Eruption and Occlusion of the Permanent Dentition

1
Eruption and Occlusion of the Permanent Dentition

Mark H. Taylor, D.D.S., F.A.C.D.
2
Dont Fake Knowledge!

• Know Nolla's stages of calcification
• Know time of eruption of permanent teeth

3
Nolla's 10 Stages of Calcification

• Stage 2 - initial calcification
• Stage 6 - eruptive movement begins (crown
  formation complete)
• Stage 8 - alveolar crest pierced (2/3 root
  development)
• Stage 9 - gingival margin pierced (3/4 root
  development)
• Interval between Stage 6 and full interdigitation
  is about 5 years

4
Time of Eruption (Years)
5
Why Know Calcification Times?
Enamel hypoplasia
6
Fluorosis
7
Fluorosis and Hypoplasia
8
Fluorosis and Hypoplasia
9
Factors Affecting Eruption

• Genetics - sequence timing mostly genetically
  controlled
• Nutrition
• Premature loss of a primary tooth

Eruption heh heh get it?
10
Eruption Facts

• Girls 5 months faster than boys
• 6-1-2-4-3-5-7 and 6-1-2-4-5-3-7 most common in
  maxilla
• (6-1)-2-3-4-5-7 and (6-1)-2-4-3-5-7 most common
  in mandible

11
Mesial Drift and Anterior Component of Force

• Mesial drift
• Ectopic eruption
• Axial inclination produces mesial force
• Space maintenance

12
Ectopic Eruption
13
Ectopic Eruption
14
Ectopic Eruption
15
???
16
???
17
???
18
???
19
Space Maintenance - PHA
20
Space Maintenance - LLHA
21
Space Maintenance - BLS
22
Space Maintenance - Distal Shoe
23
Crossbites

• Unilateral vs. bilateral
• Dental vs. skeletal
• Appliance types

24
Functional Cross Bite
25
Functional Cross Bite
26
Functional Cross Bite
27
Functional Cross Bite
28
Quad Helix Appliance
29
Quad Helix Appliance
30
Distalizing Appliance
31
Absence of Permanent Teeth

• 4-6 congenital absence
• Females more frequently missing teeth
• Most common congenitally absent teeth
• mandibular 2nd premolar
• maxillary lateral incisor
• maxillary 2nd premolar

32
?????????????
33
??????????????
34
Missing Permanent Teeth
35
Extra Permanent Teeth

• Supernumerary teeth found most frequently in the
  maxillary incisor region (mesiodens), and
  occasionally in the premolar area
• 2-3 supernumerary teeth, males more common

36
Supernumerary Teeth
37
Supernumerary Teeth
38
Supernumerary Teeth
39
Supernumerary Teeth
40
Supernumerary Permanent Tooth
41
Supernumerary Permanent Tooth
42
Supernumerary Permanent Tooth
43
Changes in Arch Width

• Intercanine and intermolar growth
• significant increases between 6 weeks and 2 years
  of age
• significant increases between 3 and 13 years
• mandibular intercanine width established by 8
  years of age
• after permanent teeth erupted, slight decrease in
  arch width in the intercanine area

Bishara, et al Arch width changes from 6 weeks
to 45 years of age AJO, April 1997
44
Changes in Arch Length and Overbite

• Arch length decreases
• late mesial shift, mesial drift, interproximal
  wear
• do not affect interach relationships
• Overbite
• decreases in primary dentition
• increases in mixed dentition
• OB/OJ relatively stable in adult

Harris, A longitudinal study or arch size and
form in untreated adults AJO, April 1997.
(20-55 yoa)
45
Intercanine Growth
46
Angle Classification

• Class I Molar (65)
• Class II Molar (30)
• Class III Molar ( 5)

47
Class I Molar
Mesial
Distal
48
Class II Molar
Mesial
Distal
49
Class III Molar
Mesial
Distal
50
Cuspid Classification

• Neutro (Class I)
• Disto (Class II)
• Mesio (Class III)

51
Neutro Cuspid (Class I)
Mesial
Distal
52
Disto Cuspid (Class II)
Distal
Mesial
53
Mesio Cuspid (Class III)
Mesial
Distal
54
Divisions of Class II

• Division I - excess OJ
• Division II - "rabbited" incisors
• Subdivision - one side

55
Divisions of Class IIDivision 1
56
Divisions of Class IIDivision 1
57
Divisions of Class IIDivision 1
58
Divisions of Class IIDivision 2
59
Divisions of Class IIDivision 2
60
Divisions of Class IIDivision 2
61
Divisions of Class IIDivision 2
62
Six Keys to Occlusion

• Class I molar relationship
• Mesial crown angulation
• Proper crown inclination
• No rotations
• Tight contacts
• Flat occlusal plane

63
Types of Faces

• Brachycephalic - broad short
• Dolichocephalic - long narrow
• Mesocephalic - normal

64
Brachycephalic
65
Dolichocephalic
66
Mesocephalic
For the ladies.
For the gentlemen...
67
Mesocephalic
For the moviegoer.
68
Mesocephalic
For the intellectual dental student.
69
You Tell Me.
70
Profile?
71
Overbite - Overjet?
72
Occlusion?
73
Huskers!!!!
