Ergonomics and Work-related Upper Extremity Disorders (WRUED)

1
Ergonomics andWork-related Upper Extremity
Disorders (WRUED)
Grace Szeto Year 3 Ergonomics April 2002
2
Work-related Upper Extremity Disorders (WRUED)

• Cumulative Trauma Disorders (CTD) Repetitive
  Strain Injury (RSI)
• Work-Related Musculoskeletal disorders (WMSD)
• Work-related Neck and Upper Limb Disorders
  (WRNULD)
• Occupational Cervicobrachial Disorders (OCD)
• Tension Neck Syndrome (TNS)
• Adverse Mechanical Tension (AMT)

3
Epidemiological Studies on CTD

• Bureau of Labour Statistics (U.S.)
• gt300,000 cases reported in private industry
  (1993)
• 42,600 cases from motor vehicle and equipment
  manufacturing
• 38,300 from meat-packing
• CTS cases Days away from work 4.8 cases per
  10,000 workers (1994)
• CTS figures even greater than back pain

4
NIOSH /ergo science/chapter1-6

• Detailed reviews of all studies on MSD/CTD
• Incidence rates/prevalence varies depending on
  definition of symptoms, or results of physical
  examination
• TNS among male industrial workers in US is 4.9
  by interviews, 1.4 by O/E
• Previous studies reported as high as 50-85
  (Silverstein et al, 1987, Hales et al, 1994,
  Bernard et al, 1993)

5
US statistics of injuries due to repetitive motion

• 1994 Bureau of Labour Statistics
• All manufacturing - 49278 cases
• All private industries - 92576 cases
• Low back injuries of repetitive nature are
  included in this category (different in HK)

6
Sommerich et al (1993)

• Summarised injury rates in shoulder region CTD
• Newspaper workers (VDU) 11 (Burt et al, 1990),
• Rotator Cuff Tendinitis in shipyard welders 18.3
  and 2 in office clerks (Herbert et al, 1984),
• 15 in grocery store checkers and 4 in
  non-checkers (Baron et al, 1990)

7
Study in Hong Kong (Siu and Chan, 1998)

• 688 office workers surveyed
• 57 neck or shoulder complaints
• 48 back complaints
• pain, ache, soreness, numbness, cramping and
  tiring
• 67 reported gt4 hours VDU work daily
• Significant relationship between incidence of MSK
  discomfort and?VDU work
• http//www.oshc.org.hk/eng/research/research.htm

8
Number of Confirmed Occupational Diseases in
1998-1999 Occupational Disease
1998 1999 Compressed Air Illness
3 3 Tenosynovitis
of Hand or Forearm 71 54
Carpal Tunnel Syndrome
0 1 Tuberculosis
39 57 Streptococcus suis
Infection 0 1
Occupational Dermatitis
34 21 Chemical Induced Upper Respiratory
Tract Inflammation 4 0
Silicosis
104 137 Asbestos-Related Disease
5 15 Occupational Deafness
631 388 Gas
Poisoning1 57
57 Total
948 734
(Figures from OSHC Hong Kong)
9
(No Transcript)
10
Occupational Diseases vs Industrial Accidents

• Traumatic injuries resulting from accidents
• occupational disease - disease/condition caused
  by certain occupation
• Upper limb problems usually classified under
  occupational diseases
• Back injuries resulting from lifting - classified
  under industrial accidents

11
Specific Syndromes include

• Cervical spine problems
• Rotator cuff tendonitis
• Lateral epicondylitis
• Carpal tunnel syndrome
• de Quervains syndrome
• tenosynovitis of forearm muscles
• nerve entrapments
• thoracic outlet syndrome
• vibration white fingers

12
Ergonomics in Manufacturing (Karwowski
Salvendy, ed), Chapter 16 An overview of upper
extremity disorders, S. Moore

• 5 conditions
• trigger finger/thumb
• de Quervains syndrome
• peritendinitis
• lateral epicondylitis
• carpal tunnel syndrome
• Cervical and shoulder conditions are excluded
• industrial - repetitive nature of work

13
Interpreting Epidemiological Studies

• Needs to know population studied, how condition
  is defined, how data is collected
• By interviews, questionaires (subjective)
• Days away from work
• Physical examination findings/ x-rays
• Physical diagnosis
• Discomfort? pain? Stiffness? Ache?
• Exact number is not important, rather the
  RELATIVE SIGNIFICANCE

14
RSI and Office Workers

• Hours of continuous VDU work
• Improved computer technology
• Long hours of static posture
• Light-touch, highly responsive keyboards
• Use of numeric keypad - Data entry
• Use of mouse - graphic design, drafting
• Hi-tech transfer or storage of information,
  replace filing/photocopying

15
Industrial Workers in Highly RepetitiveTasks

• Assembly line workers -e.g. electronic parts
• Packaging workers
• Factory workers - clothing, toy industries
• Use of hand tools- grip size, handle length
• Repetitive nature, speed and force of movements,
  joint angles-
• Affect length-tension relationship of muscles
• In Hong Kong- can you think of some local
  professions that may be prone to RSI?

16
RSI/CTD in other activities

• Musicians - piano players and string instruments
• Sports players - depend on activity and equipment
• Housewives
• Teenagers playing computer games
• Gardeners - gardening tools
• Same risk factors - speed, force, repetition,
  frequency and experience

17
Common Symptoms in RSI/CTD

• Pain - localised or referred
• Swelling - esp. in tenosynovitis - can resemble
  compartment syndrome
• Tenderness
• Weakness - can be generalised or specific
  muscles, loss of grip strength
• Headache, migraines
• Neurological symptoms - PN, sensation, power or
  reflex changes

18
O/E Findings

• Decreased ROM
• Decreased muscle power
• Tenderness on palpation
• Postural changes - poking chin
• Muscle imbalance
• ve neural tension tests
• Are subjective complaints consistent with
  objective signs?
• ?Previous injuries or underlying conditions

19
Sites and Nature of Pathology

• Neck tension neck syndrome (mechanical),
  cervical radiculopathy, degenerative changes etc
• Shoulder muscle tension (Cx related), tendinitis
• Elbow lateral or medial epicondylitis
• Wrist tendinitis, tenosynovitis, neuritis
  (carpal tunnel syndrome)

20
Neck Problems

• Tension neck syndromes
• Cervical syndromes
• Cervicogenic headaches
• Cervical nerve root syndromes
• Brachial plexus sydromes
• Trapezius myalgia
• Pain in the neck radiating to head, shoulders,
  part of or whole upper limb

21
Neck Probelms

• /- Existing degenerative changes in Cx
• Poor posture - poking chin
• Sustained forward flexion, or combined F/SF/R
• Most kinds of work involve looking down and
  head held in fixed positions
• Sudden movements, repetitive movements of head,
  or upper limbs - strain in stabilising muscles in
  neck-shoulder region

22
Neck Problems - Research Evidence

• EMG studies - Trapezius
• Sustained abduction of the arms produced muscle
  fatigue in Trapezius - worse in patients with
  neck-shoulder pain (Hagberg, 1981)
• Muscle blood flow (muscle biopsy) and EMG
  activity are worse (decreased) in painful side vs
  non-painful sides (Larsson et al, 1994)
• Compressive loading at C7T13.6x higher in full
  flexion than upright posture

23
Who get Neck Problems?

• Office workers - long hours of VDU work
• Problem with Monitor height, position, visual
  acuity
• Fine hand movements - stabilising muscles in neck
  and shoulders
• Workers who maintain their necks in flexion for
  long periods of time
• Lifting with both arms - prolonged, or lifting
  above shoulder height

24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Study on effects of static posture on performance
of keyboard task
28
(No Transcript)
29
(No Transcript)
30
Upper Limb Problems

• Tendinitis, Degenerative changes in tendons,
  impingement in rotator cuff muscles
• Scapular muscles - tightness in u. trap and
  levator scapulae, weakness in lower trap,
  rhomboids and serratus anterior
• Elbow - epicondylitis - medial and lateral
• Forearm muscles - tenosynovitis
• Thoracic outlet syndrome
• Rule out cervical and ULTT problems first

31
Problem of Neural Tension

• Became widely recognised around the same time as
  RSI
• ULTT/Brachial Plexus tests - developed by
  clinicians in 70s-80s
• Australia - some clinicians treat RSI cases only
  with brachial plexus techniques

32
Common Pathology

• Repetitive sliding of tendons in tendon sheaths
  -inflammation ? Tenosynovitis
• Awkward posture of joint (wrist) - cause
  compression of neural tissues / tendons ?CTS
• Forceful muscle actions - micro-tearing at
  tendon-bone interface ? tendinitis, tendonosis,
  traction spur
• Static isometric contractions - transient
  ischaemia in muscles, or compression on
  structures
• Adverse Mechanical Tension - muscles / joints
  working in awdward angles or adverse positions

33
(No Transcript)
34
Carpal Tunnel Syndrome (CTS)

• Pathology irritation of median nerve at the
  wrist, usually due to compression by or
  inflammation of flexor retinaculum
• Symptoms
• numbness, tingling /-burning in the thumb, index
  and middle fingers
• Loss of sensation in fingers
• Loss of grip strength
• Feeling of swollen fingers

35
Carpal Tunnel Syndrome (CTS)

• Objective Examination
• Tinels test - tapping the median nerve
• Phalens test - full flexion of wrist
• Palpation, observation
• Neurological exam
• Differentiation from Cx problems and local joint
  problems

36
Diagnostic tests

• EMG test nerve conduction velocity
• Vibrometrymeasure vibration sense in range from
  8 to 500 Hz
• Neurometry neurometer is use to assess sensory
  impairment

37
Who get CTS ?

• Office workers - keyboard work - resting wrists
  at edge of table, or holding wrist in excessive
  extension
• Industrial workers - highly repetitive movements,
  awkward hand postures
• Use of small hand tools - small grip size and
  awkward wrist positions - Dental technicians,
  electricians
• Carrying objects (e.g. large piece of glass,
  books)
• Vibrations, e.g. welders, power tools, drivers

38
Other medical conditions that may cause CTS

• Pregnancy
• Rheumatoid arthritis and other rheumatic diseases
• Obesity
• Diabetes
• Hypothyroidism
• trauma (fractures etc)

39
Tenosynovitis of forearm

• Recognised occupational disease
• repetitive actions of wrist / hand
• related to compression of blood vessels with
  prolonged contractions of muscles
• SS swelling, pain, ?ROM of wrist/hand, ?strength

40
Common Pathology

• Repetitive sliding of tendons in tendon sheaths
  -inflammation - Tenosynovitis
• Awkward posture of joint (wrist) - cause
  compression of neural tissues / tendons
• Forceful muscle actions - micro-tearing at
  tendon-bone interface
• Static isometric contractions - transient
  ischaemia in muscles, or compression on
  structures
• Adverse Mechanical Tension - muscles / joints
  working in awdward angles or adverse positions

41
De Quervains Syndrome

• Tendinitis of long abductor and short extensor
  tendons of the thumb, in the area of anatomical
  snuffbox
• Caused by repetitive frictions between thumb
  tendons and common tendon sheaths, running over
  bony areas
• Repetitive (forceful) pinching actions combined
  with flicking of wrist (e.g. scissors, pliers)
• Gardener - use of clippers
• Typists - excessive use of thumb, use of mouse

42
(No Transcript)
43
Ganglions around tendons
44
Vibration Syndrome

• Common problem in workers who use power tools
• Affected by duration of use and magnitude of
  vibration
• Symptoms include paraesthesia, loss of sensation,
  loss of fine co-ordination in fingers
• Can lead to carpal tunnel syndrome,
  tenosynovitis, nerve compression and damage,
  Vibration white fingers

45
Occupational Risk Factors

• Posture - prolonged static posture, awkward
  posture
• External Load
• Speed
• Force
• Repetitiveness (action frequency)- combined wrist
  movts e.g.F, UD, pron/sup
• Personal characteristics
• Skills and experience of worker-work technique

46
Machine operator with hand in awkward position
Ganglions around extensor tendons
47
What do these motions have in common?
48
(No Transcript)
49
3 Main Risk Factors for most work-related
musculoskeletal problems

• 1. Frequency, speed, repetitiveness
• (technical actions)
• 2. Force
• 3. Postures and movements
• (whole body and/or specific joints)

50
Office Work vs Industrial Work

• Industrial Work
• More distinct repetitive actions
• Easier to separate into technical actions
• Higher force
• Movements may be large or small
• Posture - may be static or dynamic
• Easier to quantify movements

• Office Work
• Movements very fine, less distinct, more
  difficult to quantify
• Static sustained posture of upper body
• Fine movements of hands
• Low force
• Easier to measure posture but difficult to
  measure movements

51
The RSI Epidemic

• Significant increase in compensation claims in
  large corporations such as Aust. Telecom in
  1970-1980s
• Heated debate in media, public and among medical
  professionals
• RSI - is it in the head or in the hand?
• Among physio., argument whether this is a
  cervical problem, ULTT, or muscle problem
• Criticism of the name RSI

52
Psychological Impact

• Some researchers try to establish certain psy.
  profiles or personality types assoc. with RSI
• Small of cases can be Malingerers
• Dx like RSI or LBP can lead to stereotyping -
  workers who are genuine are also put in the same
  category as malingerers
• Pressure from employer to return to work
• Peer Pressure from other employees
• Pressure from within - fear of further injury to
  self

53
Intervention Programs

• Workstation Modifications
• Worker Education - manual handling techniques
• Work Modifications- improve work habits and use
  of tools / aids
• Job Rotation
• Introduce Mini Work Breaks - Stretch Exercise
  breaks
• Remove stressful situations-improve job
  satisfaction

54
Work Rehabilitation Programs

• Physiotherapy Assessment and Treatment
• (/-) OT Assessment and Treatment
• General conditioning and fitness training
• Work hardening
• Graduated Return-to-work Programs

55
Summary

• WRMSD are problems characteristic of hi-tech
  culture - use of computers, industrial
  specialisation
• Terms highlight the work-relatedness of these
  conditions, include whole range of neck and upper
  limb conditions
• Important to examine patient and identify
  specific problems and pathology
• Identify risk factors
• Improvements in work situations is an important
  part in the rehabilitation program
