A Framework for Supporting DBMS-like Indexes in
the Cloud
Gang Chen, Hoang Tam Vo, Sai Wu, Beng Chin Ooi,
M. Tamer Özsu
2
Motivation

• NoSQL systems trade-off
• K-V model -- scalability vs. functionality (ACID,
  indexes)
• Data selection on primary key is not sufficient
• Ad-hoc queries on secondary attributes
• OLTP queries high selectivity, low latency
  expectation
• Cloud storage system huge volume of data
• parallel scan scan 1TB data to get 10 tuples?
• Indexes in the cloud
• Useful when query selectivity is high
• Distributed indexes
• central server may become bottleneck
• facilitate parallelism and load balance

- the distribution of indexes ? - scalability in
terms of data volume, network size and number of
indexes ?
3
Current State of the Art

• Asynchronous view maintenance for VLSD
  databases1
• Pre-configured queries vs. ad-hoc data selection
• Open-source systems
• Cassandra
• built-in distributed hash secondary indexes
  (from V. 7.0)
• Hbase
• a secondary index created as another table (on
  going) 2
• Closed-source systems
• Megastore 3
• consistent local indexes inside an entity group
• asynchronous global indexes across groups

1 Asynchronous view maintenance for VLSD
databases Sigmod 2009 2 http//hbase.apache.org/
book.htmlsecondary.indexes 3 Megastore
Providing Scalable, Highly Available Storage for
Interactive Services CIDR 2011
4
Current State of the Art (2)

• P2P overlays as global distributed indexes
• Distributed B-tree-like indexes 1
• based on tree-based overlay BATON
• Distributed R-tree-like indexes 2
• based on CAN overlay

1 Efficient B-tree Based Indexing for Cloud
Data Processing VLDB 2010 2 Indexing
Multi-dimensional Data in a Cloud System SIGMOD
2010
5
Our Focus

• Context
• Efficient and elastic database service with
  database functionality (DaaS)
• Aims
• Provision of indexing functionality in the
  context of DaaS
• Efficiency
• the ability to locate some specific records
  among millions of distributed candidates in real
  time
• Scalability
• multiple indexes (of different types) over
  distributed data
• Extensibility
• users can define new indexes without knowing the
  structure of the underlying network
• Performance self-tuning
• users do not have to tune the system performance
  by themselves

6
Challenges of Distributed Indexes

• Different overlays are required to support
  different types of indexes
• BATON for B-tree
• CAN for R-tree
• Chord for Hash
• Overlay routing and maintenance cost are high
• Load balancing issue
• Indexed columns have different data distribution
• Difficult to balance the load of index nodes in
  the presence of multiple indexes

7
Our Approachto providing index functionality in
the cloud

• Indexing as a service
• Generic overlay
• Data mapping
• Performance self-tuning
• Result
• A simple yet efficient and extensible framework
  for developing distributed indexes in the cloud

8
Index Node
Data Mapping
Data are transformed into a unified cayley key
space
Cayley graph
Cayley Graph Manager
chord
can
baton
- Index data are distributed into different
cluster nodes - Each node builds a local index
for maintaining the index data - Part of local
indexes are cached in memory
Buffer Manager
ConnectionManager
Local Indexes
TCP/IP Connection
A connection manager is set up to decide which
connection should be maintained
9
Overlay Mapping

• Two interfaces for mapping a specific type of
  overlay to Cayley graph
• Generating set
• Operator
• ? Applying the operator on the ID of an index
  node and the generating set will generate the
  routing table for that node

generator
2i i 0, ..., n - 1
Baton
mod 2n
operator
generator
1i, i 1, ..., n
Cayley graph manager
CAN
mod 2
operator
generator
Index search
2i i 0, ..., n - 1
A routing algorithm
Chord
mod 2n
operator
10
Data Mapping

• Uniform data mapping
• Load balance property
• Uniform data mapping provides 1-balance with the
  assumption that the data distribution is uniform

11
Data Mapping

• Sampling-based data mapping
• To deal with skewed data distribution
• Stratified random sampling 1,2
• partition the domain into disjoint subsets
• take a specified number of samples from each
  subset
• Done when bulk load data from external sources
  into cloud databases, e.g., bulk insert daily new
  feed of new items from partners into operational
  table
• Skewed online update
• perform data migration to re-balance

1 Sampling Issues in Parallel Database Systems
S. Seshadri and J. F. Naughton, EDBT, 1992. 2
Efficient Bulk Insertion into a Distributed
Ordered Table A. Silberstein et. al., Sigmod,
2008.
12
Index Building

• Each cluster node
• acts as a peer in the P2P overlay
• maintains local indexes such as hash, B-trees
  and R-trees
• Index building
• when data are imported
• publish the index entries to different indexes
  based on P2P routing protocols

13
Index Search

• Optimization
• Index base table vs. Index covering plan
• index entries contain portion of data record
• support a wider range of queries than
  materialized views

14
Index Search

• Range search
• Process on index nodes in parallel
• Parallel scan of different indexes
• Facilitate correlated access across multiple
  indexes
• Especially useful for equi-join and range join
• Join order ?

15
Index Update

• Two steps
• Delete the old corresponding index entry
• Insert the new index entry
• Index consistency
• Based on requirements of applications
• Trade-off between performance and consistency
• strict enforcement of ACID properties
• less demanding bulk update

16
Performance Self-tuning

• Why?
• Optimize the performance of existing index nodes
  before launching new ones
• Complex setting of multiple indexes of different
  types
• Adaptively cache network connections
• Effectively buffer local indexes

17
Failure and Replication

• Failures in large clusters are common
• Replication of index data
• 24X7 service provision
• Correct retrieval of index data in the presence
  of failures
• Two-tier load adaptive replication 1
• first tier k copies for data reliability
• second tier replicas created adaptively with
  query load
• Replica consistency management
• Lost updates?
• System recovery from different types of failures

1 Towards Elastic Transactional Cloud Storage
with Range Query Support H.T. Vo, B.C. Ooi, C.
Chen. PVLDB 3(1) 506-517 (2010)
18
Evaluation

• Settings
• 64-node in-house cluster and EC2
• Storage service HDFS
• TPC-W (most experiments) and synthetically
  generated data set (bigger number of indexes and
  skewed data)
• Experiments
• Index plan vs. full table scan
• Index covering vs. Indexbase approach
• Multiple indexes of different types
• Handling skewed data
• Scalability on EC2 (up to 256 nodes)
• Other results (not covered in this talk)
• Effect of varying query rate
• Effect of varying data size
• Update performance
• Performance of equi-join and range join queries

19
Index plan vs. full table (parallel) scan

• Index plan performs much better than the full
  table scan approach
• Advantage of indexes being able to identify the
  data node that contains the qualified tuple
  quickly
• Table scan time increases almost linearly along
  with the data set size

20
Index covering vs. Indexbase approach

• Index covering outperforms indexbase when the
  size of result set is large
• Index covering index entries contains sufficient
  data for answering queries directly
• Indexbase is still useful compared to table scan

21
Multiple indexes of different types

• Generalized index is superior to
  one-overlay-per-index, and provides the much
  needed scalability
• Generalized index one index process maintains
  multiple indexes and self-tunes the performance
  via resource sharing.

22
Handling skewed data

• Storage load distribution
• Sampling-based data mapping can roughly estimate
  the data distribution and consequently, a certain
  percentage of nodes maintains an equivalent
  percentage of index data
• Execution load imbalance
• Sampling-based data mapping distributes data
  among nodes better and therefore, incoming
  queries on skewed data are also distributed
  better

23
Scalability on EC2

• Elastic scaling property
• More workload can be handled by adding more nodes
  into the system

24
Conclusions

• A simple yet efficient and extensible framework
  for supporting indexes in the cloud
• Main characteristics
• Support indexes using P2P overlays
• Provide high level abstraction for definition new
  indexes
• Main benefits
• Reduce index creation and maintenance cost
• Provide the much needed scalability
• multiple indexes of different types over
  distributed data

More info at epiC project http//www.comp.nus.edu.
sg/epiC
25
Thank you!
Questions Answers
