Title: CENTRAL TENDENCY
1CENTRAL TENDENCY
2OVERVIEW
- The general purpose of descriptive statistical
methods is to organize and summarize a set score - Perhaps the most common method for summarizing
and describing a distribution is to find a single
value that defines the average score and can
serve as a representative for the entire
distribution - In statistics, the concept of an average or
representative score is called central tendency
3OVERVIEW
- Central tendency has purpose to provide a single
summary figure that best describe the central
location of an entire distribution of observation - It also help simplify comparison of two or more
groups tested under different conditions - There are three most commonly used in education
and the behavioral sciences mode, median, and
arithmetic mean
4The MODE
- A common meaning of mode is fashionable, and it
has much the same implication in statistics - In ungrouped distribution, the mode is the score
that occurs with the greatest frequency - In grouped data, it is taken as the midpoint of
the class interval that contains the greatest
numbers of scores - The symbol for the mode is Mo
5The MEDIAN
- The median of a distribution is the point along
the scale of possible scores below which 50 of
the scores fall and is there another name for P50 - Thus, the median is the value that divides the
distribution into halves - It symbols is Mdn
6The ARITHMETIC MEAN
- The arithmetic mean is the sum of all the scores
in the distribution divided by the total number
of scores - Many people call this measure the average, but we
will avoid this term because it is sometimes used
indiscriminately for any measure of central
tendency - For brevity, the arithmetic mean is usually
called the mean
7The ARITHMETIC MEAN
- Some symbolism is needed to express the mean
mathematically. We will use the capital letter X
as a collective term to specify a particular set
of score (be sure to use capital letters
lower-case letters are used in a different way) - We identify an individual score in the
distribution by a subscript, such as X1 (the
first score), X8 (the eighth score), and so forth - You remember that n stands for the number in a
sample and N for the number in a population
8Properties of the Mode
- The mode is easy to obtain, but it is not very
stable from sample to sample - Further, when quantitative data are grouped, the
mode maybe strongly affected by the width and
location of class interval - There may be more than one mode for a particular
set of scores. In rectangular distribution the
ultimate is reached every score share the honor!
For these reason, the mean or the median is often
preferred with numerical data - However, the mode is the only measure that can be
used for data that have the character of a
nominal scale
9Properties of the Median
10Properties of the Mean
- Unlike the other measures of central tendency,
the mean is responsive to the exact position of
reach score in the distribution - Inspect the basic formula SX/n. Increasing or
decreasing the value of any score changes SX and
thus also change the value of the mean - The mean may be thought of as the balance point
of the distribution, to use a mechanical analogy.
There is an algebraic way of stating that the
mean is the balance point
11Properties of the Mean
- The sums of negative deviation from the mean
exactly equals the sum of the positive deviation - The mean is more sensitive to the presence (or
absence) of scores at the extremes of the
distribution than are the median or (ordinarily
the mode - When a measure of central tendency should reflect
the total of the scores, the mean is the best
choice because it is the only measure based of
this quantity
12The MEAN of Ungrouped Data
- The mean (M), commonly known as the arithmetic
average, is compute by adding all the scores in
the distribution and dividing by the number of
scores or cases
SX
M
N
13The MEAN of Grouped Data
- When data come to us grouped, or
- when they are too lengthy for comfortable
addition without the aid of a calculating
machine, or - when we are going to group them for other purpose
anyway, - we find it more convenient to apply another
formula for the mean
S f.Xc
M
N
X Xc f f.Xc
20 - 24 15 - 19 10 - 14 5 - 9 0 - 4
22 17 12 7 2
1 4 7 5 3
22 68 84 35 6
14The MEDIAN of Ungrouped Data
- Method 1 When N is an odd number
- ? list the score in order (lowest to highest),
and the median is the middle score in the list - Method 2 When N is an even number
- ? list the score in order (lowest to highest),
and then locate the median by finding the point
halfway between the middle two scores
15The MEDIAN of Ungrouped Data
- Method 3 When there are several scores with the
same value in the middle of the distribution - ? 1, 2, 2, 3, 4, 4, 4, 4, 4, 5
- There are 10 scores (an even number), so you
normally would use method 2 and average the
middle pair to determine the median - By this method, the median would be 4
16f
f
5 4 3 2 1
5 4 3 2 1
X
X
0
0
1 2 3 4 5
1 2 3 4 5
17The MEDIAN of Grouped Data
- There are 10 scores (an even number), so you
normally would use method 2 and average the
middle pair to determine the median. By this
method the median would be 4 - In many ways, this is a perfectly legitimate
value for the median. However when you look
closely at the distribution of scores, you
probably get the clear impression that X 4 is
not in the middle - The problem comes from the tendency to interpret
the score of 4 as meaning exactly 4.00 instead of
meaning an interval from 3.5 to 4.5
18How to count the median?
0.5N f BELOW LRL
Mdn XLRL
f TIED
19THE MODE
- The word MODE means the most common observation
among a group of scores - In a frequency distribution, the mode is the
score or category that has the greatest frequency
20SELECTING A MEASURE OF CENTRAL TENDENCY
- How do you decide which measure of central
tendency to use? The answer depends on several
factors - Note that the mean is usually the preferred
measure of central tendency, because the mean
uses every score score in the distribution, it
typically produces a good representative value - The goal of central tendency is to find the
single value that best represent the entire
distribution
21SELECTING A MEASURE OF CENTRAL TENDENCY
- Besides being a good representative, the mean has
the added advantage of being closely related to
variance and standard deviation, the most common
measures of variability - This relationship makes the mean a valuable
measure for purposes of inferential statistics - For these reasons, and others, the mean generally
is considered to be the best of the three measure
of central tendency
22SELECTING A MEASURE OF CENTRAL TENDENCY
- But there are specific situations in which it is
impossible to compute a mean or in which the mean
is not particularly representative - It is in these condition that the mode an the
median are used
23WHEN TO USE THE MEDIAN
- Extreme scores or skewed distribution
- When a distribution has a (few) extreme
score(s), score(s) that are very different in
value from most of the others, then the mean may
not be a good representative of the majority of
the distribution. - The problem comes from the fact that one or two
extreme values can have a large influence and
cause the mean displaced
24WHEN TO USE THE MEDIAN
- Undetermined values
- Occasionally, we will encounter a situation in
which an individual has an unknown or
undetermined score
Person Time (min.)
Notice that person 6 never complete the puzzle.
After one hour, this person still showed no sign
of solving the puzzle, so the experimenter stop
him or her
1 2 3 4 5 6
8 11 12 13 17 Never finished
25WHEN TO USE THE MEDIAN
- Undetermined values
- There are two important point to be noted
- The experimenter should not throw out this
individuals score. The whole purpose to use a
sample is to gain a picture of population, and
this individual tells us about that part of the
population cannot solve this puzzle - This person should not be given a score of X 60
minutes. Even though the experimenter stopped the
individual after 1 hour, the person did not
finish the puzzle. The score that is recorded is
the amount of time needed to finish. For this
individual, we do not know how long this is
26WHEN TO USE THE MEDIAN
- Open-ended distribution
- A distribution is said to be open-ended when
there is no upper limit (or lower limit) for one
of the categories
Number of children (X)
f
5 or more 4 3 2 1 0
3 2 2 3 6 4
Notice that is impossible to compute a mean for
these data because you cannot find SX
27WHEN TO USE THE MEDIAN
- Ordinal scale
- when score are measured on an ordinal scale, the
median is always appropriate and is usually the
preferred measure of central tendency
28WHEN TO USE THE MODE
- Nominal scales
- Because nominal scales do not measure quantity,
it is impossible to compute a mean or a median
for data from a nominal scale - Discrete variables ? indivisible categories
- Describes shape
- the mode identifies the location of the peak
(s). If you are told a set of exam score has a
mean of 72 and a mode of 80, you should have a
better picture of the distribution than would be
available from mean alone
29CENTRAL TENDENCY AND THE SHAPE OF THE DISTRIBUTION
- Because the mean, the median, and the mode are
all trying to measure the same thing (central
tendency), it is reasonable to expect that these
three values should be related - There are situations in which all three measures
will have exactly the same or different value - The relationship among the mean, median, and mode
are determined by the shape of the distribution
30SYMMETRICAL DISTRIBUTION SHAPE
- For a symmetrical distribution, the right-hand
side will be a mirror image of the left-hand side - By definition, the mean and the median will be
exactly at the center because exactly half of the
area in the graph will be on either side of the
center - Thus, for any symmetrical distribution, the mean
and the median will be the same
31SYMMETRICAL DISTRIBUTION SHAPE
- If a symmetrical distribution has only one mode,
it will also be exactly in the center of the
distribution. All three measures of central
tendency will have same value - A bimodal distribution will have the mean and the
median together in the center with the modes on
each side - A rectangular distribution has no mode because
all X values occur with the same frequency. Still
the mean and the median will be in the center and
equivalent in value
32SYMMETRICAL DISTRIBUTION SHAPE
33POSITIVELY SKEWED DISTRIBUTION
34NEGATIVELY SKEWED DISTRIBUTION
35(No Transcript)
