Overview of Assembly Language

1
Overview of Assembly Language

• Chapter 9
• S. Dandamudi

2
Outline

• Assembly language statements
• Data allocation
• Where are the operands?
• Addressing modes
• Register
• Immediate
• Direct
• Indirect
• Data transfer instructions
• mov, xchg, and xlat
• PTR directive

• Overview of assembly language instructions
• Arithmetic
• Conditional
• Logical
• Shift
• Rotate
• Defining constants
• EQU and directives
• Macros
• Illustrative examples

3
Assembly Language Statements

• Three different classes
• Instructions
• Tell CPU what to do
• Executable instructions with an op-code
• Directives (or pseudo-ops)
• Provide information to assembler on various
  aspects of the assembly process
• Non-executable
• Do not generate machine language instructions
• Macros
• A shorthand notation for a group of statements
• A sophisticated text substitution mechanism with
  parameters

4
Assembly Language Statements (contd)

• Assembly language statement format
• label mnemonic operands comment
• Typically one statement per line
• Fields in are optional
• label serves two distinct purposes
• To label an instruction
• Can transfer program execution to the labeled
  instruction
• To label an identifier or constant
• mnemonic identifies the operation (e.g., add, or)
• operands specify the data required by the
  operation
• Executable instructions can have zero to three
  operands

5
Assembly Language Statements (contd)

• comments
• Begin with a semicolon () and extend to the end
  of the line
• Examples
• repeat inc result increment result
• CR EQU 0DH carriage return character
• White space can be used to improve readability
• repeat
• inc result

6
Data Allocation

• Variable declaration in a high-level language
  such as C
• char response
• int value
• float total
• double average_value
• specifies
• Amount storage required (1 byte, 2 bytes, )
• Label to identify the storage allocated
  (response, value, )
• Interpretation of the bits stored (signed,
  floating point, )
• Bit pattern 1000 1101 1011 1001 is interpreted as
• -29,255 as a signed number
• 36,281 as an unsigned number

7
Data Allocation (contd)

• In assembly language, we use the define directive
• Define directive can be used
• To reserve storage space
• To label the storage space
• To initialize
• But no interpretation is attached to the bits
  stored
• Interpretation is up to the program code
• Define directive goes into the .DATA part of the
  assembly language program
• Define directive format
• var-name D? init-value ,init-value,...

8
Data Allocation (contd)

• Five define directives
• DB Define Byte allocates 1 byte
• DW Define Word allocates 2 bytes
• DD Define Doubleword allocates 4 bytes
• DQ Define Quadword allocates 8 bytes
• DT Define Ten bytes allocates 10 bytes
• Examples
• sorted DB y
• response DB ? no initialization
• value DW 25159
• float1 DD 1.234
• float2 DQ 123.456

9
Data Allocation (contd)

• Multiple definitions can be abbreviated
• Example
• message DB B
• DB y
• DB e
• DB 0DH
• DB 0AH
• can be written as
• message DB B,y,e,0DH,0AH
• More compactly as
• message DB Bye,0DH,0AH

10
Data Allocation (contd)

• Multiple definitions can be cumbersome to
  initialize data structures such as arrays
• Example
• To declare and initialize an integer array of 8
  elements
• marks DW 0,0,0,0,0,0,0,0
• What if we want to declare and initialize to zero
  an array of 200 elements?
• There is a better way of doing this than
  repeating zero 200 times in the above statement
• Assembler provides a directive to do this (DUP
  directive)

11
Data Allocation (contd)

• Multiple initializations
• The DUP assembler directive allows multiple
  initializations to the same value
• Previous marks array can be compactly declared as
• marks DW 8 DUP (0)
• Examples
• table1 DW 10 DUP (?) 10 words,
  uninitialized
• message DB 3 DUP (Bye!) 12 bytes,
  initialized
• as
  Bye!Bye!Bye!
• Name1 DB 30 DUP (?) 30 bytes, each
• initialized
  to ?

12
Data Allocation (contd)

• The DUP directive may also be nested
• Example
• stars DB 4 DUP(3 DUP (),2 DUP (?),5 DUP
  (!))
• Reserves 40-bytes space and initializes it as
• ??!!!!!??!!!!!??!!!!!??!!!!!
• Example
• matrix DW 10 DUP (5 DUP (0))
• defines a 10X5 matrix and initializes its
  elements to 0
• This declaration can also be done by
• matrix DW 50 DUP (0)

13
Data Allocation (contd)

• Symbol Table
• Assembler builds a symbol table so we can refer
  to the allocated storage space by the associated
  label
• Example
• .DATA name offset
• value DW 0 value 0
• sum DD 0 sum 2
• marks DW 10 DUP (?) marks 6
• message DB The grade is,0 message 26
• char1 DB ? char1 40

14
Data Allocation (contd)

• Correspondence to C Data Types
• Directive C data type
• DB char
• DW int, unsigned
• DD float, long
• DQ double
• DT internal intermediate
• float value

15
Data Allocation (contd)

• LABEL Directive
• LABEL directive provides another way to name a
  memory location
• Format
• name LABEL type
• type can be
• BYTE 1 byte
• WORD 2 bytes
• DWORD 4 bytes
• QWORD 8 bytes
• TWORD 10 bytes

16
Data Allocation (contd)

• LABEL Directive
• Example
• .DATA
• count LABEL WORD
• Lo-count DB 0
• Hi_count DB 0
• .CODE...
• mov Lo_count,AL
• mov Hi_count,CL
• count refers to the 16-bit value
• Lo_count refers to the low byte
• Hi_count refers to the high byte

17
Where Are the Operands?

• Operands required by an operation can be
  specified in a variety of ways
• A few basic ways are
• operand in a register
• register addressing mode
• operand in the instruction itself
• immediate addressing mode
• operand in memory
• variety of addressing modes
• direct and indirect addressing modes
• operand at an I/O port
• discussed in Chapter 19

18
Where Are the Operands? (contd)

• Register addressing mode
• Operand is in an internal register
• Examples
• mov EAX,EBX 32-bit copy
• mov BX,CX 16-bit copy
• mov AL,CL 8-bit copy
• The mov instruction
• mov destination,source
• copies data from source to destination

19
Where Are the Operands? (contd)

• Register addressing mode (contd)
• Most efficient way of specifying an operand
• No memory access is required
• Instructions using this mode tend to be shorter
• Fewer bits are needed to specify the register
• Compilers use this mode to optimize code
• total 0
• for (i 1 to 400)
• total total marksi
• end for
• Mapping total and i to registers during the for
  loop optimizes the code

20
Where Are the Operands? (contd)

• Immediate addressing mode
• Data is part of the instruction
• Ooperand is located in the code segment along
  with the instruction
• Efficient as no separate operand fetch is needed
• Typically used to specify a constant
• Example
• mov AL,75
• This instruction uses register addressing mode
  for destination and immediate addressing mode for
  the source

21
Where Are the Operands? (contd)

• Direct addressing mode
• Data is in the data segment
• Need a logical address to access data
• Two components segmentoffset
• Various addressing modes to specify the offset
  component
• offset part is called effective address
• The offset is specified directly as part of
  instruction
• We write assembly language programs using memory
  labels (e.g., declared using DB, DW, LABEL,...)
• Assembler computes the offset value for the label
• Uses symbol table to compute the offset of a label

22
Where Are the Operands? (contd)

• Direct addressing mode (contd)
• Examples
• mov AL,response
• Assembler replaces response by its effective
  address (i.e., its offset value from the symbol
  table)
• mov table1,56
• table1 is declared as
• table1 DW 20 DUP (0)
• Since the assembler replaces table1 by its
  effective address, this instruction refers to the
  first element of table1
• In C, it is equivalent to
• table10 56

23
Where Are the Operands? (contd)

• Direct addressing mode (contd)
• Problem with direct addressing
• Useful only to specify simple variables
• Causes serious problems in addressing data types
  such as arrays
• As an example, consider adding elements of an
  array
• Direct addressing does not facilitate using a
  loop structure to iterate through the array
• We have to write an instruction to add each
  element of the array
• Indirect addressing mode remedies this problem

24
Where Are the Operands? (contd)

• Indirect addressing mode
• The offset is specified indirectly via a register
• Sometimes called register indirect addressing
  mode
• For 16-bit addressing, the offset value can be in
  one of the three registers BX, SI, or DI
• For 32-bit addressing, all 32-bit registers can
  be used
• Example
• mov AX,BX
• Square brackets are used to indicate that BX
  is holding an offset value
• BX contains a pointer to the operand, not the
  operand itself

25
Where Are the Operands? (contd)

• Using indirect addressing mode, we can process
  arrays using loops
• Example Summing array elements
• Load the starting address (i.e., offset) of the
  array into BX
• Loop for each element in the array
• Get the value using the offset in BX
• Use indirect addressing
• Add the value to the running total
• Update the offset in BX to point to the next
  element of the array

26
Where Are the Operands? (contd)

• Loading offset value into a register
• Suppose we want to load BX with the offset value
  of table1
• We cannot write
• mov BX,table1
• Two ways of loading offset value
• Using OFFSET assembler directive
• Executed only at the assembly time
• Using lea instruction
• This is a processor instruction
• Executed at run time

27
Where Are the Operands? (contd)

• Loading offset value into a register (contd)
• Using OFFSET assembler directive
• The previous example can be written as
• mov BX,OFFSET table1
• Using lea (load effective address) instruction
• The format of lea instruction is
• lea register,source
• The previous example can be written as
• lea BX,table1

28
Where Are the Operands? (contd)

• Loading offset value into a register (contd)
• Which one to use -- OFFSET or lea?
• Use OFFSET if possible
• OFFSET incurs only one-time overhead (at assembly
  time)
• lea incurs run time overhead (every time you run
  the program)
• May have to use lea in some instances
• When the needed data is available at run time
  only
• An index passed as a parameter to a procedure
• We can write
• lea BX,table1SI
• to load BX with the address of an element of
  table1 whose index is in SI register
• We cannot use the OFFSET directive in this case

29
Default Segments

• In register indirect addressing mode
• 16-bit addresses
• Effective addresses in BX, SI, or DI is taken as
  the offset into the data segment (relative to DS)
• For BP and SP registers, the offset is taken to
  refer to the stack segment (relative to SS)
• 32-bit addresses
• Effective address in EAX, EBX, ECX, EDX, ESI, and
  EDI is relative to DS
• Effective address in EBP and ESP is relative to
  SS
• push and pop are always relative to SS

30
Default Segments (contd)

• Default segment override
• Possible to override the defaults by using
  override prefixes
• CS, DS, SS, ES, FS, GS
• Example 1
• We can use
• add AX,SSBX
• to refer to a data item on the stack
• Example 2
• We can use
• add AX,DSBP
• to refer to a data item in the data segment

31
Data Transfer Instructions

• We will look at three instructions
• mov (move)
• Actually copy
• xchg (exchange)
• Exchanges two operands
• xlat (translate)
• Translates byte values using a translation table
• Other data transfer instructions such as
• movsx (move sign extended)
• movzx (move zero extended)
• are discussed in Chapter 12

32
Data Transfer Instructions (contd)

• The mov instruction
• The format is
• mov destination,source
• Copies the value from source to destination
• source is not altered as a result of copying
• Both operands should be of same size
• source and destination cannot both be in memory
• Most Pentium instructions do not allow both
  operands to be located in memory
• Pentium provides special instructions to
  facilitate memory-to-memory block copying of data

33
Data Transfer Instructions (contd)

• The mov instruction
• Five types of operand combinations are allowed
• Instruction type Example
• mov register,register mov DX,CX
• mov register,immediate mov BL,100
• mov register,memory mov BX,count
• mov memory,register mov count,SI
• mov memory,immediate mov count,23
• The operand combinations are valid for all
  instructions that require two operands

34
Data Transfer Instructions (contd)

• Ambiguous moves PTR directive
• For the following data definitions
• .DATA
• table1 DW 20 DUP (0)
• status DB 7 DUP (1)
• the last two mov instructions are ambiguous
• mov BX,OFFSET table1
• mov SI,OFFSET status
• mov BX,100
• mov SI,100
• Not clear whether the assembler should use byte
  or word equivalent of 100

35
Data Transfer Instructions (contd)

• Ambiguous moves PTR directive
• The PTR assembler directive can be used to
  clarify
• The last two mov instructions can be written as
• mov WORD PTR BX,100
• mov BYTE PTR SI,100
• WORD and BYTE are called type specifiers
• We can also use the following type specifiers
• DWORD for doubleword values
• QWORD for quadword values
• TWORD for ten byte values

36
Data Transfer Instructions (contd)

• The xchg instruction
• The syntax is
• xchg operand1,operand2
• Exchanges the values of operand1 and operand2
• Examples
• xchg EAX,EDX
• xchg response,CL
• xchg total,DX
• Without the xchg instruction, we need a temporary
  register to exchange values using only the mov
  instruction

37
Data Transfer Instructions (contd)

• The xchg instruction
• The xchg instruction is useful for conversion of
  16-bit data between little endian and big endian
  forms
• Example
• mov AL,AH
• converts the data in AX into the other endian
  form
• Pentium provides bswap instruction to do similar
  conversion on 32-bit data
• bswap 32-bit register
• bswap works only on data located in a 32-bit
  register

38
Data Transfer Instructions (contd)

• The xlat instruction
• The xlat instruction translates bytes
• The format is
• xlatb
• To use xlat instruction
• BX should be loaded with the starting address of
  the translation table
• AL must contain an index in to the table
• Index value starts at zero
• The instruction reads the byte at this index in
  the translation table and stores this value in AL
• The index value in AL is lost
• Translation table can have at most 256 entries
  (due to AL)

39
Data Transfer Instructions (contd)

• The xlat instruction
• Example Encrypting digits
• Input digits 0 1 2 3 4 5 6 7 8 9
• Encrypted digits 4 6 9 5 0 3 1 8 7 2
• .DATA
• xlat_table DB 4695031872
• ...
• .CODE
• mov BX,OFFSET xlat_table
• GetCh AL
• sub AL,0 converts input character to index
• xlatb AL encrypted digit character
• PutCh AL
• ...

40
Pentium Assembly Instructions

• Pentium provides several types of instructions
• Brief overview of some basic instructions
• Arithmetic instructions
• Jump instructions
• Loop instruction
• Logical instructions
• Shift instructions
• Rotate instructions
• These instructions allow you to write reasonable
  assembly language programs

41
Arithmetic Instructions

• INC and DEC instructions
• Format
• inc destination dec destination
• Semantics
• destination destination /- 1
• destination can be 8-, 16-, or 32-bit operand, in
  memory or register
• No immediate operand
• Examples
• inc BX
• dec value

42
Arithmetic Instructions (contd)

• Add instructions
• Format
• add destination,source
• Semantics
• destination destination source
• Examples
• add EBX,EAX
• add value,35
• inc EAX is better than add EAX,1
• inc takes less space
• Both execute at about the same speed

43
Arithmetic Instructions (contd)

• Add instructions
• Addition with carry
• Format
• adc destination,source
• Semantics
• destination destination source CF
• Example 64-bit addition
• add EAX,ECX add lower 32 bits
• adc EBX,EDX add upper 32 bits with carry
• 64-bit result in EBXEAX

44
Arithmetic Instructions (contd)

• Subtract instructions
• Format
• sub destination,source
• Semantics
• destination destination - source
• Examples
• sub EBX,EAX
• sub value,35
• dec EAX is better than sub EAX,1
• dec takes less space
• Both execute at about the same speed

45
Arithmetic Instructions (contd)

• Subtract instructions
• Subtract with borrow
• Format
• sbb destination,source
• Semantics
• destination destination - source - CF
• Like the adc, sbb is useful in dealing with more
  than 32-bit numbers
• Negation
• neg destination
• Semantics
• destination 0 - destination

46
Arithmetic Instructions (contd)

• CMP instruction
• Format
• cmp destination,source
• Semantics
• destination - source
• destination and source are not altered
• Useful to test relationship (gt, ) between two
  operands
• Used in conjunction with conditional jump
  instructions for decision making purposes
• Examples
• cmp EBX,EAX cmp count,100

47
Unconditional Jump

• Format
• jmp label
• Semantics
• Execution is transferred to the instruction
  identified by label
• Target can be specified in one of two ways
• Directly
• In the instruction itself
• Indirectly
• Through a register or memory
• Discussed in Chapter 12

48
Unconditional Jump (contd)

• Example
• Two jump instructions
• Forward jump
• jmp CX_init_done
• Backward jump
• jmp repeat1
• Programmer specifies target by a label
• Assembler computes the offset using the symbol
  table

• . . .
• mov CX,10
• jmp CX_init_done
• init_CX_20
• mov CX,20
• CX_init_done
• mov AX,CX
• repeat1
• dec CX
• . . .
• jmp repeat1
• . . .

49
Unconditional Jump (contd)

• Address specified in the jump instruction is not
  the absolute address
• Uses relative address
• Specifies relative byte displacement between the
  target instruction and the instruction following
  the jump instruction
• Displacement is w.r.t the instruction following
  jmp
• Reason IP points to this instruction after
  reading jump
• Execution of jmp involves adding the displacement
  value to current IP
• Displacement is a signed 16-bit number
• Negative value for backward jumps
• Positive value for forward jumps

50
Target Location

• Inter-segment jump
• Target is in another segment
• CS target-segment (2 bytes)
• IP target-offset (2 bytes)
• Called far jumps (needs five bytes to encode jmp)
• Intra-segment jumps
• Target is in the same segment
• IP IP relative-displacement (1 or 2 bytes)
• Uses 1-byte displacement if target is within -128
  to 127
• Called short jumps (needs two bytes to encode
  jmp)
• If target is outside this range, uses 2-byte
  displacement
• Called near jumps (needs three bytes to encode
  jmp)

51
Target Location (contd)

• In most cases, the assembler can figure out the
  type of jump
• For backward jumps, assembler can decide whether
  to use the short jump form or not
• For forward jumps, it needs a hint from the
  programmer
• Use SHORT prefix to the target label
• If such a hint is not given
• Assembler reserves three bytes for jmp
  instruction
• If short jump can be used, leaves one byte of nop
  (no operation)
• See the next example for details

52
Example

• . . .
• 8 0005 EB 0C jmp SHORT CX_init_done

• 0013 - 0007 0C
• 9 0007 B9 000A mov CX,10
• 10 000A EB 07 90 jmp CX_init_done
• nop 0013 - 000D 07
• 11 init_CX_20
• 12 000D B9 0014 mov CX,20
• 13 0010 E9 00D0 jmp near_jump
• 00E3 - 0013 D0
• 14 CX_init_done
• 15 0013 8B C1 mov AX,CX

53
Example (contd)

• 16 repeat1
• 17 0015 49 dec CX
• 18 0016 EB FD jmp repeat1
• 0015 - 0018 -3 FDH
• . . .
• 84 00DB EB 03 jmp SHORT short_jump
• 00E0 - 00DD 3
• 85 00DD B9 FF00 mov CX, 0FF00H
• 86 short_jump
• 87 00E0 BA 0020 mov DX, 20H
• 88 near_jump
• 89 00E3 E9 FF27 jmp init_CX_20
• 000D - 00E6 -217 FF27H

54
Conditional Jumps (contd)

• Format
• jltcondgt lab
• Execution is transferred to the instruction
  identified by label only if ltcondgt is met
• Example Testing for carriage return
• read_char
• . . .
• cmp AL,0DH 0DH ASCII carriage return
• je CR_received
• inc CL
• jmp read_char
• . . .
• CR_received

55
Conditional Jumps (contd)

• Some conditional jump instructions
• Treats operands of the CMP instruction as signed
  numbers
• je jump if equal
• jg jump if greater
• jl jump if less
• jge jump if greater or equal
• jle jump if less or equal
• jne jump if not equal

56
Conditional Jumps (contd)

• Conditional jump instructions can also test
  values of the individual flags
• jz jump if zero (i.e., if ZF 1)
• jnz jump if not zero (i.e., if ZF 0)
• jc jump if carry (i.e., if CF 1)
• jnc jump if not carry (i.e., if CF 0)
• jz is synonymous for je
• jnz is synonymous for jne

57
A Note on Conditional Jumps

• All conditional jumps are encoded using 2 bytes
• Treated as short jumps
• What if the target is outside this range?

• Use this code to get around
• target
• . . .
• cmp AX,BX
• jne skip1
• jmp target
• skip1
• mov CX,10
• . . .

• target
• . . .
• cmp AX,BX
• je target
• mov CX,10
• . . .
• traget is out of range for a short jump

58
Loop Instructions

• Unconditional loop instruction
• Format
• loop target
• Semantics
• Decrements CX and jumps to target if CX ? 0
• CX should be loaded with a loop count value
• Example Executes loop body 50 times
• mov CX,50
• repeat
• ltloop bodygt
• loop repeat
• ...

59
Loop Instructions (contd)

• The previous example is equivalent to
• mov CX,50
• repeat
• ltloop bodygt
• dec CX
• jnz repeat
• ...
• Surprisingly,
• dec CX
• jnz repeat
• executes faster than
• loop repeat

60
Loop Instructions (contd)

• Conditional loop instructions
• loope/loopz
• Loop while equal/zero
• CX CX 1
• ff (CX 0 and ZF 1)
• jump to target
• loopne/loopnz
• Loop while not equal/not zero
• CX CX 1
• ff (CX 0 and ZF 0)
• jump to target

61
Logical Instructions

• Format
• and destination,source
• or destination,source
• xor destination,source
• not destination
• Semantics
• Performs the standard bitwise logical operations
• result goes to destination
• test is a non-destructive and instruction
• test destination,source
• Performs logical AND but the result is not stored
  in destination (like the CMP instruction)

62
Logical Instructions (contd)

• Example
• . . .
• and AL,01H test the least significant
  bit
• jz bit_is_zero
• ltbit 1 codegt
• jmp skip1
• bit_is_zero
• ltbit 0 codegt
• skip1
• . . .
• test instruction is better in place of and

63
Shift Instructions

• Two types of shifts
• Logical
• Arithmetic
• Logical shift instructions
• Shift left
• shl destination,count
• shl destination,CL
• Shift right
• shr destination,count
• shr destination,CL
• Semantics
• Performs left/right shift of destination by the
  value in count or CL register
• CL register contents are not altered

64
Shift Instructions (contd)

• Logical shift
• Bit shifted out goes into the carry flag
• Zero bit is shifted in at the other end

65
Shift Instructions (contd)

• count is an immediate value
• shl AX,5
• Specification of count greater than 31 is not
  allowed
• If a greater value is specified, only the least
  significant 5 bits are used
• CL version is useful if shift count is known at
  run time
• Ex when the shift count value is passed as a
  parameter in a procedure call
• Only the CL register can be used
• Shift count value should be loaded into CL
• mov CL,5
• shl AX,CL

66
Shift Instructions (contd)

• Arithmetic shift
• Two versions as in logical shift
• sal/sar destination,count
• sal/sar destination,CL

67
Double Shift Instructions

• Double shift instructions work on either 32- or
  64-bit operands
• Format
• Takes three operands
• shld dest,src,count left shift
• shrd dest,src,count right shift
• dest can be in memory or register
• src must be a register
• count can be an immediate value or in CL as in
  other shift instructions

68
Double Shift Instructions (contd)

• src is not modified by doubleshift instruction
• Only dest is modified
• Shifted out bit goes into the carry flag

69
Rotate Instructions

• Two types of ROTATE instructions
• Rotate without carry
• rol (ROtate Left)
• ror (ROtate Right)
• Rotate with carry
• rcl (Rotate through Carry Left)
• rcr (Rotate through Carry Right)
• Format of ROTATE instructions is similar to the
  SHIFT instructions
• Supports two versions
• Immediate count value
• Count value in CL register

70
Rotate Instructions (contd)

• Bit shifted out goes into the carry flag as in
  SHIFT instructions

71
Rotate Instructions (contd)

• Bit shifted out goes into the carry flag as in
  SHIFT instructions

72
Rotate Instructions (contd)

• Example Shifting 64-bit numbers
• Multiplies a 64-bit value in EDXEAX by 16
• Rotate version
• mov CX,4
• shift_left
• shl EAX,1
• rcl EDX,1
• loop shift_left
• Doubleshift version
• shld EDX,EAX,4
• shl EAX,4
• Division can be done in a similar a way

73
Defining Constants

• Assembler provides two directives
• EQU directive
• No reassignment
• String constants can be defined
• directive
• Can be reassigned
• No string constants
• Defining constants has two advantages
• Improves program readability
• Helps in software maintenance
• Multiple occurrences can be changed from a single
  place
• Convention
• We use all upper-case letters for names of
  constants

74
Defining Constants (contd)

• The EQU directive
• Syntax
• name EQU expression
• Assigns the result of expression to name
• The expression is evaluated at assembly time
• Similar to define in C
• Examples
• NUM_OF_ROWS EQU 50
• NUM_OF_COLS EQU 10
• ARRAY_SIZE EQU NUM_OF_ROWS NUM_OF_COLS
• Can also be used to define string constants
• JUMP EQU jmp

75
Defining Constants (contd)

• The directive
• Syntax
• name expression
• Similar to EQU directive
• Two key differences
• Redefinition is allowed
• count 0
• . . .
• count 99
• is valid
• Cannot be used to define string constants or to
  redefine keywords or instruction mnemonics
• Example JUMP jmp is not allowed

76
Macros

• Macros can be defined with MACRO and ENDM
• Format
• macro_name MACROparameter1, parameter2,...
• macro body
• ENDM
• A macro can be invoked using
• macro_name argument1, argument2,
• Example Definition
  Invocation
• multAX_by_16 MACRO ...
• sal AX,4 mov AX,27
• ENDM multAX_by_16
• ...

77
Macros (contd)

• Macros can be defined with parameters
• More flexible
• More useful
• Example
• mult_by_16 MACRO operand
• sal operand,4
• ENDM
• To multiply a byte in DL register
• mult_by_16 DL
• To multiply a memory variable count
• mult_by_16 count

78
Macros (contd)

• Example To exchange two memory words
• Memory-to-memory transfer
• Wmxchg MACRO operand1, operand2
• xchg AX,operand1
• xchg AX,operand2
• xchg AX,operand1
• ENDM

79
Illustrative Examples

• Five examples in this chapter
• Conversion of ASCII to binary representation
  (BINCHAR.ASM)
• Conversion of ASCII to hexadecimal by character
  manipulation (HEX1CHAR.ASM)
• Conversion of ASCII to hexadecimal using the XLAT
  instruction (HEX2CHAR.ASM)
• Conversion of lowercase letters to uppercase by
  character manipulation (TOUPPER.ASM)
• Sum of individual digits of a number
  (ADDIGITS.ASM)

Last slide
