Particle Resuspension Model for Indoor Air Quality Applications

1
Particle Resuspension Model for Indoor Air
Quality Applications

• Goodarz Ahmadi
• Clarkson University
• Potsdam, NY 13699
• ahmadi_at_clarkson.edu

2
Outline

• Motivation and Objectives
• Adhesion and Detachment of Particles with
  elastic and
• plastic deformation
• Particle Adhesion and Detachment with
  Capillary and
• Electrostatic Forces
• Particle Removal from Rough Surfaces
• - Small Roughness
• Bumpy Particles
• Highly Rough Surfaces
• Particle Removal due to Human Walking
• - Model Description
• - Sample Results
• Conclusions and Future work

3
Motivation and general Objectives

• Concentrations of particle pollutants in the
  indoor environment are often higher than outdoor.
  Particle resuspension due to human activity is
  expected to be one cause for the increase in PM.
• Primary goal of this thrust is to provide
  quantitative understanding of the contribution of
  particle resuspension to PM concentration in
  the indoor environment

4
Specific Objectives

• Develop a particle detachment/re-suspension
  model for spherical and non-spherical particles
  from surfaces in the presence of capillary and
  electrostatic forces for indoor air quality
  applications.
• To validate the detachment/re-suspension
  model.
• To Develop a user defines subroutine for
  implementation of the model in the CFD codes.
• To asses the contribution of the resuspension
  to the increase in indoor PM concentration due
  to human activities.

5
Particle Resuspension from Smooth Surfaces
Forces Acting on a Particle

• Rolling Detachment
• Elastic and Plastic Deformations

6
JKR Adhesion Model
Maximum Resistance to Rolling
Thermodynamic Work of Adhesion
Composite Young Modulus
7
DMT and Maugis-Pollock Adhesion Model
Maximum Resistance to Rolling (DMT)
Maximum Resistance to Rolling (MP)
8
Particle Resuspension
Model Predictions Results
Critical shear velocities for particle
resuspension as predicted by different adhesion
models.
9
Particle Resuspension
Model Predictions Results
Critical shear velocities for particle
resuspension as predicted by different adhesion
models.
10
Particle Resuspension
Model Predictions Results
Comparison of the model predcition with the
experimental data of Taheri and Bragg 39 (?)
and Ibrahim et al. 40 (?).
11
Particle Resuspension
Model Predictions Results
Comparison of the model predictions with the
experimental data of Zimon 38 (?), Ibrahim et
al. 40 (?) and Ibrahim et al. 41 (?).
12
Resuspension of Rough Particles
Rough Particle
Rough Surface
13
Resuspension of Rough Particles
Comparison of the critical shear velocities as
predicted by the burst model with the
experimental data of Zimon 38
14
Bumpy Particles
Bumpy particle model of compact irregular
particles
15
Electrostatic Forces for Bumpy Particles
Charge
Hays
16
Bumpy Particles
Critical shear velocities for bumpy particle
resuspension in the presence of capillary and
electrostatic forces.
17
Bumpy Particles
Critical shear velocities for bumpy particle
resuspension in the presence of capillary and
electrostatic forces.
18
Bumpy Particles
Critical shear velocities for bumpy particle
resuspension in the presence of capillary and
electrostatic forces.
19
Bumpy Particles
Critical shear velocities for bumpy particle
resuspension in the presence of capillary and
electrostatic forces.
20
Bumpy Particles
Comparison of the critical electric field with
the experimental data of Hays (1978)
21
Resuspension form Highly Rough Surfaces
Hydrodynamic Forces
Adhesion Force
22
Sample Surface and Airflow
Velocity (m/s) Contours over a Randomly generated
surface with a roughness value of 5 micron.
23
Sample Particle Removal
24
Removal Areas for 2.5 µm Particles
V5m/s
25
Particles Pairs Removal
26
A Model for Particle Resuspension by Walking

• Assumptions
• Shoe floor contact is modeled as two circular
  disk.
• Squeezed film and wall jet models are used
  for the air flow velocity.
• Step down and up in the gait cycle are
  treated.
• Particle re-deposition is accounted for.

27
Evaluation of Squeezing Velocity
Inside Foot Area (r lt R)
Outside Foot Area (r gt R)
28
A Model for Particle Resuspension by Walking
Critical radius for particle detachment for
rolling detachment mechanisms at stepping down
process.
29
Particle Resuspension
h2.3
t (min)
Comparison of the predicted particle
concentration with the experimental data of Ferro
and Qian (2006) for hard floor.
30
Conclusions

• A particle resuspension model from smooth and
  rough surfaces in presence of capillary force
  and electrostatic forces was developed.
• The model was applied to particle resuspension
  in indoor environment due to human activities.
• Preliniary comparisons with experimental data
  was performed.

31
Future Work

• Validate the model against additional data.
• Perform detailed analysis of particle
  resuspenion in indoor environment due to human
  activities.
• Develop detailed effect of large surface
  roughness on particle resuspension.
• Develop a user defines subroutine for
  implementation of the model in the CFD codes.
• Develop a model for resuspension form
  carpeted surfaces.
