ECE 697B (667) Spring 2006 Synthesis and Verification of Digital Systems

1
ECE 697B (667)Spring 2006Synthesis and
Verificationof Digital Systems

• Verification
• Combinational Equivalence Checking

2
Equivalence Checking

• Two circuits are functionally equivalent if they
  exhibit the same behavior
• Combinational circuits
• for all possible input values

• Sequential circuits
• for all possible input sequences

3
Application of EC in mP Designs
4
Application of EC in ASIC Designs
5
Combinational Equivalence Checking

• Functional Approach
• transform output functions of combinational
  circuits into a unique (canonical) representation
• two circuits are equivalent if their
  representations are identical
• efficient canonical representation BDD
• Structural
• identify structurally similar internal points
• prove internal points (cut-points) equivalent
• find implications

6
Functional Equivalence

• Circuits for which BDD can be constructed
• represent multi-output circuits as shared BDDs
• BDDs must be identical (for the same variable
  ordering)

• Circuits whose BDDs are too large
• cannot construct BDDs, memory problem
• use partitioned BDD method
• decompose circuit into smaller pieces, each as
  BDD
• check equivalence of internal points (cut-point
  method)

7
EC Methods

• Structure-independent techniques
• exhaustive simulation
• decision diagrams (DD)
• Structure dependent techniques
• graph hashing
• SAT solvers including learning techniques

8
Functional (Structure-independent) Methods

• Decompose each function into functional blocks
• represent each block as a BDD (partitioned BDD
  method)
• define cut-points (z)
• verify equivalence of blocks at cut-points
• starting at primary inputs

9
Cutpoint-based EC
Cutpoints are used to partition the Miter

• Cutpoint guessing
• Compute net signature with random simulator
• Sort signatures select cutpoints
• Iteratively verify and refine cutpoints
• Verify outputs

10
Cut-Points Resolution Problem

• If all pairs of cut-points (z1,z2) are equivalent
• so are the two functions, F,G
• If intermediate functions (f2,g2) are not
  equivalent
• the functions (F,G) may still be equivalent
• this is called false negative

• Why do we have false negative ?
• functions are represented in terms of
  intermediate variables
• to prove/disprove equivalence must represent the
  functions in terms of primary inputs (BDD
  composition)

11
Cut-Point Resolution Theory

• Let f1(x)g1(x) ?x
• if f2(z,y) ? g2(z,y), ?z,y then f2(f1(x),y)
  ? g2(f1(x),y) ? F ? G
• if f2(z,y) ? g2(z,y), ?z,y ?? f2(f1(x),y)
  ? g2(f1(x),y) ? F ? G

We cannot say if F ? G or not

• False negative
• two functions are equivalent, but the
  verification algorithm declares them as different.

12
Cut-Point Resolution contd

• How to verify if negative is false or true ?

• Procedure 1 create a miter (XOR) between two
  potentially equivalent nodes/functions
• perform ATPG test for stuck-at 0
• find test pattern to prove F ? G
• efiicient for true negative
• (gives test vector, a proof)
• inefficient when there is no test

13
Cut-Point Resolution contd

• Procedure 2 create a BDD for F ? G
• perform satisfiability analysis (SAT) of the BDD
• if BDD for F ?G ?, problem is not
  satisfiable, false negative
• BDD for F ?G ? ?, problem is satisfiable, true
  negative

Note must compose BDDs until they are
equivalent, or expressed in terms of primary
inputs

• the SAT solution, if exists, provides a test
  vector (proof of non-equivalence) as in ATPG
• unlike the ATPG technique, it is effective for
  false negative (the BDD is empty!)

14
Structural Equivalence Check

• Given two circuits, each with its own structure
• identify similar internal points, cut sets
• exploit internal equivalences
• False negative problem may arise
• F ?? G, but differ structurally (different local
  support)
• verification algorithm declares F,G as different

• Solution use BDD-based or ATPG-based methods to
  resolve the problem. Also implication, learning
  techniques.

15
Implication Techniques

• Techniques that extract and exploit internal
  correspondences to speed up verification
• Implications direct and indirect

Direct a1 ? f0
Indirect (learning) f1 ? a0
16
Learning Techniques

• Learning
• process of deriving indirect implications
• Recursive learning
• recursively analyzes effects of each
  justification
• Functional learning
• uses BDDs to learn indirect implications

G1 ? H0
17
Learning Techniques contd

• Other methods to check implications G1 ? H0
• Build a BDD for G H
• If this function is satisfiable, the implication
  holds and gives a test vector
• Otherwise it does not hold
• Since G1 ? H0 ? (GH)1, build a BDD for
  (GH)
• The implication holds if (GH)1 (tautology)

18
Summary

• Industrial EC checkers almost exclusively use a
  combinational EC paradigm
• sequential EC is too complex, can only be applied
  to design with a few hundred state bits
• combinational methods scale linearly with the
  design size for a given fixed size and
  functional complexity of the individual cones
• Still, pure BDDs and plain SAT solvers cannot
  handle all logic cones
• BDDs can be built for about 80 of the cones of
  high-speed designs
• less for complex ASICs
• plain SAT blows up on a Miter structure
• Contemporary method highly exploit structural
  similarity of designs to be compared
