  value to each outcome in a sample space.
• Definition A random variable is discrete if its
  possible values form a discrete set.

21
Probability Mass Function

• The description of the possible values of X and
  the probabilities of each has a name the
  probability mass function.
• Definition The probability mass function (pmf)
  of a discrete random variable X is the function
  p(x) P(X x).
• The probability mass function is sometimes called
  the probability distribution.

22
Probability Mass FunctionExample
23
Cumulative Distribution Function

• The probability mass function specifies the
  probability that a random variable is equal to a
  given value.
• A function called the cumulative distribution
  function (cdf) specifies the probability that a
  random variable is less than or equal to a given
  value.
• The cumulative distribution function of the
  random variable X is the function F(x) P(X x).

24
More on a Discrete Random Variable

• Let X be a discrete random variable. Then
• The probability mass function of X is the
  function p(x) P(X x).
• The cumulative distribution function of X is the
  function F(x) P(X x).
• .
• , where the sum
  is over all the
• possible values of X.

25
Mean and Variance for Discrete Random Variables

• The mean (or expected value) of X is given by
•
  ,
• where the sum is over all possible values of X.
• The variance of X is given by
• The standard deviation is the square root of the
  variance.

26
Example
Probability mass function will balance if
supported at the population mean
27
The Probability Histogram

• When the possible values of a discrete random
  variable are evenly spaced, the probability mass
  function can be represented by a histogram, with
  rectangles centered at the possible values of the
  random variable.
• The area of the rectangle centered at a value x
  is equal to P(X x).
• Such a histogram is called a probability
  histogram, because the areas represent
  probabilities.

28
Probability Histogram for the Number of Flaws in
a Wire

• The pmf is P(X 0) 0.48, P(X 1) 0.39,
  P(X2) 0.12, and P(X3) 0.01.

29
Probability Mass FunctionExample
30
Continuous Random Variables

• A random variable is continuous if its
  probabilities are given by areas under a curve.
• The curve is called a probability density
  function (pdf) for the random variable.
  Sometimes the pdf is called the probability
  distribution.
• The function f(x) is the probability density
  function of X.
• Let X be a continuous random variable with
  probability density function f(x). Then

31
Continuous Random Variables Example
32
Computing Probabilities

• Let X be a continuous random variable with
  probability density function f(x). Let a and b
  be any two numbers, with a lt b. Then
• In addition,

33
More on Continuous Random Variables

• Let X be a continuous random variable with
  probability density function f(x). The
  cumulative distribution function of X is the
  function
• The mean of X is given by
• The variance of X is given by

34
Two Independent Random Variables

•

35
Variance Properties

• If X1, , Xn are independent random variables,
• then the variance of the sum X1 Xn is given
• by
• If X1, , Xn are independent random variables
• and c1, , cn are constants, then the variance of

• the linear combination c1 X1 cn Xn is given
• by

36
More Variance Properties

• If X and Y are independent random variables
• with variances , then the
  variance of
• the sum X Y is
• The variance of the difference X Y is

37
Independence and Simple Random Samples

• Definition If X1, , Xn is a simple random
  sample, then X1, , Xn may be treated as
  independent random variables, all from the same
  population.

38
Properties of

• If X1, , Xn is a simple random sample from a
• population with mean ? and variance ?2, then the
• sample mean is a random variable with
• The standard deviation of is

39
3.2 Sample versus Population

• Definitions
• A population is the entire collection of objects
  or outcomes about which information is sought.
• A sample is a subset of a population, containing
  the objects or outcomes that are actually
  observed.
• A simple random sample (SRS) of size n is a
  sample chosen by a method in which each
  collection of n population items is equally
  likely to comprise the sample, just as in the
  lottery.

40
Sampling (cont.)

• Definition A sample of convenience is a sample
• that is not drawn by a well-defined random
• method.
• Things to consider with convenience samples
• Differ systematically in some way from the
  population.
• Only use when it is not feasible to draw a random
  sample.

41
Simple Random Sampling

• A SRS is not guaranteed to reflect the population
  perfectly.
• SRSs always differ in some ways from each other
  occasionally a sample is substantially different
  from the population.
• Two different samples from the same population
  will vary from each other as well.
• This phenomenon is known as sampling variation.

42
Tangible Population

• The populations that consist of actual physical
  objects customers, blocks, balls are called
  tangible populations.
• Tangible populations are always finite.
• After we sample an item, the population size
  decreases by 1.

43
More on Simple Random Sampling

• Definition A conceptual population consists of
• items that are not actual objects.
• For example, a geologist weighs a rock several
  times on a sensitive scale. Each time, the scale
  gives a slightly different reading.
• Here the population is conceptual. It consists
  of all the readings that the scale could in
  principle produce.

44
Simple Random Sampling (cont.)

• The items in a sample are independent if knowing
  the values of some of the items does not help to
  predict the values of the others.
• Items in a simple random sample may be treated as
  independent in most cases encountered in
  practice. The exception occurs when the
  population is finite and the sample comprises a
  substantial fraction (more than 5) of the
  population.

45
Types of Sampling

• Weighted Sampling
• Stratified Random Sampling
• Cluster Sampling

46
3.3 Location

• Measures used to describe location of data
• (Measure of center) or (Measure of central
  tendency)
• Median
• Mean (Average)
• Robust estimators
• Trimmed average 10 of the observations in a
  sample are trimmed from each end

47
3.4 Variation

• Variation
• Natural cause
• Assignable causes
• Measures of variation
• Range (using only the extreme values)
• Variance
• Standard deviation
• Covariance

48
Variation Calculation

•

(3.1)

(3.2)

(3.3)
49
3.5 Discrete Distributions

• Random Variable Something that varies in a
  random manner
• Discrete Random Variable Random variable that
  can assume only a finite number of possible
  values (usually integers)

50
Discrete Random Variable Example

• Experiment Tossing a single coin twice and
  recording the number of heads observed
• Repeated 16 times
• X number of heads observed in each experiment
• 0 2 1 1 2 0 0 1 2 1 1 0 1 1 0 1 1 2 0
• Empirical distribution
• Theoretical distribution

51
3.5.1 Binomial Distribution

• We use the Bernoulli distribution when we have an
  experiment which can result in one of two
  outcomes. One outcome is labeled success, and
  the other outcome is labeled failure.
• The probability of a success is denoted by p. The
  probability of a failure is then 1 p.
• Such a trial is called a Bernoulli trial with
  success probability p.

52
Examples of Bernoulli Trials

1. The simplest Bernoulli trial is the toss of a
   coin. The two outcomes are heads and tails. If
   we define heads to be the success outcome, then p
   is the probability that the coin comes up heads.
   For a fair coin, p 1/2.
2. Another Bernoulli trial is a selection of a
   component from a population of components, some
   of which are defective. If we define success
   to be a defective component, then p is the
   proportion of defective components in the
   population.

53
Binomial Distribution

• If a total of n Bernoulli trials are conducted,
  and
• The trials are independent.
• Each trial has the same success probability p.
• X is the number of successes in the n trials.
• then X has the binomial distribution with
  parameters n and p, denoted X Bin(n,p).

54
Probability Mass Function ofa Binomial Random
Variable

• If X Bin(n, p), the Probability Mass Function
  of X is

(3.5)
55
Binomial Probability Histogram
(a) Bin(10, 0.4) (b) Bin(20, 0.1)
56
Example

• The probability that a newborn baby is a girl is
  approximately 0.49. Find the probability that of
  the next five single births in a certain
  hospital, no more than two are girls.

57
Another Use of the Binomial

• Assume that a finite population contains items of
  two types, successes and failures, and that a
  simple random sample is drawn from the
  population. Then if the sample size is no more
  than 5 of the population, the binomial
  distribution may be used to model the number of
  successes.

58
Example

• A lot contains several thousand components, 10
  of which are defective. Nine components are
  sampled from the lot. Let X represent the number
  of defective components in the sample. Find the
  probability that exactly two are defective.

59
Software Functions for Binomial Probabilities

• Excel
• BINOM.DIST(number_s, trials, probability_s,
  cumulative)
• Minitab
• Calc? Probability Distributions ? Binomial

60
Example

• Of all the new vehicles of a certain model that
  are sold, 20 require repairs to be done under
  warranty during the first year of service. A
  particular dealership sells 14 such vehicles.
  What is the probability that fewer than five of
  them require warranty repairs?

61
Mean and Variance of a Binomial Random Variable

• E(X) np
• E(Bernoulli Trial)(1)p(0)(1-p)p
• Var(X) np(1 p)
• Var(Bernoulli Trial)(1-p)2p(0-p)2(1-p)
• (1-2pp2)pp2(1-p)
• p-2p2p3p2-p3
• p-p2
• p(1-p)

62
3.5.2 Beta-Binomial Distribution

•

63
3.5.3 Poisson Distribution

• One way to think of the Poisson distribution is
  as an approximation to the binomial distribution
  when n is large and p is small.
• It is the case when n is large and p is small
  that the mass function depends almost entirely on
  the mean np, and very little on the specific
  values of n and p.
• We can therefore approximate the binomial mass
  function with a quantity ? np this ? is the
  parameter in the Poisson distribution.

64
Probability Mass Function, Mean, and Variance of
Poisson Dist.

• If X Poisson(?), the probability mass function
  of X is
• Mean ?X ?
• Variance
• Note X must be a discrete random variable and ?
  must be a positive constant.

(3.6)
65
Poisson Probability Histogram
Figure 4.2 (a) Poisson(1) (b) Poisson(10)
66
Poisson Probabilities

• Excel
• POISSON.DIST(x, mean, cumulative)
• Minitab
• Calc? Probability Distributions ? Poisson

67
Example

• Particles are suspended in a liquid medium at a
  concentration of 6 particles per mL. A large
  volume of the suspension is thoroughly agitated,
  and then 3 mL are withdrawn. What is the
  probability that exactly 15 particles are
  withdrawn?

68
3.5.4 Geometric Distribution

• Geometric distribution and the negative binomial
  distribution are referred as waiting time
  distributions.
• It deals with the number of trials required for a
  single success.
• Outcomes are either success/failure. Trial
  continues until success (defect) occurs for the
  first time.
• Useful for manufacturing where the line will be
  shut down for recalibration upon first defect.

69
Geometric Distribution

• Geometric Distribution
• n The number of trials required to produce 1
  success in a geometric experiment.
• p The probability of success on an individual
  trial.
• 1- p The probability of failure on an
  individual trial.

70
Geometric DistributionMean and Variance

? the average no. of trials required to produce
1 success
71
Geometric DistributionExample

• Bob is a high school basketball player. He is a
  70 free throw shooter. That means his
  probability of making a free throw is 0.70. What
  is the probability that Bob makes his first free
  throw on his fifth shot?
• Solution
• Probability of success (p) is 0.70, the number
  of trials (x) is 5, and the number of successes
  (r) is 1. We enter these values into the
  geometric formula.

72
Geometric DistributionExample

• Military contractor is producing nuts that must
  be within .04 mm of specified diameter. If nut
  exceeds the limit the line must be shut down and
  adjusted. The probability that the diameter of a
  nut will exceeds the allowable error is .0014.
• What is the probability the machine will be shut
  down exactly after the 100th nut is produced?
• What is the probability the machine will be shut
  down exactly after the 200th nut is produced?

73
3.5.5 Negative Binomial Distribution

• A negative binomial experiment is a statistical
  experiment that has the following properties
• The experiment consists of x repeated trials.
• Each trial can result in just two possible
  outcomes, a success and a failure.
• The probability of success, denoted by P, is the
  same on every trial.
• The trials are independent that is, the outcome
  on one trial does not affect the outcome on other
  trials.
• The experiment continues until r successes are
  observed, where r is specified in advance.

74
Negative Binomial Distribution

• A negative binomial random variable is the number
  X of repeated trials to produce r successes in a
  negative binomial experiment.
• The negative binomial distribution is also known
  as the Pascal distribution.

75
Negative Binomial Distribution

• n The number of trials required to produce r
  successes in a negative binomial experiment.
• r The number of successes in the negative
  binomial experiment.
• p The probability of success on an individual
  trial.
• 1-p The probability of failure on an individual
  trial.

76
Negative Binomial DistributionMean and Variance

? the average no. of trials required to produce
r successes
77
Negative Binomial DistributionsExample

• Bob is a high school basketball player. He is a
  70 free throw shooter. That means his
  probability of making a free throw is 0.70.
  During the season, what is the probability that
  Bob makes his third free throw on his fifth shot?
• Solution The probability of success (p) is 0.70,
  the number of trials (x) is 5, and the number of
  successes (r) is 3.

78
3.5.6 Hypergeometric Distribution

• A sample of size n is randomly selected without
  replacement from a population of N items.
• In the population, r items can be classified as
  successes, and N - r items can be classified as
  failures.
• A hypergeometric random variable, x, is the
  number of successes that result from a
  hypergeometric experiment

79
Hypergeometric Probability Distribution

• Where N total number of elements in the
  population
• D number of success in the population
• N-D number of failures in the population
• n number of trials (sample size)
• x number of successes in trial
• n-x number of failures in n trials

80
Hypergeometric DistributionMean and Variance

Where p r/N
81
Hypergeometric Probability DistributionExample
Suppose we select 5 cards from an ordinary deck
of playing cards. What is the probability of
obtaining 2 or fewer hearts? Solution  N 52
since there are 52 cards in a deck. r 13 since
there are 13 hearts in a deck. n 5 since we
randomly select 5 cards from the deck. x 0 to
2 since our selection includes 0, 1, or 2
hearts. We plug these values into the
hypergeometric formula as follows
82
Hypergeometric Probability in MINITAB

• Acceptance testing of ice cream cones Ice cream
  parlor checks a batch of 400 waffle cones by
  checking 50 of them. They will not buy them if
  more than 3 cones are broken.
• What is the probability that the parlor will buy
  the cones if 35 of the 400 cones are broken.
• Define N, n, D, N-D, x
• In MINITAB select Calc-gt Probability
  Distributions -gt Hypergeometric
